Bullitt Group SP4 Smartphone User Manual Mi 320
Bullitt Group Smartphone Mi 320
User Manual
1
ALL RIGHTS RESER VED
©2014. All rights are reserved. No part of this document
can be reproduced without permission. All trademarks
and brand names mentioned in this publication are
property of their respective owners.
While all the efforts have been made to ensure the
accuracy of contents in this manual, we presume no
responsibility for errors or omissions or statements of any
kind, whether such errors are omissions or statements
resulting from negligence, accidents, or any other cause.
We operate a policy of continuous development and
reserve the right to make changes, modifications and
improvements to the device, device features/
specifications or any of its parts without prior notice.
Your device may have preinstalled bookmarks and links
for third party internet sites and may allow you to access
third party sites. These are no affiliated with us, and we
do not endorse or assume liability for them. If you access
such sites, take precautions for security or content.
The limited warranty does not cover user manuals or any
third party software, settings, content, data or links,
whether included/downloaded in the product, whether
included during installment, assembly, shipping or any
other time in the delivery chain or otherwise and in any
way acquired by you. To the extent permitted by
SP4_User manual
2
applicable law(s), we do not warrant that any our
software will meet your requirements, will work in
combination with any hardware or software applications
provided by a third party, that the operations of the
software will be uninterrupted or error free or that any
defects in the software are correctable or will be
corrected.
User’s Manual is provided just to guide the user
about the functionality of the device. This does not seem
to be any certificate of technology. Some functions may
vary due to modifications and up-gradations of software
or due to printing mistake.
3
SA F ETY PRECAUTIONS
Please read the following safety guidelines before using
the device.
Do not use the phone while you are driving.
Do not place magnetic storage media near
your phone. Radiation from the phone may
erase the information stored on them.
Keep your phone and its accessories away
from children.
Mobile phones can interfere with the
functioning of medical devices such as
hearing aids or pacemakers. People having
active medical implants should keep their
cell phone at least 15 cm away from the
implant.
Permanent hearing loss may occur if you
use earphones or headphones at high
volume.
Use a wireless hands-free system
(headphone/ headset) with a low power
Bluetooth emitter.
Make sure the cell phone has a low SAR.
Keep your calls short or send a text
message (SMS) instead. This advice applies
specially to children adolescents and
pregnant women.
4
Use cell phone when the signal quality is
good.
Notice:
Do not dismantle the device or accessories
otherwise, manufacturer is not liable to pay for
damages as the device and accessories are not
covered by warranty.
Use only original batteries and charging devices.
Please back up your important data timely and
keep them properly. The company is not liable for
any failure to call or loss of data due to
mis-operation, poor signal or power cut, etc.
All the screens in this manual are for reference
only, and some contents actually displayed may
depend upon the presetting of the service
provider or the network operator, or the SIM card.
If any functions referred to in this manual are
different from those of your device, please follow
your device.
Do not put use it in a place with flammable gas
such as a petrol pumps. The temperature
recommended for using the device is 5-35℃. Do
not touch the charger, power cable or socket with
wet hands. This may cause an electric shock.
If your phone or any of its accessories do not
function normally, then please visit your nearest
authorized service facility. The qualified
5
personnel will assist you, and if necessary, will
arrange for the service.
