VGA3000 2G User Manual HTML Version

User Manual

VEGA3000 EFT-POS

Book 2

User Manual

Confidential

Version1.0

Jan 2015

CASTLES TECHNOLOGY

Castles Technology Co., Ltd.

2F, No. 205, Sec. 3, Beixin Rd., XindianDistrict,

New Taipei City 23143, Taiwan R.O.C.

http://www.castech.com.tw

Revision History

Version

Date

Descriptions

1.0

May 27, 2014

Initial creation.

1.1

Jan 14, 2015

Add FCC Warning

Contents

1. Introduction .................................................................................................................. 5

1.1. Type of Terminal .................................................................................................. 5

2. Hardware Setup ............................................................................................................ 7

2.1. Parts of the Terminal ........................................................................................... 7

2.2. Inserting the Battery ........................................................................................... 10

2.3. Inserting the SAM Card ..................................................................................... 11

2.4. Inserting the Paper Roll ..................................................................................... 12

2.5. Inserting the GSM SIM Card .............................................................................. 13

2.6. Inserting the Memory card ................................................................................. 14

2.7. Power Supply Specifications .............................................................................. 15

2.8. Operating Ambient Temperature ........................................................................ 15

3. Basic Operation ......................................................................................................... 16

3.1. Program Manager .............................................................................................. 16

3.2. Download AP ..................................................................................................... 16

3.3. System Info........................................................................................................ 18

3.4. Memory Status .................................................................................................. 19

3.5. System Settings ................................................................................................. 20

3.6. Test Utility .......................................................................................................... 23

3.7. Factory Reset .................................................................................................... 26

3.8. Power Off .......................................................................................................... 27

3.9. Function Key Password Change ........................................................................ 28

3.10. Share Object Management ................................................................................ 29

3.11. CastlesTMS ....................................................................................................... 30

3.12. Font Mng ........................................................................................................... 31

3.13. Debug Tools ...................................................................................................... 32

3.14. ULD Key Hash ................................................................................................... 33

3.15. Hardware Detect ................................................................................................ 34

4. Secure File Loading ................................................................................................... 35

4.1. ULD Key System ............................................................................................... 35

4.1.1. ULD Manufacturer Key ........................................................................... 35

4.1.2. ULD User Key ........................................................................................ 37

4.1.3. Key Change ........................................................................................... 37

4.2. File Signing ........................................................................................................ 38

4.2.1. Signing Kernel Module ........................................................................... 38

4.2.2. Signing User Files .................................................................................. 40

4.3. File Loading ....................................................................................................... 44

4.3.1. Download by User Loader ...................................................................... 44

4.3.2. Download by Removable Media ............................................................. 47

4.4. Changing ULD User Key.................................................................................... 49

5. Font Management ...................................................................................................... 56

5.1. Loading New Font.............................................................................................. 56

5.2. Custom Font ...................................................................................................... 59

5.3. Using TrueType Font (TTF) ............................................................................... 67

6. Technical Notes ......................................................................................................... 69

6.1. Serial Cable PIN Assignment ............................................................................. 69

7. FCC Warning .............................................................................................................. 70

1. Introduction

This document provides a guideline on operating and configuringCastles VEGA3000

terminal.

The scope of this document includesetting up the terminal, basic operation, application

life cycle, and some advance features.

1.1. Type of Terminal

VEGA3000 terminal is portable type can be battery operated.

Portable type is designed as two pieces of hardware, handset and base unit.

Handset unit features major components, and also optional contactless reader,

WiFi, GRPS modem. Wired connection like power, modem, Ethernet, USB or

serial ports, are be located in base unit. There are additional power connection

and USB port on handset unit, allow the handset unit can be operated alone.

Handset Base

Front View Rear View Front View Rear View

Side View

To start up the terminal needs to press “Power Button” key after the adapter

connected.

