User Manual 3
Technical
Information
Manual
CAENRFIDLib
17 January 2007
Revision n. 2
ANSI C FUNCTIONS
LIBRARY
NPO:
00117/03:RFLIB.MUTx/02
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
INDEX
1. INTRODUCTION................................................................................................................................................4
1.1. CAENRFIDLIB INTRODUCTION......................................................................................................................4
1.2. CAENRFIDLIB DESCRIPTION ........................................................................................................................4
1.2.1. CAENRFIDTypes.h ................................................................................................................................4
1.3. CAENRFIDLIB FUNCTIONS DESCRIPTION .....................................................................................................7
1.3.1. CAENRFID_Init .....................................................................................................................................7
1.3.2. CAENRFID_ End ...................................................................................................................................7
1.3.3. CAENRFID_GetSWRelease ...................................................................................................................7
1.3.4. CAENRFID_GetFWRelease...................................................................................................................8
1.3.5. CAENRFID_Inventory ...........................................................................................................................8
1.3.6. CAENRFID_SetPower ...........................................................................................................................8
1.3.7. CAENRFID_Read...................................................................................................................................9
1.3.8. CAENRFID_Write..................................................................................................................................9
1.3.9. CAENRFID_Lock...................................................................................................................................9
1.3.10. CAENRFID_TestMode.........................................................................................................................10
1.3.11. CAENRFID_SetModulation .................................................................................................................10
1.3.12. CAENRFID_GetModulation ................................................................................................................10
1.3.13. CAENRFID_AllocateChannel..............................................................................................................11
1.3.14. CAENRFID_DeallocateChannel..........................................................................................................11
1.3.15. CAENRFID_AddSourceToChannel......................................................................................................11
1.3.16. CAENRFID_RemoveSourceFromChannel...........................................................................................11
1.3.17. CAENRFID_AddReadPoint .................................................................................................................12
1.3.18. CAENRFID_RemoveReadPoint ...........................................................................................................12
1.3.19. CAENRFID_AllocateTrigger ...............................................................................................................12
1.3.20. CAENRFID_DeallocateTrigger ...........................................................................................................13
1.3.21. CAENRFID_AddReadTrigger..............................................................................................................13
1.3.22. CAENRFID_RemoveReadTrigger........................................................................................................13
1.3.23. CAENRFID_AddNotifyTrigger ............................................................................................................13
1.3.24. CAENRFID_RemoveNotifyTrigger ......................................................................................................14
1.3.25. CAENRFID_GetNotification................................................................................................................14
1.3.26. CAENRFID_GetPower.........................................................................................................................14
1.3.27. CAENRFID_SetProtocol......................................................................................................................15
1.3.28. CAENRFID_GetProtocol.....................................................................................................................15
1.3.29. CAENRFID_GetReadPointStatus ........................................................................................................15
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 2
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.30. CAENRFID_GetSourceInChannel.......................................................................................................15
1.3.31. CAENRFID_GetSourceInTrigger ........................................................................................................16
1.3.32. CAENRFID_GetTriggerInChannel......................................................................................................16
1.3.33. CAENRFID_GetChannelInTrigger......................................................................................................16
1.3.34. CAENRFID_GetReadPointInSource....................................................................................................17
1.3.35. CAENRFID_SetNetwork ......................................................................................................................17
1.3.36. CAENRFID_SetDE_SB ........................................................................................................................18
1.3.37. CAENRFID_GetDE_SB .......................................................................................................................18
1.3.38. CAENRFID_ProgramID ......................................................................................................................18
1.3.39. CAENRFID_KillTag.............................................................................................................................18
1.3.40. CAENRFID_BlockWrite.......................................................................................................................19
1.3.41. CAENRFID_SetRS232 .........................................................................................................................19
1.3.42. CAENRFID_SetDateTime ....................................................................................................................20
1.3.43. CAENRFID_GetIO...............................................................................................................................20
1.3.44. CAENRFID_SetIO................................................................................................................................20
1.3.45. CAENRFID_SetSourceConfiguration ..................................................................................................20
1.3.46. CAENRFID_GetSourceConfiguration .................................................................................................21
1.3.47. CAENRFID_GetAllocatedTriggers......................................................................................................21
1.3.48. CAENRFID_GetAllocatedChannels.....................................................................................................21
1.3.49. CAENRFID_SetEventMode..................................................................................................................22
1.3.50. CAENRFID_GetEventMode.................................................................................................................22
1.3.51. CAENRFID_FirmwareUpgrade...........................................................................................................22
1.3.52. CAENRFID_Lock_C1G2 .....................................................................................................................22
1.3.53. CAENRFID_KillTag_C1G2.................................................................................................................23
1.3.54. CAENRFID_KillTag_C1G2.................................................................................................................23
1.3.55. CAENRFID_ProgramID_EPC119.......................................................................................................23
1.3.56. CAENRFID_ProgramID_C1G2...........................................................................................................24
1.3.57. CAENRFID_Read_C1G2.....................................................................................................................24
1.3.58. CAENRFID_Write_C1G2 ....................................................................................................................24
1.3.59. CAENRFID_QueryTag_C1G2.............................................................................................................25
1.3.60. CAENRFID_SetQ_C1G2 .....................................................................................................................25
1.3.61. CAENRFID_GetQ_C1G2.....................................................................................................................25
1.3.62. CAENRFID_GetReaderInfo.................................................................................................................25
1.3.63. CAENRFID_FreeTagsMemory ............................................................................................................26
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 3
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1. Introduction
The CAEN Long Range UHF Readers are developed in Europe and in compliance with
European and US telecommunication regulations, are a step forward in UHF RFID
readers. Capable of long distance reading using extremely low RF energy, the CAEN
Long Range UHF Readers are optimized to increase receiver sensibility and reduce
transmitter noise.