6
TA B LE O F CONTENTS
ALL RIGHTS RESERVED ...................................... 1
SAFETY PRECAUTIONS ....................................... 3
TABLE OF CONTENTS ......................................... 6
1. UNDERSTANDING YOUR DEVICE .................... 8
1.1 GENERAL INFO ....................................................... 8
1.2 DEVICE OVERVIEW ................................................ 9
2.1 INSTALLING CARDS & BATTERY ........................ 11
2.2 POWERING ON/OFF THE DEVICE ....................... 13
3. BASIC OPERATIONS ...................................... 15
3.1 CALLING ................................................................. 15
3.2 MESSAGING .......................................................... 16
3.3 CONTACTS ............................................................ 18
3.4 EMAIL ..................................................................... 19
3.5 BROWSER ............................................................. 19
4. HOME SCREEN............................................... 21
4.1 STATUS BAR ......................................................... 21
4.2 CUSTOMIZING SCREEN ....................................... 22
5. MULTIMEDIA .................................................. 24
5.1 FILE MANAGER ..................................................... 24
5.2 CAMERA ................................................................. 24
5.3 SOUND RECORDER ............................................. 24
5.4 GALLERY ............................................................... 24
5.5 FM RADIO .............................................................. 25
6. NETWORK ...................................................... 26
6.1 WI-FI ....................................................................... 26
6.2 3G ........................................................................... 26
7
6.3 BLUETOOTH .......................................................... 27
7. SETTINGS ....................................................... 28
7.1 SIM MANAGEMENT ............................................... 28
7.2 WIRELESS & NETWOKS ....................................... 28
7.3 AUDIO PROFILES .................................................. 28
7.4 DISPLAY ................................................................. 29
7.5 STORAGE .............................................................. 29
7.6 BATTERY ............................................................... 29
7.7 APPLICATIONS ...................................................... 29
7.8 LOCATION ACCESS .............................................. 30
7.9 SECURITY .............................................................. 30
7.10 LANGUAGE AND INPUT ..................................... 31
7.11 BACKUP & RESET ............................................... 31
7.12 ACCOUNTS .......................................................... 31
7.13 DATE AND TIME .................................................. 31
7.14 SCHEDULE POWER ON/OFF ............................. 32
7.15 ACCESSIBILITY ................................................... 32
7.16 ABOUT PHONE .................................................... 32
8. APPLICATIONS & UTILITIES .......................... 33
8.1 CALCULATOR ........................................................ 33
8.2 CLOCK .................................................................... 33
8.3 GMAIL ..................................................................... 33
8.4 PLAY STORE ......................................................... 34
9. SPECIFICATIONS ........................................... 35
ENVIRONMENTAL CONCERN ............................ 36
8
1. UNDER STAND ING YOU R D EVICE
1.1 GENERAL INFO
SP4 is a multi SIM phone that encloses features, such as
Android version 4.4.2, Wi-Fi, 8 MP digital Camera.etc.
This phone is provided with two SIM slots for two different
SIM cards. The SIM card inserted in the slot1 is called
SIM1, and the other one in the slot2 is known as SIM2.
You can select to operate SIMs as per your personal and
professional needs.
9
1.2 DEVICE OVERVIEW
Position of Keys
1. Earphone Jack
2. Earpiece
3. Touch Screen
4. Menu Key
5. Home Key
6. USB port
7. Back Key
8. Front camera lens
9. Camera lens
10. Battery cover
10
11. Speaker
12. Volume key
13. Power Key
14. Strobe
11
2. GETTING STAR TED
2.1 INSTALLING CARDS & BATTERY
Please switch off your device before inserting or
removing the battery/ SIM card or memory card.
Installing SIM Card and Battery
Your device is provided with two SIM slots for two
different SIM cards. In order to install battery and SIM
card in the device, please follow the steps mentioned
below:
Remove the back cover of the device.
Hold the device with the front facing downwards
and pull the battery cover.
Insert the SIM cards in the device.
Attach the battery.
Push the battery cover until it clicks into place.
12
Installing Memory Card
Your device supports T-Flash card, which is a multimedia
memory card used to multiply the memory of the device.
The T-flash card is small and should be pulled out and
installed carefully and prudently in order to avoid any kind
of damage. Please follow the steps mentioned below to
install the memory card in the device:
Remove the battery cover.
Slot the T-Flash memory card into the slot.
Fix the battery cover until it mount properly into
place.
13
Note：T-Flash card is hot-swappable.
Charging the Battery
The device prompts a warning tone and message stating
insufficient battery when the battery power is low.
