User Manual
Bluetooth Selfie Function
1. Bluetooth Selfie function is on when the phone is connecting
the device by Bluetooth.
2. Open the phone's camera, long press to take a photo.
TF Mode
Insert TF card, it will automatically enter TF Card mode. The
device will read TF Card and play music.
Line-in Mode
Use Aux cable to connect the device with your phone, it will
automatically enter Line-in Mode.
Mode Selection
Press to select Bluetooth mode/TF mode/Line-in mode.
Specification
Unit Size: 80*87*40mm
Connectivity: Bluetooth/Aux in/TF card
Function: Handsfree / Selfie
Output power: 2.2W x 1 (RMS)
Built in 600mah Battery
Playing time: around 4~6 hours
Reset
In case of accidental crash, long press reset button to turn off.
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
User Manual
Bluetooth Speaker
Model No.: S-23
Bluetooth Mode
1. Press for 2 seconds to boot, after the prompt voice it enters
Bluetooth pairing mode, the blue indicator light flashes fast.
In any mode, press for 2 seconds, it shuts down after the
prompt voice.
2. Open the Bluetooth in your mobile phone, search and find the
name "S-23", then connect. Open the phone music player and
start playing music.
Bluetooth Hands-free Function
After connecting the device with phone by Bluetooth, when the
phone call comes, the device will have ring tone. To answer the
phone call, short press ; to hang up the phone call, short
press again. To reject the phone call, short press twice .
① Power / Source
