INSTALLATIONINSTRUCTIONS

ProgrammableTirePressureMonitorSystem(”P‐TPMS”)SensorAssemblies

VS‐61U003(315MHz)

WARNING

Readallinstructionsandwarnings,andreviewallillustrationsbeforeinstalling.For

reasonsofsafetyandforoptimalfunction,ShanghaiVeiShengAutoParts

ManufacturingCo.,ltd(“Cub”)recommendsthatanymaintenanceandrepairworkis

carriedoutbytrainedexpertsonlyandaccordingtotheguidelinesofthevehicle

manufacturer.Thevalvesaresafety‐relevantpartswhichareintendedfor

professionalinstallationonly.



TheseProgrammableTirePressureMonitoringSystem(”P‐TPMS”)sensorassemblies

arereplacementormaintenancepartsformotorvehiclesthathaveafactory

installedTirePressureMonitoringSystem(”TPMS”)only.Failuretofollowinstallation

instructionsmayresultinthefailureofthemotorvehicleP‐TPMSsensortooperate

properly.Cubdoesnotassumeanyliabilityincaseofthefaultyorincorrect

installationoftheproduct.



CAUTION

EachP‐TPMSsensorisdesignedandmanufacturedtooperateinblankatinitial

statuswhichusingtheproperfrequenciestocommunicatewiththemotorvehicle

TPMsystem.TheoriginalP‐TPMSisblanksoftwareinside,besuretoprogramthe

sensorbyCubGen.3toolforyourspecificmotorvehiclemake,modelandyear

beforeinstallation.OnlyinstallprogrammedP‐TPMSsensorstotheapplicationlisted

inthetool.ImproperTPMSinstallationortheuseofunauthorizedTPMSSensors

causethemotorvehicleTPMSystemtofailtooperateproperly.Donotinstall

programmedP‐TPMSsensorsindamagedwheels.Uponcompletionofinstallation,

testthemotorvehicleTPMSSystemusingproceduresdescribedintheoriginal

manufacturer’sserviceguidetoconfirmproperinstallation.IftheTPMSystemfails

tooperateproperly,checkallinstallationprocedurestoensureproperinstallation

andretest.IftheTPMSSystemcontinuestofailtooperate,immediatelyconsultwith

Cubsupportoranauthorizedmotorvehicledealership.

TheseP‐TPMSsensorassembliesaredesignedandmanufacturedtooperatein

OriginalEquipmentwheelsandtiresonly.IfOriginalEquipmentwheelsand/ortires

arenotused,theTPMsystemandthelowtireinflationwarningthresholdofyour

vehicle’sTPMsystemmaynotfunctionormayfunctioncorrectly.IftheOriginal

Equipmentwheelsand/ortiresarenotsued,itistheresponsibilityofthevehicle

ownertoensurethattheTPMSisworkingcorrectly.RefertotheOriginalEquipment

manufacturer’svehicleserviceguideforinstructionincludingthewarningthreshold

resetprocedureandseektheassistanceofanauthorizedvehicledealershipto

ensuretheTPMsystem,includingsystemcompatibilitywiththenon‐Original

Equipmentwheelsand/ortires,isworkingproperly.Thevehicleownerexpressly

assumessoleandcompleteFailuretoensurethattheTPMSisworkingcorrectlycan

resultinsevereinjuryordeath.



WARRANTY

CubwarrantsthattheP‐TPMSsensorcomplieswithCub’sproductspecificationsand

shallbefreefromdefectsinworkmanshipandmaterialforaperiodoftwelve(12)

monthsafterthesaleofproducttocustomer.Intheeventthatwithintheabove

mentionedwarrantyperiod,Cubconfirmsthataproductisdefective;Cubwill

replacetheproductatnocosttocustomer.Ifitisdeterminedthattheproducthas

beensubjecttoaccident,misuseorabusethiswarrantyandthelimitedobligations

hereunderwillbevoid.THISISTHESOLEANDEXCLUSIVEWARRANTYANDLIABILITY

TOCUSTOMER.CUBEXPRESSLYDISCLAIMSANDOTHERWARRANTYINLUDINGTHE

WARRANTIESOFMERCHANTIABILITY,FITNESSFORPURPOSEOFOTHERIMPLIEDOR

EXPRESSWARRANTIES.UNDERNOCIRCUMSTANCESSHALLCUBBELIABLETO

CUSTOMERFORANIYOTHEAMOUNTSINCLUDINGLABORCHARGESFOR

INSTALLATIONORREINSTALLATIONOFPRODUCTSNORSHALLCUBLIABLEUNDER

ANYTHEORYFORANYOTHERDAMAGESINCLUDINGBUTNOTLIMITEDTODIRECTLY,

INDIRECT,SPECIAL,CONSEQUENTIALANDINCIDENTALDAMAGES.



