ENGLISH

Be sure to read this instructions before you use the equipment.

Keep this instructions on hand for reference to ensure optimum preformance.

CANON ELECTRONICS INC.

1248, SHIMOKAGEMORI, CHICHIBU-SHI, SAITAMA 369-1892, JAPAN

CANON U.S.A. INC.

ONE CANON PLAZA, LAKE SUCCESS, N.Y. 11042, U.S.A.

CANON CANADA INC.

6390 DIXIE ROAD, MISSISSAUGA, ONTARIO L5T 1P7, CANADA

CANON EUROPA N.V.

BOVENKERKERWEG 59-61, P.O.BOX 2262, 1180EG AMSTELVEEN, THE NETHERLANDS

CANON LATIN AMERICA, INC.

703, WATERFORD WAY, SUITE 400 MIAMI, FLORIDA 33126 U.S.A.

CANON AUSTRALIA PTY. LTD.

1 THOMAS HOLT DRIVE, NORTH RYDE, SYDNEY. N.S.W, 2113. AUSTRALIA

CANON SINGAPORE PTE. LTD.

1 HARBOUR FRONT AVENUE #04-01 KEPPEL BAY TOWER, SINGAPORE 098632

CANON HONGKONG CAMPANY LTD.

19TH FLOOR, THE METROPOLIS TOWER, 10 METROPOLIS DRIVE, HUNGHOM, KOWLOON, HONG KONG.

PUB.CE-IE-338-02 0608C0.1 © CANON ELECTRONICS INC. 2007 PRINTED IN JAPAN

*CE-IE-338-02*

MS 300_english_Cover.p65 08.6.5, 2:57 PM1

Copyright

Copyright © 2007 by Canon Electronics Inc. All rights reserved. No part of this publication may be

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or

computer language in any form or by any means, electronic, mechanical, magnetic, optical, chemical,

manual, or otherwise, without the prior written permission of Canon Electronics Inc.

Trademarks

• Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and

other countries.

• ISIS is a trademark of EMC Corporation in the United States.

• Kodak is a trademark of Eastman Kodak Company.

• 3M is a trademark of Minnesota Mining Manufacturing Company.

• TUSCAN is a trademark of the TUSCAN Corporation.

Other brand and product names may be trademarks or registered trademarks of their respective compa-

nies.

FCC REGULATIONS (For 120V models)

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy, and if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation of this equip-

ment in a residential area is likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If

such changes or modifications should be made, you could be required to stop operation of the equip-

ment.

RADIO INTERFERENCE REGULATIONS (For 120V models)

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus

set out in the Interference-causing equipment standard entitled "Digital Apparatus", ICES-003 of the

Industry Canada.

RÈGLEMENT SUR LE BROUILLAGE RADIOÉLECTRIQUE (For 120V models)

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils

numériques de Classe A prescrites dans la norme sur le matériel brouilleur: "Appareils Numériques",

NMB-003 édictée par l'lndustrie Canada.

MODEL NAMES

The following names may be provided for the safety regulations in each sales region of this Microfilm

Scanner.

Model Microfilm Scanner 300II : M31026.

MS 300_english_Cover.p65 08.6.5, 2:57 PM2

1

INTRODUCTION

These instructions describe the operating procedures for the Canon

Microfilm Scanner 300II. After you set up the unit, keep this

manual in a convenient location so you can find it when you need

it.

MS 300_english.p65 07.5.14, 10:141

2

Conventions

A few symbols and notations alert you to additional information

that will make operation of the scanner more efficient, trouble

free, and safe.

(➞P.13)

A number preceded by an arrow and enclosed in parentheses shows

you the page number that contains more information about the

previous statement or paragraph.

WARNING

Warnings are provided for your safety and contain

extermely impotant infoumation. Failure to observe the

instructions provided in a warning could result in death

or serious injury to yourself or your co-workers.

CAUTION

Caution notices are also provided for your safety and

contain important information. Failure to observe the

instructions provided in a caution notice could result in

serious injury to yourself or your co-workers or dam-

age to the equipment.

HEAT CAUTION

There will be cautions for heat injury caused by hot

sections. For your safety, be sure to follow instructions

given in these cautions.

Important

These important notes contain important information

on procedures that must be followed or actions that

must be avoided. Failure to observe a request could

result in damage to the equipment or a malfunction.

Notes

Notes provide additional tips or advice that can save

your time and effort in using the scanner.

MS 300_english.p65 07.5.14, 10:142

3

CONTENTS

INTRODUCTION...................................................................................... 1

Conventions ............................................................................................................ 2

BEFORE YOU BEGIN ............................................................................. 5

Work Safety! ..................................................................................................... 5

Choosing a safe location ................................................................................... 5

Power supply..................................................................................................... 7

Daily handling ......................................................................................................... 8

Features of the Microfilm Scanner 300II ............................................................... 10

About operation modes ..........................................................................................11

Unpacking: What's in the box? ............................................................................. 12

Options.................................................................................................................. 13

Important parts and their functions ....................................................................... 14

Operation panel .................................................................................................... 15

Preparing the carrier ............................................................................................. 16

Preparing the lens ................................................................................................. 17

Fixed lens ........................................................................................................ 17

Zoom lenses.................................................................................................... 17

Checking the lens label ................................................................................... 17

Switching the lens ........................................................................................... 17

Preparing optional printer (for the DMP mode) ..................................................... 19

Preparing the computer (scanner mode) .............................................................. 20

TURNING THE POWER ON/OFF.......................................................... 23

Turning the power on ............................................................................................ 23

Turning the power off ............................................................................................ 23

Scanner recognition .............................................................................................. 24

ABOUT THE SOFTWARE...................................................................... 28

Installing the ISIS/TWAIN driver ........................................................................... 28

