CE LINK TWST02 Bihaural Wireless bluetooth headset User Manual TWS T02

CE LINK LIMITED Bihaural Wireless bluetooth headset TWS T02

User_Manual

Using instructions
Using
instructions
Charge line diagram
1Product Description
Using instructions
TWS-T02
2.Parts list 4.Wireless Earbuds Parameters
5.Headphone wear and wireless
earbuds connection
1.Wear Earbuds
3.Attention
● Please charge the headphone first, then wear the headphone
according to the instructions.
● Do not hit the host seriously.
● Do not touch thinner chemicals such as benzene.
Do not disassemble, repair or modify it by yourself.
● Do not listen at a large volume for a long time to avoid adverse
effects on your hearing.
● Do not expose to the sun for a long time.
Do not leave it in water or in a damp place for a long time.
Wireless earbuds version:TWS-T02 wireless earbuds 4.2,
support automatic boot, automatic connection,With English
voice prompts, the device name is TWS-T02.
Communication distance: 10m
Waterproof Grade: IPX4
Channel model: Two-channel stereo models
Battery type: Lithium Ion batter
Headset Battery: 3.7v,60mahy
Charging box battery: 3.7V, 800mah, can charge the
headphones 5 times.
Frequency response: 20hz-20khz
Play time: about 3h
Talk time: about 3h
Main material: Plastic
(1)Remove the earphones from the charging box and wear
the left and right ears according to the “L” and “R” on the
headphones.
(2)Ear caps are divided into large, medium and small types,
according to the size of individual ears to choose to change
the ear caps until feeling comfortable to wear.
(3)Put the ears in the ear profile, so that the sound is more
effective, more stable, more comfortable.
2.Wireless earbuds connection
(1)Manual boot: press the multi-function button on the left and
right headphones for 2 seconds, you can boot up.
Automatic boot: Remove the left and right headphones from
the charging box, it is already turned on.
righta.power on b.Connected,right channel
c.please pair to your device (on masterearbud)
lefta.power on b.Connected,left channel
FCC warning
The FCC ID number of this product is: A4X-TWST02
This device complies with Part 15 of the FCC Rules
(1) This device may not cause harmful interference
(2) This device must accept any interference
received,including interference that may cause
undesired operation.
(2)Turn on wireless earbuds on your mobile device
Click "Settings" → open "wireless earbuds" → turn on
"wireless earbuds" → search for devices
→ Click on “TWS-T02” to connect (while hearing the voice
prompt: “Pairing Successful”)Just fine.
(3)If you want to pair with another wireless earbuds device.
a.Turn on wireless earbuds , click on the name of the paired
device, and click cancel pairing, while shutting down the existing
equipment;
b. Click on "Search for devices", find the name of the device you
want to connect to, and click Connect.
6. Music Play
1. After the wireless earbuds is connected successful ly ,
turn on music play equipment;
2. Click any multi-function button on the headphones to start
playing music;
3. Click any multi-function button on the headset again to
stop playing.
Status Indicator
Left ear brace Right ear brace
Multifunction button(right)
Multifunction button(left)
Ear cap Ear cap
Charging Storage shell
Left earphone
charging indicator
Battery charging
indicator
Right earphone
charging indicator
7.Voice Command
1.Double-click the multifunction button on either side of
the hedphones.
2. The Siri helper and Android Google helper of the Iphone
will be activated.
3. You can voice to ask any questions or requests.
8. Answer the call
1. When you receive an incoming call, the voice will report the
mobile number of the call,
click on the multi-function button on either side to connect to
the phone, but only the main earphone
can hear the sound.
2. Click the multi-function button again to hang up the phone.
3. When you receive a call alert, press and hold any
multi-function button for 1s and you can reject the call.
9. If you change the right earphone to the main
earphone,the steps are as follows:
1. After removing the left and right earphones from the charging
box, at the same time,press the multi-function button to force the
shutdown;
2. Press and hold the left and right headphone multi-function
buttons at the same time until the status indicator lights flashing
read and blue lights.
3. Double-click the left multi-function button to set the left
earphone as the main body
(The status indicator will continue to display red and blue flashing,
and the right headset status indicator will be displayed.Slow
flashing blue light. );
4. Wireless earbuds connection method can be connected
according to 5 (2).
Headphones
Headphones full of electricity can be played about 3h.
1. When the power is low, the voice will
Remind "Battery low";
2. Put the left and right headphones into the charging box, close
Lid, you can charge the headset;
3. When left and right headphones are full of electricity,
The headset is automatically connected when it is removed.
2. wireless earbuds headphones always disconnected after connecting
with wireless earbuds device.
(1 )Power is insufficient, please charge the wireless earbuds headphones
as soon as possible;
(2 )The distance between the wireless earbuds device and the wireless
earbuds headphones
exceeds the wireless earbuds reception distance.
3.Do you need to re-search to connect to wireless earbuds every time
you use it?
No, as long as you have connected the TWS-T02 wireless earbuds
headphones once, when you take it from the charging box, wireless
earbuds will connect to your wireless earbuds device automatically.
4. When I use the wireless earbuds headphones to make a call, only the
right earphone can hear the sound, If I want to change to the left ear, can
I hear the call?
Because only the main earphone can connect to the phone when answering
the call, you can only heard the voice from one side of the headphones.
If you want to set the left earphone as the main earphone , please follow
the instructions in section 9 to changes the setting operation of main earphone.
5. Do I have to turn it on manually before and after use,
how about shut down?
No, open the lid of the charging box, and take out the earphone ,it will
automatically turn on. When you put the earphones back inside the charging
box, the earphones are automatically turned off and charged.again
When you remove the box, Bluetooth automatically connects to your
Bluetooth device.
6. If the headphones are removed and not used for a long time, whether
the headphones will wait for the powert o run out and then shut down?
No, the headphones will automatically shut down after 15 minutes
without using it.
11. Troubleshooting problems
1. The phone cannot search for wireless earbuds.
(1)Check if the left earphone is flashing slowly (already paired with the host
automatically), and the right earphone (host) red and blue lights flash
alternately.wireless earbuds search mode
(2) If wireless earbuds is still not connected to the headphone, please
put the left and right headphones into the charging box.After that, try
again and the wireless earbuds connected device will restart at the same time;
When charging, the status
indicator light of the right
earphone is red,lights went
out when the electricity
was filled.
When charging, the status
indicator light of the left
earphone is red,lights went
out when the electricity
was filled.
10.Charging
charging box
The fully charged charging box can clclic charge headphones
for 5 times .
1. Insert the attached Micro USB cable included in the box
into the Micro USB port of charging box .
2. Plug the other end
of the Micro USB cable.
Power can be charged.
When charging,
the status indicator light is red,
The lights went out when the
electricity was filled.
Data cable diagram
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
