Manual
User Manual
Acoustix
Model :IVACTX
Brand:ivation
FCC ID:2AD2WIVACTX
IC:12680B-IVACTX
Product
Information Guide
Welcome. You are using Waterproof Bluetooth Speaker.
This guide contains helpful information that
enables you to enjoy all of the features of your speaker.
Congratulations
Thanks for purchasing the portable wireless speaker.
Enjoy this smart product, please read below instructions carefully. It's more than just a Bluetooth
Speaker!
Care and Maintenance
1. Do not attempt to service the product yourself. Opening or removing covers may expose you to
dangerous voltages or other hazards, please contact your dealer.
2. Do not use the product in temperature exceed the standard. Extreme temperature will lead to
damage of product, decrease of battery capacity or product durability.
3. Keep the product out of the reach of children.
4. Do not use the product close to other wireless devices or radiators.
5. Do not drop the product into the fire, battery explosion will cause personal injury or death.
6. Risk of explosion if battery is replaced by an incorrect type.
7. Dispose of used batteries according to the instructions.
8. Use the product in proper volume. Extremely high volume can be harmful to your ears.
9. Fully charge the product before use if it has not been used for a long period of time.
Features List
1. Clear and crystal sound , superior stereo performance
2. Build-in microphone
3. Bluetooth connection (Bluetooth V4.0)
4. Bluetooth mode, FM mode, AUS mode Optional
5. Music playing control
6. Waterproof
7. Receiving and rejecting a call by button
8. volume selectable (15 levels+off)
9. Preset the station
10. Store 10 FM stations
11. Manual or Auto search
12. Low battery LED indication
13. LED indicator (Low battery/Charging/full charging)
14. Display
Layout
Front View
Speaker Mesh
Rear View
Micro-USB charging port
Audio in jack
Top View
Inside View
Key Instruction
Function Key Function Operate
Power key
Power on Press and hold 3 seconds.
Power off Press and hold 3 seconds.
Vo l um e +( Vol +)
Volu me up Press briefly or press and hold .
Volume- (Vol -)
Volume down Press briefly or press and hold .
Mode key
Switch mode Press briefly to switch the next mode
between BT/AUX/FM cyclically.
Play/Pause
Play/Pause
Bluetooth Music Operation
Press briefly to play or stop the music.
Radio Operation-Listening interface
Press briefly to enter the preset station
list interface .
Radio Operation-Presetting station interface
Press briefly to set to the current station.
Press and hold to store the current station.
Radio Operation
Press briefly to go to next preset in that direction.
Hold or to tune up and down
automatically.
Will stop at next available station.
Previous/Next
Bluetooth Music Operation
Press to go to next song.
Press to go to previous song.
Call
Press briefly to answer the call,
press again to end the call and return to previous mode.
Use Instruction(BT Mode)
Function Item BT Status Key Operation Function
Basic function
(See P12
Pairing and
connecting)
Disconnected
/Connected
Press and hold
3 seconds.
Pair second device
Disconnected
Press and hold
12 seconds.
Delete the pair
Press briefly. Re-connect
Play music
function
Connected Press briefly. Play
Playing Press briefly. Pause
Press briefly or
press and hold .
Previous Song/Rewind
Press briefly or
press and hold .
Next Song/Fast Forward
Call function Outgoing call Press briefly. End
Press and hold
3 seconds.
Last Number Redial
Incoming call Press briefly. Reject
Press briefly. Answer
Call waiting Press briefly. End the current call and
answer the 3rd party call
Press briefly. Hold the current call and
answer the 3rd party call
During the
call
Press briefly. End the current call
Press briefly. Switch between the current call
and the 3rd party call
Press briefly or
press and hold .
Volu me u p
Press briefly or
press and hold .
Volume down
Use Instruction(FM Mode)
Interface Key Operation Function
All Press briefly or press and
hold .
Volu me u p
Press briefly or press and
hold .
Volume down
Listen
interface
Press briefly. Enter the preset station list
interface
Press briefly. Take you to the next
preset station down
Press briefly. Advance to the next
preset station up
Press and hold . Automatically search
Previous station
Press and hold . Automatically search
next station
the preset
station list
interface
Press briefly. Go to previous station
Press briefly. Go to next station
Press briefly. Set to the current
radio station
Press and hold . Store the current
radio station
Press briefly. Exit the preset station
list interface
Battery/Charger
Acoustix has a built-in Li-ion battery (3.7V, 2500mAh), so it can be used without connecting to a
power supply(DC 5V,0.5A). To charge the battery, connect included micro-USB cable to charging
port. Plug other end into computer USB port, or connect to AC adaptor and plug into wall outlet.
Notes:
1. When Acoustix is in charging mode, the Red LED is on. When fully charged, the Red LED will
go off and the Green LED will be on.
2. From fully discharged battery to full charge will take 3 hours.
3. You can charge Acoustix while still using it when its battery is low, but this could shorten the
battery life. It is recommended to power off Acoustix and fully charge it before use.
Operations
Power On / Off
Power On: in power off mode, press and hold 3 seconds to power on Acoustix(The default
mode is BT mode).
Power Off: in standby status, press and hold 3 seconds.
Adjust Volume
1. Press briefly to increase the volume.
Or press and hold to increase volume continually.
2. Press briefly to decrease the volume.
Or press and hold to decrease volume continually.
Mode Switch
Press briefly to switch to the Bluetooth mode, FM mode, AUX mode cyclically.