2. Hardware Setup

2.1. Parts of the Terminal

Front

1. LCD Display (Color TFT)

2. Privacy Shields

3. Keyboard

4. Cancel Key

5. Clear Key

6. Enter Key

7. Magnetic Stripe Reader

8. Smart Card Reader

9. Contactless Card Landing

Zone

10. Paper Roll Handle

VEGA3000

Rear

11. RechargeableBattery

Cover

12. Battery Cover Lock

13. Base Connector

14. SAM Slots

15. Micro SD Card Slot

16. GSM SIM Card Slots

17. RTC Battery

18. Battery Connector

VEGA3000

Rechargeable

Battery

Side

19. Power Connector

20. USB Port

Base (Portable)

21. Base Connector

22. Base LED

23. Power Connector

24. Com port 3

25. Com port 2

26. Com port 1

27. Modem - Line Port

28. Ethernet Port

29. Micro USB Port

VEGA3000 Portable

2.2. Inserting the Battery

Step 1: Remove battery cover

Step 2: Insert battery into compartment, battery contact point must align with

batteryconnector.

Align

Step 2

Step 1

2.3. Inserting the SAM Card

Step 1: Remove battery cover / back cover

Step 2: Insert SAM card into desire slot.

SAM 1 & 2:

Gold contact at lower side of card and facing right.

SAM 3 & 4:

Gold contact at lower side of card and facing left.

VEGA3000 Portable

SAM1

SAM2

SAM3

SAM4

2.4. Inserting the Paper Roll

Step 1: Pulluppaper roll box handle.

Step 2: Gentle open paper roll cover.

Step 3: Insert paper roll as direction showed.

Paper specification

Width: 57mm

Outside diameter: 40mm

Step 2

Step 1

Step 3

2.5. Inserting the GSM SIM Card

Step 1: Remove battery cover / back cover

Step 2: Open SIM socket and insert GSM SIM card into desire slot.

SIM 1 & 2:

Gold contact at upper side of card and facing down.

SIM2

SIM1

VEGA3000 Portable

2.6. Inserting the Memory card

Step 1: Remove battery cover / back cover

Step 2: Insert Micro SD memory card.

Micro SD :

Gold contact at lower side of card and facing right.

Micro SD

VEGA3000 Portable

2.7. Power Supply Specifications

I/P: 9Vdc, 4A

2.8. Operating Ambient Temperature

Range : 0° ~ 50°

3. Basic Operation

3.1. Program Manager

Upon power on, terminal will enter Program Manager if not default application

selected. All user applications are list in Program Manager. User may select an

application and run the application or view the application info, delete the

application or set to default run upon power on. User may enter System Menu to

configure terminal settings.

Program Manager

 Press[0] button to enter System Menu.

 Press [1] button to toggle default application selection.

 Press [2] button to delete application.

 Press [3] button to view application info.

 Press [OK] button to run application.

 Press [Power] or [．] buttonas up and down bottonto select application.

System Menu

Page 1 Page 2

 Press [．] button to page 2.

3.2. Download AP

Program Manager

-----------01/02

1.App1

2.App2

0:Download

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

System Menu

1.Castles TMS

2.FontMng

3.Debug Tools

4.ULD KEY HASH

5.HW Detect

Up:Prev Page

Download user application or kernel modules firmware.

System Menu

 Press [1] button to enter Download AP menu.

Download AP Menu

Select download source:

 Press [1] button to select source as RS232 or USB connection and enter ULD

download mode.

 Press [2] button to select source as USB disk.

 Press [3] button to select source as SD card.

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

Download EX

1.RS232 or USB

2.USB Disk

3.SD Card

Select DW Source

3.3. System Info

View kernel module firmware information.

System Menu

 Press [2] button to enter System Info menu.

System Info Menu

Page 1 Page 2 Page 3

 Press [．] button to next page.