Please follow the instructions mentioned below to charge
your device:
Plug the connector of the charger into the jack of
the device.
Plug the charger into a standard AC wall outlet.
Charging……. Fully Charged…….
You should fully charge the battery before using the
device for the first time.
2.2 POWERING ON/OFF THE DEVICE
Turning On the Device
After installing the SIM cards and charging the battery,
you are now ready to turn on your device.
14
Long press and hold the Power Key to turn on the
device.
The first screen that appears is known as the
home/idle Screen.
Drag the lock icon sidewards to unlock the
screen.
If the screen turns off, then short press the Power
Key to turn on the display.
Turning Off the Device
Press and hold the Power Key for 3 seconds.
A pop-up window appears, select Power off.
Select OK to confirm.
15
3. BASIC OPERA TI ON S
3.1 CALLING
To Make Calls
If the icon appears on the screen, then you can
make or receive calls.
To make a call, please follow the steps mentioned below:
Enter the Main Menu, select Phone.
Enter the phone number using the on-screen
keyboard.
Tap to delete a wrong number. Tap and
hold it to erase the entire number.
After entering phone number, tap .
To end the call, tap
Answer/Reject an Incoming Call
When you receive an incoming call, a notification
message appears on the screen. In order to accept the
call, drag towards right. If you wish to reject the call,
drag towards left.
Other Options during the call
To put a call on hold
If you are having a call conversation and there is another
incoming call, accept the call and the first call will be held
16
on automatically.
To set up conference calls
You are already having a call conversation.
Select Add Call to make another call. .
After connecting to the second call, select
merge calls to set up the conference call.
3.2 MESSAGING
Your device features, sending and receiving of SMS
(Short Message Service) and MMS (Multimedia Message
Service). Go to Main Menu and then select Messaging.
Creating a Message
Tap Compose new message.
In Type name or number field; enter the
recipient‟s name or phone number.
Type message in the Type text message field.
Tap to Send.
Receiving and Managing Messages
When you send and receive messages to or from a
contact, these messages are grouped as a message
thread. A message thread looks like an exchanged
conversation.
To reply to a text message
Enter the Main Menu, select Messaging.
17
Select a message thread to open it.
Select Type text message to enter your
message.
Tap to Send.
To forward a text message
Enter the Main Menu, select Messaging.
Tap to view a message thread.
Press and hold a message to view the message
options.
Select Forward.
In the Type name or number field, enter the
recipient‟s name or phone number.
Tap to Send.
To delete all text messages
Enter the Main Menu, select Messaging.
Tap Menu > Delete all threads.
All the messages will be deleted.
To copy message text
You can use this function to copy the text from a
message to a new message you are composing.
Enter the Main Menu, select Messaging.
Select a message thread to open it.
Press and hold the message to view the
submenu options.
Select „Select text‟,and then copy the message
you want.
Go to Compose new message.
18
Press and hold Type text message.
Select „Paste‟ to paste the copied text to your
new message.
MULTIMEDIA MESSAGE
A Multimedia message or MMS can contain letters, an
image, an audio or video file. To create and send a MMS,
please follow the steps mentioned below:
Enter the Main Menu, select Messaging.
Tap Compose new message.
Select Menu > Add subject.
In the Type name or number field, enter the
recipient‟s name or phone number and enter the
Subject.
To insert a picture or video file, etc, tap .
To insert text, tap Type text message, and then
enter your message.
3.3 CONTACTS
Contacts refer to the phonebook that lets you store
names, phone numbers, e-mail addresses and other
information. You can save information such as name,
picture, phone numbers, e-mail addresses, etc for each
contact listed in your Contacts menu.
To add a Contact
Enter the Main Menu select Phone.
Enter number > Tap Menu key > New contact.
19
Select the storage
You can enter contact information such as name,
phone number, email address etc, if you select
storage as “Phone contact”.
Tap Done to save the contact.