The CAEN Long Range UHF Readers’ open architecture uses a multi-protocol
technology. The tag protocol interface was developed using a field programmable gate
array, which allows easy modification of the tag protocol definition. On the host side, a
powerful 32bit micro-controller enables fast firmware updating for maximum
upgradeability to future generations of the EPC specification. Easily integrated with most
popular database software and fully compliant with ISO 18000-6B and EPC Class 1 –
Generation 1 protocol, Philips UCODE EPC 1.19, the CAEN Long Range UHF Readers
can be used in conjunction with any passive or active tag that conforms to the same
standards; moreover, it can be easily upgraded for compliancy with other protocols1.
With their extended read range, the CAEN Long Range UHF Readers are well suited to
asset management and logistics applications that require the simultaneous reading of a
large number of tags from a great distance.
1.1. CAENRFIDLib introduction
This section describes the CAENRFIDLib library and its implemented functions.
CAENRFIDLib is a set of ANSI C functions which permits an user program the use and
the configuration of the CAEN Long Range UHF Readers.
The present description refers to CAENRFIDLib, available in the following formats:
− Win32 DLL (CAEN provides the CAENRFIDLib.lib stub for Microsoft Visual C++ 6.0)
CAENRFIDLib is logically located between an application like the samples provided and
the lower layer software libraries.
1.2. CAENRFIDLib description
1.2.1. CAENRFIDTypes.h
#define MAX_ID_LENGTH 12
typedef int CAENRFIDHandle;
/* Error codes
*/
typedef enum {
CAENRFID_StatusOK = 0, // Operation completed successfully
CAENRFID_PortError = -1, // Error on selected port
CAENRFID_ParityError = -2, // Parity error
CAENRFID_InitError = -3, // Error on init
CAENRFID_StatusByteError = -4, // Error on status byte
1 Software upgrades will be available at: http://www.caen.it/rfid/
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 4
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
CAENRFID_InvalidParam = -5, // Invalid parameter error
CAENRFID_TimeOutError = -6, // Time out error
CAENRFID_Max4Byte = -7, // Data length greater than 4
CAENRFID_PowerOutRange = -8, // Power out of range
CAENRFID_BadAntenna = -9, // Antenna not connected
CAENRFID_GenericError = -10, // Generic error
CAENRFID_InvalidHandle = -11 // Invelid Handle
} CAENRFIDErrorCodes;
/*
ID length enum
*/
typedef enum {
L64bit = 8,
L96bit = 12
} CAENRFIDLenghtID;
/*
Communication ports enum
*/
typedef enum {
RS232 = 0,
RS485 = 1,
TCP = 2,
USB = 3
} CAENRFIDPort;
/*
Antenna select enum
*/
typedef enum {
NOANT = 0,
ANT1 = 1,
ANT2 = 2,
ANT3 = 3,
ANT4 = 4
} CAENRFIDAntenna;
/*
Tag identification struct: for each tag it contains
the ID, the length of the ID and the antenna used to
identify the tag.
*/
typedef struct {
byte ID[MAX_ID_LENGTH];
int Length;
CAENRFIDAntenna Antenna;
} CAENRFIDTag;
/*
General purpose outputs masks
*/
typedef enum {
GPO0 = 0x01,
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 5
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
GPO1 = 0x02,
GPO2 = 0x04,
GPO3 = 0x08,
} CAENRFIDGpo;
/*
Bit rate modulation control enum
*/
typedef enum {
TX10RX10 = 0,
TX10RX40 = 1,
TX40RX40 = 2,
TX40RX160 = 3
} CAENRFIDTxRxConf;
#ifndef CAENRFID_ODL
/*
RF field control enum
*/
typedef enum {
CARRIER_OFF = 0,
CARRIER_ON = 1
} CAENRFIDControl;
/*
*/
typedef enum {
STANDBY = 0,
ACTIVE = 1
} CAENRFIDPas;
/*
Command mode control enum
*/
typedef enum {
SINGLE = 0,
START_SEQ = 1,
END_SEQ = 2,
SUSTAINED = 3
} CAENRFIDSetCMD;
#endif
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 6
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3. CAENRFIDLib Functions description
1.3.1. CAENRFID_Init
Name: CAENRFID_Init
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function generates an opaque handle to identify a module
attached to the PC.