Installing CapturePerfect....................................................................................... 29

Using the software ................................................................................................ 30

Using the ISIS/TWAIN Driver .......................................................................... 30

Using CapturePerfect ...................................................................................... 30

About the Reader-Printer mode ............................................................................ 31

Starting up Reader-Printer mode .................................................................... 31

Uninstalling the software ....................................................................................... 33

SETTING THE SCANNER ..................................................................... 34

Loading the film..................................................................................................... 34

Adjusting the image .............................................................................................. 34

Rotating the image .......................................................................................... 34

Enlarging and reducing image size ................................................................. 34

Focusing the image ......................................................................................... 34

MS 300_english.p65 07.5.14, 10:143

4

Selecting the polarity............................................................................................. 35

Brightness adjustment .......................................................................................... 35

Automatic adjustment...................................................................................... 35

Manual adjustment .......................................................................................... 35

Trimming/border removal settings......................................................................... 36

Trimming ......................................................................................................... 36

Border removal................................................................................................ 37

Printing (DMP mode).............................................................................. 38

USER MODE ......................................................................................... 40

User mode setting ................................................................................................. 40

User mode setting functions ................................................................................. 40

Power saver mode .......................................................................................... 40

Hi-speed scanning........................................................................................... 41

Scanning resolution......................................................................................... 41

Cleaning mode ................................................................................................ 41

Switching the operation modes ....................................................................... 41

MAINTENANCE AND TROUBLESHOOTING........................................ 42

Replacing the lamp ............................................................................................... 42

Routine cleaning ................................................................................................... 44

Cleaning the screen and main unit.................................................................. 44

Cleaning the lens ............................................................................................ 44

Cleaning mode ...................................................................................................... 45

Cleaning the Fixing Rollers ............................................................................. 45

Troubleshooting .................................................................................................... 46

User call errors...................................................................................................... 47

Scanner mode ................................................................................................. 47

DMP mode ...................................................................................................... 47

Service Call Errors ................................................................................................ 48

SPECIFICATIONS.................................................................................. 49

INDEX .................................................................................................... 50

MS 300_english.p65 07.5.14, 10:144

5

■ BEFORE YOU BEGIN ... ■

BEFORE YOU BEGIN ...

To ensure safe, efficient operation, read the follow precautions

and recommendations before you choose a location and set up the

system.

Work Safety!

Choosing a safe location

■To ensure adequate space for ventilation, operation, and mainte-

nance, make sure there is enough space around the system on all

sides. To prevent overheating, never block the ventilation slots.

■Avoid exposure to direct sunlight. When exposure to sunlight is

unavoidable, install curtains to protect the unit.

■Avoid a dusty location. Dust can adversely affect the internal parts

of the unit.

■Do not set up and use the unit in a location where the unit is ex-

posed to water, steam, or high humidity. Keep all liquids away

from the unit.

50cm

10cm

10cm

MS 300_english.p65 07.5.14, 10:145

6

■ BEFORE YOU BEGIN ... ■

■Avoid areas like laboratories where fumes from ammonia, acetone,

or other volatile chemicals are present. Never use any kind of

volatile, flammable spray near the unit.

■Never set up the unit in an area where flammable substances like

alcohol, thinner, or other organic chemicals are present.

■Select a flat, stable surface that can support the 26 kg (57.2 lb)

weight of the unit.

■Choose a location that is free of excessive vibration.

■Avoid a location subject to sudden or wide changes in tempera-

ture. Condensation inside the unit can cause poor image quality.

Use the unit in a location within these ranges for temperature and

humidity.

Temperature 10˚C to 32.5˚C (50˚F to 90.5˚F)

Humidity 10% to 80% RH

Use Fileprint in a work environment that is suitable for Fileprint.

■Do not place the unit near large speakers, a radio, a television, or

any other type of equipment that can generate a strong magnetic

field.

MS 300_english.p65 07.5.14, 10:146

7

■ BEFORE YOU BEGIN ... ■

Power supply

If you have any questions about the power source at

your work site, contact your supplier or the power com-

pany.

■The unit should have an independent power source that is not

shared with any other electrical device. If you have to use an ex-

tension cord or power strip, make sure the total ampere rating for

all the equipment does not exceed the ampere rating of the exten-

sion cord.

■Do not place anything on the power cord, and do not locate the

unit where people working around the unit will walk on the cord.

■Do not bundle the power cord or wrap it around an object like a

table or chair leg. The area around the unit should be clear of all

obstacles. In case of an emergency, you should be able to reach

the power source quickly to unplug the cord.

■To remove the power cord from the power outlet, grasp the head

of the plug firmly to remove it. Never pull on the cord to remove

the plug from the power outlet. Never touch the power cord with

wet hands.

MS 300_english.p65 07.5.14, 10:147

8

■ BEFORE YOU BEGIN ... ■

Daily handling

Before using the equipment, make sure you and your co-workers

read the following warnings about using this equipment.

PAY ATTENTION TO THESE WARNINGS! FAILURE

TO FOLLOW THESE WARNINGS COULD RESULT

IN INJURY FROM FIRE OR ELECTRICAL SHOCK!

WARNING

■Always observe these warnings when using the scanner. Failure

to follow these warnings could result in injury due to fire or elec-

tric shock.

■Do not set up the scanner in a location close to flammable sol-

vents such as alcohol and paint thinners.

■Do not cut, damage or modify the power cord, do not pull or bend

the power cord excessively, and do not place heavy objects on the

power cord.

■Never plug in or unplug the power cord with wet hands.

■Do not place objects on top of the scanner as such objects could

fall and cause injury. Do not plug the scanner into a multi-socket

adapter.

