Z513
FCC ID: Y7WPLUMZ513
Warnings
Not following these simple guidelines may be dangerous or
illegal. Read the complete user guide for further
information.
TURN ON SAFELY
Do not turn on the phone when wireless phone is prohibited
or when it may cause interference or danger.
ROAD SAFETY
Obey all road safety laws. Always use both of your hands to
operate the vehicle while driving.
INTERFERENCE
All wireless phones may be sensitive to interference, which
may affect performance.
TURN OFF IN HOSPITALS
Follow all restrictions. Turn off the phone near medical
equipment.
TURN OFF ON AIRCRAFTS
Follow all restrictions. Wireless devices can cause
interference on aircrafts.
TURN OFF WHEN REFUELING
Do not use the phone at/near refueling stations. Do not use
near fuel or chemicals.
USE SENSIBLY
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only appropriate enhancements and batteries. Do not
connect incompatible products.
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACKUP COPIES
Remember to make back-up copies or keep a written record
of all important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any external device, read its user guide
for detailed safety instructions. Do not connect with
incompatible products.
Content
Your Phone .......................................................................... - 1 -
Keypad Descriptions ........................................................... - 1 -
Start to Use .......................................................................... - 2 -
Charge the Battery ............................................................... - 3 -
Use Touch Screen ................................................................ - 3 -
Make a Call .......................................................................... - 4 -
Answer a Call ...................................................................... - 4 -
Emergency Service .............................................................. - 4 -
Input Method ....................................................................... - 4 -
1. Backup and Restore ......................................................... - 5 -
2. Browser ............................................................................ - 5 -
3. Calculator......................................................................... - 5 -
4. Calendar ........................................................................... - 5 -
5. Camera ............................................................................. - 6 -
6. Clock ................................................................................ - 6 -
7. Downloads ....................................................................... - 6 -
8. Email ................................................................................ - 6 -
9. Social Networking Function ............................................ - 6 -
10. File Manager .................................................................. - 7 -
11. FM Radio ....................................................................... - 7 -
12. Gallery ........................................................................... - 7 -
13. Services .......................................................................... - 7 -
14. Messaging ...................................................................... - 7 -
15. Movie Studio ................................................................. - 8 -
16. Music ............................................................................. - 8 -
17. People ............................................................................ - 8 -
18. Phone ............................................................................. - 9 -
19. Quick Start Guide .......................................................... - 9 -
20. Search ............................................................................ - 9 -
21. Settings .......................................................................... - 9 -
22. SIM Toolkit .................................................................. - 11 -
23. Sound Recorder ........................................................... - 11 -
24. Video Player ................................................................ - 11 -
25. Wireless Connection Direct ............. 错误！未定义书签。
26. YouTube Hot Trend ..................................................... - 11 -
27. Widgets ........................................................................ - 11 -
Accessories ........................................................................ - 11 -
Care and Maintenance ....................................................... - 12 -
Technical Information ........................................................ - 13 -
- 1 -
Your Phone
The phone appearance is shown as below. The picture is for reference
only; your phone may be different. Please take your actual phone as
the standard.
Keypad Descriptions
Power Key
Long press the key to turn on the phone.
In the power on status, press the key to lock keypad
and screen; long press the key to show phone
options.
- 2 -
Option Key
Press the key to enter option menu.
Home Key
Press the key to return to standby mode.
Long press the key to show recent list.
Back Key
In the menu mode, press the key to go back to
upper menu.
Volume Key
To adjust incoming call ringtone volume.
During a call, while playing music, video, or
listening to radio, press the keys to adjust volume.
Start to Use
Install Memory Card, SIM Card and Battery
When you apply for a network, you will get a plug-in SIM card. SIM
(Subscriber Identity Module) card that contains the phone number
and service projects, and can be used to store phone numbers and
personal information.
Attention: Do not bend or scratch SIM card, do not let it contact with
static electricity, dust or water.
Keep all SIM cards where children cannot touch.
- 3 -
Note: Keep the SIM card chip contacts face downward. Make the
SIM card fits card slot.
Remove Memory Card, SIM Card and Battery
Note: If the phone is turned on, long press Power Key about 2
seconds until it tips phone options and select Power off and
then press OK to turn off the phone. Then, remove the battery,
SIM card and memory card.
Do not plug or remove memory card in boot state, otherwise it
will cause damage to the file system.
Charge the Battery
1. Before charging, check the battery slot to ensure the battery has
been installed correctly.
2. Plug one end of the charger into phone.
3. Connect another end of the charger to the socket.
4. Start charging. It can be charged whether power on or power
off.
▪ In power on state, when the battery icon on screen start rolling
means it is been charged. When the icon is full and stop rolling means
charge is completed.
▪ In power off state, the battery icon on screen start rolling means
it is been charged. When the icon is full and stop rolling means
charge is completed.
