Inter-m column speakers provide a clean and dediated design with rich sound
quality and are used for indoor/outdoor announcement and BGM. A variety of line-
ups can be easily adopted in any type of user environment depending on power
and size
Column
Speaker
CU-410/420/430/440
CU-910(V)/920(V)/930(V)/940(V)/
920HV/940HV
CS-810/820/830/840
CS-410/420/430/440/510/520/530/540
CU-510/520/530/540
High quality sound
Simple design with rounded
corners and edges
Easy and time saving installation
Angle adjustment by mounting
bracket
High quality sound
Simple and unique design
Easy and time saving installation
Angle adjustment by mounting
bracket
Speaker terminal (800 series)
CS-SERIES
CU-400/500 SERIES
Top quality tweeter is used
Detail and rich sound quality
Strong aluminum frame
Easy and time saving installation
Angle adjustment by mounting bracket
Speaker terminal
CU-900 SERIES
CS-03/03A/05
CS-20/30/80
CS-3/6/12
CS-10/44/45
CS-10/44/45
Inter-m ceiling speakers provide a natural and smooth sound with a variety of
mounting and fit to any places that announcements and BGM required such as
buildings, apartments, hotels and etc. It has variety of line-up from 1W APT series
to 2way type high powered speaker.
Ceiling
Speaker
APT-01A
MS-03A
APT-01C/03C
MS-15/30
APT-01R APT-01W/03W
Clean and clear sound reproduction
A design harmonized with interior decoration
Easy installation on ceilling or wall
High quality sound
Easy installation on the ceilling
Multi-tap for different setting
High quality sound
Installation can be done without any
tool
Solid structure and material
APT SERIES
CS SERIES
MS SERIES
High quality speaker unit
Stylish and sleek design
Easy installation
Outdoor speaker
High reliability
A outstanding design harmonized with interior
decoration
A coner design considering the spatial arrangement
Built-in switchable impedance matching transformer
2 way speake
r
SWS-03/10(I/B)
WS-203(I/B)/210(I/B)/230(I/B)
CF-60/120(B/W)
IWS-10(I/B)
Inter-M wall speakers are ideal for BGM playback and also offer precise voice
reproduction. Our new articulated mounting bracket offers ease of installation with
precision speaker orientation.
Wall
Speaker
High quality speaker unit
Stylish and sleek design wall speaker
A design adopted in modern sense
IWS-10(I/B)
High quality speaker unit produce detail and rich sound
Stylish and sleek design wall speaker
Harmonized with general structure when installed
SWS-3/10(I/B)
WS-203(I/B)/210(I/B)/230(I/B)
CF-60/120(B/W)
WS-203(I/B)/210(I/B)/230(I/B)
Inter-M surface mounted speakers are manufactured using high-quality drivers
and components. Our custom design and tuned crossover network ensures a
smooth frequency responses and maximizes the SPL of the High-frequency and
Low-frequency drivers.
Surface
Mounted
Speaker
High quality sound
Dual circuit with high and low impedance
Screw terminal for speaker line
High quality transformer for long distance
operation
High-strength ABS Injection
Mounting bracket included
Safety ring included
High quality sound
Dual circuit with high and low impedance
Screw terminal for speaker line
High quality transformer for long distance
operation
High-strength abs injection
Mounting bracket included
Safety ring included
CI-40(T)/60(T)
GS-50N
FS-30N/60N/100N
GS-50N
Optimized sound quality on musicplayback
& voice intelligibility
Compact vented encloser
High quality transformer
Circuit Protection
Articulated Mounting Bracket
Safety ring included
CI-40(T)/60(T)
FS-30N/60N/100N/52N
High sound pressure and straightness
Wide frequency range with remarkable vocal clarity
Indoor or outdoor use
Wide range of angle adjustment
High reliability and high powered HORN
DRIVER UNIT
Rated power and SPL
DU-30T : 30W, 8Ω330Ω660Ω, 110dB
DU-40T : 40W, 8Ω/250Ω/500Ω, 110dB
DU-50 : 50W 8Ω, 113dB
DU-75 : 75W 8Ω, 114dB
DU-100 : 100W 8Ω, 113dB
Size and Weight
SH-317 : 317(W) x 205(H) x 290(D)mm
DU-30T : 114(Ø) x 120mm, 1.55Kg
DU-40T : 114(Ø) x 120mm, 1.75Kg
DU-50 : 120(Ø) x 90mm, 2Kg
DU-75 : 120(Ø) x 92mm, 2.65Kg
DU-100 : 117(Ø) x 102mm, 3.5Kg
Inter-m horn speakers are commonly installed in commercial building, factories,
schools, public areas, civic centers and so on because it has excellent intelligibility &
Loudness, High directivity, Good reliability.