■Do not knot or bundle the power cord, and ensure that the plug is

pushed fully into the power outlet.

■Use only the power cord supplied with the scanner.

■Do not attempt to disassemble or modify the scanner. There are

no user-serviceable parts inside the scanner.

■Do not use flammable sprays or aerosols near the scanner.

■Switch the scanner off and unplug the power cord before cleaning

the scanner.

■To clean the unit, use a cloth lightly dampened with water or a

mild detergent.

■If the scanner emits an unusual noise, odor, smoke or sparks, or if

the scanner will not function when switched on, immediately

switch the scanner off, unplug the power cord and contact an au-

thorized Canon dealer or service center.

■Before you move the scanner even a short distance, switch the

scanner off and unplug the power cord.

CAUTIONS

■Do not set up the scanner on sloping, wobbly or otherwise un-

stable surfaces or in locations affected by excessive vibration. The

scanner could cause injury if it falls over or slides off the surface.

■Do not block the ventilation slots as this could result in a fire due

to the build up of heat inside the scanner.

■Do not place vessels containing liquids (cups, vases, etc.) or small

metal objects (paper clips, staples, necklaces, etc.) on top of the

scanner. Liquids or metal objects falling into the scanner could

cause an electric shock or fire. If any liquids or metal objects fall

into the scanner, immediately switch the scanner off, unplug the

power cord and contact an authorized Canon dealer or service

center.

■Do not set up the scanner in dusty or humid locations as this could

result in an electric shock or fire.

■Do not place heavy objects on top of the scanner as such objects

could fall and cause injury.

MS 300_english.p65 07.5.14, 10:148

9

■ BEFORE YOU BEGIN ... ■

■Use only a power supply having the rated voltage. The use of

other voltages could result in a fire or electric shock.

■Always unplug the power cord by grasping the plug itself. Pulling

on the power cord can damage the cord so that the core wires are

exposed or snapped and could cause a fire or electric shock.

■Do not use an extension power cord as this could cause a fire or

electric shock.

■Keep the area around the power outlet free of obstacles to ensure

that the scanner can be unplugged quickly in the event of an emer-

gency.

■Take care not to tip water or flammable solvents such as alcohol,

thinners or benzene into the scanner as this could result in a fire or

electric shock.

■If the scanner will be left unused for a lengthy

period, always unplug the scanner as a safety measure.

■To avoid injury when you are moving the scanner, take care not

to put your hands on the metal protrusions on the underside

of the scanner unit.

HEAT CAUTIONS

■Avoid touching internal scanner components when you perform

routine cleaning or maintenance such as changing the lamp. Some

internal components generate high temperatures or high voltages.

To avoid injury such as burns or electric shocks, take care also

that metal objects such as necklaces or bracelets do not come into

contact with internal scanner components.

MS 300_english.p65 07.5.14, 10:149

10

■ BEFORE YOU BEGIN ... ■

Features of the Microfilm Scanner 300II

❏Space saving

The economical design of this compact film scanner requires less

space on your desk or work table.

❏Internal SCSI-USB converter

SCSI-USB converter is built-in, so you can use both SCSI and

USB interfaces. See “Preparing the computer (scanner mode)”

(➞ P.20)

❏Automatic film polarity detection

The unit automatically detects the presence of negative film or

positive film and sets itself accordingly.

❏Uses a variety of film formats

A wide variety of roll/fiche carriers or auto carriers can be in-

stalled so you can use several film formats like microfiche, aper-

ture card, and roll film.

❏Easy operation

Operations like border removal and image trimming can be per-

formed at the press of a few keys before scanning.

❏Reader-Printer mode (CapturePerfect)

This is a mode which enables the scanner to perform the same

Reader-Printer functions as a Microfilm printer does. Scanned im-

ages can be printed out directly through a designated printer.

❏Expandability

By adding the optional DMP board, sold separately, in the Micro-

film Scanner 300II, the scanner can be used as a Digital Micro-

film Printer (DMP).

Before you use the equipment, make sure you and your co-work-

ers read the following warnings about using this equipment.

MS 300_english.p65 07.5.14, 10:1410

11

■ BEFORE YOU BEGIN ... ■

About operation modes

The following operating modes are available with this scanner.

Select one of the following modes according to your system envi-

ronment before using the scanner. For details, contact your ser-

vice representative.

❏Scanner mode

Using this scanner in connection with a personal computer, the

image projected on the scanner’s screen can be saved in the PC as

image data, or printed out through a printer connected to the PC.

❏DMP mode

By installing the optional DMP board in the scanner and connect-

ing it to a DMP-dedicated printer, the MS300II can be used as a

digital microfilm printer (DMP). The image projected on the

scanner’s screen can be printed out through the DMP-dedicated

printer. In this case, no personal computer is required.

❏Reader-printer mode

Using the CapturePerfect bundled with the MS300II, the scanner

that is set to the Scanner mode will operate as if it is set to the

DMP mode. The image projected on the scanner’s screen can be

printed out directly through a printer connected to the personal

computer. In this case, however, the image cannot be saved in the

PC as image data.

When the DMP board is installed in this scanner, switch

the “DMP mode” and “scanner mode” in the user mode

before use. (➞P.40 “USER MODE”)

If the computer is connected with the user mode set to

“DMP mode” when the DMP board is installed in this

scanner and the MS300II is used as a scanner, the

operation panel may not be operable or other prob-

lems may occur.

MS 300_english.p65 07.5.14, 10:1411

12

■ BEFORE YOU BEGIN ... ■

Unpacking: What's in the box?

When you unpack the box, use the checklist below to make sure

that you have everything. If anything is missing, contact your sup-

plier.