5. Unplug the charger from the socket.
6. Disconnect the charger and phone.
Use Touch Screen
Press: Use finger to press the desired option to confirm selection
or start an application.
Long press: Long press the screen in current operation interface,
icon, or input area, you can open the option menu in current
interface.
Slide: Slide the finger on screen horizontally or vertically. For
example, slide the screen in standby mode or main menu
- 4 -
horizontally to change menu page.
Drag: Use finger to long press desired item, drag it to anywhere
on screen. For example, you can drag the icon in main menu to
standby screen.
Make a Call
1. In standby mode or in main menu, Click the icon to enter
dialing telephone interface, then click the keyboard icon, enter
the number
2. Press dial icon, select SIM card to dial the number.
3. Press “End” to cancel the call.
You need to unlock the phone if the keypad and screen
is locked.
You can make calls through call log, contacts, and
messages.
During a call, press Volume Keys to adjust the volume.
Your phone supports intelligent dial. When input
numbers, the phone will search the corresponding
contact in phonebook and call log.
Answer a Call
When there is an incoming call, you can:
▪ Drag the icon toward right to answer the call.
▪ Drag the icon toward left to decline.
▪ Drag the icon upward to reject the call with SMS.
Emergency Service
You can call emergency service number directly without SIM card.
Different networks using different emergency numbers, please query
your network operator.
Input Method
Your phone has the built-in input method. In edit mode, long press
“,…” to show Input options and set input languages and Android
- 5 -
keyboard settings.
Input English
Press the on-screen keypad to enter corresponding letters.
Input Number
Press “?123”, you can input numbers directly by press the number
icons. Long press the letter icons with number, or after long press,
slide finger to the numbers to input.
Input Symbol
Press “?123” to enter symbol list. Press the desired symbol to input.
Long press “.…” or “:-)…” to show symbol list, slide finger to the
desired symbol to input.
1. Backup and Restore
In this menu, you can choose to BACKUP and RESTORE
applications and personal data.
2. Browser
You can use your phone to access Wireless Application Protocol
(WAP) sites and use WAP-based services. To browse WAP pages, you
must subscribe to the data service from your service provider and
configure your phone's relevant settings.
Select the website list on screen or input URL in address bar to visit.
3. Calculator
The calculator can execute simple calculations. Slide the screen
toward left or right, you can change the calculator in Basic panel and
Advanced panel.
4. Calendar
In the calendar, you can check schedules for current month. It has
alarm for the date with schedule. Select one date to check all
schedules for that day, or you can edit or delete the schedules.
- 6 -
5. Camera
By using the camera application, you can take photos or records for
around people or events anytime. Press the Camera icon in main
menu to enter. Press the shoot icon to take photo or record. Slide the
camera icon toward right to shift camera into video recorder.
Press the icons on screen to operate the camera or recorder.
6. Clock
In the clock interface, you can check time and date. Press the alarm
icon, you can add new alarm clock or turn on/off existed alarm
clocks.
In the clock interface, you can also press the icons to enter count
down function, stopwatch, cities settings, night mode, and settings.
7. Downloads
To check all downloads applications.
8. Email
You can use Email to send and receive emails.
Setup Email Account
According to the tips on screen to input email address and password,
and press Next. You can press Manual setup to setup server
information manually.
Check Emails
In the Inbox, select the email you want to check to enter. Press the
icons at bottom to delete, reply, add to favorite, and mark.
Compose and Send Email
In the Inbox, press new mail icon to create new email. Input receiver
email address, subject, and content, and then press send icon to send
the email.
9. Social Networking Function
- 7 -
Your phone has several built-in social networking applications, such
as Facebook, Skype, Twitter and so on.
10. File Manager
In this menu, you can select to check Phone storage and SD card.
11. FM Radio
Select FM Radio in the main menu and plug earphone to enter.
Press Power icon to turn on/off the radio. Press setting icon and select
Search, the phone will search available channels and save in the list.
Press the icons on screen to operate the FM radio.
12. Gallery
You can use Gallery to view or manage photos and videos.
13. Services
Availability of Google applications, services, and features may vary
according to your country or carrier. Please follow local laws and
regulations to use them.
When you turn on your mobile phone for the first time, touch a
Google services such as Gmail, Maps, Play Store and so on, or
Hangouts and you may be prompted to sign in to your Google
account.
Ensure that your mobile phone has an active data connection
(4G/3G/GPRS) before you sign in to your Google account.
If you already have a Google account, touch Sign in and enter your
username and password.
14. Messaging
Select Messaging in the main menu or standby mode to enter. Select
new message icon at left down corner to create new SMS or MMS
and send.
1. Enter receiver’s number or add number from contacts.
2. Press “Type text message” to input message content.
3. If you want to send picture or video file, press to add pictures,
videos and audio. The message will shift to multimedia message
- 8 -
automatically.