Horn
Speaker
HS-20/30/50
HS-20RT/30RT/40RT
SH-317
DU-50
DU-30T
DU-75
DU-40T
DU-100
CH-522/532
High sound pressure and straightness
Wide frequency range with remarkable vocal clarity
Easy installation
Highly reliable and high power horn driver unit
Rated input and output sound pressure
Size and weight
HS-20/30/50/20RT/30RT/40RT
CH-522/532
DRIVER UNIT
Accessories
SB-1 SB-2
FSB-3
FSB-1 FSB-2
TSS-1
Exclusive material for speaker of sound system
Inner conductor size
Number of core wire
Inner wire can be identified through the transparent
insulator
SW-2200/2300
SW-2200/2300
Angle adjustment (L/R, Up/Down)
SOLID fixed ANGLE adjustment
Safety ring included
Screws included
FSB-3
Small speaker mounting bracket
Angle adjustment (L/R, Up/Down)
FSB-1/FSB-2
SB-1/2
Stand for small and large speaker
SHORT/LONG TYPE
Single angle of beam spread
Easily mounting on the wall or cielling
Stand for small and large speaker
Maintain stability as a tripod
TSS-1
PA Speakers Specifications
Speaker type Model Type Rated Power Frequecy Response SPL Impedance Dimension(mm)
<WxHxD>
Column
Speaker
CS-410
1 Way
10W
180Hz - 12KHz
91dB 1KΩ/2KΩ159x300x115
CS-420 20W 94dB 500Ω/1KΩ159x400x115
CS-430 30W 95dB 330Ω/660KΩ159x500x115
CS-440 40W 180Hz - 10KHz 97dB 250Ω/500Ω159x600x115
CS-510 10W
180Hz - 12KHz
89dB 1KΩ/2KΩ159x300x115
CS-520 20W 92dB 500Ω/1KΩ159x400x115
CS-530 30W 93dB 330Ω/660KΩ159x500x115
CS-540 40W 180Hz - 10KHz 95dB 250Ω/500Ω159x600x115
CS-810
2 Way
10W
150Hz - 20KHz
90dB 1KΩ/2KΩ149x310x124
CS-820 20W 93dB 500Ω/1KΩ149x420x124
CS-830 30W 94dB 330Ω/660KΩ149x530x124
CS-840 40W 150Hz - 12KHz 96dB 250Ω/500Ω149x640x124
CU-410
1 Way
10W
180Hz - 14KHz
91dB 1KΩ/2KΩ156x300x129
CU-420 20W 94dB 500Ω/1KΩ156x400x129
CU-430 30W 95dB 330Ω/660KΩ156x500x129
CU-440 40W 97dB 250Ω/500Ω156x600x129
CU-510 10W 91dB 1KΩ/2KΩ156x300x129
CU-520 20W 94dB 500Ω/1KΩ156x400x129
CU-530 30W 95dB 330Ω/660KΩ156x500x129
CU-540 40W 97dB 250Ω/500Ω156x600x129
CU-910(V)
2 Way
10W
220Hz-15KHz/
220Hz-18KHz(V)
87dB/88dB(V) 1KΩ/2KΩ104x290x86
CU-920(V) 20W 89dB/91dB(V) 500Ω/1KΩ104x400x86
CU-930(V) 30W 91dB 330Ω/660KΩ104x490x86
