User Manual
User Manual
2
Table of Contents
Product Features .............................................................. 3
Using Touchpad ................................................................ 3
Product Mode ................................................................... 4
Charging the Device ......................................................... 4
PicoBit Main Menu ............................................................ 5
Connection Methods ......................................................... 5
Miracast .................................................................................................. 5
Air Pico ..................................................................................................... 6
HDMI / MHL ............................................................................................. 7
DLNA ....................................................................................................... 7
Micro SD Card .......................................................................................... 8
Internet.................................................................................................... 9
Bluetooth ................................................................................................. 9
Android Settings ............................................................. 10
Projector Settings .......................................................... 10
Keystone Adjustment ............................................................................ 10
Screen Rotation ..................................................................................... 11
Screen Setting ....................................................................................... 11
Laser Alignment ..................................................................................... 12
Bi-Phase Adjustment ............................................................................. 12
Pico Reset .............................................................................................. 12
Specifications ................................................................. 13
Safety Cautions .............................................................. 13
Product Certifications ..................................................... 14
Warranty ........................................................................ 15
3
Product Features Using Touchpad
For your safety, do not point the laser light directly into eyes or people. Doing so may
cause serious injuries.
Volume Down
Projection Aperture
Volume Up
Touchpad
Micro SD Card
Power
Micro HDMI/MHL
Speaker USB Type C Charging port
3.5 mm Audio Jack
The top surface of PicoBit is touchpad. When PicoBit is fully loaded, cursor will appear
on the screen for users to control using this touchpad.
1
2
1Tap these icons to increase and decrease
volume.
2Freely navigate the screen using a finger - this
area recognizes your finger movement as cursor
movement on the screen.
• Left click – Tap once
• To go back or cancel – Tap once with two
fingers
• Scroll – Tap once and hold down with two
fingers. Without releasing the fingers, scroll up
and down.
• Zoom in & out – Using two fingers, pinch in
to zoom out and pinch out to zoom in.
• Drag – Tap once and hold down. Without
releasing the finger, slide finger in any
direction to drag. Release finger on desired
area.
4
Product Mode Charging the Device
1 LED indicator - Different colors of LED indicator located below touchpad
represent status of the PicoBit.
• Solid Blue – PicoBit is powered on
• Blinking Blue – In sleep mode
• Green – Fully charged
• Red – Charging
2 Power on – Press power switch for 3 seconds.
3 Power off – Press power switch for 6 seconds. After 3 seconds, power menu
will be displayed. Continue to press it for another 3 seconds, and the product will
power off.
4 Power menu – While product is turned on, press power switch for 3 seconds
to see the Power menu (Power off or Restart option). This menu does not show
during HDMI or WiFi Display mode.
5 Automatic sleep mode – PicoBit automatically enters sleep mode (power save
mode) after idling for 5 minutes. To wake up sleep mode, press the power button
shortly and PicoBit will display the image shown before entering the sleep mode.
Users can set sleep mode time through Android settings app. Automatic sleep
mode does not work during HDMI connection or WiFi Display connection with a
mobile device.
6 APC (Auto Power Control) setting – This setting is to efficiently control the
amount of light emitting from PicoBit’s laser diodes. Due to this setting, a thin
white line on the top of the screen will always be present when PicoBit is turned
on.
Battery Operating Time: Approx. 2 hours
Battery Charging Time: 4-5 hours
To charge PicoBit : Use the supplied USB Type-C cable and power adapter to
charge the device.
Please note that using other adapters than the one provided may result in longer
charging times or damage to the internal battery.
Environmentally Friendly Disposal and Recycling
To protect the environment, dispose this product separately
from household waste once it has reached its end of life, or
take it to your local electronic waste disposal center.
5
PicoBit Main Menu
1 2 3 4 5 6
1Power Menu To power off or restart the device
2Volume control button To decrease volume
3Back button To go back to the previous page
4Home button To go back to the main menu
5Task manager button To manage applications running on PicoBit
6Volume control button To increase volume
Connection Methods
Miracast
(WiFi Display / Smart View / Screen Sharing / Screen Mirroring)
• On the default menu screen, select “WiFi Display” icon to enter WiFi display mode.
• On a mobile device, find and select Miracast (WiFi Display / Smart View / Screen
Sharing / Screen Mirroring) option.
