Brydge Global BRY500X BRYDGE Mini User Manual QSG Mini 1 2
BRYDGE GLOBAL BRYDGE Mini QSG Mini 1 2
User Manual
for iPad Mini1, Mini 2 & Mini 3
1) Choose
Choose from either the
black or white shims.
2) Insert
Remove the tape and
insert the shims into the
hinges.
Note: Ensure the rubber foot
push through the heel of the
hinge.
3) Test
Ensure both hinges are
aligned, insert your iPad
then remove it to make
sure your iPad is held
securely.
4) Adjust
To get the right fit,
remove the iPad and
gently squeeze the hinge.
Note: Repeat this process
until the iPad is held firmly.
Attach
Getting Started
2015 Brydge Global Pte Ltd, All Rights Reserved.
iPad® and Apple® are registered trademarks of Apple, Inc.
The Bluetooth word, mark and logos are owned by Bluetooth SIG, Inc.
Use of such marks by Brydge Global Pte Ltd is under license.
Pair
1) Switch
Turn your keyboard on
by switching the left-hand
button to the right. A green
dot will appear.
2) Press
Put the keyboard into
pairing mode by pressing
and holding the right-hand
button for 3 seconds.
3) Select
Under Settings / Bluetooth,
(on your iPad) select
BrydgeAir - Mini
4) Confirm
Your iPad will indicate
it is connected to the
Brydge Keyboard.
1) Flat
A flashing blue light indicates
the keyboard has less than
10% battery life left.
2) Insert
Inset the supplied MICRO
USB cable.
3) Charge
Charging is confirmed by
a solid red light.
4) Charged
Your keyboard is fully
charged when the light
turns off.
Charge
Note: Charging takes up to
3 hours.
Note: Press the Fn button
to access the secondary
character on the keyboard!
FCC STATEMENT:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
