Installation and Operation Instructions for the Wireless Temperature Sensor.
Building Automation Products, Inc.
Wireless Temperature Sensor
Installation and Operation Instructions
Description
The Building Automation Products, Inc. Wireless Temperature Sensor, Model BA/WT-D-BB is a battery
operated, surface mounted sensor with a 418 MHz radio transmitter.
The BA/WT-D-BB is designed to require very little energy; the two internal 3.6 Volt Lithium batteries will
operate the sensor for 5 to 8 years in normal operation
The BA/WT-D-BB enclosure is designed to mount directly onto a ventilation duct surface or outside wall with
the sensing probe being mounted out the back [duct] or out the bottom [outdoor]. The enclosure is supplied
with a ‘foam-back’ to minimize vibration and air leakage from a duct or electrical conduit. The enclosure is
also provided with additional screws to lock the cover and base together to prevent tampering.
The BA/WT-D-BB has one internal push-button which allows for easy training and identification of the
transmitter. The push-button is used when linking the transmitter to any Analog Output Module. See BAPI’s
INS/OPS for details. The BA/WT-D-BB also has an internally mounted LED. The LED will flash briefly when
the sensor transmits a data packet using the 418 MHz radio. This happens roughly about once every 10 seconds
or shortly after the use of the push-button.
750 North Royal Avenue, Gays Mills, WI 54631 USA
Tel: +1-608-735-4800 • Fax: +1-608-735-4804 • E-mail:sales@bapihvac.com • www.bapihvac.com
Building Automation Products, Inc.
Upgrade to BAPI. 100% Compatible. Guaranteed.
Sensors for HVAC/R — Temperature • Humidity • Pressure • Air Quality
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC ID: T4F060811
TEMP
MADE IN USA
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESERED OPERATION
WARNING
:Changes or modifications not expressly approved by the manufacturer for
compliance could void the user’s authority to operate the equipment.
