Cannice Technology AS-L Bluetooth Earphone User Manual
Shenzhen Cannice Technology Co., Ltd. Bluetooth Earphone Users Manual
Users Manual
AS INSTRUCTION
Pairing
Pair one phone
1.After power on L/R earphones re-conneted automatically,
than the L earphones enter pairing mode.
2.Activate Bluetooth on your phone (See below for more details).
iPhone
a.On your phone, open the Settings menu.
b.Select Bluetooth. If Bluetooth is off, turn it on.
The iPhone will search for new devices automatically.
Android phone
a.On your phone, open the Settings menu.
b.Select Bluetooth (For old Android phone, Bluetooth is found in the
Wireless & Networks). If Bluetooth is off, turn it on. Select Search for
Devices if your phone does not automatically search for new devices.
Note: When the earphone and phone have been paired once,
they will automatically connect when the earphone is on and
Bluetooth is activated on the phone.
Following items are included
Start here
USB cable
Ear cushions
Do not use earphone in thunderstorm weather, the earphone may
not work properly in the condition, and increase the risk of being hit
by lightning .
Using earphone at high to moderate volumes for extended periods
of time will result in permanent hearing damage .It is advised you
keep volume levels moderate to low at all times for your safety.
Do not use any corrosive cleaner/oil to clean the earphone.
If the earphone comes in contact with liquids, quickly wipe away .If
submersed in water, do not turn the earphone on until completely dried.
Tips: liquid submersion voids the warranty.
Keep the earphone and packaging out of reach of children .
Do not use while driving a car, cycling, operating machinery, or
performing other activities that require hearing surrounding sounds.
Earphone may not work properly under high temperature or high
humidity conditions.
Safety and care
Bluetooth
ON
Se arc h
AS
3. Select "AS". If your phone asks, enter 0000 (four zeros) for the
Pass code or accept the connection. The LED indicator stops flashing
red and blue once successfully paired, you hear "connected".
Some phone list an option to "Play through earphone", select to use the
earphones.
Charging
Your new earphone has enough power to pair and make a few
calls. It takes 2 hours to fully charge the earphone; while charging,
the battery indicator light is red, the indicator light flashes blue
once charging is complete.
Note: The lifetime of the battery will be significantly reduced if
your earphone is left uncharged for a long period. We recommend
that you recharge your earphone at least once a month.
Windows Phone 8
a. On your phone, open the Settings menu.
b. Select Bluetooth. If Bluetooth is off, turn it on.
The Phone will search for new devices automatically.
Bluetooth
ON
Se arc h
AS
Music
Music play / pause
Press Multifunction button once to play / pause music. (Some
phones may require you to start a media player first) .
Switch Music and Call
When a call rings during a music playing, the music automatically
pauses to allow you to answer or ignore the call. Once the call is
ignored or ends, the music is resumed.
(Need media player support).
Volume up / down
In streaming mode or calling mode double press the multifunction
button ,the volume change from small to large step by step ,
from large to small all at once.
Track forward
Press and hold the multifunction button for 2 seconds in streaming state.
Use
Answer a call
Reject a call
Press and hold the Multifunction button for about 2 seconds.
Press the Multifunction button once.
End a call
Charging
Stays on red while charging. Stays on blue after fully charged.
Power on
Power off
Press and hold Multifunction button for about 3 seconds in off state.
The earphone says "power on" and the LED stays blue 2 senconds.
Press and hold Multifunction button for about 5 seconds in open state.
The earphone says "power off" and the LED stays red 2 senconds.
Tips: When the distance between the earphone and phone is beyond
effective range, earphone disconnects with phone. Earphone will power
off automatically once no active for 5 minutes.
Press the multifunction button once.
Product overview
1. Charge jack
2. Multifunction button
3. Talking mic
4. Battery
& Status indicator
1
2
4
3
1
Basic operation
Hard reset
If the earphone cannot be turned on even when fully charged or does
not respond during use, follow the instructions below to reset it.
1.While pressing and holding the multifunction button, connect the
earphone to your PC's USB port or a USB power adapter with the
charging cable.
2.Keep pressing and holding the Multifunction button until the
earphone turns on. The earphone is now reset.
Status indicator
Voice prompts
Power on
Power off
Pairing
/
Instruction
Power on
Power off
Standby
Incoming call
Pairing
Battery low
LED status
Stay blue about two second
Stay red about two second
Flashes blue quickly
Flashes red and blue alternately
Stays on blue
Blue LED turn to Red low Battery,
please charge
Ring tone
234
5678
9 10 11 12
Bluetooth Earphone
