CJ Global 72XXP Bluetooth Speaker User Manual F001 20180525

CJ Global Inc. Bluetooth Speaker F001 20180525

user_manual

Thanks for buying this product
This is a MINI bluetooth speaker can answer your call and
communicate, can use in home and outdoor sports.
Please read and keep well this brochure, if any questions or
missing in the brochure pls be free to contact us any time,
thanks!
Security Issues
□Please read carefully and keep well for later use.
□Please put the product in a place where children cannot reach.
□Don't throw the product.
□Don't throw it to the fire and keep it away from the heat source
because it is built-in battery.
□To avoid to get an electric shock pls don't use it without
grounding socket.
□Don't open it and repair it by yourself.
□Please contact the nearest dealer for after-sales service.
Product Specifications
□ Model：72784/72786/72788
□ Speaker：4W/3Ω
□ Lithium battery：3.7V/400mAh
□ Playtime：About 3h
□ Charging time：About 3h
□ DC input ：DC3.7V/100mA
□ Working temperature：-20~50℃
□ Net weight：0.2Kg
□ Size：59*59*45mm
□ Bluetooth Distance：About 10m
Main functions
□Connect your phone and play music.
□Can answer your call and communicate after connect your phone.
Product Overview
Connect your phone
Long press the on/off button in 3 seconds and the speaker will turn
on, so open your phone device and open the bluetooth control
interface and then turn on the bluetooth. Find the bluetooth name
”Zoko”,click it and connect it.then the speaker will say bluetooth
device is connected sucessfully.
Instructions:
Charging the Integrated Battery:
Press to switch the speaker on and off
Short press for the previous song, long press to turn the
volume down.
Short press for the next song, long press to turn the volume up.
Press to pick up or hang up a phone call(Tip: Press this twice to
redial the last phone call).
Press to play or pause the music.
USB Socket
Charging port
Power ON/OFF
Pick up or hang
up a phone call
Play or Pause the music
Next song Previous song
12
43
MINI
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’sauthorityto
operatetheequipment.ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterference
inaresidentialinstallation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnotinstalledand
usedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno
guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
