How to Place ThermoSENSOR™ (TSS-24XX)

Identify an area for ThermoSENSOR™ (TSS-24XX) to be pasted.

1. Place 3 fingers down from the navel.

Refer to diagram.

2. Place the first layer of adhesive dressing about half the distance from the

center to the side of the body.

Refer to diagram.

3. Place ThermoSENSOR™ on another layer of adhesive dressing*.

The second layer of dressing should be pasted over the front of the sensor. Do not paste the

dressing on the metal part of the sensor. You may use any suitable medical adhesive dressing

e.g. 3M tegaderm

4. Place ThermoSENSOR™ (with the second layer of adhesive dressing) over

the first layer of adhesive dressing.

5. For cleaning before use, wipe the ThermoSENSOR™ with an alcohol swab.

Please Note:

Cadi Scientific recommends 3M Tegederm dressing for use with the ThermoSENSOR as

it has been tested to have no adverse effect on the user/ThermoSENSOR.

Please Note:

Changes or modifications not expressly approved by the manufacturer could void

the user’s authority to operate the equipment.

3 fingers

down