Page 4 Page 5 Page 6

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

SYSTEM INFO

---Kernel Ver---

BIOS : VR0016

SULD : VRF014

LINUXKNL: VR0019

ROOTFS : VR0010

SYSTEM INFO

--- KOVer ---

SECURITY: VR0025

KMS : VR0024

DRV: VR0039

USB: N/A

SAM: VR0028

CL : VR0018

SC : VR0011

SYSTEM INFO

--- SOVer---

UART : VR0014

USBH : VR0011

MODEM : VR0014

ETHERNET: VR0029

FONT : VR0025

LCD : VR0034

PRT: VR0020

RTC : VR0013

ULDPM : VR0022

PPP MODEM: VR0026

KMS: VR0025

FS : VR0015

GSM : VR0022

BARCODE : VR0013

SYSTEM INFO

--- SO Ver2 ---

TMS : VR0014

TLS : VR0011

CLVW : VR0019

CTOSAPI : VR0033

SYSTEM INFO

--- HWMVer ---

CRDL/ETHE:ONCHIP

CLM-MP : N/A

--- APVer ---

ULDPM : VR0028

SYSTEM INFO

HUSB ID:00000000

CUSBID:N/A

--Factory S/N---

FFFFFFFFFFFFFFFF

Page 7

3.4. Memory Status

View terminal flash memory and RAM information.

System Menu

 Press [3] button to enter Memory Status menu.

Memory Status Menu

SYSTEM INFO

-EXT SO Ver P.1 -

CRDLMDL : VR0100

CACLENTRY: VR0100

CAMPP: VR0300

CAVPM : VR0012

CAEMVL2 : VR0013

CAEMVL2AP: VR0004

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

MEMORY STATUS

--FLASH Memory--

Total: 31616KB

Used : 22640KB

--SDRAM Memory--

Total: 31872KB

Used : 10908KB

3.5. System Settings

View or change terminal system settings.

Setting

Descriptions

Key Sound

Enable (Y) or disable (N) the beep sound when

pressing any key.

Exec DFLT AP

Enable (Y) or disable (N) execution of default

selected application.

USB CDC Mode

Enable (Y) or disable (N) USB CDC mode.

FunKey PWD

Enable (Y) or disable (N) password protection to

access function key (0 ~ 3) in Program Manager.

PMEnter PWD

Enable (Y) or disable (N) password protection to

enter Program Manager.

SET USB Host

Enable (Y) or disable (N) USB host mode.

Base USB CDC

Enable (Y) or disable (N) USB CDC mode in base

unit. [Portable model only]

List SHR Lib

Enable (Y) or disable (N) to list all shared libraries

in Program Manager.

Key MNG Mode

<TBC>

Bat Threshld

Battery charging threshold value. [Portable model

only]

Null Cradle

Enable (Y) if base is null cradle. [Portable model

only]

Debug Mode

Enable (Y) or disable (N) console debug mode.

Debug Port

Serial port for console debug.

Mobil AutoON

Enable (Y) or disable (N) to auto turn on GSM

module after start up the terminal.

Bklit Auto Off

Enable (Y) or disable (N) Auto OffLCDBacklight

Bklit Off Time

Thresholdof Auto Off LCD Backlight

PWR KEY OFF

Enable (Y) or disable (N) Power key rebooting

GDB Mode

Enable (Y) or disable (N) GDB mode.

GDB Timeout

GDB connection timeout.

GDB Channel

GDB connection channel.

ETHER IP/PORT

GDB Ethernet connection setting.

RTC Time Zone

Set Time Zone of Real Time Clock.

NTP Enable

Enable (Y) or disable (N) Network Time Protocol.

NTP Update Freq

Frequency of Network Time Protocol updating.

System Menu

 Press [4] button to enter System Settings menu.

System Settings Menu

Page 1



 Press [Power] or [．]button to select setting.

 Press [OK] button to change the setting value.

 Press [] button to toggle Y  N  Y.

 Press [2] button to next page.

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

SYS SETTINGS

Key Sound : Y

Exec DFLT AP: Y

-AP Name

USB CDC Mode: Y

FunKeyPWD :N

PMEnterPWD:N

SET USB Host: N

Base USB CDC: X

List SHR Lib: N

Key MNG Mode: 0

Bat Threshld: X

Null Cradle : X

Debug Mode :N

Debug Port :X

2: Next Page

Page 2

 Press [Power] or [．]button to select setting.

 Press [OK] button to change the setting value.

 Press [] button to toggle Y  N  Y.

 Press [1] button to previous page.

 Press [2] button to next page.

SYS SETTINGS

Mobil AutoON: N

Bklit Auto Off:X

Bklit Off Time: N

PWR KEY OFF:N

GDB Mode:X

GDB Timeout: X

ETHER IP/PORT

RTC Time Zone :GMT

NTP Enable:N

NTP Update Freq:X

1:PrevPage

3.6. Test Utility

Perform terminal hardware components diagnostic.