■Microfilm Scanner 300II

■Setup CD

ISIS/TWAIN Driver

CapturePerfect

■USB cable

■Power cord

■Instructions (This manual)

■Canon Software License Agreement

■Warranty Card (U.S.A. and Canada only)

MS 300_english.p65 07.5.14, 10:1412

13

■ BEFORE YOU BEGIN ... ■

Options

In addition to the accessories provided in the product package, a

number of optional accessories that are required for using the scan-

ner, such as carriers and lenses, are also sold, as well as other

optional accessories that can be purchased as needed. Contact your

nearest authorized Canon Dealer for details.

■Carriers (➞P.16 “Preparing the carrier”)

multiple carriers can be used for all types of film, including cartrige

film, microfiche, jacket film and aperture cards.

Since the scanner does not come with a carrier, purchase the car-

rier best suited to your needs.

■Installation Kit (➞P.16“Preparing the carrier”)

Some carriers require an Installation Kit. Contact your nearest

authorized Canon service outlet for details.

■Lenses (➞P.17 “Preparing the lens”)

One fixed-focus lens and five zoom lenses are available for the

Microfilm Scanner 300II. Since the scanner dose not come with a

lens, purchase the lenses best suited to your needs.

■DMP board

This optional board is required to use the scanner in the DMP

mode.

■Fileprint 270/470 (➞P.19 “Preparing optional printer (for the DMP

mode)”)

These printers are DMP-dedicated printers that support the scan-

ner when used in the DMP mode.

■Framing Kit (➞P.36 “Trimming”)

This optional unit allows you to selectibely scan a portion of the

image projected onto the screen. This Framming Kit is required

in order to use the Trimming function provided by the scanner.

MS 300_english.p65 07.5.14, 10:1413

14

■ BEFORE YOU BEGIN ... ■

Important parts and their functions

Before you use the unit, take a few minutes to become familiar

with the names of the important parts.

Screen

Displays images and allows you to view

images before you print them.

DIN connector

Allows you to connect a

cable for the Autocarrier

100C, FS Controller I or

Roll/Fiche carrier 200.

Light adjustment dial

Allows you to adjust the intensity of the light.

Adjust to the magnification power of the inter-

changeable lens.

Operation panel

Provides keys that allow you to perform

settings for image adjustment or film

mode selection.

Power switch

Allows you to turn power on and

off.

Carrier stage

Holds an interchangeable

carriers.

Lamp unit

Holds the lamp for the main source of

illumination. Remove to change the

halogen lamp.

Lens holder

Holds an interchangeable

lens.

MS 300_english.p65 07.5.14, 10:1414

15

■ BEFORE YOU BEGIN ... ■

Operation panel

This is a summary of the keys on the operation panel.

1 Negative/Positive key Three settings are available:

( ) In negative film mode produces positive output from nega-

tive film images.

( ) In positive film mode, produces positive output from posi-

tive images.

( A ) In automatic mode, selects the mode based on the type of

film detected.(➞P.35)

2 Trimming/Border key Use this key to trim the image to be scanned or to remove the

black border around the image.(➞P.36)

3 Brightness indicator Shows the brightness adjusted using the brightness adjustment

key.

4 Brightness adjustment keys Use the or key to adjust brightness of the image manually,

or the use AE key to adjust it automatically. In the DMP mode,

this applies to brightness for printing.

5 Print/Error Display Displays the number of prints (01 to 99) in case of the Reader-

Printer mode. Also displays error message(User and Service

releated).

6 Print number setting key Use these keys to set the number of prints to make for each

image in the Reader-Printer mode or the DMP mode (➞P.11).

Also use them to set various settings or confirm the SCSI ID of

the scanner.

7 Clear/Stop key Stops scanning or resets the number of prints. Also defines an

area for trimming, or defines a specified time for the power

saver mode.

When the scanner is connected to the Fileprint 470 and used in

the DMP mode, this key is also used to switch to the cassette

select mode (➞P.38).

8 Start key In the case of the Scanner mode: press this key to start scan-

ning with the “Panel Start” set to on in the application, or to

start scanning in the Reader-Printer mode (➞P.11).

In the case of the DMP mode: press this key to start printing.

The Print/Error display stays blinking from the time the key is

pressed until the time scanning begins.

MS 300_english.p65 07.5.14, 10:1415

16

■ BEFORE YOU BEGIN ... ■

Preparing the carrier

This is a list of all the carriers that can be installed and used with

the Microfilm Scanner 300II. For more details about these op-

tions, contact your supplier. For details about installation and op-

eration, refer to the instructions provided with each auto carrier.

Some carriers require an optional Installation Kit.

■Fiche Carrier 190RII

A microfish carrier which allows viewing of fiche, jackets, or ap-

erture cards up to 105 mm x 190 mm.

■Autocarrier 100C (AC100C)

A motorized auto carrier for 16 mm cartridge films (ANSI, ANSI

ENCLOSED*1, Kodak Ektamate, 3M) that features fast autoload-

ing and high speed film transport.

■FS Controller I

A motorized auto carrier for 16 mm cartridge films (ANSI, Kodak

Ektamate, 3M). This carrier is required for reading film marked

with blips for automated image search and retrieval.

■Roll/Fiche Carrier 200

A motorized fiche auto carrier for either fiche, jacket, or aperture

card format film, 16mm/35mm film standard open reels or 3M,

TUSCAN M-Type*2 cartridges.

*1 ANSI ENCLOSED cartridge is defined as ANSI MS-15.

*2 TUSCAN M-Type is a TUSCAN cartridge with a 3M-type core.

MS 300_english.p65 07.5.14, 10:1416

17

■ BEFORE YOU BEGIN ... ■

Preparing the lens

The following types of lenses are available.