Parameters: [in] Port: Communication port (see CAENRFIDPort enum).
[in] Address: Communication address (i.e.: "COM1" for RS232,
"USB0" for USB of IP address for TCP/IP etc.)
[out] Handle: The handle that identifies the device.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Init (CAENRFIDPort Port, char *Address,
CAENRFIDHandle *Handle, CAENRFIDProtocol *Protocol);
1.3.2. CAENRFID_ End
Name: CAENRFID_End
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: Notifies the library the end of work and free the allocated
resources
Parameters: [in] Handle: The handle that identifies the device
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_End(CAENRFIDHandle Handle);
1.3.3. CAENRFID_GetSWRelease
Name: CAENRFID_GetSWRelease
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: Permits to read the software release of the library.
Parameters: [out] SwRel: Returns the software release of the library
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetSWRelease(char *SwRel);
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 7
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.4. CAENRFID_GetFWRelease
Name: CAENRFID_GetFWRelease
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: Permits to read the firmware release loaded into the device
Parameters: [in] Handle: The handle that identifies the device.
[out] FWRel: Returns the firmware release of the device
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetFWRelease(CAENRFIDHandle Handle, char
*FWRel);
1.3.5. CAENRFID_Inventory
Name: CAENRFID_Inventory
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function returns all the IDs of the tags under the reader
fieldusing all the available antennae. The Tags array contains
The IDs together with other information related to the single ID
such as the antenna under which is the ID and the format of the
ID itself (see CAENRFIDTag struct for the details).
Parameters: [in] Handle: The handle that identifies the device.
[in] LogicalSourceName: The name that identify the Logical
Source
[out] Tags: Returns an array containing the tags read.
[out] TagsNo: Returns the number of tags in the array.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Inventory(CAENRFIDHandle Handle, char
*LogicalSourceName, CAENRFIDTag **Tags, int *TagsNo);
1.3.6. CAENRFID_SetPower
Name: CAENRFID_Inventory
Reader: A928EU, A948EU
Description: The function permits to set the RF field power relative to the
antenna socket
Parameters: [in] Handle: The handle that identifies the device.
[in] Power: RF field power expressed in mW.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetPower(CAENRFIDHandle Handle, unsigned int
Power);
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 8
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.7. CAENRFID_Read
Name: CAENRFID_Read
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: This function allows to read Length bytes from the memory of a
specific tag identified by the ID (regardless of its status) at the
address specified by Address.
Parameters: [in] Handle: The handle that identifies the device.
[in] ID: The tag ID.
[in] Address: The address of the memory to read.
[in] Length: The number of bytes to read.
[out] Data: The data read from the tag's memory.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Read(CAENRFIDHandle Handle, CAENRFIDTag
*ID, int Address, int Length, void *Data);
1.3.8. CAENRFID_Write
Name: CAENRFID_Write
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: This function allows to write Length bytes to the memory of a
specific tag identified by the ID (regardless of its status) at the
address specified by Address.
Parameters: [in] Handle: The handle that identifies the device.
[in] ID: The tag ID.
[in] Address: The address of the memory to write.
[in] Length: The number of bytes to write.
[in] Data: The data to write in the tag's memory.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Write(CAENRFIDHandle Handle, CAENRFIDTag
*ID, int Address, int Length, void *Data);
1.3.9. CAENRFID_Lock
Name: CAENRFID_Lock
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: This function allows to lockthe memory of a specific tag identified
by the ID at the address specified by Address.
Parameters: [in] Handle: The handle that identifies the device.
[in] ID: The tag ID.
[in] Address: The address of the memory to write.
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 9
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Lock(CAENRFIDHandle Handle, CAENRFIDTag
*ID, int Address);
1.3.10. CAENRFID_TestMode
Name: CAENRFID_TestMode
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to enable/disable te TestMode.
Parameters: [in] Handle: The handle that identifies the device.
[in] TestMode: 0 Disable TestMode >0 Enable
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_TestMode(CAENRFIDHandle handle, unsigned int
TestMode);
1.3.11. CAENRFID_SetModulation
Name: CAENRFID_SetModulation
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to control to choose the modulation (the bit
rate of the transmission and receive)
Parameters: [in] Handle: The handle that identifies the device.
[in] TxRxCfg: Modulation setting.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetModulation(CAENRFIDHandle Handle, unsigned
short TxRxCfg);
1.3.12. CAENRFID_GetModulation
Name: CAENRFID_GetModulation
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to retrieve the modulation (the bit
rate of the transmission and receive).