CU-940(V) 40W 91dB 250Ω/500Ω104x580x86
CU-920H 20W 180Hz-15KHz 86dB 500Ω/1KΩ104x400x86
CU-920HV 180Hz-18KHz 87dB
CU-940H 40W 180Hz-15KHz 87dB 250Ω/500Ω104x580x86
CU-940HV 180Hz-18KHz 88dB
Ceiling Speaker
APT-01A(K)
1 Way
1W 300Hz-16KHz 82dB 8Ω/10KΩ120x120x15
APT-01C 1W 260Hz-10KHz 85dB 10KΩ41(∮)x120(D)
APT-03C 3W 260Hz-12KHz 86dB 3.3KΩ41(∮)x119(D)
APT-01R 1W 260Hz-10KHz 84dB 10KΩ152(∮)x55(D)
APT-01W 1W 260Hz-10KHz 85dB 10KΩ120x120x50
APT-03W 3W 260Hz-12KHz 86dB 3.3KΩ
CS-03 3W 100Hz-15KHz 90dB 3.3KΩ/5KΩ/10KΩ228(∮)x96(D)
CS-03A 3W 150Hz-15KHz 227(∮)x100(D)
CS-05 5W 150Hz-14KHz 92dB 2KΩ/4KΩ/8KΩ
CS-20
2 Way
20W
200Hz-20KHz
88dB 500Ω/1KΩ/2KΩ
230(∮)x180(D)CS-30 30W 90dB 330Ω/500Ω/1KΩ
CS-80 80W 88dB 125Ω/250Ω/500Ω
CS-3
1 Way
3W
250Hz-15KHz 88dB 3.3KΩ/5KΩ/10KΩ
230(∮)x100(D)CS-6 6W 1.7KΩ/4KΩ/8KΩ
CS-12 12W 89dB 800Ω/1KΩ/2KΩ
CS-10 10W 120Hz-10KHz 92dB 1KΩ/2KΩ
303x303x95CS-44 3W 180Hz-10KHz 90dB 3.3KΩ/5KΩ/10KΩ
CS-55 3W 110Hz-14KHz
MS-03A 3W 110Hz-10KHz 90dB 3.3KΩ/5KΩ/10KΩ246x174x110
MS-15 15W 250Hz-17KHz 97dB 660Ω/1KΩ/2KΩ286x200x130
MS-30 30W 220Hz-18KHz 330Ω/500Ω/1KΩ
Wall
Speaker
CF-60 2 Way 60W 120Hz-20KHz 85dB 8Ω/166Ω/333Ω/660Ω226x327x163
CF-120 120W 8Ω/83Ω/166Ω/333Ω
IWS-10
1 Way
10W 220Hz-12KHz 90dB 1KΩ/3.3KΩ179x312x109
SWS-03 3W 220Hz-14KHz 93dB 3.3KΩ/5KΩ/10KΩ182x274x120
SWS-10 10W 160Hz-10KHz 91dB 1KΩ/2KΩ/3.3KΩ
WS-203
2 Way
3W
200Hz-16KHz
93dB 3.3KΩ/5KΩ/10KΩ
315x183x124WS-210 10W 92dB 1KΩ/2KΩ/3.3KΩ
WS-230 30W 93dB 330Ω/500Ω/1KΩ
Surface
Mounted
Speaker
FS-30N
1 Way
30W
100Hz-12KHz 89dB
8Ω/330Ω
177x302x163
FS-60N 60W 8Ω/167Ω
FS-100N 100W 8Ω/100Ω
FS-52N
2 Way
50W 55Hz-20KHz 86dB 8Ω/200Ω
CI-40(T) 20W 55Hz-15KHz 87dB 8Ω/500Ω(T) 143x230x145
CI-60(T) 30W 55Hz-22KHz 88dB 8Ω/333Ω(T)
Horn
Speaker
CH-522
1 Way
20W 140Hz-12KHz 91dB 500Ω/1KΩ294x209x326
CH-532 30W 180Hz-9KHz 93dB 165Ω/333Ω
HS-20 20W 350Hz-5.5KHz
106dB
500Ω/1KΩ250∮x280
HS-30 30W 250Hz-5KHz 330Ω/660Ω280∮x330
HS-50 50W 250Hz-5KHz 200Ω/400Ω320∮x350
HS-20RT 20W 350Hz-5KHz 104dB 500Ω/1KΩ250x197.5x310
HS-30RT 30W 250Hz-5KHz 106dB 330Ω/660Ω320x210x365
HS-40RT 40W 250Hz-5KHz 200Ω/400Ω320x210x365