4. Press send icon and select SIM card to send the message.
15. Movie Studio
With the movie studio function, you can play or edit video files. In
the play mode, press the + at upper right corner or press Option Key
to do option.
16. Music
Select Music in main menu. Press Artists, Albums, Songs, and
Playlists at the top of screen to change category. Select one audio file
to play the music. Press the icons on screen to operate the audio
player.
17. People
In the People, press search icon to search contact, press add new icon
to add new contact. Press Option Key to enter:
Delete Contact
Select one contacts, then press OK to delete selected contacts.
Contacts to Display
Select All contacts, contacts on SIM card, Phone, or Customize the
contacts to display.
Import/Export
Copy the contacts from storage, and Export to SIM card or storage,
and manage Sim card contacts.
Accounts
Select whether to Auto-sync app data.
Settings
To set display options of Sort list by, or View contact names as.
Share Visible Contacts
Select one or more contacts, press OK and then share the selected
contacts via BT, Email, Gmail, MMS, SD card, or Skype, SMS.
Memory Query
To check the memory of phone and SIM cards.
Join Contacts
Use this function to merge same contacts.
- 9 -
18. Phone
Press the icons on screen to input numbers in sequence. After
inputting numbers, press dial icon and select SIM card to dial. Press
the icons at the top of screen, you can enter call log or contact.
19. Quick Start Guide
This quick start guide contains 4 useful tips and introduces you basic
gestures and phone management.
20. Search
Input keyword in search bar, the phone will match applications or
contacts first. If there is no result, press the icon on right to link to
network and search.
21. Settings
Wireless & Networks
In this menu, you can select and set SIM management, WLAN, BT,
Data usage, Under More - Airplane mode, VPN, Tethering &
portable hotspot, Mobile networks, and USB Internet.
WLAN
You can connect to a wireless LAN (WLAN), use it to access and
download with high speed.
In Menu/Settings/WIRELESS & NETWORKS, slide the icon
beside WLAN toward right to turn on WLAN. Press WLAN to
check available WLAN networks. Select one open network, you can
access to the network directly. If the network you selected is
encrypted, you need to input password.
BT
The phone supports BT. It can exchange information between devices
including mobile phones wirelessly. Through BT, you can sync
phone and computer, exchange data with other BT devices, and can
connect to BT earphone.
- 10 -
In Menu/Settings/WIRELESS & NETWORKS, slide the icon
beside BT toward right to turn on BT and set. Before transmit data,
you may need to match with other BT devices.
Device
In this menu, you can set audio profiles and display, check storage
and battery, and manage applications.
Personal
Location Access
Select whether to access to my location, whether to turn on GPS
satellites, or whether to use WLAN & mobile network location.
Security
You can select SCREEN SECURITY, ENCRYPTION, SIM
CARD LOCK, PASSWORDS, DEVICE ADMINISTRATION,
and CREDENTIAL STORAGE in this menu.
Language & Input
Select and set Language, keyboard & input methods, speech, and
mouse/trackpad.
Backup & Reset
In this menu, select Factory data reset and then select Reset phone
to clear all data in the phone memory. Select DRM reset to delete all
DRM licenses.
Accounts
Add Account
To add new account of Corporate, Email, Facebook, Google,
SkypeTM, or Twitter.
System
Date & Time
Set time and date for the phone.
Scheduled Power On & Off
Set time to power on/off the phone automatically.
- 11 -
Accessibility
To set accessibility functions for the phone.
About Phone
To check status, battery use, legal information, etc.
22. SIM Toolkit
If your SIM card supports STK (SIM Tool Kit) function, the phone
can display different first level menu according to different STK card.
This function needs the network provider support. If user finds STK
function can’t operate normally, please contact the network provider.
If the network provider does not support this function, we do not
claim any responsibility whatsoever.
23. Sound Recorder
The phone support sound record function. You can send a recorded
file via BT, message or email.
24. Video Player
You can use Video player to view or manage videos.
25. Wireless Connection Direct
You can add new device or check paired wireless input device in the
menu.
26. YouTube Hot Trend
This app gives you tons of hot YouTube videos.
27. Widgets
In the widgets list, you can select desired widget to add to idle screen.
Accessories
You can use accessories approved by our company, the other
accessories can be provided by the seller.
battery
We provide lithium battery with 2000mAh capacity.
Travel charger
- 12 -
Charger can charge the mobile phone very quickly. Plug the charger
into the electrical plugs and connects the other side connects to the
left side of the phone.
Care and Maintenance
Battery Care
• Your device is powered by a rechargeable battery. When the power
is weak, please charge the battery. In order to extend the lifespan of
the battery, use all the battery's power before recharging.
