CHINA ELECTRONICS M1 BLUETOOTH SPEAKER User Manual
China Electronics Shenzhen Company BLUETOOTH SPEAKER
User manual
EN
1
SAFETY INSTRUCTIONS
Read the operating instructions carefully before use.
Save these instructions for future reference.
・ Protect the appliance and the power cord from heat, sunlight, water and sharp
edges.
・ Never poke any metal objects into the appliance – risk of short circuiting.
・ Do not use the appliance in extremely dry air – risk of static electricity.
・
・ The product may become warm when charging
・ Do not modify the product – the manufacturer cannot accept liability for any
・ The product and antenna must not be located or used in conjunction other
antennas or transmitters.
・ Do not attempt to repair the appliance. Any repairs must be carried out by an
TECHNICAL DATA
Electrical data 14 VDC, 1 A
Bluetooth that supports 3.0+EDR
Range 10 m
Frequency response 80 Hz to 16 kHz
RMS-output 25 W (THD = 10%)
Distortion ≤ 0.5 %
Signal/noise ratio ≥ 65 dB
Drive unit 2 x 3"
Output power 2x12,5 W RMS
Battery capacity 2000 mAh
Operating time 3-4 hours
Charging time 2-2.5 hours
Interface BT, AUX
Dimensions 260 x 150 x 150 mm
Weight 2 kg
EN
2
DESCRIPTION
1 Bluetooth/AUX input selector 5 Previous song
2 Volume setting 6 Next song
3 Play/Pause 7 AUX input
4 Power switch 8 Charger socket (rear)
1 32
5 6
4 7
8
EN
3
USE
When the product is new
Charging the speaker
1. Connect the adapter cable to the speaker's charging port.
2. The red status light comes on to show that the product is charging.
3.
Pairing
1. Place the speaker within 9 metres of the Bluetooth device.
2.
3. Follow the instructions on the Bluetooth device to search for the speaker.
4. The speaker's name when pairing is M1. If a PIN code is requested, enter 0000.
5.
Use
Set the switch in the ON position to start the speaker. An audio signal is give and the blue status lamp
Status lights
Charging Red light on
Fully charged Red light out
Pairing mode
Connected Blue light on
Playback
EN
4
FCC Warning:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Statement
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be
installed and operated with minimum distance between 20cm the radiator your body: Use
only the supplied antenna.