Parameters: [in] Handle: The handle that identifies the device.
[out] TxRxCfg: Modulation setting
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetModulation(CAENRFIDHandle handle, unsigned
short *TxRx);
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 10
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.13. CAENRFID_AllocateChannel
Name: CAENRFID_AllocateChannel
Reader: A928EU, A948EU
Description: The function permits to allocate a notification Channel
Parameters: [in] Handle: The handle that identifies the device.
[in] ChannelName: The Name of the Channel.
[in] ChannelAddress: The Address of the Channel in the form
[TCP|USB|RS232]://[ip address:port]
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_AllocateChannel(CAENRFIDHandle handle, char
*ChannelName, char *ChannelAddress);
1.3.14. CAENRFID_DeallocateChannel
Name: CAENRFID_DeallocateChannel
Reader: A928EU, A948EU
Description: The function permits to Deallocate a Channel.
Parameters: [in] Handle: The handle that identifies the device.
[in] ChannelName: The Name of the Channel.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_DeallocateChannel(CAENRFIDHandle handle, char
*ChannelName);
1.3.15. CAENRFID_AddSourceToChannel
Name: CAENRFID_AddSourceToChannel
Reader: A928EU, A948EU
Description: The function permits to add a LogicalSource to a notification
Channel.
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The Name of the Logical Source.
[in] ChannelName: The Address of the Channel.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_AddSourceToChannel(CAENRFIDHandle handle,
char *SourceName, char *ChannelName);
1.3.16. CAENRFID_RemoveSourceFromChannel
Name: CAENRFID_RemoveSourceFromChannel
Reader: A928EU, A948EU
Description: The function
p
ermits to remove a Lo
g
icalSource from a
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 11
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
notification Channel
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The Name of the Logical Source.
[in] ChannelName: The Address of the Channel.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_RemoveSourceFromChannel(CAENRFIDHandle
handle, char *SourceName, char *ChannelName);
1.3.17. CAENRFID_AddReadPoint
Name: CAENRFID_AddReadPoint
Reader: A928EU, A948EU
Description: The function permits to add a read point (antenna) to a logical
source
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The name of the Logical Source.
[in] ReadPoint: The name of the Read Point.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_AddReadPoint(CAENRFIDHandle handle, char
*SourceName, char *ReadPoint);
1.3.18. CAENRFID_RemoveReadPoint
Name: CAENRFID_RemoveReadPoint
Reader: A928EU, A948EU
Description: The function permits to remove a read point (antenna) frpm a
logical source
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The name of the Logical Source.
[in] ReadPoint: The name of the Read Point.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_RemoveReadPoint(CAENRFIDHandle handle, char
*SourceName, char *ReadPoint);
1.3.19. CAENRFID_AllocateTrigger
Name: CAENRFID_AllocateTrigger
Reader: A928EU, A948EU
Description: The function permits to create a trigger of the specified type
Parameters: [in] Handle: The handle that identifies the device.
[in] TriggerName: The name of the trigger.
[in] TriggerType: The type of the trigger.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 12
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
CAENRFID_AllocateTrigger(CAENRFIDHandle handle, char
*TriggerName, char *TriggerType);
1.3.20. CAENRFID_DeallocateTrigger
Name: CAENRFID_DeallocateTrigger
Reader: A928EU, A948EU
Description: The function permits to destroy a trigger
Parameters: [in] Handle: The handle that identifies the device.
[in] TriggerName: The name of the trigger
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_DeallocateTrigger(CAENRFIDHandle handle, char
*TriggerName);
1.3.21. CAENRFID_AddReadTrigger
Name: CAENRFID_AddReadTrigger
Reader: A928EU, A948EU
Description: The function permits to associate a trigger to a source in order to
start a read cycle
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The name of the Logical Source.
[in] TriggerName: The name of the trigger
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_AllocateTrigger(CAENRFIDHandle handle, char
*TriggerName, char *TriggerType);
1.3.22. CAENRFID_RemoveReadTrigger
Name: CAENRFID_RemoveReadTrigger
Reader: A928EU, A948EU
Description: The function permits to remove the read trigger from the logical
source
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The name of the Logical Source.
[in] TriggerName: The name of the trigger
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_RemoveReadTrigger(CAENRFIDHandle handle,
char *SourceName, char *TriggerName);
1.3.23. CAENRFID_AddNotifyTrigger
Name: CAENRFID_AddNotifyTrigger
Reader: A928EU, A948EU
Description: The function
p
ermits to associate a tri
gg
er to a channel in order
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 13
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
to start a notification.
Parameters: [in] Handle: The handle that identifies the device.
[in] ChannelName: The Address of the Channel.
