Brydge Global BRY101 Brydge 9.7 User Manual 9 7 Manual
BRYDGE GLOBAL Brydge 9.7 9 7 Manual
User Manual
SHIMS
1
Place your iPad into the hinges with the
home button on the right, and your
Brydge placed on a flat surface
Lift iPad to test the hinge grip.
Your iPad and Brydge should
be held tightly together
INSERT/REMOVE
2
PAIR
3
If iPad is loose, remove and give the
hinges a gentle squeeze. Repeat this
process until your iPad is held firmly
Press the power
key. A green dot
will illuminate
On your iPad, under Settings>Bluetooth, select Brydge 9.7
Bluetooth
Bluetooth
Brydge 9.7 Keyboard Connected i
Settings
Bluetooth On
To check battery life, press and hold the
battery key for three seconds
Power key will flash:
One time = 25%
Two times = 50%
Three times = 75%
Four times = 100%
Power key will flash red when the battery is
below 14% and needs charging
To remove, grab your iPad and pull
straight up, with one hand firmly holding
your Brydge against a hard surface
Insert the supplied MICRO USB cable
Power key will be illuminated red while
charging, and is fully charged when the light
turns off
IMPORTANT:
Your Brydge 9.7 is set up for the iPad
Air 2 and the iPad Pro 9.7-inch
If you have an iPad Air 1, you will need
to use the second set of shims
provided in the box
(located next to the Micro USB)
CHARGE
4
NOTE: Charging can take up to 3 hours
TO REPLACE: Remove the current shims, and
pick away any large tape residue
NOTE: It’s not necessary to remove
everything, just the bigger bits
NOTE: Ensure the shim is pressed
firmly against the bottom of the hinge
Remove tape backing from front and
back of new shims, and line up where
the previous ones were.
Insert into hinges
3M
M
Press and hold the
BluetoothTM key for 3
seconds. The power key will
flash blue until Bluetooth is
successfully paired
NOTE: The power key will illuminate
for 2 seconds to let you know the
Brydge is powered on
To power off: Press and hold for
three seconds. Key will turn green,
then flash red twice to indicate
Brydge is powered off
NOTE: The power key will illuminate in all situations
C
M
Y
CM
MY
CY
CMY
K
9.7 - Manual.pdf 1 11/18/16 10:43 AM
© 2016 Brydge. All Rights Reserved.
iPad® and Apple® are registered trademarks of Apple, Inc.
The Bluetooth word, mark, and logos are owned by Bluetooth SIG, Inc.
Use of such marks by Brydge is under license.
enter
VOLUME
Adjust volume
up, down, or
mute
QUICK LOCK
Lock your iPad
with a single touch
HOME/SIRI
- Press once for
home screen
- Press/hold for Siri
SCREEN
BRIGHTNESS
Adjust screen
brightness up
and down
BACKLIT KEYS
Adjust the
brightness of your
keyboard
BATTERY
Press to see how
much battery life
is left
POWER
Turn your
Brydge on or off
PLAYER
CONTROLS
Rewind,
Play/Pause, and
Fast Forward
SIRI
Dedicated Siri
button
BLUETOOTH
Press to pair your
Brydge and iPad
ON-SCREEN
KEYBOARD
Easily toggle
between your
Brydge and
on-screen
keypad