Tip: Or enter the Main Menu and select Contacts,
tap create New contact.
To import contacts
Enter the Main Menu select Contacts.
Tap Menu key > Import/export.
Select to import contacts from Phone contact/
Phone storage/ SIM Card/ SD Card.
Select a particular source to import the contacts
from.
Select Next.
Select the destination, such as Phone storage to
copy contacts to.
Select Next.
Select “Select All” to import all contacts or mark
the required contacts.
Select OK.
3.4 EMAIL
Your device allows you to compose, read and send
emails.
3.5 BROWSER
20
Browser is a tool which enables you to access the
Internet.
21
4. HOME SCREE N
From Home screen, you can quickly access common
features, view notifications of missed calls, received
messages and check connection status.
4.1 STATUS BAR
The Status bar icons indicate different types of
information. The table below lists various icons that might
appear on the status bar of the device.
Network intensity of SIM card 1 or SIM
card 2
Battery level of the device
New short message
Missed call notification
Headset is plugged in
USB connected
Wi-Fi is connected.
Bluetooth is activated
GPRS network is in use.
22
4.2 CUSTOMIZING SCREEN
The device features a touch screen with idle displays and
access to utilities at just one-touch. So you can swipe
right or left to navigate through various screens
accessing your favorite features without entering the
main menu. Each screen can be customized by adding
various widgets, shortcuts and folders.
Shortcuts
In order to add a shortcut on the screen: Long press on
the desired application to add on the screen.
Widgets
Save time with live updates right on Home screen and get
all of your personalized updates at one place.
Setting the wallpaper
You can customize the wallpaper of your Home screen
with default wallpaper or with pictures taken from your
device.
In the idle mode, tap Menu Key > WALLPAPER.
Set up your home screen‟s wallpaper.
Rotating Your Mobile Phone Screen
The orientation of most screens will change to landscape
or portrait view when you rotate your phone sideways.
23
On the Home screen, tap > Settings >
Display > Auto-rotate screen to disable this
function.
24
5. MULTIMEDIA
Your device features various multimedia options, such as
Music Player, Camera and Video Player.
5.1 FILE MANAGER
You can browse, open and manage the data saved in the
Device and Memory card by accessing the File Manager
sub-menu. The device provides a certain space for users
to manage files and supports the T-Flash card. You can
use the file browser to conveniently manage various
directories and files on the T-Flash card.
5.2 CAMERA
Your device is equipped with camera and camcorder,
which enables you to capture photos and videos.
5.3 SOUND RECORDER
You can use the sound recorder to record sounds and
also select to save the recordings in your phone. Tap
select Application tab > Sound Recorder. When in the
sound recorder interface, press menu key to select
Recording mode.
5.4 GALLERY
25
You can view the captured images, recorded video clips,
and downloaded images in the Gallery.
The picture folder and video folder will be displayed.
Select to view the camera pictures or camera videos. The
images or videos will be displayed in thumbnails.
5.5 FM radio
You can use your phone to listen to FM radio stations
once the original Headset is plugged into the connector.
Please press the side key to adjust music volume.
Tap to exit FM radio function. Tap the
( ) to search the channels.
26
6. NETWORK
6.1 WI-FI
Connect to a wireless network to browse Internet.
Enter Main Menu and tap Settings.
Tap to activate Wi-Fi.
Tap Wi-Fi > Network notification to start
detecting networks. The available networks will
then be listed.
Tap Add Wi-Fi network to add a connection.
Note:
If the device before the connection is successful,
the equipment information will be saved in the
pop-up window selected connection, select forget
to remove device information.
If the device does not encrypt, select connection
in the pop-up window to connect.
If the device is encrypted, the pop-up window will
appear, enter the password.
Network connection is successful; the status bar
icon appears Wi-Fi connection.
6.2 3G
The device supports WCDMA protocol. Please make
sure that you device is turned off, then insert or remove
the SIM card.
