CASTLES TECHNOLOGY EZWAVE RFID Device User Manual EZProx Windows API Design Manual
CASTLES TECHNOLOGY CO., LTD. RFID Device EZProx Windows API Design Manual
Users Manual
EZWave Contactless Reader
User’s Manual
Version 1.0
September 2008
http://www.castech.com.tw
Doc.# Confidential Level:
Table of Contents
TABLE OF CONTENTS ................................................................................................................................................... 1
REVISION HISTORY ...................................................................................................................................................... 1
WARNING ......................................................................................................................................................................... 2
ABOUT THIS MANUAL .................................................................................................................................................. 2
1 INTRODUCTION ........................................................................................................................................................... 3
2 PACKING LIST ............................................................................................................................................................... 3
3 POWER ............................................................................................................................................................................ 4
4 INSTALLATION ............................................................................................................................................................. 4
FOOT STAND......................................................................................................................................................................4
SAM INSERTION.................................................................................................................................................................5
PLACEMENT NOTICE............................................................................................................................................................6
5 LED INDICATOR ........................................................................................................................................................... 6
FRONT SIDE........................................................................................................................................................................6
LED’S REPRESENTATION STATES..........................................................................................................................................7
6 CONTACTLESS CARD LANDING ZONE ...................................................................................................................
EZWAVE Contactless Reader User’s Manual V1.0
Revision History
Version Date Editor Description
V1.0 2008.09.16 Bill Created
Castles Technology Co., Ltd. All Rights Reserved.
1/7
EZWAVE Contactless Reader User’s Manual V1.0
Castles Technology Co., Ltd. All Rights Reserved.
2/7
WARNING
Information in this document is subject to change without prior notice.
No part of this publication may be reproduced, transmitted, stored in a retrieval system, nor
translated into any human or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual, or otherwise, without the prior written
permission of Castles Technology Co., Ltd.
All trademarks mentioned are proprietary of their respective owners.
FCC Compliance Statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
ABOUT THIS MANUAL
EZWAVE Contactless Reader User’s Manual V1.0
1. Introduction
The description of EZWave Contactless Reader.
1 LCD DISPLAY 6 LANDING ZONE
2 GREEN LED 7 CARD HOLDER
3 RED LED 8 SAM CARD COVER
4 ORANGE LED 9 SWITCH
5 RED LED
2. Packing List
EZWave *1
SDK *1
Castles Technology Co., Ltd. All Rights Reserved.
3/7
EZWAVE Contactless Reader User’s Manual V1.0
3. Power
There are two ways to supply the power to the reader, please choose one of
the follows:
By PS2 keyboard Port,
By USB Port,
4. Installation
Foot Stand
User can be open or close the foot stand like the picture.
Castles Technology Co., Ltd. All Rights Reserved.
4/7
EZWAVE Contactless Reader User’s Manual V1.0
SAM Insertion
Step 1.Unscrew SAM Cover Step 2.Open SAM Cover
Step 3.Insert SAM Card Step 4.Close SAM Cover
Castles Technology Co., Ltd. All Rights Reserved.
5/7
EZWAVE Contactless Reader User’s Manual V1.0
Placement Notice
X. METAL O. WOOD OR PLSTICS
5. LED indicator
FRONT SIDE
Castles Technology Co., Ltd. All Rights Reserved.
6/7
EZWAVE Contactless Reader User’s Manual V1.0
LED’s Representation States
The state of the LED indicators described as follows by user define
6. Contactless Card Landing Zone
The icon of Land Zone has printed on the center of working area, which
indicate that where is the correct location to approach user’s card
