Calix 813GV2-1 GigaHub User Manual 813Gv2 QSG with Safety Viewable indd
Calix Inc. GigaHub 813Gv2 QSG with Safety Viewable indd
Calix >
User Manual
Scan the QR code at left to access the installation instructions for this
product. All product documentation is available online from the Calix
Resource Center (support.calix.com).
P/N 220-01066 Rev 10
813Gv2 GigaHub Quick Start/Safety and
Regulatory Statements Guide
This document provides general installation practices for the GigaHub model 813Gv2.
This document also provides guidance for site preparation, installation, basic troubleshooting, and
safety/Regulatory statements.
Package Contents
GigaHub - Model 813Gv2
Power Adapter (Optional - may ship separately or with UPS*)
Tabletop Mounting Stand
GigaHub Quick Start Guide (this document)
Product identifi cation labels with login credentials (x2)
* NOTE: For instructions on installing the optional UPS, refer to the GigaHub Installa-
tion Guide.
www.calix.com
— 2 —
A Quick Look
Installation Variables
Before installing the 813Gv2 GigaHub, consider what additional services may be implemented.
Various Ethernet and telephone ports are available on the back of the unit which may or may not be
used. Prior to determining the unit’s fi nal location, you need to account for the following variables:
• Where will the telephone lines be routed?
• Where will the Ethernet cables be routed?
• What type of building material is used in the home? Make sure you have the appropriate drills,
drill bits and fasteners for routing subscriber services and/or power cables as they pass through
walls and the like.
Tabletop Mounting
Calix GigaHubs can be mounted on a tabletop in a “tower” confi guration using the tabletop stand
shipped with the product.
Assemble the tabletop stand and the GigaHub as shown in the following diagram.
Line-up GigaHub and
Tabletop Stand as shown.
Allow a 9/16” offset between
the bottom corner of the GigaHub
and the top edge of the Tabletop Stand
1
Slide GigaHub down
onto Tabletop Stand until
flush
2
7077
Push stand to the right while
pulling the GigaHub to the
left until locked into place
3
ETHERNET 2
ETHERNET 1
PHONE 1
PHONE 2
USB
WPS
Model 813Gv2-2
Barrel Power
Connector
Model 813Gv2-1
8-Pin Power
Connector
ONOFF
Power
Broadband
Service
2.4 GHz Wi-Fi
Ethernet (1-4)
Telephone (1-2)
WPS
Reset Button
Telephone Ports (x2)
(RJ-11)
Ethernet Ports (x4)
(RJ-45)
Power On/Off
(Toggle Switch)
Power Adapter Port
Tabletop Stand
7616
POWER
BROADBAND
SERVICE
WiFi 2.4 GHz
ETHERNET 1
ETHERNET 2
ETHERNET 3
ETHERNET 4
PHONE 1
PHONE 2
USB
WPS
Model 813Gv2-2
Only
— 3 —
Connecting the Equipment
In order to facilitate table-top mounting of the 813Gv2 GigaHub, do the following:
1. Remove the 813Gv2 GigaHub from its packaging and inventory all parts.
2. Remove the fi ber access cover and set aside temporarily.
3. Plug in the power adapter to an available wall socket and attach the other end to the Giga-
Hub’s power port.
4. Attach the fi ber pigtail to the bulkhead fi tting on the GigaHub until it snaps into place. Re-install
the fi ber access cover.
5. Push the ON/OFF switch (model 813Gv2-2 only) to ON and allow the GigaHub to boot up
(about 3 minutes).
NOTE: To ensure proper airfl ow around the unit, do not block the sides of the GigaHub.
7742
Reset
ON/OFF POWER1 2 3 4
ETHERNET
1 2
PHONE
WAN Interface
(Fiber)
Power Adapter (110/220 VAC)
Ethernet Cable
Connecting Outside Services
Subscriber voice, IP video and data services are attached to the rear of the GigaHub.
