Installation and Operation Instructions for the Wireless Temperature and Relative Humidity Sensor.
Building Automation Products, Inc.
Wireless Temperature and Relative Humidity Sensor
Installation and Operation Instructions
Description
The Building Automation Products, Inc. Wireless Temperature and Relative Humidity Sensor, Model BA/BS2-
WTHT, is a battery operated, wall mounted sensor with a 418 MHz radio transmitter.
The BA/BS2-WTHT is designed to require very little energy; the two internal 3.6 Volt Lithium batteries will
operate the sensor for 5 to 8 years in normal operation
The BA/BS2-WTHT enclosure is designed to mount directly onto a drywall surface or onto a standard 2”x4” J-
box. The enclosure is supplied with a ‘foam-back’ to minimize the effects of wall temperature on the device.
The enclosure is also provided with security screws to lock the cover and base together to prevent tampering.
The BA/BS2-WTHT has one internal push-button which allows for easy training and identification of the
transmitter. The push-button is used when linking the transmitter to any Analog Output Module. See BAPI’s
INS/OPS for details. The BA/BS2-WTHT also has an internally mounted LED. The LED will flash briefly
when the sensor transmits a data packet using the 418 MHz radio. This happens roughly about once every 10
seconds or shortly after the use of the push-button.
WARNING: Changes or modifications not expressly approved by the manufacturer for compliance could void
the user’s authority to operate the equipment.
FCC ID: T4F16963N16964
MADE IN USA
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESERED OPERATION
