Cadent EA03586 Wireless Foot Pedal User Manual Manual
Cadent Ltd. Wireless Foot Pedal Manual
Cadent >
Manual
iTero HDU
Optical Impression Device
for Intra-Oral Digital
Impression
Operation Manual
Wireless Foot Pedal
P/N EA03586
FCC ID: UZ2EA03586
August
2011
OPERATION MANUAL
iTero HDU Operation Manual Wireless Foot Pedal
2 Publication EA03586-A
Foot Pedal Maintenance
Checking Foot Pedal Battery
The foot pedal unit contains two AA 1.5V batteries. It
is recommended to keep back-up batteries of this type
in your office.
When battery is low, the following indications will be
provided by the system:
Pressing a foot pedal causes no response within
the iTero Scanner software.
A warning dialog requests that the battery be
replaced.
Replacing Foot Pedal Battery
To change the foot pedal battery, follow the instructions below:
1. Open the battery cover
2. Replace batteries with new ones and close the cover.
CAUTION: Be sure to follow local governing ordinances and recycling instructions
regarding disposal or recycling of batteries.
CAUTION: Refer to qualified service personnel for verifying that pedal dongle is
assembly on HDU cart.
English iTero HDU Operation Manual
Publication EA03586-A 3
FCC Radio frequency interference statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Cadent Ltd. is not responsible for any radio or communication interference caused by using other
than specified or recommended cables and battery or by unauthorized changes or modifications
to this equipment. Unauthorized changes or modification could void the user’s authority to
operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
