User manual

1
BTAE -12/6733
BLUETOOTH STEREO STAY-FIT EARBUDS
WITH BUILT-IN MIC
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE USE
2
Getting started
Remove the product from the box.
Remove any packaging from the product.
Please retain all packaging after you have checked and counted all the parts and the contents
against the list.
Package Contents
Bluetooth Stereo Sports Earbuds
USB charging cable
2 different sizes of silicon tips included
Instruction Manual
Key Features
Enjoy music wirelessly via Bluetooth technology
Stereo Sound
USB Rechargeable (USB Cable Included)
Built-in Microphone
Easy to switch between calls and music, you will not miss the incoming call whilst listening to
music
Answer & end a call at click of a button
Built-in Volume & Media Control (pause/play)
Connects to previously connected device automatically
Safety Instructions
Keep the unit away from heat sources, direct sunlight, humidity, water and any other liquids.
Do not operate the unit if it has been exposed to water, moisture or any other liquids to prevent
against electric shock, explosion and/or injury to yourself and damage to the unit.
Do not use the unit if it has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by a qualified electrician. Improper repairs
may place the user at serious risk.
Do not use the unit with wet hands.
Do not put objects into any of the openings.
Keep the unit free from dust, lint etc.
Do not use this unit for anything other than its intended use.
Keep the unit out of reach of children.
This product is not a toy.
Do not use the handset at excessive volume levels, as damage to hearing may occur.
3
Description of Parts:
1
Speaker
2
LED Light Indicator
3
Charging port (side)
4
Volume Increase (+) / Next Track
5
MF (Multi-Function) / Phone button
6
Volume Decrease (-) / Previous Track
7
Built-In Microphone (rear)
4
INSTRUCTIONS FOR USE
Charging Instructions
The Bluetooth Earbuds come with a built in rechargeable battery. Before using it for the first time we
recommend you charge the battery fully. Only use the supplied USB Cord to charge the Bluetooth
Earbuds. Please charge for about 2 hours.
Connect the USB charging cable to a computer USB port and the Micro USB plug to the charging port
of the device. The Red LED light turns on while the device is charging. It takes around 2 hours for the
unit to fully charge. When the battery is fully charged, it will change to Blue LED light.
Switching on/off the device
Press and hold the MF button for 4-6 seconds to turn ON or OFF the device with sound message
‘Power On’ or ‘Power Off’ correspondingly.
Pairing the device with Bluetooth devices (phone or music device)
Ensure the device is turned off, then press and hold the MF button for 4-6 seconds to turn on with
sound message ‘Power On, Pairing’, and the LED flashes red and blue. Place the Bluetooth Earbuds
and Bluetooth device (phone or music device) so that they are no further than 3 feet apart;
Activate the Bluetooth function on your Bluetooth device (phone or music device). Please refer to the
manufacturer’s instructions for instructions on enabling Bluetooth on your device.
Once you have activated Bluetooth on your device, select the “SL BT EARBUDS” from the list of
available Bluetooth devices.
If required, enter the password ‘0000’ to confirm & finalize pairing.
Once paired successful, beep sound with message ’Connected’ will be heard and the LED flashes blue.
You can now start to use the device.
Please note pairing mode on the device will last for up to 30 minutes. If no devices are paired within
30 minutes the device will power off automatically.
If pairing is unsuccessful, turn off the device first and then re-pair following the above steps.
Once you have paired the Bluetooth Earbuds with a device, the Earbuds will remember this device and
will pair automatically when the device’s Bluetooth is activated and in range. You do not need to
re-pair any previously connected devices.
The Bluetooth Earbuds will attempt to automatically connect to the last device it was paired with
when switched on. If you want to pair it with a new device, please follow the steps outlined above.
Once the Bluetooth Earbuds is paired with your device the music will transmit through the Bluetooth
Earbuds. Please refer to your device’s user manual for further information.
5
Function Summary
Listening to Music
Once the Earbuds are paired with your device you can stream music wirelessly through the Bluetooth
Earbuds. Should you encounter any problems while streaming please refer your device’s user manual
for further information.
Control Function
Function
Operation
Button
Increase Volume
Playing music
A long press on the +button once will increase the volume
Decrease Volume
Playing music
A long press on the -button once will decrease the volume
Pause
Playing music
A short press on the MF button will pause the music
Play
Pausing
A short press on the MF button will restart the music
Previous track
Playing music
A short press on the -button will return you to the previous
track
Next track
Playing music
A short press on the +button will take you to the next track
An indication tone with sound message ‘Volume maximum’ will alert you when the volume is adjusted
to the maximum level.
Making a call with the Bluetooth Earbuds in Bluetooth mode
Basic operation
Function
Operation
Button
Answer a call
Incoming Call
Press the MF button once to answer an incoming
call
Reject a call
Incoming Call
Double short press the MF button, and then
release once you hear the sound with message
‘Call rejected’.