Fixed lens

EX7 (x7)

Zoom lenses

EZ01 (x9.5 to x16)

EZ02 (x16 to x32)

EZ03 (x30 to x55)

EZ04 (x10 to x24)

Checking the lens label

Report to your dealer if the lens label attached to a lens that you

intend to use differs from a sample shown in the figure below.

Switching the lens

Follow the procedure below to install or exchange lenses.

1. If a lens is already installed, grasp the edge of the holder and

slide it out of the unit.

MS 300_english.p65 07.5.14, 10:1417

18

■ BEFORE YOU BEGIN ... ■

2. Slide the other lens into the unit.

If you are using the FS Controller I, before you insert

the lens, remove the bottom cover of the lens as shown

in the illustration. Make sure you keep the cover and

install it on the lens again after it is removed from the

unit.

3. Turn the light adjustment dial to the left or right to adjust the

light intensity of the screen. Adjust the light intensity to the

type of lens installed.

Set the light intensity adjustment dial to the same mark that is

written on the label of the lens you are using.

Light adjustment dial

Lens Label

MS 300_english.p65 07.5.14, 10:1418

19

■ BEFORE YOU BEGIN ... ■

Canon Fileprint 270

Canon Fileprint 470

Preparing optional printer

(for the DMP mode)

This is a list of all the optional printer that can be installed and

used with the Microfilm Scanner 300II. For more details about

these options, contact your supplier. For details about installation

and operation, refer to the instructions provided with each printer.

• Connecting a printer to the scanner should be per-

formed by a service representative.

• For preparation of the printer, refer to the Fileprint

270 or the Fileprint 470 user’s guides.

MS 300_english.p65 07.5.14, 10:1419

20

■ BEFORE YOU BEGIN ... ■

Preparing the computer

(scanner mode)

In addition to the accessories provided in the product package,

the following are required to use the scanner in scanner mode.

■Hardware requirements

• CPU: Intel Celeron 733MHz or better

• Main memory: minimum of 256MB

• Hard disc space: minimum of 400MB

• SCSI card and SCSI cable, or Hi-speed USB2.0 interface port

• Display: Minimum screen resolution of 1024 x 768 (XGA)

• If you are not sure about the system requirements,

contact an authorized Canon dealer or your com-

puter manufacturer' s support center.

• If your CPU, memory or SCSI board does not meet

the recommended specifications, you may experi-

ence problems such as slow scanning or a slow data

transfer rate.

• Even if your computer meets the above require-

ments, slow scanning may occur depending on the

scanner settings.

■Operating system requirements

Depending on the connection, operating system requirements dif-

fer as follows:

•When using a SCSI card:

• Microsoft Windows 98SE

• Microsoft Windows Me

• Microsoft Windows 2000 Professional SP4 or later

• Microsoft Windows XP Professional SP2 or later

• Microsoft Windows XP Home Edition SP2 or later

•When using a USB connection:

• Microsoft Windows 2000 Professional SP4 or later

• Microsoft Windows XP Professional SP2 or later

• Microsoft Windows XP Home Edition SP2 or later

The scanner does not support USB connectivity with

Windows 98SE and Windows Me. Use a SCSI con-

nection instead.

MS 300_english.p65 07.5.14, 10:1420

21

■ BEFORE YOU BEGIN ... ■

■Connecting via SCSI

When connecting the scanner to a computer using a SCSI card,

use the following SCSI cards and cables.

•SCSI card

Use one of the following recommended SCSI cards:

Adaptec SCSI card (for PCI bus)

• AHA-2930U

• AHA-2940AU

• ASC-19160

• ASC-29160

When installing a SCSI card on your computer, follow the direc-

tions in both the manual for the SCSI card and the computer.

•SCSI cable

• The SCSI connector on the scanner is a half-pitch 50-pin con-

nector (pin-type). No SCSI cable is supplied with the scanner.

To connect the scanner to a computer, obtain a SCSI cable

with the correct connectors for the scanner and the SCSI card

installed in the computer.

• The maximum length of SCSI cables are defined by the SCSI

standard. For details, see the user manual for your SCSI card.

• Only one SCSI port can be used on the scanner

and terminator setting is fixed to ON.

You cannot daisy chain multiple MS300II scanners.

• The SCSI ID for the scanner can be set from ID0 to

ID5. By default, the SCSI ID for the scanner is set to

SCSI ID=2. When changing the SCSI ID setting,

make sure to contact an authorized Canon dealer

or service professional.

• When daisy chaining the scanner with the other SCSI

devices, note the following:

• Change the ID of the other SCSI devices so they

do not to overlap.

• Make sure that the scanner is at the end of the

chain and the terminate setting of the other de-

vices is OFF.

MS 300_english.p65 07.5.14, 10:1421

22

■ BEFORE YOU BEGIN ... ■

■Connecting via USB

USB connectivity is achieved through the use of a SCSI-USB

converter connected to the scanner's SCSI port. Connecting via

USB means that scanning speeds are slightly slower than when

using the SCSI port.

•USB port

• Use the Hi-Speed USB 2.0 port that is equipped normally to

the computer.

• Install the latest Microsoft USB 2.0 drivers. For details, con-

tact an authorized Canon dealer.

• Complete functionality using the USB interface is not guaran-

teed. For details, contact an authorized Canon dealer.

•USB cable

Use the supplied USB cable or a Hi-Speed USB 2.0 cable.

■Connecting to a Computer

Setup, configuration, and connection of the scanner to the com-

puter should be done by the supervising service personnel. To

change the connection or settings, contact an authorized Canon

dealer or service professional.

• The interface cable for connecting to the computer

should match the interface used during setup.

• You cannot use a SCSI and a USB connection at

the same time. Before changing the interface, make

sure to contact an authorized Canon dealer or ser-

vice professional.