[in] TriggerName: The name of the trigger.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_AddNotifyTrigger(CAENRFIDHandle handle, char
*ChannelName, char *TriggerName);
1.3.24. CAENRFID_RemoveNotifyTrigger
Name: CAENRFID_RemoveNotifyTrigger
Reader: A928EU, A948EU
Description: The function permits to remove the notification trigger from a
channel.
Parameters: [in] Handle: The handle that identifies the device.
[in] ChannelName: The Address of the Channel.
[in] TriggerName: The name of the trigger.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_RemoveNotifyTrigger(CAENRFIDHandle handle,
char *ChannelName, char *TriggerName);
1.3.25. CAENRFID_GetNotification
Name: CAENRFID_RemoveNotifyTrigger
Reader: A928EU, A948EU
Description: The function permits to decode data coming from the notification
channel
Parameters: [in] Skt: The handle to the TCP socket.
[out] Items: A list of data items.
[out] NoItems: The number of data items in the list.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetNotification(SOCKET Skt, CAENRFIDNotify
**Items, int *NumberItems);
1.3.26. CAENRFID_GetPower
Name: CAENRFID_GetPower
Reader: A928EU, A948EU
Description: The function returns the value of the ERP power setting in the
reader
Parameters: [in] Handle: The handle that identifies the device.
[out] Power: The ERP power of the reader.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID GetPower
(
CAENRFIDHandle Handle
,
unsi
g
ned int
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 14
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
*Power);
1.3.27. CAENRFID_SetProtocol
Name: CAENRFID_SetProtocol.
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to change the tag protocol used by the
reader
Parameters: [in] Handle: The handle that identifies the device.
[in] Protocol: The tag protocol to be set in the reader.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetProtocol (CAENRFIDHandle Handle,
CAENRFIDProtocol Protocol);
1.3.28. CAENRFID_GetProtocol
Name: CAENRFID_GetProtocol
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to know what tag protocol is used by the
reader
Parameters: [in] Handle: The handle that identifies the device.
[out] Protocol: The tag protocol to be set in the reader.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetProtocol(CAENRFIDHandle Handle, int
*Protocol);
1.3.29. CAENRFID_GetReadPointStatus
Name: CAENRFID_GetReadPointStatus
Reader: A928EU, A948EU
Description: The function permits to check the status of a read point
Parameters: [in] Handle: The handle that identifies the device.
[in] ReadPoint: The name of the Read Point.
[out] Status: The status of the read point.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetReadPointStatus(CAENRFIDHandle Handle,
char *ReadPoint, CAENRFIDReadPointStatus *Status);
1.3.30. CAENRFID_GetSourceInChannel
Name: CAENRFID_GetSourceInChannel
Reader: A928EU, A948EU
Description: The function
p
ermits to check if a lo
g
ical source is associated to
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 15
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
a specified notification channel that is, the data read from the
source is sent to the channel.
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The name of the Logical Source.
[in] ChannelName: The name of the Channel.
[out] isPresent: A flag indicating if the source is associated to
the specified channel.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetSourceInChannel(CAENRFIDHandle Handle,
char *SourceName, char *ChannelName, short *isPresent);
1.3.31. CAENRFID_GetSourceInTrigger
Name: CAENRFID_GetSourceInTrigger
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to check if a logical source is associated to
a specified trigger.
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The name of the Logical Source.
[in] TriggerName: The name of the Trigger.
[out] isPresent: A flag indicating if the source is associated to
the specified trigger.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetSourceInTrigger(CAENRFIDHandle Handle,
char *SourceName, char *TriggerName, short *isPresent);
1.3.32. CAENRFID_GetTriggerInChannel
Name: CAENRFID_GetTriggerInChannel
Reader: A928EU, A948EU
Description: The function permits to check if a trigger is associated to a
specified notification channel.
Parameters: [in] Handle: The handle that identifies the device.
[in] TriggerName: The name of the Trigger.
[in] ChannelName: The name of the ChannelName.
[out] isPresent: A flag indicating if the trigger is associated to
the specified channel.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetTriggerInChannel(CAENRFIDHandle Handle,
char *TriggerName, char *ChannelName, short *isPresent);
1.3.33. CAENRFID_GetChannelInTrigger
Name: CAENRFID_GetChannelInTrigger
Reader: A928EU, A948EU
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 16
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
Description: The function permits to check if a channel is associated to a
specified notification trigger.
Parameters: [in] Handle: The handle that identifies the device.
[in] ChannelName: The name of the ChannelName.
[in] TriggerName: The name of the Trigger.
[out] isPresent: A flag indicating if the channel is associated to
the specified trigger.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetChannelInTrigger(CAENRFIDHandle Handle,
char *ChannelName, char *TriggerName, short *isPresent);
1.3.34. CAENRFID_GetReadPointInSource
Name: CAENRFID_GetReadPointInSource
Reader: A928EU, A948EU
Description: The function permits to check if a read point is associated to a
specified logical source that is, the read point is used within a
read cycle performed in the source.