1. Locate the telephone, video, and data cables coming from the home.
2. Connect the incoming telephone lines to the RJ-11 connectors on the rear of the GigaHub.
3. Connect CAT5 or better to the LAN Ethernet (RJ-45) ports for direct-attached devices.
4. Secure all subscriber service wiring as appropriate.
Default Device Settings
Inserted inside the shipping carton of each 813Gv2 GigaHub, the inventory label (x2) provides
necessary product information. This information may be attached to a work order or applied to the
exterior of the device for future reference.
• Serial Number of the 813Gv2 GigaHub
• ONU MAC address
• Default Wi-Fi security type
• Wi-Fi security key (WPA Key)
• Default IP address of the home gateway router (needed at initial turn-up)
• Default login credentials (User Name/Password)
— 4 —
Getting Started
To turn up network services on the 813Gv2 GigaHub, two options are available:
1. Connect an active optical fi ber to the 813Gv2 GigaHub’s bulkhead fi tting, power the unit on,
and allow the network OLT (for example, a Calix E7) to discover the device as an unprovi-
sioned ONT. At the OLT, the network administrator will provision the GigaHub and provide
operational parameters remotely.
2. With the fi ber disconnected, access the Smart Activate or Voice Activate application included
with the 813Gv2 and then enter the Registration ID into the application. With the Registration
ID having previously been entered at the OLT, once the fi ber is connected, the GigaHub will
come up as a provisioned ONT based on the pre-provisioning that was completed for that
Registration ID.
Home Gateway Settings
To turn up home gateway services on the GigaHub, complete the following tasks:
1. Connect your PC to any LAN Ethernet port on the GigaHub using a standard Ethernet cable.
2. Open a browser and enter the IP address of the GigaHubs Embedded Web Interface (EWI):
http://192.168.1.1.
Status Quick Start Wireless Utilities Advanced
Home Logon AboutHelp
3. Enter the credentials provided on the label shipped inside the GigaHub box.
4. Navigate to the Quick Start Menu and set-up the following:
a. Choose how to connect to the Internet
b. Confi gure your 2.4 GHz Wireless Network
c. Set the local time zone (may be automatically set by network)
For more information about device provisioning from the EWI, refer to the GigaHub User’s Guide.
Frequently Asked Questions
Q: How do I reset the device without having to unplug the unit?
A: If the RESET button is depressed for less than 5 seconds, it resets the unit using the current
confi guration settings.
Q: How do I reset the device back to factory settings?
A: Pressing the RESET button on the back of the unit for at least 5 seconds, or access the “Restore
Defaults” reset button located in the “Utilities” section of the Embedded Web Interface.
Q: How does the WPS button work?
A: Pressing the WPS button broadcasts the GigaHubs credentials (network password) to other WPS
capable devices for a period of 2 minutes, allowing these devices to gain access to the wireless
network.
Q: Is the Wireless radio on by Default?
A: Yes.
— 5 —
Q: Is Wireless Security on by Default?
A: Yes, unit is set with WPA2 Key Wi-Fi security type and login/password credentials that are
printed on the inventory label and the product label affi xed to the device.
Q: What if the User Name or login keys are forgotten?
A: Try setting up the wired connection and confi guring the wireless encryption again.
Press the reset button of the wireless router for at least fi ve seconds.
Device reverts to factory default settings
Custom confi guration options (such as SSID names) are reset as well.
Q: My Wi-Fi signal strength is lower than I expected?
A: A wireless signal degrades with distance and obstructions. Common signal impairments
include walls, ceilings, metal, concrete, cinder blocks, fl uorescent lights, microwaves, furniture,
etc. While the 813Gv2 has been optimized to provide wireless coverage for most devices, there
may be dependencies based on the location where the device is installed. Please contact your
service provider for troubleshooting assistance.
Q: What mounting options are available for installing the 813Gv2?
A: The 813Gv2 should be installed using the tabletop stand or wall mount bracket to ensure best
Wi-Fi performance and proper fi ber optic cable management. The 813Gv2 can be installed fl at
on a desktop independent of the tabletop stand. Please ensure that the fi ber optic cable can be
properly routed to the device without excessive bends or pinching of the cable.