27
6.3 BLUETOOTH
You can transfer data, such as music to other device
using Bluetooth. Search the device and accept/transfer
data. The received data is automatically stored in the
directory.
Access Settings by entering the main menu
Check Bluetooth to turn on Bluetooth
To make your device discoverable, select
bluetooth settings and check discoverable.
28
7. SETTINGS
Select Settings to view and adjust the settings of your
device. The Settings menu is categorized into: Wireless &
networks, Audio profiles, Display, Storage, Battery, Apps,
Location, Security, Language & input, Backup & reset,
Accounts and System.
7.1 SIM MANAGEMENT
Your device supports two SIM cards, which can be
managed by accessing the SIM Management sub-menu.
You can view/change the roaming settings of the cards
using this menu.
7.2 WIRELESS & NETWO KS
Access this sub-menu to change/view the Wi-Fi,
Bluetooth, Mobile Networks, VPN settings, etc. Please
refer to network section for detailed information on Wi-Fi
and bluetooth.
7.3 AUDIO PROFILES
Your device provides four pre-defined user profiles that
allow the operations of the device to best suit the
environment you are in. The profiles are General, Silent,
Meeting and Outdoor. The Touch icon adds a new
profile; tap the icon to select Reset to restore the
29
default settings.
7.4 DISPLAY
With this function you can configure the display
characteristics of the device including brightness,
Auto-rotate screen, etc.
7.5 STORAGE
View and manage the data storage of your device:
Total Space and Available Space: Lists the amount of
space on the microSD card installed in your device and
the amount you have used to store photos, videos, music,
and other files.
Unmount SD Card: Un-mounts the microSD card from
your device so that you can format the card or safely
remove it when the device is on.
Available Space: The amount of internal phone storage
used by the operating system, its components,
applications (including those you downloaded), and their
permanent and temporary data.
7.6 BATTERY
You can check the battery status of the device by
accessing this sub-menu.
7.7 APPLICATIONS
This sub-menu enables you to manage all the installed,
running and applications saved in the device memory and
30
SD card. You can remove and manage installed
applications, view and control running applications.
7.8 LOCATION ACCESS
Your device supports Global Positioning System.
7.9 SECURITY
You can protect your device from unauthorized users by
setting the PIN code or entering a password.
Enable or Disable SIM card PIN
When PIN code is enabled, you are required to enter the
PIN code before using your phone.
Go Main Menu> Settings > Security.
On the SIM card lock tab, select Set up SIM card
lock.
Select a SIM card.
Tap Lock SIM card to use PIN. Check to enable,
uncheck to disable.
Enter the current PIN code.
To change the PIN code, select Change SIM PIN.
Enter the old PIN code.
Enter the new PIN code and confirm.
Setup Screen Lock
You can set up a lock for your screen in form of Pattern,
PIN code or password.
Go to Settings > Security
Set up Screen lock
31
Select a desired form (None, Slide, Pattern, PIN
or Password)
7.10 LANGUAGE AND INPUT
Use the Language & Keyboard settings to select the
language for the text on your device and for configuring
the onscreen keyboard, including words that you‟ve
added to its dictionary.
7.11 BACKUP & RESET
You can use the Privacy settings to manage your
personal information, such as back up my data,
automatic restore and factory date reset.
7.12 ACCOUNTS
Use the Accounts to add, remove, and manage your
Google and other supported accounts. You also use
these settings to control how and whether all applications
send, receive, and sync data on their own schedules, and
whether all applications can synchronize user data
automatically.
7.13 DATE AND TIME
You can select to set date, time and time zone using this
sub-menu.
Use Automatic unless you need to override the network
values.
32
Use 24-hour format: Select to set 24-hour formats on or
off.
Choose Date format: Select from a variety of formats.
7.14 SCHEDULE POWER ON/OF F
You can set the time for auto power on /off. Do turn the
status on before using that function, and then the time.