System Menu

 Press [5] button to enter Test Utility menu.

Test Utility Menu

Page 1

 Press [1] and [OK] button to diagnose LCD.

 Press [2] and [OK] button to diagnose keyboard.

 Press [3] and [OK] button to diagnose flash memory.

 Press [4] and [OK] button to diagnose smart card module.

 Press [5] and [OK] button to diagnose backlight.

 Press [6] and [OK] button to diagnose magnetic stripe reader.

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

Main Menu 0014

1:LCD

2:Key Board

3:FLASH

4:Smart Card

5:Backlight

6:MSR

7:LED

8:RTC

9:Printer

10:FONT

11:CL_Transparent

12:CL Card Test

13:SD Card Test

14:Wi-Fi Test

 1/2

 Press [7] and [OK] button to diagnose LED.

 Press [8] and [OK] button to diagnose real time clock.

 Press [9] and [OK] button to diagnose printer.

 Press [1], [0]and [OK] button to view font.

 Press [1], [1] and [OK] button to diagnose contactless reader in transparent

mode.

 Press [1], [2]and [OK] button to diagnose contactless card.

 Press [1], [3] and [OK] button to diagnose SD memory card.

 Press [1], [4] and [OK] button to test Wi-Fi.

 Press [．] button to next page.

Note: Default password for changing RTC is 8418.

Page 2

 Press [1], [5]and [OK]button to enter Power Saving Test Menu.

 Press [1], [6] and [OK] button to enter Communication Test Menu.

 Press [Power] button to previous page.

 Press [X] button to exit.

Power Saving Test Menu

 Press [1] button to Standby Mode.

 Press [2] button to Sleep Mode.

Main Menu 0014

15:Power Saving

16:Comm Menu

 2/2

Power Saving Test

1. Standby Mode

2. Sleep Mode

Communication Test Menu

 Press [1] button to diagnose Com 1.

 Press [2] button to diagnose Com 2.

 Press [3] button to diagnose Com 3.

 Press [4] button to diagnose Ethernet module.

 Press [5] button to diagnose USB.

 Press [6] button to diagnose modem.

 Press [7] button to diagnose GPRS.

 Press [8] button to diagnose all, from item 1 to 7.

Communicate Test

1. COM1 2. Com2

3. Com3

4. Ethernet Test

5. USB Test

6. Modem Test

7. GPRS Test

8. All Test

3.7. Factory Reset

Perform factory reset, all user application, fonts and data will be deleted.

System Menu

 Press [6] button to enter Factory Reset menu.

Factory Reset Menu

 Press [OK] button to perform factory reset.

 Enter factory reset password.Default password: 8418

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

Factory Reset

OK to reset ?

Factory Reset

Password :

****

3.8. Power Off

Power off terminal.

System Menu

 Press [7] button to power off terminal.

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

3.9. Function Key Password Change

Change function key access password.

System Menu

 Press [8] button to enter FunKey Password menu.

FunKey Password Menu

 Enter current password. (Default password is "0000")

 Enter new password.

 Enter new password again to confirm.

FunKey Password

Enter Password:

****

FunKey Password

New Password:

****

Confirm Password

****

FunKey Password

New Password:

****

Confirm Password

****

PWD Changed OK

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

3.10. Share Object Management

View share object in terminal.

System Menu

 Press [9] button to enter Share Object Management menu.

Share Object Management Menu

 Press [1] button to view shared library.

 Press [2] button to view shared file.

Share objMng

1.Share LIB

2.Share File

System Menu

1.Download AP

2.System Info

3.Memory Status

4.Sys Settings

5.Test Utility

6.Factory Reset

7.Power Off

8.FK PWD Change

9.Share objMng

Down: Next Page

3.11. CastlesTMS

Connect to TMS (Terminal Management Software) server, set or delete TMS

configuration.

System Menu (Page 2)

 Press [1] button to enter Castles TMS menu.

Castles TMS Menu

 Press [1] button to connect to TMS server.