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The name of the Logical Source.
[in] ReadPoint: The name of the Read Point.
[out] isPresent: A flag indicating if the read point is associated to
the specified source.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetReadPointInSource(CAENRFIDHandle Handle,
char *ReadPoint, char *SourceName, short *isPresent);
1.3.35. CAENRFID_SetNetwork
Name: CAENRFID_SetNetwork
Reader: A928EU, A948EU
Description: The function permits to configure the network address, the
netmask and the default gateway of the reader. The settings are
activated after a reboot of the reader.
Parameters: [in] Handle: The handle that identifies the device.
[in] IPAddress: The IP address to set in the form
XXX.XXX.XXX.XXX
[in] NetMask: The netmask to set in the form XXX.XXX.XXX.XXX
[in] Gateway: The Gateway to set in the form
XXX.XXX.XXX.XXX
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetNetwork(CAENRFIDHandle Handle, char
*IPAddress, char *NetMask, char *Gateway);
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 17
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.36. CAENRFID_SetDE_SB
Name: CAENRFID_SetDE_SB
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to enable the use of the data exchange
status bit in the ISO18000-6b anticollision algorithm.
Parameters: [in] Handle: The handle that identifies the device.
[in] Enable: Enable flag.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetDE_SB(CAENRFIDHandle Handle, unsigned int
Enable);
1.3.37. CAENRFID_GetDE_SB
Name: CAENRFID_GetDE_SB
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to know if the data exchange status bit is
used in the ISO18000-6b anticollision algorithm.
Parameters: [in] Handle: The handle that identifies the device.
[out] Status: The status flag.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetDE_SB(CAENRFIDHandle handle, unsigned
short *Status);
1.3.38. CAENRFID_ProgramID
Name: CAENRFID_ProgramID
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to program an EPC Class 1 Gen 1 tag
Parameters: [in] Handle: The handle that identifies the device.
[in] TagID: The EPC to program in the tag.
[in] Password: The kill password to program in the tag.
[in] Lock: Aflag indicating if the EPC has to be locked.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_ProgramID(CAENRFIDHandle Handle,
CAENRFIDTag *TagID, char Password, unsigned short Lock);
1.3.39. CAENRFID_KillTag
Name: CAENRFID_KillTag
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 18
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
Description: The function permits to kill an EPC Class 1 Gen 1 tag
Parameters: [in] Handle: The handle that identifies the device.
[in] TagID: The EPC of the tag.
[in] Password: The kill password for the tag.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_KillTag(CAENRFIDHandle Handle, CAENRFIDTag
*TagID, char Password);
1.3.40. CAENRFID_BlockWrite
Name: CAENRFID_BlockWrite
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: This function allows to write Length bytes to the memory of a
specific tag identified by the ID (regardless of its status) at the
address specified by Address. This function doesn't work with
semi-passive tags
Parameters: [in] Handle: The handle that identifies the device.
[in] ID: The tag ID.
[in] Address: The address of the memory to write.
[in] Length: The number of bytes to write.
[in] Data: The data to write in the tag's memory
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_BlockWrite(CAENRFIDHandle handle,
CAENRFIDTag *ID, int Address, int Length, void *Data);
1.3.41. CAENRFID_SetRS232
Name: CAENRFID_SetRS232
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to configure the serial communication of the
reader
Parameters: [in] Handle: The handle that identifies the device.
[in] baud: The baudrate value.
[in] datab: The databit value.
[in] stopb: The stopbit value.
[in] parity: The parity value.
[in] flowc: The flowcontrol value
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetRS232(CAENRFIDHandle handle, unsigned long
baud, unsigned long datab, unsigned long stopb,
CAENRFID_RS232_Parity parity,
CAENRFID_RS232_FlowControl flowc);
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 19
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.42. CAENRFID_SetDateTime
Name: CAENRFID_SetDateTime
Reader: A828EU, A828US, A829EU, A829US, A946EU, A949EU,
A928EU, A948EU
Description: The function permits to set the date e the time in the reader.
Parameters: [in] Handle: The handle that identifies the device.
[in] datetime: The current date ed time.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetDateTime(CAENRFIDHandle handle, char
*datetime);
CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
_CAENRFID_GroupSelUnsel(CAENRFIDHandle handle, char
*SourceName, CAENRFID_SelUnsel_Op code, int Address, int
BitMask, void *data, CAENRFIDTag *ID);
1.3.43. CAENRFID_GetIO
Name: CAENRFID_GetIO
Reader: A928EU, A948EU
Description: The function permits to read the IO register
Parameters: [in] Handle: The handle that identifies the device.
[out] IORegister: The current IO Register
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetIO(CAENRFIDHandle handle, unsigned int
*IORegister);
1.3.44. CAENRFID_SetIO
Name: CAENRFID_SetIO
Reader: A928EU, A948EU
Description: The function permits to write the IO register
Parameters: [in] Handle: The handle that identifies the device.