■Other

•Software

• The ISIS-compatible application software or TWAIN-com-

patible application software that operate normally on the op-

eration system described above.

• The ISIS/TWAIN driver provided with the scanner is not nec-

essarily compatible with all ISIS-compatible or TWAIN-com-

patible application software. For details, contact your applica-

tion software dealer.

•Printer

The printer that operates normally under your operation system.

MS 300_english.p65 07.5.14, 10:1422

23

■ TURNING THE POWER ON/OFF ■

TURNING THE POWER ON/OFF

Follow the procedures described below when turning the power

on and off.

Turning the power on

Follow the procedure below to turn the unit on.

1. On the front of the main unit, locate the power switch on the

lower left corner then press the I side of the switch to turn the

power on.

2. Turn on the power switch of the computer and printer.

• Switch on the scanner before you switch on the com-

puter.

• The USB port on this scanner uses a SCSI-USB

converter to convert the SCSI port to a USB port.

Even when connecting via a USB port, switch on

the scanner before you switch on the computer.

Turning the power off

Follow the procedure below to turn the unit off.

1. Turn the computer off.

2. To turn the unit off, press the side of the power switch.

• Switch off the computer first before switching off the

scanner.

• The USB port on this scanner uses a SCSI-USB

converter to convert the SCSI port to a USB port.

Do not switch off the scanner while the computer is

on. Do not plug in or unplug the USB cable when

the computer is on.

• If the scanner will not be used for a lengthy period,

unplug the power cord as a safety measure.

MS 300_english.p65 07.5.14, 10:1423

24

■ TURNING THE POWER ON/OFF ■

Scanner recognition

If you are using Windows 98/Me/2000 or Windows XP, then the

first time that you turn on your computer after connecting this

scanner to your computer, Windows Plug and Play automatically

displays a screen prompting you to install the scanner driver. Fol-

low the instructions on the screen to proceed with the installation.

• The device that is detected differs depending on the

connection (SCSI or USB)

• When the scanner is recognized normally, the scan-

ner is recognized by the device manager as “CANON

MS300 SCSI” regardless of the connection used.

• When the connection to the computer is changed,

the scanner recognition may be required.

■In the case of Windows 98/Me

When you are using the Windows 98/Me, only a SCSI connection

can be used. Follow the procedure below to install the scanner driver.

•When you are using Windows 98, “CANON MS300 SCSI

Scanner Device” is detected and “Add New Hardware

Wizard” dialog appears.

1. Click the Next button.

2. Select “Search for the best driver for your device. (Recom-

mended).” and then click the Next button.

3. Load the setup disc into the computer’s CD-ROM drive.

4. Select “Specify a location”, specify the following folder and

then click the Next button.

D:\INF (where “D” is the drive letter assigned to your CD-

ROM drive)

5. Click the Next button.

6. Click the Finish button.

•When you are using Windows Me, “CANON MS300 SCSI

Scanner Device” is detected and “Add New Hardware

Wizard” dialog appears.

1. Select “Specify the location of the driver (Advanced)” and

then click the Next button.

2. Load the setup disc into the computer’s CD-ROM drive.

3. Select “Specify a location”, specify the following folder and

then click the Next button.

D:\INF (where “D” is the drive letter assigned to your CD-

ROM drive)

4. Click the Next button.

5. Click the Finish button.

MS 300_english.p65 07.5.14, 10:1424

25

■ TURNING THE POWER ON/OFF ■

■In the case of Windows 2000/XP

When you are using Windows 2000 or XP, you can use both SCSI

and USB connection.

SCSI connection

Only “CANON MS300 SCSI Scanner Device” is detected.

When using a USB connection, the following devices are

detected in due order.

CANON USB Adapter for MS

↓

CANON USB MassStorage Device

↓

CANON MS300 SCSI Scanner Device

Perform the procedures for each connection and reboot

the computer when all installation are completed.

•If you are using Windows 2000 Professional, “Found

New Hardware Wizard” dialog appears when new de-

vice is detected.

CANON USB Adapter for MS (only when connecting via a

USB port)

1. Click the Next button to proceed to the “Install Hardware De-

vice Drivers” screen.

2. Select “Search for a suitable driver for my device (recom-

mended)” and then click the Next button to proceed to the

“Locate Driver Files” screen.

3. Select “Specify a location” and then click the Next button.

4. Load the setup disc into the computer’s CD-ROM drive.

5. Specify the following folder and then click the OK button.

D:\USB Driver (where “D” is the drive letter assigned to your

CD-ROM drive)

6. Click the Next button.

7. In the “Driver Files Search Results” screen, click the Next

button.

8. On the “Completing the Found New Hardware Wizard” screen,

click the Finish button.

CANON USB MassStorage Device (only when connecting

via a USB port)

1. Click the Next button to proceed to the “Install Hardware De-

vice Drivers” screen.

2. Select “Search for a suitable driver for my device (recom-

mended)” and then click the Next button to proceed to the

“Locate Driver Files” screen.

3. Select “Specify a location” and then click the Next button.

4. Load the setup disc into the computer’ s CD-ROM drive.

MS 300_english.p65 07.5.14, 10:1425

26

■ TURNING THE POWER ON/OFF ■

5. Specify the following folder and then click the OK button.

D:\USB Driver (where “D” is the drive letter assigned to your

CD-ROM drive)

6. Click the Next button.

7. In the “Driver Files Search Results” screen, click the Next

button.

8. If the message “Digital Signature Not Found” appears, simply

click Yes to continue installation.

9. On the “Completing the Found New Hardware Wizard” screen,

click the Finish button.

CANON MS300 SCSI Scanner Device

1. Click the Next button to proceed to the “Install Hardware De-

vice Drivers” screen.