• Unplug the charger from the electrical plug and the device when not
in use. Do not leave the battery connected to a charger more than a
week. Overcharging may shorten its lifespan.
• Extreme temperatures can affect the ability of your battery to charge.
Battery needs the fit temperature. If the surrounding temperature is
over 50°C, the battery cannot be charged.
• Use the battery only for its intended purpose. Never use any charger
or battery that is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur
when a metallic object such as a coin, clip, or pen causes direct
connection of the positive (+) and negative (-) terminals of the battery.
(These look like metal strips on the battery.) Short-circuiting the
terminals may damage the battery or the connecting object.
• Leaving the battery in hot or cold places, such as in a closed car in
summer or a freezer in winter conditions, will reduce the capacity and
lifetime of the battery. A hot or cold battery may not function
temporarily, even when the battery is fully charged.
• Do not dispose of batteries in a fire! Dispose of batteries according
to local regulations. Please recycle when possible. Cellphones are not
considered household waste.
Mobile phone maintenance
• Keep the device dry. Precipitation, humidity, and all types of liquids
or moisture can contain minerals that will corrode electronic circuits.
- 13 -
If your device does get wet, remove the battery and allow the device
to dry completely before replacing it.
• Do not use or store the device in dusty, dirty areas. Its moving parts
and electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten
the life of electronic devices, damage batteries, and warp or melt
certain plastics.
• Do not store the device in cold areas. When the device returns to its
normal temperature, moisture can form inside the device and damage
electronic circuit boards.
• Do not attempt to open the device other than as instructed in this
guide.
• Do not drop, knock, or shake the device. Rough handling can break
internal circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents
to clean the device.
• Do not paint the device Paint can clog the moving parts and prevent
proper operation.
• Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage
the device and may violate regulations governing radio devices.
All of the above suggestions apply to your device, battery, charger, or
any enhancement. If any device is not working properly, take it to the
nearest authorized service facility for service.
Caution: The manufacturer assumes no responsibility for the
consequences of the users does not comply with the above
suggestions or misuse of the phone.
Technical Information
Weight: 140g (with battery)
- 14 -
Size: 143.3mm*72.8mm*9.1mm
Battery capacity: 2000mAh
Networks: GSM: 850/900/1800/1900MHz
WCDMA: Band 2/Band 4/Band 5
4G: Band 4
The actual situation of the phone using is related to local environment,
SIM card and way of use.
Note: If the version of user manual upgrades, we will do not
notice. The company has the final interpretation of the user
manual.
The pictures in user manual only for reference, please
take your actual phone as the standard.
FCC RF EXPOSURE INFORMATION:
WARNING!! Read this information before using your phone
In August 1986 the Federal Communications Commission (FCC) of the United States with its
action in Report and Outer FCC 96-326 adopted an updated safety standard for human exposure
to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those
guidelines are consistent with the safety standard previously set by both U.S. and international
standards bodies. The design of this phone complies with the FCC guidelines and these
international standards. Use only the supplied or an approved antenna. Unauthorized antennas
modifications, or attachments could impair call quality, damage the phone, or result in violation
of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result. Please contact your local dealer for
replacement antenna.
BODY-WORN OPERATION:
This device was tested for typical body-worn operations with the back of the phone kept 10mm
from the body. To comply with FCC RF exposure requirements, a minimum separation distance
of 10mm must be maintained between the user's body and the back of the phone, including the
antenna. Third-party belt-clips, holsters and similar accessories containing metallic components
shall not be used. Body-worn accessories that cannot maintain 10mm separation distance between
the user’s body and the back of the phone, and have not been tested for typical body-worn
operations may not comply with FCC RF exposure limits and should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When
it is ON, it receives and also sends out radio frequency (RF) signals. In August, 1996, the Federal
Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for
hand-held wireless phones. Those guidelines are consistent with the safety standards previously
set by both U.S. and international standards bodies:
<ANSIC95.1> (1992) / <NCRP Report 86> (1986) / <ICIMIRP> (1996)
Those standards were based on comprehensive and periodic evaluations of the relevant
scientific literature. For example, over 120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available body of research to develop
the ANSI Standard (C95.1). Nevertheless, we recommend that you use a hands-free kit with
your phone (such as an earpiece or headset) to avoid potential exposure to RF energy. The
design of your phone complies with the FCC guidelines (and those standards).
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and may violate FCC regulations.
NORMAL POSITION:
Hold the phone as you would any other telephone with the antenna pointed up and over your
shoulder.
RF Exposure Information:
This product is compliance to FCC RF Exposure requirements and refer to FCC website search for FCC
ID: Y7WPLUMZ513 to gain further information include SAR Values.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
Do not use the device with the environment which below minimum -10℃ or over maximum
50℃, the device may not work.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Ad Hoc function is supported but not able to operate on non-US frequencies.
