Building Robotics AT-CARD-MT Enlighted Card Beacon User Manual
Enlighted, Inc. Enlighted Card Beacon
User Manual
AT-CARD-MT
Datasheet V1.0
Enlighted Card Beacon
Model
Description
AT-CARD-MT
Rectangle shape, white & waterproof casing, CE&FCC certified BLE
4.0 module, powered by a Lithium Polymer battery, RoHS
TEL: +86-755-8886 8480
FAX: +86-755-2982 5342
EMAIL: sales@minewtech.com
URL: www.minewtech.com
Page 1
AT-CARD-MT
Datasheet V1.0
The BLE Beacon Card is designed based on the Low Energy Bluetooth 4.0 technology, the shape of
Beacon Card AT-CARD-MT looks a bank/RFID card but it is waterproof and it has packed a Lithium
polymer battery. Beacon Card AT-CARD-MT broadcasts the data at regular and adjustable intervals
according to Apple’ standard iBeacon protocol, it can be heard and interpreted by iOS and Android
BLE-enabled devices that are equipped with many mobile apps.
It widely used for the access control, trade shows, conferences, events and so on.
FEATURES
-Programmed MiniBeacon standard firmware
-Powered by Lithium polymer battery
-The max. 100 meters advertising distance
-Ultra-low power consumption chipset Nordic nRF52832
with ARM core
-Easy to print the logo on the waterproof case;
CERTIFICATIONS
-iBeacon MFi License (iBC-14-00582)
-FCC Regulation (FCC Part 15.)
-CE Regulations (Included EN300328/301489/60950/62479)
AT-CARD-MT
Image 1
SPECIFICATION
Compatibility
- Supported iOS 7.0+ and Android 4.3+ system;
- Compatible with Apple iBeaconTM standard;
- Compatible with all Bluetooth 4.0 (BLE) devices;
Long Battery Lifetime and Battery Level
- 24 months @ default settings;
- One-time using @ waterproof case;
- Easy to get the real-time battery level notification;
Soft-reboot
- Reboot the device via command without any tools;
Connection Mode
- Advertising mode, non-connectable;
- Configuration mode, connectable;
Mounting
- 3M branded adhesive for direct mounting to wall;
Configurable Parameters
- UUID, Major, Minor, Device Name, Password etc.
- Special Configuration APP;
Transmission Power Levels
- Default setting: 0dBm
- Transmission power level: -23dBm, +0dBm;
- The level must be programmed at the factory;
Long Range
- The max. Range 100 meters in the open space;
- The range depends on the physical environment;
Security
- 8 characters password (Lock/Unlock parameters);
- Broadcast the encrypted data if needed;
- AES HW encryption
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 2
AT-CARD-MT
TURN ON C1
Datasheet V1.0
Please DO take out the battery sheet from the beacon device before using.
CONFIGURABLE PARAMETERS
Characteristic
Item
Default Settings
0xFFF1
UUID
E2C56DB5-DFFB-48D2-B060-D0F5A71096E0 (Proximity)
0xFFF2
Major
0
0xFFF3
Minor
0
0xFFF4
Measured Power
-59 (0xC5)
0xFFF5
Transmission Power
6 (0dBm)
0xFFF6
Change Password
minew123 (Must be 8 characters)
0xFFF7
Broadcasting Interval
9(900mS)
0xFFF8
Serial ID
Random (Unique serial ID for beacon)
0xFFF9
iBeacon Name
MiniBeacon_ (the maximum 14 characters)
0xFFFE
Connection Mode
0 (connectable, configuration mode)
0xFFFF
Soft Reboot
minew123 (it is same as the value of Change Password)
ELECTRONIC PARAMETERS
Item
Value
Remarks
Case Color
white
Other colors can be customized
Battery Model
Lithium Polymer battery
1pc x 3.7V
Operation Voltage
1.8-3.9V
DC
Transmission
Current
4.5mA (Max.)
Tested at 0dBm transmission power
Transmission Range
100 meters
Maximum
Antenna
50ohm
On board / PCB Antenna
Accessories
Double adhesive
1pc, high-strength, 3M brand;
Net Weight
18.0g
With battery
Size
90 x 60 x 4 mm
Null
TECHNICAL SUPPORT
Item
Version
File Name
Updated Date
Datasheet
V1.0
AT-CARD-
MT_MiniBeacon
15th August, 2015
Instruction
V2.03
InstructioDatasheet_1.0.pdfns_MiniB eacon_V2.03.
25th May, 2015
SDK
V1.0
Android Reference Source Code;
28th February, 2015
iOS Reference Source Code;
APP Tools
V2.0
iBeaconCFG; iBeaconDFU;
3rd March, 2015
* Minew sales team will send you these documents after the sample arrived.
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com Page 3
AT-CARD-MT
PACKING INFORMATION
Standard Package:
Datasheet V1.0
Image 7
Details
Package Box
Carton
Quantity
(AT-CARD-MT)
80pcs per package box
800pcs per carton
Net Weight
1.45kg
14.5Kg
Gross Weight
1.55Kg
16.5Kg
Size
30.5 x 11 x 7.5 cm
32 x 23 x 40 cm
DECLARATION
The contents of this datasheet are subject to change without prior notice for further improvement.
Minew team reserves the right to explain all the terms of this datasheet. <END>
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com Page 4