 Press [2] button to set TMS configuration.

 Press [3] button to delete TMS configuration.

System Menu

1.Castles TMS

2.Font Mng

3.Debug Tools

4.ULD KEY HASH

5.HW Detect

Up:Prev Page

CASTLES TMS

1.Connect Server

2.SetConfig

3.DelConfig

3.12. Font Mng

View Font Management.

System Menu (Page 2)

 Press [2] button to view Font Management.

FontManagment

 Press [1] button to view FNT Font list.

 Press [2] button to view TTF Font list.

Font Mng

1.FNT File

2.TTF File

System Menu

1.Castles TMS

2.Font Mng

3.Debug Tools

4.ULD KEY HASH

5.HW Detect

Up:Prev Page

3.13. Debug Tools

Perform the Debug Tools.

System Menu (Page 2)

 Press [3] go to the Debug Tools Menu.

Debug Tools

 Press [1] go get the Core Dump error from terminal.

 Press [2] go to the Debug Log Menu.

Debug Log

 Press [1] get the Debug Log from the memory of terminal to SD card.

 Press [2] clean all the Debug Log from the SD card.

System Menu

1.Castles TMS

2.Font Mng

3.Debug Tools

4.ULD KEY HASH

5.HW Detect

Up:Prev Page

Debug Tools

1.CoreDump

2.Debug Log

Debug Log

1.Upload

2.Clean All

3.14. ULD Key Hash

View ULD user keyset hash value.

System Menu (Page 2)

 Press [4] button to view hash value.

System Menu

1.Castles TMS

2.Font Mng

3.Debug Tools

4.ULD KEY HASH

5.HW Detect

Up:Prev Page

USER ENC KEY

9572BC621C1D5406

0856D00BCC207000

D3320077

USER SIGN KEY

A927768EA7DD7B9E

7E3F395C10726B6F

43B35C5A

3.15. Hardware Detect

View the hardware type of the termianl.

System Menu (Page 2)

 Press [5] button to view the hardware type of the termianl.

System Menu

1.Castles TMS

2.Font Mng

3.Debug Tools

4.ULD KEY HASH

5.HW Detect

Up:Prev Page

HW TYPE

Qriginal

HW-TYPE :MEGC

New

HW-TYPE :MEGC

Please Any Key.

4. Secure File Loading

Castles implemented an interface in terminal named User Loader(ULD) to provide secure file

loading to system memory. Loading of user application, kernel firmware, font and others

must use User Loader.

The loading process is secure by signing the files using ULD Key System.

4.1. ULD Key System

The ULD Key System uses two key sets for securely managing the kernel

updating and application downloading. Each key set contains two RSA key pairs.

One is used for key encryption and the other is used for signature. These two key

sets are specified as below:

ULD Manufacturer Key Set

 ULD Manufacturer Key Encryption Key (RSA)

 ULD Manufacturer Signature Key (RSA)

ULD User Key Set

 ULD User Key Encryption Key (RSA)

 ULD User Signature Key (RSA)

For VEGA3000, the RSA key length is 2048bits.

4.1.1. ULD Manufacturer Key

The system consists of several kernel modules. These kernel modules

are provided by the Manufacturer, and released in CAP format file with

encryption and signing via ULD Manufacturer Keys.

The ULD Manufacturer keys are managed and maintained by the

manufacturer. The manufacturer uses these keys to generate kernel

CAP files for updating the system. However, the system is not permited

to be updated with these kernel CAP files directly generated by the

manufacturer. This is because only the user can have the privilege to

decide whether the system is to be updated. Therefore, before system

updating, the kernel CAP files must be “signed” via ULD User Key to get

the user permission. For simple expression, we call the kernel CAP files

generated by the manufacturer as “unsigned kernel CAP(s)” and call the

kernel CAP files “signed” by the user later as “signed kenel CAP(s)”.

Notes:

1. Tthe kernel modules are encrypted by a random-generated 3DES

key, which is retrieved from the Key Encryption Block of the CAP by

ULD Manufacturer Key Encryption Key, not directly encrypted by ULD

RSA Key.

