COMISO DIGITAL TECHNOLOGY X26 Wireless speaker User Manual
SHENZHEN COMISO DIGITAL TECHNOLOGY LIMITED Wireless speaker Users Manual
User manual
1. Charging: Please fully charge the speaker for about 7.5~8 hours
before first use.(The indicator light is red when charging, and it will
turn to green after fully charged.) Use the original charging cable to
connect to the power adapter (≧DC 5V/1A) to get charged.
2. Power On/Off: Long press the power button“ ”until the blue
indicator light flashes, then release the power button, the speaker
turns on with a prompt tone.
3. Bluetooth Pairing: After turned on, the blue indicator light keeps
flashing quickly. Then open your smartphone’s Bluetooth function,
search for and choose “X26 ”. After successful paring, you will
hear the“di~di” prompt tone . Now you can play music in your
smartphone with this speaker.
4.Automatic Connection:If you already paired with phone,tablet or
other bluetooth devices,when it turns on (not for the first time), the
speaker will automatically pair with this smartphone.
5.After paired successfully,the blue light flashes slowly,and you can
play music or video via it,and you can check the battery level on
your phone.
6.When you are playing music via bluetooth,short press to
increase the volume, long press to listen next song
7.
“ ”
“ ”
When you are playing music via bluetooth,short press“ ”to
decrease the volume, long press“ ” to listen previous song.
8.When the speaker connected with IOS device, the volume control
is synchronized.
9.After paired successfully,short press“ ”to play and pause.
Precaution
1.It is normal that the speaker will get hot in playing or charging.
3.Do not throw or tread on the speaker. Please place it on a
stable surface when in use.
4.Do not place the speaker close to extremely cold or hot objects.
5.Please use the original accessories provided by us.
7.Do not disassemble the speaker without authorization.
Accessories
USB Charging Cable x 1
Instruction x 1
Hook x 1
Functions
Functions
Functions Troubleshooting
1. The “X26” device is in smartphone’s Bluetooth device list, but failed
to connect.
Reason A: The speaker is not in pairing mode
Solution: Long press the Play/Pause button for about 3 seconds to
set it to pairing mode, when the blue indicator light flashes
fast, choose "X26" to pair.
Solution:Delete the device "X26" in your phone,
then search X26 and choose it to pair again ." "
2. The smartphone could not search X26 ." "
3. The charging time is too long.
R eason : The adapter’s power output is too low, and the charging
Solution: Please choose the adapter with output not less than DC
5V/1A and use the original charging cable.
Warranty Service
We provide following warranty services:
1. 30-day money-back guarantee for any reason: Within 30 days after the
date of purchase, return your undamaged speaker and receive a full
refund for any reason.
2. 18-month warranty for quality-related issues: Within 18 months after
the date of purchase, we take care of all quality-related issues with a
replacement or full refund.
3. Within the warranty validity, we provide free after sale service, except for
A. No original warranty card or valid invoice.
B. The speaker's malfunction or damage is caused by force majeure,
incorrect operation (not as this instruction manual directed) or any
C. The speaker is not purchased from authorized dealer and no
authorized dealer’s stamp on the warranty card.
E. The speaker's malfunction or damage appears during shipment.
F. The speaker’s malfunction or damage is caused by disassembly or
repairing without authorization.
Please ask the dealer to fill the warranty card immediately after
purchasing. We recommend to keep this card for future reference.
Name Age
Tel Num.Postcode
Gender Product
Date of Purchase Product Code
Part Num.Sale Num.
Postal Address
Dealer Stamp:User Signature:
Warning Warranty Card
2.Please turn off the speaker and disconnect it with all audio devices
before cleaning. Do not use alcohol, benzene or other chemicals to
clean the speaker.
Reason B: The speaker’s paired information has been cleared.
Reason : The speaker is not in pairing mode.
Solution: Long press the “Play/Pause” button for about 3 seconds to
set it into paring mode, when the blue indicator light flashes
fast, choose "X26" to pair.
following cases:
D. The date of purchase on the warranty card has been changed.
man-made factors.
10.After paired successfully, when there is a calling,short press
play/pause button to pick up the call by this speaker, long press the
Play/Pause button for 2 seconds to reject this call,and when
answering the call, short press the Play/Pause button to end it.
Redial: double press the Play/Pause button, your smartphone will
redial your last dialed number.
11.Automatic Power Off:the speaker will turn off in 10 minutes in
below situations to save battery power:A.the device is not
connected B:the phone is out of transmission range.C:the
bluetooth is turned off in your phone.
Play/Pause button for 3 seconds until
you hear the “di~di” prompt tone,the blue indicator light will turn
to flash quickly, it means that the smartphone B could search for
“X26” and choose it to pair .
13. Clear Paired Information: The speaker can remember up to 8
device’s pairing information, if you need to clear these information,
turn on the speaker , and long press the Play / Pause button for 6
seconds until you hear the “di~di” prompt tone and the pairing
information list is cleared.
14.TWS connection: Power on the two speakers ,do not pair it with
your phone,first long press “ ”button of each speaker to set
them into the TWS paring mode, and the blue indicator flashes
twice with “di-di”prompt tone after paired successfully. And then
open the bluetooth in your phone to connect one of the X26 to play
music.(NOTE:TWS means True Wireless System)
12. Pair to Another Smartphone: Method A: Turn off the
smartphone A’s Bluetooth function, you will hear the “di~di”
prompt tone and the blue indicator light will turn to flash quickly.
Then the smartphone B can search for “X26” and choose it to pair .
Method B: Long press the
15.Low Battery Warning: When the speaker ’s battery is less than
20%, the red indicator light will flash, then please charge the
speaker.When battery is less than 5%,it will turn off automatically.
16.Charing time:DC 5V/1A,7.5-8 hours, indicator light is red during
charging,and it will turn to green after fully charged.
17. If the speaker is not to be used for a long time, please fully
charge it at least once a month to avoid decreasing the speaker
battery life.
MODEL:X26
Wireless speaker
Mic
Indicator light
Reset
Charging port
TWS pairing
Product Overview
User Instruction
cable’s consumption is too high.
Specifications
CSR4.2+TWS
Output Channel 2.0
Voltage input DC5V/1A
RMS Power 5W*2
Speaker Φ40*2 4Ω5W
Battery lithium 3.7V/4400 mAh
Product Size D70mm * H150.5mm
Product Weight 400g
Bluetooth Solution
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