Q: What do I do if I cannot log on to the 813Gv2 gateway?
A: Contact your service provider.
Q: Who do I contact for service and support?
A: Contact your service provider.
Safety Information
The 813Gv2 GigaHub is a highly sophisticated electronic device. To get the most out of it, be sure
to read the following text about product care, safety and effi cient use.
• Treat the product with care, keep it in a clean and dust free environment.
• Do not expose the GigaHub to liquid, moisture or humidity.
• Do not expose the GigaHub to extreme high or low temperatures; refer to the topic Environ-
mental Conditions for more detailed information.
• Do not expose the GigaHub to open fl ames or lit tobacco products.
• Do not drop, throw, or try to bend the product, since rough treatment could damage it.
• Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool.
• Do not attempt to disassemble the GigaHub. A broken warranty seal will void the warranty.
The product does not contain consumer-serviceable components. Only Certifi ed Service
Centers should perform service.
• Do not use any accessories other than those approved by the manufacturer or your service
provider. Use of non-original or non-approved accessories may result in loss of perfor-
mance, damage to the product, fi re, electric shock or injury, and may violate regulations.
The warranty does not cover product failures that have been caused by use of non-original
or non-approved accessories.
— 6 —
L’information sur la sécurité
Le 813Gv2 GigaHub est un appareil électronique sophistiqué. Pour tirer le meilleur parti de celui-
ci, assurez-vous de lire ce qui suit sur les soins, la sécurité et l’utilisation effi cace du produit.
• Traitez le produit avec soin, gardez-le dans un environnement propre et exempt de pous-
sière.
• N’exposez pas le GigaHub au liquide ou à l’humidité.
• N’exposez pas le GigaHub à des températures extrêmes élevées ou basses. Se référer à la
partie Conditions environnementales pour des informations plus détaillées.
• N’exposez pas le GigaHub à des fl ammes nues ou à des produits du tabac allumés.
• Ne laissez pas tomber votre appareil, ne le lancez pas et ne tentez pas de le plier, car un
traitement brutal pourrait l’endommager.
• N’utilisez pas ce produit près de l’eau, par exemple, près d’une baignoire, un lavabo, un
évier ou un lavoir, en sous-sol humide, ou près d’une piscine.
• N’essayez pas de démonter le GigaHub. Un sceau de garantie brisé annule la garantie. Le
produit ne contient pas de pièces réparables par le consommateur. Seulement les centres de
service agréés devraient effectuer des réparations.
• N’utilisez pas d’accessoires autres que ceux approuvés par le fabricant ou votre fournisseur
de services. L’utilisation d’accessoires non originaux ou non approuvés peut entraîner une
perte de performance, des dommages au produit, un incendie, des chocs électriques ou des
blessures et peut contrevenir aux règlements. La garantie ne couvre pas les pannes provo-
quées par l’utilisation d’accessoires non standards ou non approuvés.
Potentially Explosive Atmosphere
Do not use the GigaHub in an area where a potentially explosive atmosphere exists.
Atmosphère potentiellement explosive
N’utilisez pas le GigaHub dans un endroit où existe une atmosphère potentiellement explosive.
Intended Use
This product is classifi ed as telecommunication equipment not intended for direct purchase by the
public.
This product is designed and approved for use in an indoor location only.
!
CAUTION! Use of any controls, adjustments, or procedures other than those
specifi ed herein may result in hazardous radiation exposure.
Utilisation prévue
Ce produit est classé comme équipement de télécommunication non destiné à l’achat direct par le
public.
Ce produit est conçu et approuvé pour utilisation en intérieur uniquement.
!
MISE EN GUARDE ! L’utilisation de contrôles, réglages ou procédures autres
que ceux spécifi és dans ce manuel peut entraîner une exposition dangereuse
à des rayonnements.
— 7 —
Power Supply
• Ensure that a suitable AC power outlet is located near the GigaHub and easily accessible.