2. Select “Search for a suitable driver for my device (recom-

mended)” and then click the Next button to proceed to the

“Locate Driver Files” screen.

3. Select “Specify a location” and then click the Next button.

4. Load the setup disc into the computer’ s CD-ROM drive.

5. Specify the following folder and then click the OK button.

D:\INF (where “D” is the drive letter assigned to your CD-

ROM drive)

6. Click the Next button.

7. In the “Driver Files Search Results” screen, click the Next

button.

8. If the message “Digital Signature Not Found” appears, simply

click Yes to continue installation.

9. On the “Completing the Found New Hardware Wizard” screen,

click the Finish button.

•If you are using Windows XP, “Found New Hardware

Wizard” dialog appears when new device is detected.

CANON USB Adapter for MS (only when connecting via a

USB port)

1. On the dialog asking you a permission to connect to the Win-

dows Update search site, Select “No, not this time”, then click

the Next button.

2. Load the setup disc into the computer’s CD-ROM drive.

3. In the “Welcome to the Found New Hardware Wizard” screen,

select “Install from a list or specific location (Advanced)”,

and then click the Next button.

4. Select “Search for the best driver in these locations”, and then

clear the “Search removable media (floppy, CD-ROM...)”

check box. Select “Include this location in the search”, specify

the following folder and then click the OK button.

D:\USB Driver (where “D” is the drive letter assigned to your

CD-ROM drive)

5. Click the Next button.

6. Click the Continue Anyway button in the “Hardware Installa-

tion” dialog box.

7. Click the Finish button in the “Completing the Found New

Hardware Wizard” screen.

MS 300_english.p65 07.5.14, 10:1426

27

■ TURNING THE POWER ON/OFF ■

CANON USB MassStorage Device (only when connecting

via a USB port)

1. On the dialog asking you a permission to connect to the Win-

dows Update search site, Select “No, not this time”, then click

the Next button.

2. Load the setup disc into the computer’s CD-ROM drive.

3. In the “Welcome to the Found New Hardware Wizard” screen,

select “Install from a list or specific location (Advanced)”,

and then click the Next button.

4. Select “Search for the best driver in these locations”, and then

clear the “Search removable media (floppy, CD-ROM...)”

check box. Select “Include this location in the search”, specify

the following folder and then click the OK button.

D:\USB Driver (where “D” is the drive letter assigned to your

CD-ROM drive)

5. Click the Next button.

6. Click the Continue Anyway button in the “Hardware Installa-

tion” dialog box.

Although a message appears indicating that the driver

“has not passed Windows logo testing”, simply con-

tinue operation.

7. Click the Finish button in the “Completing the Found New

Hardware Wizard” screen.

CANON MS300 SCSI Scanner Device

1. On the dialog asking you a permission to connect to the Win-

dows Update search site, Select “No, not this time”, then click

the Next button.

2. Load the setup disc into the computer’ s CD-ROM drive.

3. In the “Welcome to the Found New Hardware Wizard” screen,

select “Install from a list or specific location (Advanced)”,

and then click the Next button.

4. Select “Search for the best driver in these locations”, and then

clear the “Search removable media (floppy, CD-ROM...)”

check box. Select “Include this location in the search”, specify

the following folder and then click the OK button.

D:\INF (where “D” is the drive letter assigned to your CD-

ROM drive)

5. Click the Next button.

6. Click the Continue Anyway button in the “Hardware Installa-

tion” dialog box.

Although a message appears indicating that the driver

“has not passed Windows logo testing”, simply con-

tinue operation.

7. Click the Finish button in the “Completing the Found New

Hardware Wizard” screen.

MS 300_english.p65 07.5.14, 10:1427

28

■ ABOUT THE SOFTWARE ■

ABOUT THE SOFTWARE

Before installing the software, be sure to open and read

the Readme.txt file on the setup disc.

The setup disc included with the scanner contains the following

software:

■ISIS/TWAIN driver

This driver allows this scanner to be used with ISIS-compatible

application software or TWAIN-compatible application software.

The driver must be installed in order to be able to use the scanner.

■CapturePerfect

This is a TWAIN-compatible scanning software application. In-

stall this application if necessary.

Installing the ISIS/TWAIN driver

Follow the procedure described below to install the ISIS/TWAIN

driver.

If another ISIS-compatible driver is already installed in

your computer, you must back up the files listed be-

low. These files may be overwritten when you install

this ISIS/TWAIN driver.

C:\Windows\System\pix*.dll

C:\Windows\PixTran\*.*

The name of the “\Windows” and “\Windows\System”

folder varies, depending on which version of Windows

you are using. Substitute accordingly in the above folder

names with the folder names for Windows used in your

system.

1. Turn on your computer. Windows starts.

If you are using Windows 2000 Professional, or Win-

dows XP, be sure to log on as a user with administra-

tor privileges.

2. Load the setup disc in the computer's CD-ROM drive.

3. On the Start menu, Click Run.

The Run dialog box appears.

MS 300_english.p65 07.5.14, 10:1428

29

■ ABOUT THE SOFTWARE ■

4. In the Open box, type “D:\Driver\Setup.exe” (where “D” is

the drive letter assigned to your CD-ROM drive) and then click

the OK button.

The Installer starts.

5. Follow the instructions on the screen and complete the instal-

lation process.

Installing CapturePerfect

Follow the procedure described below to install CapturePerfect.

1. Turn on your computer. Windows starts.

If you are using Windows 2000 Professional, or Win-

dows XP, be sure to log on as a user with administra-

tor privileges.

2. Load the setup disc in the computer's CD-ROM drive.

3. On the Start menu, click Run.

The Run dialog box appears.

