Cannice Technology A864 Bluetooth Headset / Earbuds User Manual
Shenzhen Cannice Technology Co., Ltd. Bluetooth Headset / Earbuds
user manual
01
02
03
05
06
07
09
04
08
10
11
13
12
14
15
17
18
16
19
21
22
23
* Improper battery replacement can result in explosion hazard and can only
be replaced with batteries of the same type or equivalent type.
*For batteries with removable batteries, batteries must be recycled or
handled properly. Disassembly is not allowed for products that cannot be
removed.
* Do not disassemble, strike, crush or put the battery into fire. Do not
expose the battery to conductive materials, liquids, fire, or high
temperatures.
* Do not allow metal objects to touch the two poles of the battery. Do not
continue to use the battery if it has bulges, leaks, discoloration, odors, or
any other abnormality.
* Do not use the battery after it has been immersed in water.
* If the battery is used improperly, it may explode or leak, causing burns
and other personal injuries. If the battery leaks, it should be carefully
disposed of according to the local laws and regulations concerning
battery disposal.
Battery warning!
Wear Method
Step1：Choose the suitable ear cushions.
Step2：
Wear it in the ear and adjust to a comfortable
position (please note the left and right earbuds).
Safety and care
1.Using earbuds at high to moderate volumes for extended periods
of time will result in permanent hearing damage .It is advised you,keep volume
levels moderate to low at all times for your safety.
2.Do not use while driving a car, cycling, operating machinery, or performing
other
activities that require hearing surrounding sounds.
3.Do not use earbuds in thunderstorm weather, the earbuds m a y n o t w o r k
properly in the condition, and increase the risk of being hit by lightning.
4.Earbuds may not work properly under high t emperature or high
humidity conditions.
5.Do not use any corrosive cleaner/oil to clean the earbuds.
6.Do not remove or modify the earbuds for any reason, as it may cause the
head set to malfunction or burn out.
7.
K e e p t h e e a r b u d s a n d p a c k a g i n g o u t o f r e a c h o f c h i l d r e n .
8.Do not dispose of this electronic design as normal waste when disposing of
it. To reduce pollution and maximize the protection of the Earth's
environment, recycle it.
This document applies to individual product bodies (collectively referred to as "products"). Other
factory-configured parts, accessories and external equipment and other materials (collectively
referred to as"parts") and products or components not covered by this range (such as promotional
items, gifts, and other factory-added parts) are warranted and warranted. Their separate warranty
terms are enforced.
If the product is in normal use and maintenance conditions, performance failure due to material,
process or manufacturing problems, during the warranty period, we will explain according to the
provisions of this document.
"
Normal use and maintenance conditions
"
means that the installation,
use, maintenance, storage, transportation, etc. of the product meet the requirements of the
instructions for use and for a reasonable purpose or use.
"
Influencing normal use
"
means that the
product does not perform the functions it should provide. We will not charge you for the warranty
service unless you have previously stated or legally and agreed to pay the fee. The above are all
warranties for our product quality and service, and no other express or implied warranties. If the
seller or any other third party has an additional commitment to you, you should fulfill the request to
these third parties, and Konexin is not responsible for it.
The corresponding warranty period of the product shall be counted from the date of first purchase of
the product, and the date of purchase shall be based on the invoice date of the purchased product,
and the service shall be guaranteed for one year. In the absence of a valid invoice, the warranty
period will be calculated from the date of manufacture (label on the back or bottom of the product).
In accordance with the notice, Koneyin’s notice is executed in accordance with the notice.
Products or parts that have been repaired or replaced within the scope of warranty will continue to
be covered by the warranty for the remainder of the warranty period. The remaining warranty period
is less than 3 months for 3 months, but for products with an initial warranty of less than 1 year, In the
case, the remaining warranty period is less than 30 days and is calculated as 30 days. If the contract
signed by Konexin and you has otherwise provided for it, it shall be implemented as required.
Dear users：
Thank you for choosing Cannice products and services.
For the products under this document, we will provide you with the following
warranty and warranty services.：
AFTER-SALES SERVICE
NOTE
Method 1
Method 2
Power On
Long press the multifunction button for about 3 seconds in off
state，Stays on white 2 seconds.
Pick up automatic start from the charging box，Stays on white 2
seconds.
Pick up automatic start from the charging box，Stays on white 2
seconds.
Setting Bluetooth
Bluetooth
Device
A864-01
Mobile phones and earbuds
Pairing
Turn on the left and right earbuds respectively. After the two are
automatically connected back, the right earbuds will automatically
enter the pairing state. Select A864-01 from the Bluetooth list of the
mobile phone.
Attention：
1.right earbuds as main earbuds.
2.If the two fail to connect back, the right earbuds will not enter the pairing
state and need to be operated again.
Situation 1：Bluetooth off
Connection lost
Turn off the player device phone Bluetooth Reconnection timeout for 5
minutes, the earbuds automatically Power Off.
Situation2：Out of connection distance
The mobile phone and the earbuds connection is beyond the scope
effectively reconnection timeout for 5 minutes, the earbuds
automatically Power Off.
Volume"＋"
During play or call, click R Headset Multifunction button twice.
Note: This function is not supported when L/R headphones are used alone.
Volume"±"
In play or call, double-tap the L earbuds multifunction button.
Note: This function is not supported when L/R headphones are used alone.
Volume"－"
Pause
In the pause state, click the R/L earbuds multi-function button once.