• Connect the power supply cord only to the AC power outlet that meets the specifi cations
marked next to the appliance AC power inlet on the GigaHub.
• Never alter the AC power cord. If necessary have the correct outlet installed by a qualifi ed
electrician or call your service provider for assistance.
• To reduce risk of damage to the electric cord, remove it from the outlet by holding onto
the AC power adapter rather than the cord. Make sure the cord is positioned so that it will not be
stepped on, tripped over or otherwise subjected to damage or stress
WARNING! Do not use any other power adapter except the one that accompanies
this unit or a power supply identifi ed in the list below. Use of another adpater could
result in damage to the unit. To prevent electrical shock, please do not open the
cover. The following power adapters are qualifi ed to be used with this GigaHub.
813Gv2-2 Power Supply Specifi cation
This GigaHub must be powered by Amigo
AMS115-1201500FU or equivalent UL Listed LPS power source rated at:
Input: 90-264 VAC, 47/63 Hz, 0.8A
Output: Nominal 12 VDC, 1.5A Maximum, 18W
813Gv2-1 Power Supply Specifi cation
This GigaHub must be powered by Amigo
AMS157-1202000FU or equivalent UL Listed LPS power source rated at:
Input: 90-264 VAC, 47/63 Hz, 1A,
Output: Nominal 12 VDC, 2A Maximum, 24W
Alimentation électrique
• Assurez-vous qu’une prise de courant C.A. appropriée est située près du GigaHub et qu’elle
soit facile d’accès.
• Connectez le câble d’alimentation uniquement à une prise de courant qui correspond aux
spécifi cations indiquées à côté de l’entrée d’alimentation du GigaHub.
• Ne modifi ez jamais le câble d’alimentation. Si nécessaire, faîtes installer la bonne prise de
courant par un électricien qualifi é ou contactez votre prestataire de services pour assistance.
• Pour réduire le risque de dommage au câble électrique, retirez-le de la prise de courant en
tenant l’adaptateur secteur plutôt que le câble. Assurez-vous que le câble est positionné de
manière à éviter qu’il soit possible de marcher ou trébucher dessus, ou de l’endommager.
Attention ! N’utilisez pas d’autre adaptateur secteur que celui qui accompagne
cet appareil ou une alimentation électrique autre que celle identifi ée dans la liste
ci-dessous. L’utilisation d’un autre adaptateur pourrait endommager l’appareil.
Pour éviter les chocs électriques, n’ouvrez pas le couvercle. L’adaptateur élec-
trique suivant est qualifi é pour être utilisé avec le GigaHub.
Specifi cations de l’alimentation du 813Gv2-2
L’adaptateur électrique suivant est qualifi é pour être utilisé avec le GigaHub
Ce GigaHub doit être alimenté par un adapteur Amigo AMS115-1201500FU ou une source d’ali-
mentation équivalente certifi ée UL LPS de capacité:
Entree: 90-264 VCA, 47/63 Hz, 0.8A,
Sortie: Valeur nominale 12 VDC, 1.5A Maximum, 18W
— 8 —
Specifi cations de l’alimentation du 813Gv2-1
L’adaptateur électrique suivant est qualifi é pour être utilisé avec le GigaHub
Ce GigaHub doit être alimenté par un adapteur Amigo AMS157-1202000FU ou une source d’ali-
mentation équivalente certifi ée UL LPS de capacité:
Entree: 90-264 VCA, 47/63 Hz, 1A,
Sortie: Valeur nominale 12 VDC, 2A Maximum, 24W
Class 1 Laser Device
WARNING! Optical Safety for Fiber Optic Modules. Never look at the
transmit laser while it is powered on. Never look into the fi ber optic port when
the device is powered on. Never look into the end of the fi ber optic cable at
any time.
Appareil laser de Classe 1
Attention ! Sécurité optique pour les modules de fi bre optique. Ne regardez
jamais l’émetteur laser lorsqu’il est sous tension. Ne regardez jamais dans le port
de fi bre optique lorsque l’appareil est sous tension. Ne regardez jamais dans
l’extrémité du câble de fi bre optique.