IMPORTANTWARRANTYINFORMATION

Professionalinstaller:WhenreplacinganentireP‐TPMSsensorassembly,please

completethefollowingP‐TPMSsensorwarrantyinformationgivingonecopytothe

customerandsendtheduplicatecopytotheindicatedaddress.



WARNING:FAILURETOFOLLOWINSTALLATIONINSTRUCTIONSORTHEUSEOF

IMPROPERTPMSSENSORSMAYRESULTINTHEMOTORVEHICLETPMSYSTEM

FAILURECAUSINGPROPERTYDAMAGE,PERSONALINJURYORDEATH.



CUSTOMERTPMSP‐SENSORMulti‐ApplicationSensorInformationCard

(Pleasekeepinmotorvehicleglovebox)



ProfessionalInstaller:Name:PlaceofRepair:Address:Phone:

VehicleOwner:Name:Address:

MotorVehicle:Make:Model:Year:VINNumber:

P‐TPMSsensordateofinstallation:(M)/(D)/(Y)

P‐TPMSsensordatecode.TakedatecodefromP‐TPMSsensorhousing: 

(8digits)



1. Clearvalvestemholeinrimofanycorrosionordirt.Ensurethereisaclean

smoothsurfaceforthematingoftheP‐TPMSsensorscrew(fig.1),rubberwasher

andvalvecoreassembly(fig.3),P‐TPMSwasher(fig.4),andP‐TPMSnut(fig.5)to

therim.

2. RemoveP‐TPMSsensorscrew(fig.1),washers(fig.4)andnut(fig.5)fromP‐TPMS

sensorvalvestemassembly(fig.3)

3. WhileholdingP‐TPMSsensorbody(fig.2),thegrey(plastic)sideofP‐TPMSsensor

facingthetire,pushP‐TPMSsensorvalvestem(fig.3)throughrimbyhanduntil

P‐TPMSrubberwasher(fig.3)meetsinsideedgeofrim.

4. LocktheP‐TPMSsensor(fig.2)andP‐TPMSsensorvalvestemassemblytogether

byscrew(fig.1)

5. HoldP‐TPMSsensorbody(fig.2)downagainsttherimdropcenterand

thread/tightenP‐TPMSsensorwasher(fig.4)andnut(fig.5)to35inch‐pounds，

andtightenP‐TPMSsensorscrewandvalveassembly(fig.3)to9.7inch‐pounds.



No.Part

1P‐TPMSsensorscrew

2P‐TPMSsensor(mountedinsidewheel)

3P‐TPMSsensorvalvestem,rubberwasherand

valvecoreassembly

4P‐TPMSwasher(mountedoutsidewheel)

5P‐TPMSsensornut(mountedoutsidewheel)

6P‐TPMSsensorcap





Eachtimeatireisservicedordismounted,oriftheP‐TPMSsensor(fig.2)is

removed,itisMANDATORYtoreplacetheP‐TPMSsensorwasher(fig.4),P‐TPMS

sensornut(fig.5),andP‐TPMSsensorvalvecore(fig.3)withCUBparts(useonly

CUBservicecomponentkitsdesignedforP‐TPMSsensor)toensureproper

sealing.



ItisMANDATORYtoreplacetheP‐TPMSsensorifitisexternallydamaged.



Warning:TheP‐TPMSsensornutmustbeproperlyinstalledandtightenedfor

properinstallation.Carefullyfollowinstructionsanduseatorquewrenchto

ensureproperinstallation.FailuretotorquetheP‐TPMSsensornutproperlywill

voidthewarrantyandtheTPMSmaynotfunctionproperly.



CorrectP‐TPMSsensornuttorque:35inch‐pounds,correctP‐TPMSsensorscrew

torque:9.7inch‐pounds.

P‐TPMSSENSORAND/ORP‐TPMSSENSORVALVESTEMSBROKENBY

OVERTORQUEARENOTCOVEREDUNDERWARRANTY.FAILURETOACHIEVETHE

NECESSARYP‐TPMSSENSORNUTTORQUEMAYRESULTINANINADEQUATEAIR

SEAL,RESULTINGINTIREAIRLOSS.



SHANGHAIVEISHENGAUTOPARTSMANUFACTURINGCO.,LTD

NO.51,JinwenRoad,ZhuqiaoTown,PudongNewDistrict,Shanghai,PRC

Tel: +86‐21‐33756101Fax:+86‐21‐33754788

Email:sales@cubelec.com.tw

Web:www.cubelec.com.tw



WARNING

Readallinstructionsandwarning,andreviewallillustrationsbeforeinstalling.