Music
In playback mode, click the R/L earbuds multi-function button once.
Play
R
Track backward
In the playing state, long press the R earbuds multifunction key
Note: This function is not supported when L/R earbuds are used alone.
In playback mode, long press the L earbuds multifunction button.
Note: This function is not supported when L/R earbuds are used alone.
Track forward Earbuds charging
Charging
put the earbuds into charging box
Charging: Stays on blue
Fully charged: Stays on white
LED status when the charging box charges
the earbuds
The first light flashes when the L earbuds is charged;
The third light flashes when the R earbuds is charges;
When L and R are charged at the same time,
the 1st and 3rd light flash at the same time;
When the earbuds is full, the battery compartment
will show the battery pack power for 5 seconds.
Charging box charging
LED status when charge the charging box
Charging box electricity LED status when not charging
When the power is below 30%, the first light flashes;
When the power is 30%~70%, the first light is always
on, and the second light flashes;
When the power is greater than 70%, the front 2 lights
are always on, and the 3rd light flashing;
When the power is 100%，3 lights are always on .
<10%
10%~30%
30%~70%
70%~100%
When the power is below 10%, the first light flashes;
When the power is 10%~30%, the first light flashes;
When the power is 30%~70%, the front 2 lights are on;
When power is 70%~100%, 3 lights are always on.
<30%
30%~70%
>70%
100%
Dear users, this warranty card is an important certificate for applying for warranty
service. Please fill in and keep it with the seller, thank you!
Product
Information
User Name
E-mail
Contact Address
Phone Number
Postal Code
Product Name
Model Name
Product barcode
Name
Address
Phone Number
Sales Date
Invoice Number
Postal Code
Dealer
Information
Remarks
① This form is confirmed by the dealer stamp；
② For products subject to the relevant warranty;
User
Information
WARRANTY CARD
The number in this logo indicates that the product has an environmental protection
period of 10 years under normal use.
Depending on the model, the product may not include all of the above components,
Based on the actual sales configuration of the product.
This form is prepared in accordance with the provisions of SJ/T 11364.
○：Indicates that the content of the hazardous substance in all homogeneous materials
of the part is below the limit requirement specified in GB/T 26572.
×：Indicates that the hazardous substance is at least in a homogeneous material of the part
exceeding the limit requirement of GB/T 26572.
All parts marked “×” in the table comply with EU RoHS regulations (Directive 2011/65/EU).
Note: The environmental protection period depends on the temperature and humidity
conditions of the normal working of the product.
According to the Chinese electronic industry standard SJ/T 11364 and related Chinese
government regulations, this product and some of its internal or external components may carry
an environmentally friendly service life mark, depending on the component and component
manufacturer, the use of the product and its components. The term identifier may vary. The
expiration date on the component takes precedence over any conflicting or different
environmental use period identifiers on the product.
Harmful Substance
Components Name
Metal Component
Plastic Accessories
Plastic Component
Electric Cable
Board Assembly
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Manual
A864 WARRANTY
SERVICE CARD
www.cannice.com
Packing list
Ear cushions x3
Earbuds x1
USB cable x1
Charging Box x1
Manual/Warranty card
Start
Product overview
1. Charging box LED light
2. USB
3. Multifunction button
4. Earbuds light
5. Talking mic
6. Magnetic charge point
7. Breathable hole
8. L/R logo
4
5
37
8
6
Earbuds answer
Incoming call
Earbuds hangs up
Earbuds refused to answer the call
long press two seconds
Press once
0：35
Press the multifunction
button once.
Long press the multifunction button for 2 seconds.
Press the multifunction
button once when calls.
Method1
Method2
Power Off
In the power on state, Long press the multifunction button for 5
seconds. The red indicator light will be on for 2 seconds
Put the earbuds into the charging box for automatic shutdown
and the blue indicator lights up.
Specification
1. Bluetooth version：Bluetooth V5.0
2. Rated input：5.0V 500mA
3. Frequency Range：20Hz-20KHz
4. Effective wireless range：10m
5. Charging time：1.5h
6. Nominal impedance：32Ω±15%
7. Support protocols：HSP、HFP、A2DP、AVRCP
8. Play time：3.5h（earbuds）+12h（charging box）
9. Drive unit：8mm dynamic speaker
10. Sensitivity（SPL）：98±3dB/mW（IEC-711 at 1KHz）
11. Product performance standards ：GB 4943.1-2011
Restoring left and right ear links
1、Put the separately paired earbuds into the charging box.
2、At the same time, take the left and right earbuds out of the charging
box and they will be automatically paired into the pairing mode.
3、Open the phone to search for "A864-01", click on the link to complete
the use of left and right ear stereo.
Setting
Bluetooth
Bluetooth
device
A864-01
Setting
Bluetooth
Bluetooth
device
A864-01
Monaural use
Monaural Use And Recovery
1、Take out one of the earbuds from the charging box and long press the
multifunction button for 5 seconds until the earbuds lights up blue ( power off ).
2、Long press the multifunction button for 5 seconds until the blue and white
lights flash alternately.
3、Open the phone Bluetooth search "A864-01", click on the link to complete
the monaural use.
long press 5 seconds
long press 5 seconds
344mm
封面
80g书纸，344*258mm，折叠 正面 背面
86mm
258mm
R
L
R
L
The name and content of harmful substances in the product
Bluetooth Headset