7.15 ACCESSIBILITY
You can use the Accessibility settings to configure any
accessibility plug-ins you have installed on your device.
7.16 ABOUT PHONE
You can view system information Including Status, Legal
information, Model number, Android version and so on.
33
8. APPLICAT IONS & U T I L I TIES
For your entertainment purpose, your device is provided
with several interesting games, applications and utilities.
Please ensure that you have GPRS setting in your device
to access the applications. Contact your operator for
GPRS settings if you need it.
8.1 CALCULATOR
Calculator helps you perform basic arithmetic functions,
such as addition, subtraction, multiplication and division.
8.2 CLOCK
This function gives you an access to the alarm clock.
Go to Main Menu Clock，Tap to add alarm.
8.3 GMAIL
Gmail is Google's web-based email service. Google Mail
is configured when you first set up your device.
Depending on your synchronization settings, Google Mail
on your device is automatically synchronized with your
Google Mail account on the web.
Go to Main Menu > Gmail.
Select “Existing” or “New” start the Gmail.
Follow the on screen instructions to login or
create your Gmail username and password.
34
Once logged in, you can begin reading and
sending emails from your Gmail account.
8.4 PLAY STORE
Play store allows you to find and download applications
and fun games for your device.
Go to Main Menu > Play Store and setup your
Google account.
Select Create to create a new account or Sign in
to sign in your existing account.
Once you are signed in you can begin searching and
downloading programs from the market. Tap Apps to
view the list of applications available and tap Games to
view the list of games available.
35
9. SP E CIFICATIO NS
Screen
4.5 inch (qHD)
Battery
1700 mAh
Dimensions
133X 68 X 8.9 mm
Sensor Pixel
QUXGA(8.0Mega)
Network
GSM: 850/900/1800/1900 MHz
WCDMA:
BAND1(2100)\BAND8(900)
Standby Time
350 hours
Maximum Talk
Time
300 Minutes
* The standby time and maximum talk time depend upon
the network signals and settings.
36
E N VI R ONM ENTAL CONCER N
Help us save Our Environment…GO GREEN..!!
All our endeavors are directed towards providing
environment friendly products to you. The materials used
in our devices are recyclable and can be reused to make
new products. We strive to make products that are safe
for our consumers as well as the environment. Come join
hands with us and make world a better place to live.
Preserve natural resources for future generations by
recycling your phone. The phone contains some metals,
when recycled properly; these can be put back into
circulation, decreasing the need for new metal mining.
Recycling reduces the need for raw materials, saves
energy, helps mitigate Global Warming and reduces
pollution, reduces waste products in landfills; therefore
preserving natural resources for the future and saving the
planet.
Follow some simple steps and contribute towards saving
the planet.
DOs
Recycle your handset and its accessories.
To protect natural resources and to promote re-use of the
material, kindly separate batteries from other type of
waste.
DONTs
Do not dispose off your mobile and its battery in fire.
37
Do not dispose your mobile with the regular waste.
Do not over charge your handset. Remove the charger
when battery is full.
Don‟t trash your phone, instead RECYCLE it
This logo signifies that this product and/or its
consitituents should not be disposed off with other
household waste.
Hazards of Improper handling, accidental breakage,
damage and /or improper recycling of hazardous
elements
If this product is improperly handled, broken or damaged
or carelessly recycled or disposed off in the fire, can
result in environmental and data security concerns,
including the following:
Affect nearly every system in the human body and result
in birth defects, brain, heart, liver, kidney and skeletal
system damage. They will also significantly affect the
nervous and reproductive systems of the human body;
When burned, create cancer-producing dioxins which are
released into the air we breathe; If thrown in landfills, may
leach into groundwater affecting
your local community;
In warm climates, the oxidation of
mercury in the environment can be
accelerated, leading to the creation
of oxidized Hg atoms that are
38
known to be associated with ozone depletion; and
Improper recycling additionally results in data security
issues, as private electronic information remains on hard
drive, if not properly removed before disposal.