Professionalinstallationonly.



Failuretofollowinstallationinstructionmayresultinthefailureofthemotor

vehicleTirePressureMonitoringSystem(“TPMS”)tooperateproperly.



WARNING

FailuretocompleteandreturnP‐TPMSsensorwarrantyinformationwillmakeit

difficultofCubtocontactyouintheunlikelyeventtheP‐TPMSsensorrequires

specialservicing.





IMPORTANTWARRANTYINFORMATIONTOACTIVEWARRANTY,pleasecomplete

thefollowingsectionandsendto:

P‐TPMSsensorwarranty●ShanghaiVeiShengAutoPartsManufacturingCo.,Ltd

●Attn:No.51,JinwenRoad,ZhuqiaoTown,PudongNewDistrict,Shanghai,PRC

201323



ProfessionalInstaller:Name:PlaceofRepair:Address:Phone:

VehicleOwner:Name:Address:

MotorVehicle:Make:Model:Year:VINNumber:

P‐TPMSsensordateofinstallation:(M)/(D)/(Y)

P‐TPMSsensordatecode.TakedatecodefromP‐TPMSsensorhousing: 

(8digits)

PartNumberofsensorbeingreplaced(takefromoldsensorhousing):

Manufacturerofsensorbeingreplaced(takefromoldsensorhousing),circle

selection:

SchraderorAirAware/TRWorEnTireSolutions/Orange/Beru/Lear/IntelliTire/Simens

VDO/Continental/Pacific/other:



ImportantInstallerandCustomerP‐TPMSsensorInformation

Installertoreviewpriortoinstallation.Installertoreviewwithcustomerandkeep

inmotorvehicleglovebox.Photocopyasnecessary.



 UponP‐TPMSsensor’sinstallation,nearlyeveryChryslervehiclemodelyear

2004andlatermustbedrivenforthevehiclerelearnprocess,withnoTPMSscan

toolprocedure(automaticrelearn).

 Forallothervehicles,anelectronicTPMSscantool(alsoknownasatriggeror

relearntool)mustbeusedfortheP‐TPMSsensor’svehiclerelearnprocess.

P‐TPMSsensorsworkwithallmajorTPMSscantoolsincludingCubGen.3tool.

FollowtheOETPMSsensorprocedureonthescantoolforthevehiclerelearn.

 Undercertaincircumstances,theTPMSscantooltriggerbuttonmayneedtobe

pressedmorethanonceorthetoolmayneedtoberesettocompletevehicle

relearnprocess(mayapplytobothP‐TPMSsensormulti‐applicationsensorsand

OEsensors).

 Undercertaincircumstances,theTPMSscantooldisplayduringP‐TPMSsensor’s

triggeringprocessmayshowdifferentinformationversusOEsensors.TPMSscan

toolvehiclerelearnprocessremainsunchanged.

 EachP‐TPMSsensorhasauniqueID#.TheID#canbeobtainedafter

programmingtheblanksensorbyCubGen.3tool.Duetothelargevarietyof

differentvehiclerequirementandtheTPMSscantoolused,thesensorID#on

theTPMSscantooldisplaymaybeinhexadecimalordecimalformatandmaybe

equaltoorfewerthan10‐digit.ThesedifferencesmayresultinanID#onthe

TPMSscantooldisplayduringtriggeringthatappearstonotcoincidewiththe

ID#whichreadonGen.3tool.Thehexadecimalordecimalformatcanbe

transformedbysettingtheCubGen.3tool.Aftertransformingtheformat,

reprogramtheP‐TPMSsensor.BesuretoconfirmtheID#afterthe

reprogramming.

 DuetodifferingTPMSprotocolscalingfactors,tirepressuredisplayedon

electronicTPMSscantoolmaynotbeaccurate(mayapplytobothP‐TPMS

sensorsandOEsensors).Besuretoconfirmtirepressurewithtirepressure

gauge.

 P‐TPMSsensor’smaximumpotentialpressurereadingisapproximately130psi.

P‐TPMSsensorsarenotintendedforhighpressurevehicleapplications.

 P‐TPMSsensorstransmittirepressureandtemperaturedataregularlywhilethe

vehicleisinmotionaboveapredeterminedvehiclespeedthreshold(approx.

15mph(25kph)),oratthetimeoftriggeringbyanelectronicTPMSscantool.



FCCCaution

.Anychangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor

compliancecouldvoidtheuser'sauthoritytooperatethisequipment.

.Thisdeviceanditsantenna(s)mustnotbeco‐locatedoroperatinginconjunction

withanyotherantennaortransmitter.



FCCNotice

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe

followingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,and

(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay

causeundesiredoperation.