Note
Wireless display feature (Miracast) is called different names on different devices.
( i.e. Samsung device = Smart View / Screen Mirroring, LG device = Screen
Sharing, etc.)
6
• When device discovers “Android_XXXX”, tap to connect.
• PicoBit will display “Invitation to Connect” screen for confirmation.
• Use touchpad to select “ACCEPT”.
• PicoBit will start mirroring display upon successful connection.
Air Pico
• PicoBit and the desired iOS device must be connected to the same WiFi network
for this feature (If there is no WiFi network available, use iOS device’s hotspot to
connect PicoBit’s WiFi to the device).
• After checking both devices are connected to the same WiFi network, select “Air
Pico” icon on the default menu screen to enter the Air Pico mode.
• Below image will be displayed upon entering Air Pico mode.
• Follow instructions on screen: On your iOS device, pull up the task bar from the
bottom of screen and select AirPlay.
• Select “PICOBIT-XXXXX” and turn on “Mirroring” option.
• PicoBit will start mirroring display upon successful connection.
7
HDMI / MHL
• On the default menu screen, select “HDMI/MHL” icon to enter wired connection
mode.
• For MHL connection, use MHL cable (sold separately) to connect PicoBit with an
Android mobile device.
• For HDMI connection, use Micro HDMI to HDMI cable (sold separately) to connect
PicoBit with the device.
• You may tap touchpad with two fingers or disconnect cable connection to exit
HDMI/MHL mode during usage.
DLNA
Desired mobile device must have applicable DLNA app installed and running.
(Ex. ArkMC, BubblePnP, etc.)
1 Go to “Apps” icon on the default menu screen, then find “Setting” icon to
check connected WiFi on PicoBit.
2 Connect to that same WiFi network on a mobile device.
3 After verifying that PicoBit and the mobile device are connected to the same
network, select “Apps” icon on the main menu.
4 Find and select “eHomeMediaCenter” app to enter DLNA mode.
8
5 Go to the mobile device you wish to connect, and open up DLNA app
(ex. ArkMc DLNA).
6 On PicoBit, select the “Media Player” option to see the list of saved media
contents in connected mobile device.
7 Select your device.
8 Find an image or a video to play through PicoBit (Files saved in SD card will be
not discovered).
Micro SD Card
• Insert Micro SD card.
• To enjoy videos or movies stored on SD card, select “Video” icon on the default
menu.
• Browse through and select the video file to play through PicoBit.
• To share images stored in the SD card, select “Gallery” icon on the default menu.
• Browse through and select an image to display through PicoBit.
9
Internet
• Go to settings and connect PicoBit to WiFi network.
• On the default menu screen, select “Internet” icon to use internet browser.
• Freely use the web to do web surfing, streaming, etc.
Bluetooth
• To connect a Bluetooth device to PicoBit, select “Apps” icon on the default menu.
• Find and select “Settings” app.
• Go to Bluetooth option and turn on Bluetooth.
• Find and connect desired Bluetooth device (Bluetooth mouse, speaker, headset, etc)
to PicoBit.
10
Android Settings Projector Settings
Android Settings – Make changes to basic device settings.
• From the main menu, select “Apps” icon.
• Find and select “Settings” app.
• Make changes to various settings as needed.
Pico Settings – Make changes to projector settings. All adjustments are saved as it
is made.
Keystone Adjustment
• Auto adjustment enables automatic keystone feature (only up and down angles).
• For manual adjustment, select UP, DOWN, LEFT, and RIGHT icons to adjust screen
shape as needed.
• All adjustments made will be erased and reset to the default setting when the device
powers off.
11
Screen Rotation
• Select icons to change screen orientation as desired.
• All adjustments made will be erased and reset to the default setting when the device
powers off.
Screen Setting
• Custom Mode – Users can modify various screen settings as desired.
- Move the pink dot controller to adjust contrast, hue, saturation, brightness of the
screen as desired.
- Adjustment range: Contrast: -10 ~ 10 Hue: -15 ~ 15
Saturation: -15 ~ 15 Brightness: -30 ~ 30
• Standard Mode (DEFAULT setting) – For a generic environment
• Dynamic Mode – For a relative bright environment
• Super Dynamic Mode – For more brighter environment
• Cinema Mode – For a dark environment
• All the adjustments made will be erased and reset to the default Standard mode
when the device powers off.