2. The “sign” action via ULD User Keys actually is done by” the second

encryption”. “The second encryption” is done by using the random-

generated 3DES key, which is encrypted by ULD User Key Encryption

Key, to perform Triple DES encryption again on the cipher data segment

of the kernel CAP files. This ensures that the system cannot retrieve the

correct data from the kernel CAPs without the user permission.

CAP Generator

Kernel Module

ULD Manufacturer

Keys

Unsigned Kernel

CAPs

Unsigned Kernel

CAPs CAP Signing Tool Signed Kernel CAPs

ULD User Keys

4.1.2. ULD User Key

ULD User Key are used to encrypt and sign the user/shared

applications. In addition, they are as goalkeepers to prevent the system

updating without user permission. This is done by the kernel CAPs

which are encrypted and signed by the manufacturer having to perform

the “signed’ action via ULD User Keys.

Notes: Applications are encrypted by a random-generated 3DES key,

which is retrieved from the Key Encryption Block of the CAP by ULD

User Key Encryption Key, not directly encrypted by ULD RSA Key.

Application Application CAPs

ULD User Keys

CAP Generator

4.1.3. Key Change

The ULD RSA Keys are able to be changed. The system uses a special

CAP file, KEY CAP, for the manufacturer and user to change their own

keys. The KEY CAP contains a new set of ULD keys (Key Encryption

Key and Signature Key). These new keys are encrypted and signed via

the original keys. In other words, if the user would like to change the

ULD User Keys, they have to use their original ULD User Keys with the

new ULD User Keys to generate a KEY CAP.

Key CAP Generator

Original ULD

Manufacturer/User

Keys

New ULD

Manufacturer/User

Keys

User KEY CAP

4.2. File Signing

4.2.1. Signing Kernel Module

Castles will release new version of kernel module in “unsigned” form.

This files required to sign with ULD User Key before it can load to

terminal.

Castles Technology provideds a tool named “CAP Signing Tool” to

perform this task.

The CAP Signing Tool is located at:

C:\Program Files\Castles\VEGA3000\tools\Signing Tool

 Run CAP Signing Tool

(VEGA3000)

 Insert Key Card and select smart card reader

 Enter Key Card PIN

 CAP Signing Tool is ready, press “Select MCI File” button to browse

the file.

 Output file will be located in “signed” folder.

4.2.2. Signing User Files

Following files are required to sign before load to terminal. This is to

ensure the application data and codes confidential and integrity. The

output fille will be “CAP” file which is file format defined by Castles.

 User application

 User application data files

 User application library

 Font file

 Share library

 Share files

 System setting

 Key CAP (Manufacturer ULD Key Set)

Castles Technology provided a tool named “CAP Generator” to perform

this task.

The CAP Generator is located at:

C:\Program Files\Castles\VEGA3000\tools\CAPG (KeyCard)

 Run CAP Generator

 Insert Key Card and select smart card reader

 Enter Key Card PIN

 CAP Generator is ready, select the correct Type from the list.

 Press “Step 1: Select AP Executable File” to select file to sign. This

is valid for all the files to sign.

 Enter file details and press “Step 2: Sign Application” to sign the file.

This is valid for all the files to sign.

 The output file will be in a set. A “mci” file with one or more “CAP”

files.CAP file contents the signed file binaries, where MCI file

contents the list of CAP files.

Note: If user would like to load multiple set of signed file, create a new

file with extension of “mmci”. Then put the mmci file contents with the list

of mci file.

App.CAP

App.mci

MultiApp.mmci

4.3. File Loading

There are several ways of loading file to VEGA3000terminal.

 Download by User Loader

 Download by removable media

 Download by user application

 Download by Castles TMS

User Loader is a tool provided by Castles Technology. It’s the formal way to

download file to terminal.

User may implement their own ways of updating application or files using CTOS

API provided, CTOS_UpdateFromMMCI().

Castles TMS (CTMS or CASTLES Terminal Management System) is provided by

Castles Technology. It’s use to perform remote download via Ethernet,

GPRS/UMTS or modem.

4.3.1. Download by User Loader

The User Loader works for VEGA3000.