[in] IORegister: The IO Register value.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetIO(CAENRFIDHandle handle, unsigned int
IORegister);
1.3.45. CAENRFID_SetSourceConfiguration
Name: CAENRFID_SetSourceConfiguration
Reader: A928EU, A948EU
Description: The function permits to configure the Logical Source
Parameters: [in] Handle : The handle that identifies the device.
[in] SourceName: The Name of the Logical Source.
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 20
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
[in] parameter: The parameter of Logical Source to configure.
[in] value: The the value of the parameter.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetSourceConfiguration(CAENRFIDHandle handle,
char *SourceName, CAENRFID_SOURCE_Parameter
parameter, int value);
1.3.46. CAENRFID_GetSourceConfiguration
Name: CAENRFID_GetSourceConfiguration
Reader: A928EU, A948EU
Description: The function permits to get the value of the Logical Source
configuration
Parameters: [in] Handle: The handle that identifies the device.
[in] SourceName: The Name of the Logical Source.
[in] parameter: The parameter of Logical Source to configure.
[out] value: The the value of the parameter
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetSourceConfiguration(CAENRFIDHandle handle,
char *SourceName, CAENRFID_SOURCE_Parameter
parameter, int *pvalue);
1.3.47. CAENRFID_GetAllocatedTriggers
Name: CAENRFID_GetAllocatedTriggers
Reader: A928EU, A948EU
Description: The function permits to get the allocated triggers
Parameters: [in] Handle: The handle that identifies the device.
[out] TriggerNum: The number of triggers allocated.
[out] Triggers: The Triggers's names of allocated triggers
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetAllocatedTriggers(CAENRFIDHandle handle, int
*TriggerNum, char **Triggers);
1.3.48. CAENRFID_GetAllocatedChannels
Name: CAENRFID_GetAllocatedTriggers
Reader: A928EU, A948EU
Description: The function permits to get the allocated channels
Parameters: [in] Handle: The handle that identifies the device.
[out] ChannelNum: The number of channels allocated.
[out] Channels: The channels's names of allocated channels
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID GetAllocatedChannels
(
CAENRFIDHandle handle
,
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 21
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
int *ChannelNum, char **Channels);
1.3.49. CAENRFID_SetEventMode
Name: CAENRFID_SetEventMode
Reader: A928EU, A948EU
Description: The function permits to set the Event Generation Mode of the
reader
Parameters: [in] Handle: The handle that identifies the device.
[in] EMode: The Event Mode
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetEventMode(CAENRFIDHandle handle,
CAENRFID_EventMode EMode);
1.3.50. CAENRFID_GetEventMode
Name: CAENRFID_GetEventMode
Reader: A928EU, A948EU
Description: The function permits to get the Event Generation Mode of the
reader
Parameters: [in] Handle: The handle that identifies the device.
[out] EMode: The Event Mode of the reader
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetEventMode(CAENRFIDHandle handle,
CAENRFID_EventMode *EMode);
1.3.51. CAENRFID_FirmwareUpgrade
Name: CAENRFID_FirmwareUpgrade
Reader: A928EU, A948EU
Description: The function permits to upgrade the reader's firmware
Parameters: [in] Handle: The handle that identifies the device.
[in] type: The kind of upgrading
[in] arg: The argument for the upgrading in the form '[tftpserver
ip]:[filename]'
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_FirmwareUpgrade(CAENRFIDHandle handle,
CAENRFID_FWUpgradeType type, char *arg);
1.3.52. CAENRFID_Lock_C1G2
Name: CAENRFID_Lock_C1G2
Reader: A928EU, A948EU
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 22
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
Description: This function allows to lockthe memory of a specific tag identified
by the ID and by Payload
Parameters: [in] Handle : The handle that identifies the device.
[in] ID : The tag ID.
[in] Payload : The payload of the tag's memory.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Lock_C1G2(CAENRFIDHandle handle,
CAENRFIDTag *ID, int payload);
1.3.53. CAENRFID_KillTag_C1G2
Name: CAENRFID_KillTag_C1G2
Reader: A928EU, A948EU
Description: The function permits to kill an EPC Class 1 Gen 2 tag
Parameters: [in] Handle : The handle that identifies the device.
[in] TagID : The EPC of the tag.
[in] Password : The password for the tag.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_KillTag_C1G2(CAENRFIDHandle handle,
CAENRFIDTag *ID, int password);
1.3.54. CAENRFID_KillTag_C1G2
Name: CAENRFID_KillTag_C1G2
Reader: A928EU, A948EU
Description: The function permits to kill an EPC Class 1 Gen 2 tag
Parameters: [in] Handle : The handle that identifies the device.
[in] TagID : The EPC of the tag.