12
Laser Alignment
• Select up, down, left, and right arrows to adjust Red1, Red2, Green1, Green2, and
Blue lasers to align the lasers.
• Align the lasers until the white cross lines are as thin as it can be.
• Adjustment range: Up & Down: -20 ~ 20
Left & Right: -120 ~ 120
• Once saved, all adjustments made will remain through power cycles.
Bi-Phase Adjustment
• Use left and right arrows to align the lines.
• Adjust the lines until the white lines are aligned together.
• Once saved, all adjustments made will remain through power cycles.
Pico Reset
• All changes made in Pico Settings will be erased.
• Android settings will remain unchanged. To reset Android settings, go to Android
settings menu and select Factory Reset
13
Specifications Safety Cautions
Item Specification
Display Method Laser Beam Scanning
Product Lifetime 14,000 hours
Brightness
55 ANSI lumens*
(The perceived brightness is about 100 lam-based
projector (DLP) lumens)
Aspect Ratio 16:9
Throw Ratio 1.3 : 1
Sequential Contrast Ratio 80,000 : 1
Resolution 1920 X 720p (Upscaled HD)
Color Depth 16.7 M colors (R/G/B 24bit)
Focus Infinite Focus (always in focus)
Maximum Image (Screen) Size 200 inches (depending on ambient light)
Embedded OS Android 5.1.1 (Lollipop)
CPU Quadcore 1.3 GHz
Internal Memory 4 GB
WiFi Dual (2.4 Ghz & 5 Ghz)
Bluetooth 4.0
Battery Capacity Approx. 3,500 mAh
Operating Time Approx. 2.5 hours
(Average movie playing time on SD card)
Audio Interface Internal speaker, 3.5mm ear phone jack, or Bluetooth
Operating Temperature 32 °F – 104 °F (0 °C – 40 °C)
Size 138 x 66.5 x 15 mm
(5.4 x 2.6 x 0.6 inches)
*The perceived brightness of laser projectors with a given ANSI brightness measure is about
1.7 times higher to human eye.
• This product is not waterproof – avoid using it near water or wet places.
• There is a risk of malfunction if product is used in places where sudden or extreme
temperature changes occur.
• Applying excessive force or impact to this product may result in product damage,
and will void warranty.
• Never attempt to disassemble or service this product yourself. Doing so can result in
electrical shock and void warranty.
• This is a Class 3R Laser product. For your safety, please do not look directly into the
laser source. Doing so may damage your eyes.
14
Product Certifications
RoHS
FCC Class Notice
This equipment has been tested and found to comply within the limits for a Class
B digital device, pursuant to Part15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a residential environment. This equipment generates, uses, and
radiates radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur with special installation. If this
equipment does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician.
FCC Caution
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
a minimum distance of 20 centimeters between the radiator and your body. This
transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
CE Class Notice
This product is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. The declaration of conformity may be consulted at:
http://______
CE Caution
Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.
IEC-60825-1 Caution
Use of control or adjustments or performances of procedures other than those
specified here in may result in hazardous radiation exposure.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION
IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
•
15
The MIT License (MIT)
Copyright (c) Sergey Ryazanov (http://home.onego.ru/~ryazanov)
Permission is hereby granted, free of charge, to any person obtaining a copy of this
software and associated documentation files (the “Software”), to deal in the Software
without restriction, including without limitation the rights to use, copy, modify,
merge, publish, distribute, sublicense, and/or sell copies of the Software, and to
permit persons to whom the Software is furnished to do so, subject to the following
conditions:
The above copyright notice and this permission notice shall be included in all copies or
substantial portions of the Software.
THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.
IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY
CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT,
TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE
SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
Warranty
Celluon warrants this product to be free from defects in materials and workmanship
under normal use for a period of one (1) year from the date of purchase, as evidenced
by the receipt of purchase.
During the warranty period, Celluon shall repair or replace the product if defective. If
replaced, the replacement shall be with a product of equal or greater value.
Celluon does not warrant against normal wear and tear, nor damage caused by
accident or abuse.
This warranty is limited to the purchaser and is not transferable.
Please contact support@celluon.com for warranty supports.