The Loader is located at:

C:\Program Files\Castles\VEGA3000\tools\Loader

 Run User Loader

 Select COM port

 Browse and select mci file or mmci file

 Setup terminal to enter download mode

 Press [0] button in Program Manager (PM)

 Press [1] button to select “1. Download AP“

 Press [1] button again to select download via RS232 or USB

 Press “Download” button to start.

Note: To download using USB cable, terminal must enable CDC mode.

Set USB CDC Mode to Y.

SYS SETTINGS

Key Sound : Y

Exec DFLT AP: Y

-AP Name

USB CDC Mode: Y

FunKeyPWD : N

PMEnterPWD : N

SET USB Host: N

Base USB CDC: X

List SHR Lib: N

Key MNG Mode: 0

Bat Threshld: X

Null Cradle : X

Debug Mode : N

Debug Port : X

2: Next Page

4.3.2. Download by Removable Media

The file download process can be achieved without PC by using

removable media, USB flash drive or MicroSD memory card. We

recommend don’t put unwantedfile to removable media, as it will

increase the time during detection.

 Create a folder name “vxupdate” under root directory.

 Place the mci file and cap file to “vxupdate” folder.

Note: If user would like to load multiple application, create a new file

with extension of “mmci”. Then put the mmci file contents with the

list of mci file.

root

vxupdate

root

vxupdate

App.CAP

App.mci

MultiApp.mmci

 Insert removable media to terminal, and select the removable media

type in “Download AP” menu.

Download AP Menu

o Press [2] button to select USB flash drive.

o Press [3] button to select MicroSD card.

 Finally, terminal will process the file “vxupdate” folder.

Download EX

1.RS232 or USB

2.USB Disk

3.SD Card

Select DW Source

4.4. Changing ULD User Key

User may change their ULD User Key Set stored in Key Card. Castles

Technology provided a tool named “Secure Key Generator” to perform this task.

 Run Secure Key Generator

 Insert Key Card and select smart card reader

 Enter Key Card PIN, default PIN is “1234”.

 To change Key Card PIN, press “Update PIN” button. If not, please skip this

steps.

 Enter new PIN, enter new PIN again to confirm, then press [Enter] button

to change PIN in Key Card.

 To view current key set hash value, goto “Option” and select key.

 To generate new user key set

 Please generate the RSA key by yourself,thelength of the RSA key set

should be 2048 (bits).

 Copy RSA key components to RSA Key for Kenc in Secure Key

Generator.

 Generate second RSA key set for Signature.

 Click [Get Hash] button to calculate the hash value for key sets.

 Please copy down all the values into a text file and keep in a safe place.

You will need this if you need to create duplicate Key Card.

 To generate the key CAP for the newly generated user key set, press [Make

Key CAP File] button.

 The output file will be located in the Secure Key Generator folder.

 To update the newly generated key set to Key Card, press [Save to Card]

button to write the key set to Key Card.

SecureKeyGenerator

key.mci

key.cap

5. Font Management

5.1. Loading New Font

 Run FontManager.exe

Located at C:\Program Files\Castles\Font Manager

 Select font to download

 Press [Setting] button to configure terminal type.

 Select VEGA5000, press [Save] button to save and return font manager.

 Press [Generate] to create the font file.

 Output file “Font.FNT” will be located at sub-directory named “Font” in “Font

Manager” folder.

 Sign the file using CAP Generator, the type must set to “11 – Linux Font”.

 Lastly, download the signed file (CAP file) to terminal using Loader.

Font Manager

Font

Font.FNT

5.2. Custom Font

User may create font they preferred for displaying or printing on terminal.

There are two zone defined:

Zone 0x00 ~ 0x7F – ASCII characters, you may replace with the font type

preferred or your own language character set.

Zone 0x80 ~ 0xFF – Free to use, you may use for symbols.

Following steps demonstrate how to create a 12x24 font.

 Run GLCD Font Creator

 Select [File]  [New Font]  [Import An Existing System Font]

 Select the font needed, simply choose a font size. The final value of font size

should be determine by the minimum pixel width. You may need to repeat this

steps few times to find the best fit font size.

 Set the import range from 0 to 127.

 Check the minimum pixel width and height.

 If the pixel width of the font size is larger than expected, then you have to

repeat the previous steps to import font with smaller size.

