Installation and Operation Instructions for the Wireless Temperature and Relative Humidity Sensor with slide
set-point and local override.
Building Automation Products, Inc.
Wireless Temperature and Relative Humidity Sensor with slide set-point
and local override
Installation and Operation Instructions
Description
The Building Automation Products, Inc. Wireless Temperature and Relative Humidity Sensor, Model BA/BS2-
WTH-SO, is a battery operated, wall mounted sensor with a 418 MHz radio transmitter.
The BA/BS2-WTH-SO is designed to require very little energy; the two internal 3.6 Volt Lithium batteries will
operate the sensor for 5 to 8 years in normal operation
The BA/BS2-WTH-SO enclosure is designed to mount directly onto a drywall surface or onto a standard 2”x4”
J-box. The enclosure is supplied with a ‘foam-back’ to minimize the effects of wall temperature on the device.
The enclosure is also provided with security screws to lock the cover and base together to prevent tampering.
The BA/BS2-WTH-SO has one internal push-button which allows for easy training and identification of the
transmitter. The push-button is used when linking the transmitter to any Analog Output Module. See BAPI’s
INS/OPS for details. The BA/BS2-WTH-SO also has an internally mounted LED. The LED will flash briefly
when the sensor transmits a data packet using the 418 MHz radio. This happens roughly about once every 10
seconds or shortly after the use of the push-button.
750 North Royal Avenue, Gays Mills, WI 54631 USA
Tel: +1-608-735-4800 • Fax: +1-608-735-4804 • E-mail:sales@bapihvac.com • www.bapihvac.com
Building Automation Products, Inc.
Upgrade to BAPI. 100% Compatible. Guaranteed.
Sensors for HVAC/R — Temperature • Humidity • Pressure • Air Quality
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
.
FCC ID: T4F061213RSO
MADE IN USA
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESERED OPERATION
WARNING
:Changes or modifications not expressly approved by the manufacturer for
compliance could void the user’s authority to operate the equipment.