Children
Do not allow children to play with the GigaHub. It contains small parts that could become de-
tached and create a choking hazard.
Regulatory Information
!
CAUTION! Changes or modifi cations to this product not expressly approved
by the party responsible for compliance could void your authority to operate
the equipment and invalidate approvals.
!
MISE EN GUARDE ! Les changements ou modifi cations non approuvés
expressément par l’autorité responsable de la conformité peuvent annuler
l’autorisation accordée à l’utilisateur d’utiliser cet équipement.
Environmental Conditions
Maximum environmental values during use:
Temperature: 0° C to +40° C (32° to 104° F), Humidity: 5% to 95% RH, non-condensing
RoHS Compliance
This 813Gv2 GigaHub meets the requirements detailed in the European RoHS Directive
(2011/65/EU).
— 9 —
WEEE Directive
Requirements according to WEEE directive (2012/19/EU)
Disposal of old electrical and electronic equipment (Applicable in the European
countries with separate collection systems).
This symbol on the product indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point
for the recycling of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropri-
ate waste handling of this product. The recycling of materials will help to conserve
natural resources. Calix offers take-back and recycling services for products in
many locations around the world. The customers are advised to contact the local
Calix representative for further information.
Federal Communications Commission (FCC)
INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced technician for help.
NON-MODIFICATIONS STATEMENT
Any changes or modifi cations not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
CAUTION: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condi-
tions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause unde-
sired operation.
For product, available in the USA/Canada market, only channel 1~11 can be operated. Selection of other chan-
nels is not possible.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter except in accordance with FCC multi-transmitter product procedures.
ADDITIONAL CONSIDERATIONS
The country code selection is for non-US models only and is not available on any US models. Per FCC regula-
tions, all Wi-Fi products marketed in the US must be fi xed to US operational channels only.
FCC RADIATION EXPOSURE STATEMENT
This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any
part of your body.
— 10 —
Industry Canada Requirements - English
The manufacturer declares that this product is in conformity with the requirements and other relevant provisions of
the following Canadian standards:
• CAN ICES-3 (B)/NMB-3(B)
• This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to
the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired operation
of the device.
RADIATION EXPOSURE STATEMENT
The product complies with the Canada portable RF exposure limit set forth for an uncontrolled environment and are
safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the
product can be kept as far as possible from the user body or set the device to lower output power if such function
is available.
IMPORTANT NOTE - IC RADIATION EXPOSURE STATEMENT: This equipment complies with IC RSS-102 radia-
tion exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with
a minimum distance of 20cm between the radiator & your body.
Le fabricant déclare que ce produit est conforme aux exigences et aux autres dispositions pertinentes des normes
canadiennes:
• Peut-ICES-3 (B)/NMB-3(B)
• Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisee aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est
susceptible d’en compromettre le fonctionnement.
DECLARATION D’EXPOSITION AUX RADIATIONS
• Le produit est conforme aux limites d’exposition pour les appareils portables RF pour les Etats-Unis
et le Canada etablies pour un environnement non controle.
• Le produit est sur pour un fonctionnement tel que decrit dans ce manuel. La reduction aux exposi-
tions RF peut etre augmentee si l’appareil peut etre conserve aussi loin que possible du corps de
l’utilisateur ou que le dispositif est regle sur la puissance de sortie la plus faible si une telle fonction
est disponible.
• Delete this line and replace it with the following:
• Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un envi-
ronnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20cm de
distance entre la source de rayonnement et votre corps
For Radio Equipment Only
You must set the correct country code with the set WLAN country-code command to avoid violating
local radio spectrum laws. This command sets the selectable channel range and transmit power level
so that a WLAN connection can be established. For more information about country codes, see the
hardware guide for your device.
