COMISO DIGITAL TECHNOLOGY VICTSING Bluetooth Speaker User Manual
SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED Bluetooth Speaker
User manual
The Speaker has a fever phenomenon when normally
operated or charging, it’s normal.
If you need to clean the speaker. Please turn off the
speaker and disconnect it with all external devices
before cleaning.
Do not drop or trample the speaker.
use alcohol, benzene and other chemicals to
clean the the Speaker.
put it close to the extreme cold or hot objects.
Please use the accessories provided original.
dismantle the speaker without authorization.
The service time of the Speaker’s battery depends
on the output volume of the matched mobile phone.
Please turn down the volume of your cell phone to
about 70% of the maximum volume, which can prolong
the service time.
The Protective Level of the speaker reaches IP65,splash
is ok,but it can not be submerged into the water.
Do not
Do not
Do not
Precaution
USB Cord 1PCS
Instruction Book/Warranty Card 1PCS
Operating Instruction:
1. Turn on the Speaker, the LED indicator light will flash,
voice prompts “power on” at the same time.
2. Turn on the Bluetooth function of your Smartphone.
3. Search for the Bluetooth devices and select "C6" from the
list.
4. Click it and pair the speaker with your Smartphone.
5. Enter the code "0000" if needed.
6. After successfully paired, the speaker can play music of your
Smartphone.
7. For next time, you just need to press the“ON/OFF”button
until you hear "power on" and release it, then thespeaker will
connect to your mobile device automatically.
Pair it with your Bluetooth Device:
USB charging:
Connect the speaker with computer or mobile by USB charging
cable. Red led light means charging the speaker. The led light
indicator turning off means speaker be fully charged. This
charging method is a little slow, it will take about 5-6 hours
to full charge the speaker. It will be faster charging with mobile
power adapter (5V 1A), it is about 2-3 hours. Speaker can also
work during charge.
1.The fashion designed bluetooth speaker can offer you
endless enjoyment when you are travelling on the road.
2.It has bluetooth function and can wirelessly connect
with other mobile devices, and it is attached with an
Aluminum alloy hook. You can conveniently hang this
Speaker on the mountaineering bag or a bicycle with
the hook.
3.It has built-in MIC Bluetooth speaker and hands-free
function, so you can conveniently pick up a call by this
mini Speaker in car, bathroom, at home or office,
anywhere when it is connected to your Smartphone.
4.The suction cup on the back of the Speaker can be
easily attached on the wall or any flat surface and is
great for shower, baths, swimming pools, and boats, etc.
5.After the speaker is suspended for 15 minutes, it will
shut down automatically
Product overview:
In order to let you enjoy the service better, Please read
following agreement:
The validity period of product warranty starts from the date
of sale (“three guarantees”). During the validity period of
“three guarantees”, the malfunction of this product will be
solved according to the provision of “three guarantees”:
repair, replacement or return. During validity period of
product warranty, the Company provides free maintenance
service (exceeds the range of warranty). And, during the
“three guarantees” period, the company will implement
the paid service for following cases:
1.Cannot show the original warranty and effective invoice
2.The malfunction and damage are caused by irresistible
factors and other reasons
3.The damage and failure are caused by your error in operation
(not in accordance with the “manual” of normal operation)
4.The failure and damage are caused by the transportation
5.The failure and damage are caused by the fault disassembly
and maintenance without prior authorization of company. As
for fault repair, please return the warranty card and sale
invoice, and you need to deliver the warranty card and sales
invoice together to after-sales service center and afford the
transportation fees by yourself.
The key definitions:
1. Long press the “ ”button to increase the volume, and
short press the button to play the next song.
2. Long press the “ ” button to decrease the volume, short
press the button to play the previous song.
3. The button is used to control music (play/pause)
and calls. During playing music, short press the button to stop
playing music. And, when there is an incoming call, the
Speaker will automatically stop playing music, at that moment,
the ring of cell phone sounds. You just need to click the
button to answer the incoming call and long press the button
to refuse the incoming calls. After answering the incoming
call, click this button again to hang up the call. Also click the
button twice to automatically redial the last telephone
number.
“ ”
Specification:
Input voltage: DC-5V/600MA
Output power: 5W THD + N ≤10% (1Khz/0dB)
Polymer battery: 3.7V/500mAh
Speaker unit: Φ 45 mm 4ohm/5W
Frequency Response: 120Hz-22 kHz
S/N: ≥90DB
Weight: 145g
Size: 87mm (W) x 45mm (D) x 95mm (H)
Working time: 3-4.5 hours
Stand by time: 2 weeks
Warranty Agreement:
This is a Waterproof indoor/outdoor Wireless A2DP Bluetooth
3.0 Speaker With Built-in Microphone. It supports most
Bluetooth cell phones, PDA, tablet PC, iPad, Mac Air, MP3
players, PCs, laptops and any other electronic devices with
Bluetooth function. And, it has double built-in MIC, so you
can enjoy music without the hassle of long cable. You can use
this item at home, office, car and of course in your bath room!
Great suction cup and it’s 5W speaker will offer you a nice
using experience, you will love it! Hook 1PCS
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