How to Recycle
Please get your electronics products recycled only
through authorized recyclers, approved by Pollution
Control Board. We provide facility of recycling of our
products. For details of our collection centers, please visit
our website or call our customer care. Help us to GO
GREEN.
Constitution of Hazardous Elements in your Device:
Your device does not contain the following hazardous
elements in a proportion higher than the limits provided
hereunder: maximum concentration value of 0.1% by
weight in homogenous materials for lead, mercury,
hexavalent chromium, polybrominated biphenyls and
polybrominated diphenyl ethers; and maximum
concentration value of 0.01% by weight in homogenous
materials for cadmium.
39
EU Regulatory Conformance Hereby, Bullitt Group
declares that this device is in compliance
with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Safety Information and Notices
Failure to comply with the following precautions may be
dangerous or illegal.
Never attempt to disassemble your phone. You alone are
responsible for how you use your phone
and any consequences of its use.
As a general rule, always switch off your phone wherever
the use of a phone is prohibited. Use of
your phone is subject to safety measures designed to
protect users and their environment.
Do not use your phone in damp areas (bathroom,
swimming pool…). Protect it from liquids and
other moisture.
The max. recommended temperature is 35°C.
Do not leave your phone within the reach of small
children (certain removable parts may be
accidentally ingested). Please carefully read and observe
the terms below:
Distance of operation
This phone model has been tested and meets
radiofrequency exposure guidelines when used as
follows:
• Against the ear: Place or receive a phone call and hold
the phone as you would a wire line
telephone.
• Body worn: When transmitting, place the phone in a
40
carry accessory that contains no metal and
positions the phone a minimum of 1.0 cm form your body.
Use of other accessories may not
ensure compliance with radiofrequency exposure
guidelines. If you do not use a body worn
accessory and are not holding the phone at the ear,
position the phone a minimum of 1.0 cm from
your body,
• Data operation: When using a data feature, position the
phone a minimum of 1.0 cm from your
body for the whole duration of the data transmission.
Adapter
Adapter shall be installed near the equipment and shall
be easily accessible.
Sound pressure safety
Use carefully with the earphone maybe possible
excessive sound pressure from earphones and
headphones can cause hearing loss.
Caution
Risk of explosion if battery is replaced by an incorrect
type. Dispose of used batteries according to
the instructions.
Proper use
As described in this manual, your mobile phone can be
used only in right location. If possible,
please do not touch the antenna area on your phone.
1g SAR(W/Kg):
Head:0.909 Body-worn:1.19
Hotspot: 1.19
FCC Caution.
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved
by the party responsible for compliance could void the
user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
41
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
Specific Absorption Rate (SAR) information:
This mobile phone meets the government's
requirements for exposure to radio waves. The
guidelines are based on standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety
margin designed to assure the safety of all persons
regardless of age or health.
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over
one gram of tissue. Device types: Instamatic (FCC ID:
ZL5SP4) has also been tested against this SAR limit.
The highest SAR value reported under this standard
during product certification for use at the ear is
0.909W/kg and when properly worn on the body is
1.19W/kg. This device was tested for typical
body-worn operations with the back of the handset kept
1.0cm from the body. To maintain compliance with FCC
RF exposure requirements, use accessories that
maintain a 1.0cm separation distance between the
user's body and the back of the handset. The use of
belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use
of accessories that do not satisfy these requirements
may not comply with FCC RF exposure requirements,
and should be avoided.
42
Body‐worn Operation
This device was tested for typical body-worn operations.
To comply with RF exposure requirements,
a minimum separation distance of 1.0cm must be
maintained between the user’s body and the handset,
including the antenna.
Third-party belt-clips, holsters, and similar accessories
used by this device should not contain any metallic
components. Body-worn accessories that do not
meet these requirements may not comply with RF
exposure requirements and should be avoided. Use
only the supplied or an approved antenna.
43