[in] Password : The password for the tag.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_KillTag_C1G2(CAENRFIDHandle handle,
CAENRFIDTag *ID, int password);
1.3.55. CAENRFID_ProgramID_EPC119
Name: CAENRFID_ProgramID_EPC119
Reader: A928EU, A948EU
Description: The function permits to program an EPC 119 tag
Parameters: [in] Handle: The handle that identifies the device.
[in] ID: The actual ID of the tag.
[in] NewID: The new ID for the specified tag.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_ProgramID_EPC119(CAENRFIDHandle handle,
CAENRFIDTag *ID, char *NewID );
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 23
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.56. CAENRFID_ProgramID_C1G2
Name: CAENRFID_ProgramID_C1G2
Reader: A928EU, A948EU
Description: The function permits to program an EPC Class 1 Gen 2 tag
Parameters: [in] Handle: The handle that identifies the device.
[in] ID: The EPC to program in the tag.
[in] nsi: The NSI value for the EPC C1G2.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_ProgramID_C1G2(CAENRFIDHandle handle,
CAENRFIDTag *ID, unsigned short nsi );
1.3.57. CAENRFID_Read_C1G2
Name: CAENRFID_Read_C1G2
Reader: A928EU, A948EU
Description: This function allows to read Length bytes from the bank memory,
specified by membank, of a specific tag identified by the ID
(regardless of its status) at the address specified by Address.
Parameters: [in] Handle : The handle that identifies the device.
[in] ID : The tag ID.
[in] membank : The memory Bank of EPC C1G2 Tag
[in] Address : The address of the memory to read.
[in] Length : The number of bytes to read.
[out] Data : The data read from the tag's memory.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Read_C1G2(CAENRFIDHandle handle,
CAENRFIDTag *ID, short membank, int Address, int Length, void
*Data);
1.3.58. CAENRFID_Write_C1G2
Name: CAENRFID_Write_C1G2
Reader: A928EU, A948EU
Description: This function allows to write Length bytes to the bank memory,
specified by membank, of a specific tag identified by the ID
(regardless of its status) at the address specified by Address.
Parameters: [in] Handle : The handle that identifies the device.
[in] ID : The tag ID.
[in] membank : The memory Bank of EPC C1G2 Tag
[in] Address : The address of the memory to write.
[in] Length : The number of bytes to write.
[in] Data : The data to write in the tag's memory.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_Write_C1G2(CAENRFIDHandle handle,
CAENRFIDTa
g
*ID
,
short membank
,
int Address
,
int Len
g
th
,
void
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 24
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
*Data);
1.3.59. CAENRFID_QueryTag_C1G2
Name: CAENRFID_QueryTag_C1G2
Reader: A928EU, A948EU
Description: The function permits to perform the Query command of C1G2
protocol
Parameters: [in] SourceName : The Name of the Logical Source.
[out] isPresent: A flag indicating if the tag answered at Query
command
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_QueryTag_C1G2(CAENRFIDHandle handle, char
*SourceName, short *isPresent);
1.3.60. CAENRFID_SetQ_C1G2
Name: CAENRFID_SetQ_C1G2
Reader: A928EU, A948EU
Description: The function permits to set the Q parameter of C1G2 protocol
Parameters: [in] Q : The value of Q.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_SetQ_C1G2(CAENRFIDHandle handle, int Q);
1.3.61. CAENRFID_GetQ_C1G2
Name: CAENRFID_GetQ_C1G2
Reader: A928EU, A948EU
Description: The function permits to get the Q parameter of C1G2 protocol
Parameters: [out] Q : The value of Q.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetQ_C1G2(CAENRFIDHandle handle, int *Q);
1.3.62. CAENRFID_GetReaderInfo
Name: CAENRFID_GetReaderInfo
Reader: A928EU, A948EU
Description: Permits to read the Model and the Serial number of the Reader
Parameters: [out] Model : Returns the model of the reader.
[out] SerialNum : Returns the Serial number of the reader.
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API CAENRFIDErrorCodes __stdcall
CAENRFID_GetReaderInfo(CAENRFIDHandle handle,char
*Model, char *SerialNum);
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 25
Document type: Title: Revision date: Revision:
User's Manual (MUT) RFID ANSI C Library 17/01/2007 2
1.3.63. CAENRFID_FreeTagsMemory
Name: CAENRFID_FreeTagsMemory
Reader: A928EU, A948EU
Description: The function permits to free the allocated by CAENRFIDInventory
Parameters: [in] Tags : Reference to CAENRFIDTag obtained from
CAENRFIDInventory
Returns: An error code about the execution of the function
Syntax: CAENRFIDlib_API void __stdcall
CAENRFID_FreeTagsMemory(CAENRFIDTag **Tags)
NPO: Filename: Number of pages: Page:
00117/03:RFLIB.MUTx/02 RFIDCLIB_REV2.DOC 26 26