Select Language
1. Press and hold 10 seconds to enter language setting.
2. Press or briefly to select English, French and Spanish.
3. Press briefly or leave idle for 10 seconds to confirm and exit.
Return to the Default Setting
Press and hold and at the same time about 5 seconds.
Pairing and Connecting(Bluetooth mode)
1. Press and hold 3 seconds to power on, the speaker will enter pairing mode automatically.
The display will show "Pairing". The Bluetooth blue indicator will flash.
2. Enable Bluetooth function on mobile device you wish to connect and search Bluetooth
accessories in range.
3. When ''Acoustix'' appears on your mobile device, select it.
4. The Bluetooth blue indicator light steadily and a single beep will sound. Devices are now
connected.
Note:
If you did not delete the paired device, you must press and hold 5 seconds to pair other new
devices.
Re-connect
In the unconnected state, press , it will reconnect to the last connected device.
Delete the paired device
In the unconnected state, press and hold 12 seconds until you sound two long beeps.
Calling(Bluetooth mode)
Answer A Call
Press briefly to answer an incoming call.
Reject A Call
Press briefly to reject the call.
End A Call
After calling, press briefly to end the call or end the call on the phone. Acoustix will return to
the previous mode: bluetooh, AUX or radio.
Last Number Redial
Press and hold for 3 seconds to redial the last call.
Call Waiting
1. During the call, if you have second call, press briefly to end the current call and answer the
3rd party call.
Or press briefly to hold the current call and answer the 3rd party call.
2. During the call waiting, you can press briefly to switch between the current call and the
3rd party call.
Music Playing(Bluetooth mode)
After Acoustix is connected to your Bluetooth device1：
1. Press on Acoustix to play music, press it again to pause.
2. Press briefly to get to the previous song. Press a briefly to play next song.
Or press and hold or to fast forward/rewind the music.
3. Press briefly or press briefly to adjust the volume.
Or press and hold or to increase/decrease volume continually.
Notes:
1. A music player app is required on your device to support this feature.
2. Pair and connect your Bluetooth device with Acoustix before using this feature.
3. If a call is received when you are listening to music, the music will pause automatically and
replaced by the incoming-call-tone. Press to answer the incoming call. Once the call is
finished, the music will continue.
Listening(FM mode)
1. Press briefly to switch to the FM mode.
2. Press briefly to take you to the next preset station down.
Press briefly to advance you to the next preset station up.
3. Press and hold , Acoustix will search previous station automatically.
Press and hold , Acoustix will search next station automatically.
4. Press briefly or press briefly to adjust the volume.
Or press and hold or to increase/decrease volume continually.
Presetting station (FM mode)
1. In FM mode, press briefly to enter the Preset Mode.
2. In the preset station list interface, press briefly to go to previous station.
Press briefly to go to next station.
3. Press briefly to set the channel to current channel.
4. You can store the station you like, follow this steps:
a. You should be listening to the station you want to store.
b. Press briefly to enter the Preset Mode.
c. Then press and to choose the preset you want to store the station to.
d. Press for 3 seconds to store the station in that preset number.
5. Press briefly or press briefly to adjust the volume.
Or press and hold or to increase/decrease volume continually.
6. Press briefly or leave idle for 10 seconds will exit and return to previous mode.
Timeout Instruction
System Pattern Timeout Event Timeout Action after Timeout
BT/FM/AUX Low battery 3 minutes Power off
Screen is light on
but no operation
1 minute Screen off
BT Unconnected 10 minutes Power off
Pair 3 minutes Enter unconnected state
Re-connect
if out of range
10 minutes Enter unconnected state
FM No signal 10 minutes Power off
AUX Not insert audio
line
10 minutes Power off
Interval Time
System Pattern Repeat Event Interval Time
BT Re-connect
if out of range
10 seconds
Troubleshooting
Volume Is Not High Enough
·Increase the volume of Bluetooth device or Acoustix volume.
·Ensure that the Bluetooth device or Acoustix has been charged.
Hearing Distortion
·Lower Acoustix, Bluetooth device volume slightly.
·If low battery capacity, please charge it.
Cannot Pair With Bluetooth Device
·Make sure that your device is compatible with Bluetooth.
·Turn off your Acoustix and Bluetooth device, then power on and reconnect.
·Ensure your Acoustix and Bluetooth device are in the connection range.
Signal Loss Or Distortion
·Move Acoustix closer to the Bluetooth device.
·Ensure it's charged up.
·Turn off your Acoustix and Bluetooth device, then power on and reconnect.
Specifications
Bluetooth Compliance Bluetooth V 4.0
Frequency Band 2.4~2.4835GHz ISM Spectrum
Operating Range Up to 10m (indoor)
Battery Capacity 3.7V, 2500mAh
Power Supply DC 5V, 0.5A
Charging Time About 3 hours
Standby Time About 120 hours
Compatibility Mobile phone/device supporting Bluetooth
V1.1 (and above)
Size 178mm*56mm*64mm
Ambient temperature -20℃ ~ 60℃
Humidity 45%~70%
*Design and specifications are subject to change without notice.
FCC Statement:
This equipment has been tested and found to comply with the limits for Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: Modifications to this product will void the user’s authority to operate this equipment.
IC Statement :
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device."
IC Déclaration:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Remarque: Toute modification de ce produit annule l'autorité de l'utilisateur à utiliser cet équipement.