This device complies with the essential requirements of the Radio Equipment directive: 2014 / 53 / EU. The
following test methods have been applied to prove presumption of conformity with the essential requirements of the
Radio Equipment directive: 2014 / 53 / EU:
EN 300 328 (2.4 GHz), EN 62311:2008, EN 50385, EN 301489-1, EN 301489-17, IEC 60950-1, IEC 60825-1.
FREQUENCIES MAX POWER INDOOR/OUTDOOR
2400-2483.5 100 mW Indoor
RADIATION EXPOSURE STATEMENT
The minimum distance between the user and/or any bystander and the radiating structure of the transmitter is 20
cm.
— 11 —
NOTICE OF WIRELESS RADIO LAN USAGE IN THE EUROPEAN COMMUNITY
BE BG CZ DK This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all
EU member states and EFTA countries, except in France where restrictive use applies. This
device may not be used for setting up outdoor radio links in France and in some areas, the
RF output power may be limited to 10 mW EIR P in the frequency range of 2454 –2483.5
MHz. For detailed information, the end-user should contact the national spectrum authority
in France.
This equipment may be operated in AL, AD, BE, BG, DK, DE, FI, FR, GR, GW, IS, IT, HR, LI,
LU, MT, MK, MD, MC, NL, NO, AT, OL, PT, RO, SM, SE, RS, SK, ES, CI, HU, CY
DE EE IE EL
ES FR HR IT
CY LV LT LU
HU MT NL AT
PL PT RO SE
SK FI SE UK
UISNOTR
CH
Usage Notes
• To remain in conformance with European National spectrum usage regulations, frequency and
channel limitations will be applied on the products per the country where the equipment will be
deployed.
Declaration of Conformity
Language Declaration of Conformity
български [Bulgarian]
С настоящото Calix Inc. Това декларира тази Wireless Broadband Терминал за достъп е в съответствие
с Директива 2014/53 / ЕС.
Пълният текст на ЕС декларацията за съответствие е достъпна онлайн от сайта на декларациите на
Calix (https://www.calix.com/declarations).
hrvatski [Croatian]
OOvime Calix Inc. To izjavljuje ovaj bežični širokopojasni pristup terminala u skladu s Direktivom 2014/53 /
EU.
Puni tekst izjave o sukladnosti za EU je dostupan online od kaliks web deklaracije (https://www.calix.com/
declarations).
English
Hereby, Calix Inc. declares that this Broadband wireless Access Terminal is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available online from the Calix Declarations site (https://
www.calix.com/declarations).
český [Czech]
Tím Calix Inc. Která deklaruje toto Wireless Broadband Access Terminal je v souladu se směrnicí 2014/53 /
EU.
Úplné znění EU prohlášení o shodě je k dispozici online na webové stránce prohlášení kalichu (https://www.
calix.com/declarations).
Deutsch [German]
Hiermit Calix Inc. Das erklärt der Wireless Broadband Access Terminal in Übereinstimmung mit der Richtlinie
2014/53 / EU.
Der vollständige Wortlaut der EU-Konformitätserklärung wird online von den Calix Website Erklärungen zur
Verfügung (https://www.calix.com/declarations).
Eesti [Estonian]
Käesolevaga Calix Inc. See kinnitab seda traadita lairibaühenduse Terminal on kooskõlas direktiivi 2014/53
/ EL.
Tervikteksti ELi vastavusdeklaratsiooni on saadaval võrgus Calix veebilehel deklaratsioonid (https://www.calix.
com/declarations).
español [Spanish]
Por la presente, Calix Inc. Que declara esta Terminal de banda ancha de acceso inalámbrico está en confor-
midad con la Directiva 2014/53 / UE.
El texto completo de la declaración de conformidad de la UE está disponible en línea desde el sitio web
Declaraciones de Calix (https://www.calix.com/declarations).
Ελληνική [Greek]
Δια του παρόντος, Calix Inc. Αυτό δηλώνει αυτό το Wireless Terminal Ευρυζωνική πρόσβαση είναι σε
συμμόρφωση με την οδηγία 2014/53 / ΕΕ.