 Use the following buttons to adjust the font size to match with expected font

size.

Add row on

top

Add row

on bottom

Remove

row on top

Remove row

on bottom

Add column

on left

Add

columnonrigh

Removecolum

nonleft

Removecolumn

onright

 After adjust font size, select [File]  [Export for MicroElektronika].

 Select output format as [mikroC].

 Remove comment “// Code for char “ from offset 0x00 to 0x1F. Remove

empty line if found. Then click [Save] button to save to file.

 Run Font Manager Tool.

 Click [Setting] button

Remove

 Enter the file name, font id, and select the size.

 Click [Create] button, and select the C file previously created using GLCD

Font Generator.

 Select [Font Manager] tab and tick the newly createdfont, and press

[Generate] button to export to FNT file.

 Use CAP Generator to conver the FNT file to CAP.

Set type to [11 – Linux Font], press [Step 1] button select the FNT file. Then

press [Step 2] to generate CAP file.

 Download the font CAP file to terminal.

 In terminal application, add following code to display message using the

newly created font.

CTOS_LanguageConfig(0xA000,d_FONT_12x24,0,d_FALSE);

CTOS_LanguageLCDSelectASCII(0xA000);

CTOS_LCDTPrintXY(1, 1, "ABCDEFGH");

Or print message using the newly created font.

CTOS_LanguagePrinterSelectASCII(0xA000);

CTOS_PrinterPutString("ABCDEFGH");

5.3. Using TrueType Font (TTF)

TrueType Font (TTF) is only supported in VEGA5000S terminal.You may

download the TrueType font preferred to terminal for displaying or printing.

Following steps demonstrate how to use “Cooper Black” TrueType font.

 Copy the TTF file needed to a empty folder.

 Use CAP Generator to conver the TTF file to CAP.

Set type to [11 – Linux Font], press [Step 1] button select the TTF file.

Then press [Step 2] to generate CAP file.

 Download the font CAP file to terminal.

TTF

COOPBL.TTF

 In terminal application, add following code to display message using the

newly added font.

CTOS_LCDTTFSelect("COOPBL.TTF", 0);

CTOS_LCDFontSelectMode(d_FONT_TTF_MODE);

CTOS_LCDTSelectFontSize(0x203C); // 32x60

CTOS_LCDTClearDisplay();

CTOS_LCDTPrintXY(1, 1, "Hello World");

Or print message using the newly added font.

CTOS_PrinterTTFSelect("COOPBL.TTF", 0);

CTOS_PrinterFontSelectMode(d_FONT_TTF_MODE);

CTOS_LanguagePrinterFontSize(0x203C, 0, 0); // 32x60

CTOS_PrinterPutString("Hello World");

6. Technical Notes

6.1. Serial Cable PIN Assignment

RJ12 6P6C

Male Plug

RS232

Female

1 ○

2 ○

3 ○

4 ○

5 ○

6 ○

○ 1

○ 2

○ 3

○ 4

○ 5

○ 6

○ 7

○ 8

○ 9

VCC

TXD

RTS

RXD

CTS

GND

VCC

RXD

TXD

GND

RTS

CTS

7. FCC Warning

Federal Communication Commission interference statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures: -

Reorient or relocate the receiving antenna. -Increase the separation between the equipment

and receiver. -Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

FCC Caution

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) this device may not cause harmful interference and

(2) this device must accept any interference received, including interference that may cause

undesired operation

RF Exposure Warning

The equipment complies with RF exposure limits set forth for an uncontrolled environment.

The antenna(s) used for this transmitter must not be co-located or operating in conjunction

with any other antenna or transmitter.

You are cautioned that changes or modifications not expressly approved by the party

responsible for compliance could void your authority to operate the equipment.

This equipment should be installed and operated with a minimum distance of 20 centimeters

between the radiator and your body.

~ END ~

CASTLES TECHNOLOGY VGA3000-2G EFTPOS User Manual VEGA5000 Book 2

CASTLES TECHNOLOGY CO., LTD. EFTPOS VEGA5000 Book 2

User Manual

Navigation menu

Namespaces

Views

Navigation