End a call
Incoming Call
After your phone conversation, short press the
MF button and you hear beep sound with
message ‘Call ended’.
Increase Volume
During a call
Long press on the +button once will increase the
volume
Decrease Volume
During a call
Long press on the -button once will decrease the
volume
Redial last number
Standby mode and
connected to a device
Short press the MF button twice
6
Please Note
Not all mobile phones support all the functions listed above. Please refer to your cell phone’s
user’s manual for further information.
Certain functions and indication tone maybe vary depending on your mobile phone.
When the volume is adjusted to max, you will hear an indication tone with message ‘Volume
maximum’.
LED indicator
Please refer to the below tables for a list of the LED statuses whilst using the Bluetooth Earbuds.
Charging Indication
Status of the BT Earbuds
Charging
Charging Completed
LED Indication
Status of the BT Earbuds
Pairing mode
Low Battery Power
Care and Maintenance
Read the following recommendations before using the Bluetooth Earbuds. Following these you will be
able to enjoy the product for many years.
Do not expose the Bluetooth Earbuds to liquid, moisture or humidity to avoid the product’s
internal circuit being affected.
Don’t use abrasive cleaning solvents to clean the device.
Do not expose the device to extremely high or low temperature as this will shorten the life of
electronic devices, destroy the battery or distort certain plastic parts.
Don’t dispose of the device in a fire as it will result in an explosion.
Don’t expose the device to contact with sharp objects as this will cause scratches and damage.
Don’t let the device fall on the floor. The internal circuit might get damaged.
Don’t attempt to disassemble the device as it may get damaged if you are not professional.
In case the device doesn’t function properly, send it to the store you bought it. The staff will help you
to the problem.
7
Specifications
Bluetooth specification
Bluetooth 3.0
Operating distance
33 Feet
Working time
Up to 3 hours (max volume), up to 5 hours (moderate volume)
Charging input voltage
DC 5V
Charging time
About 2 hours
Speaker Power
2 x 5mW
Built-In Battery
60mAh
(Note: Battery life & charging time may vary based on usage & types of devices used.)
FCC STATEMENT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
FCC Radiation Exposure Statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without RF striction.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital,
pursuant to Part 15 or the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
casue harmful interference to radio communications, However, there is no guarantee that interference
will not occur in a particular installation. If the equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
--- Reorient or relocate the receiving antenna.
--- Increase the separation between the equipment and receiver.
--- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
--- Consult the dealer or an experienced radio/ TV technician for help.
8
LIMITED WARRANTY
This manufacturer's product warranty extends to the original consumer purchaser of the product. Neither the
retailer nor any other company involved in the sale or promotion of this product is a co-warrantor of this
manufacturer warranty.
WARRANTY DURATION: All materials and workmanship are warranted to the original consumer purchaser
for a period of ninety (90) days from the original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials or workmanship. This warranty
is void if the product has been damaged by accident, in shipment, unreasonable use, misuse, neglect,
improper service, commercial use, repairs by unauthorized personnel or other causes not arising out of
defects in materials or workmanship. This warranty doesn’t cover the following which may be supplied
with this product, including but not limited to; LCD Screens, glass parts, lenses, bulbs etc. This warranty is
effective only if the product is purchased and operated in USA and Canada, and does not extend to any
units which have been used in violation of written instructions furnished by manufacturer or to units which have
been altered or modified or, to damaged products or parts thereof which have had the serial number removed,
altered, defaced or rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or implied and no representative or
person is authorized to assume for manufacturer any other liability in connection with the sale of our products.
There shall be no claims for defects or failure under any theory of tort, contractor commercial law including but
not limited to, negligence, gross negligence, strict liability, breach of warranty and breach of contract. Under
no circumstances will Manufacturer’s / Distributor’s maximum liability exceed the retail value of the product.
WARRANTY PERFORMANCE: During the above 90 day warranty period, a product with a defect will be either
repaired or replaced with a reconditioned comparable model (at manufacturer's option). The repaired or
replacement product will be in warranty for the balance of the 90 day warranty period and an additional
one-month period. No charge will be applicable for such repair or replacement.
SERVICE AND REPAIR: If service is required for this product, you should first contact Midwest Trading Group
Customer Service at info@mtradinggroup.com or by calling 1 (866) 815-4714, Monday to Friday 10am to 6pm
EST.
NOTE: Manufacturer cannot assume responsibility for loss or damage during incoming shipment. As a
precautionary measure, carefully package the product for shipment, and insure it with the carrier. Be sure
to enclose the following details with the product: your full name, return address and daytime phone number,
a note describing the problem you experienced, a copy of your sales receipt or other proof of purchase to
determine warranty status. C.O.D. shipments cannot be accepted.
