Installation Manual

BM70659installationmanual

Jun17,2011

CANONINC.

MedicalEquipmentDesignGroup

TheImageforinstallationofBM70659Module

FlexibleFlatCable

BM70659Module

RFcoaxilal connector

InstalledinsideDigitalRadiography

■PowerSupplyVoltage

PowersupplyvoltageofBM70659Moduleis3.5V±10%.

Theendproductmustsupplythepowersupplymentionedabove.

■ForU.S.A.andCanada

Thefollowingsentencesareaddedtothelabelofendproduct.

“ContainsFCCID:AZDBM70659,IC:498J‐BM70659“

Thefollowingsentencesareaddedtotheusersmanualofendproduct inEnglishandFrench.

(1)Thistransmittermustnotbeco‐locatedoroperatedinconjunctionwithanyotherantennaor

transmitter.

(2)Theavailablescientificevidencedoesnotshowthatanyhealthproblemsareassociatedwith

usinglowpowerwirelessdevices.Thereisnoproof,however,thattheselowpowerwireless

devicesareabsolutelysafe.LowpowerWirelessdevicesemitlowlevelsofradiofrequencyenergy

(RF)inthemicrowaverangewhilebeingused.WhereashighlevelsofRFcanproducehealth

effects(byheatingtissue),exposureoflow‐levelRFthatdoesnotproduceheatingeffectscauses

noknownadversehealtheffects.Manystudiesoflow‐levelRFexposureshavenotfoundany

biologicaleffects.Somestudieshavesuggestedthatsomebiologicaleffectsmightoccur,butsuch

findingshavenotbeenconfirmedbyadditionalresearch.

XXXXX*hasbeentestedandfoundtocomplywithFCC/ICradiationexposurelimitssetforthforan

uncontrolledenvironmentandmeetstheFCCradiofrequency(RF)ExposureGuidelinesin

SupplementCtoOET65andRSS‐102oftheICradiofrequency(RF)Exposurerules.

*XXXXXisthemodelnameoftheendproduct.

(3)5.15‐5.25GHzbandisrestrictedtoindooroperationsonly.