Το πλήρες κείμενο της δήλωσης συμμόρφωσης ΕΕ είναι διαθέσιμα στο διαδίκτυο από την ιστοσελίδα Calix
Δηλώσεις (https://www.calix.com/declarations).
français [French]
Par la présente, Calix Inc. Cet accès qui déclare haut débit sans fi l terminal est conforme à la directive
2014/53 / UE.
Le texte intégral de la déclaration de conformité C’est disponible en ligne à partir des déclarations de site
Calix (https://www.calix.com/declarations).
Language Declaration of Conformity
Italiano [Italian]
Con la presente, Calix Inc. Che dichiara questo terminale di accesso wireless a banda larga è conforme alla
Direttiva 2014/53 / UE.
Il testo integrale della dichiarazione di conformità UE è disponibile online dal sito Dichiarazioni Calix (https://
www.calix.com/declarations).
Latvijas [Latvian]
Ar šo, Calix Inc. Tas paziņo, šis bezvadu platjoslas piekļuves termināls atbilst Direktīvas 2014/53 / ES.
Pilns teksts ES atbilstības deklarācijas ir pieejama tiešsaistē no Calix tīmekļa deklarācijas (https://www.calix.
com/declarations).
Lietuvos [Lithuanian]
Šiuo dokumentu Calix Inc Tai deklaruoja tai bevielės plačiajuostės prieigos terminalas atitinka Direktyvos
2014/53 / ES.
Visą tekstą ES atitikties deklaraciją galima rasti internete nuo CALIX svetainės deklaracijas (https://www.calix.
com/declarations).
Magyar [Hungarian]
Ezáltal Calix Inc. Hogy kijelenti ezt Wireless Broadband Access Terminal irányelvnek megfelelően 2014/53
/ EU.
A teljes szöveg az EU-megfelelőségi nyilatkozat elérhető online az Calix honlapján Nyilatkozatok (https://
www.calix.com/declarations).
Polski [Polish]
Niniejszym, Calix Inc. Deklaruje, że ten Szerokopasmowy dostęp bezprzewodowy terminal jest zgodny z
dyrektywą 2014/53 / UE.
Pełny tekst deklaracji zgodności UE jest dostępna on-line ze strony internetowej calix deklaracji (https://www.
calix.com/declarations).
português [Portuguese]
Por este meio, Calix Inc. Que declara esta Terminal de Acesso de Banda Larga sem fi os está em conformi-
dade com a Directiva 2014/53 / UE.
O texto completo da declaração UE de conformidade está disponível online a partir de declarações do Web
site da Calix (https://www.calix.com/declarations).
român[Romanian]
Prin prezenta, Calix Inc poate declara que acces de bandă largă fără fi r Terminal este în conformitate cu
Directiva 2014/53 / UE.
Textul integral al declarației de conformitate UE este disponibilă online din calix declarațiile site-ul (https://
www.calix.com/declarations).
slovenščina[Slovenian]
S tem lahko calix Inc. razglasi que širokopasovnega brezžičnega dostopa Terminal je v skladu z Direktivo
2014/53 / EU.
Celotno besedilo izjave EU o skladnosti je na voljo na spletu na spletni strani izjavami calix (https://www.calix.
com/declarations).
slovenský [Slovak]
Týmto Calix Inc. môže vyhlásiť tento que Broadband Wireless Access Terminal je v súlade so smernicou
2014/53 / EÚ.
Úplné znenie vyhlásenia o zhode EÚ je k dispozícii online na webovej stránke vyhlásenie kalichu (https://
www.calix.com/declarations).
License Information
Open Source Software Utilization Notice
The 813Gv2 GigaHub uses Open Source Software Programs. Such software programs are made available subject to
certain third party terms and conditions.
The fact that you are about to begin using or have purchased this product requires that you be informed of the use
of these software packages and or libraries and in some cases, the third party terms and conditions applicable to
such software. This information can be found on the manufacturer’s support portal. Refer to the appropriate software
release notes for additional information on Open Source Software Programs used by this product.
— 12 —