4. In the Open box, type “D:\CapturePerfect1.0\Setup.exe”

(where “D” is the drive letter assigned to your CD-ROM drive)

and then click the OK button.

The Installer starts.

5. Follow the instructions on the screen and complete the instal-

lation process.

Selectable languages are “English” or “Japanese.”

MS 300_english.p65 08.6.5, 2:58 PM29

30

■ ABOUT THE SOFTWARE ■

Using the software

Using the ISIS/TWAIN Driver

The ISIS/TWAIN driver help menu describes how to use the ISIS/

TWAIN driver. To access the ISIS/TWAIN driver help, click Start

- Programs (when using Windows XP, click All Programs) - Canon

Document Scanner - Canon MS300/350 Help, or click the Help

button displayed in the dialog box.

Using CapturePerfect

Follow the procedure described below to start and close

CapturePerfect.

The basic method for scanning using CapturePerfect

is described in the CapturePerfect help. From the Help

menu on the CapturePerfect menu bar, click Help, then

refer to the explanation of how to use CapturePerfect.

■Starting CapturePerfect

1. Turn on the scanner.

2. Turn on your computer. Windows starts.

3. Click the “Start” button, and then click “Programs” (when using

Windows XP, “All programs”) – “CapturePerfect 1.0” –

“CapturePerfect 1.0.”

“Multi Scan Setting” and “Multi Scan Start” are functions for

users who connect the Microfilm Scanner 300 via SCSI at the

end of a Microfilm Scanner 300 chain to use it as a multi scan-

ner. For details, refer to the Microfilm Scanner 300 Instructions.

“CapturePerfect 1.0” starts up.

To start CapturePerfect 1.0 Help, click “Help” from the

Help menu on the CapturePerfect menu bar.

Refer to CapturePerfect 1.0 Help on how to use

CapturePerfect 1.0.

■Closing CapturePerfect

1. On the File menu, click Exit.

CapturePerfect closes.

When the scanner is scanning or some operation is

pending after scanning has been started (such as when

scanning has been interrupted), the mouse pointer

changes to an hourglass. If the mouse pointer appears

as an hourglass while the scanner is not scanning, the

previous scanning operation has not been completed.

On the File menu, click Cancel Scanning to cancel

hourglass display, then close CapturePerfect.

MS 300_english.p65 07.5.14, 10:1430

31

■ ABOUT THE SOFTWARE ■

About the Reader-Printer mode

When the scanner is set to the Reader-Printer mode, all the set-

tings and operation of the scanner must be performed through the

operation panel on the main body. For how to operate the scan-

ner, see “SETTING THE SCANNER” (➞P.34).

The Reader-Printer mode is a mode in which the scan-

ner can perform the same functions as an ananlog

Reader-Printer does. In the Reader-Printer mode, im-

ages scanned by the scanner can be directly printed

out through a printer that is designated by the

CapturePerfect. (Note, however, that the scanned im-

ages will not be saved.)

Starting up Reader-Printer mode

The ReaderPrinter Emulation mode is started up from the

CapturePerfect 1.0 menu.

■Setting the Reader-Printer mode

1. Select “Reader-Printer Mode Settings” in the “File” menu and

display the “Reader-Printer Mode Settings” dialog.

For the Reader-Printer Mode Settings, refer to the

CapturePerfect Help.

2. Click “OK” when settings are completed.

■Starting up the Reader-Printer mode

1. Select “Reader-Printer Mode” in the “File” menu to start up the

Reader-Printer mode.

• When the Reader-Printer mode once starts up, the

CapturePerfect main screen is going to reside in the

task tray as the icon.

• The number appearing on the icon indicates the

SCSI ID that the scanner is connected to.

• All settings and operation of the scanner can mostly

be performed through the operation panel on the

main body.

MS 300_english.p65 07.5.14, 10:1431

32

■ ABOUT THE SOFTWARE ■

■Exiting the Reader-Printer mode

1. To change settings of the Reader-Printer mode, click the icon

in the task tray with the right mouse button, then click “Exit Reader-

Printer mode.”

2. Again, click the icon in the task tray with the right mouse

button, then click “Exit application.”

To restart the Reader-Printer mode, click “Start,” and

to change settings, click “Change settings and start.”

MS 300_english.p65 07.5.14, 10:1432

33

■ ABOUT THE SOFTWARE ■

Uninstalling the software

Follow the procedure described below to uninstall the ISIS/

TWAIN driver and CapturePerfect.

If you are using Windows 2000 Professional, or Win-

dows XP, be sure to log on as a user with administra-

tor privileges.

1. On the Start menu, point to Settings and click Control Panel.

If you are using Windows XP on the Start menu, click

Control Panel.

The “Control Panel” window is displayed.

2. Double-click the “Add/Remove Programs” icon.

If you are using Windows XP, click the “Add or Re-

move Programs” icon.

The “Add/Remove Programs Properties” dialog box is dis-

played.

If you are using Windows XP, the “Add or Remove

Programs” dialog box is displayed.

3. Select “Canon MS300/350” or "CapturePerfect 1.0" from the

list, and then click the Add/Remove button.

If you are using Windows XP, click the Change/Re-

move button.

The “Confirm File Deletion” dialog box is displayed.

4. Click the Yes button to start the uninstaller.

Follow the instructions on the screen and complete the

uninstallation process.

MS 300_english.p65 07.5.14, 10:1433

34

■ SETTING THE SCANNER ■

SETTING THE SCANNER

In the Scanner mode, the image projected on the scanner’s screen

can be saved by the connected personal computer, or printed out

through a printer connected to the PC. Actual settings and opera-

tions for scanning differ depending on the application you use.

In the DMP mode, the image projected on the scanner’s screen

can be printed out through a printer connected to the scanner.

Here below explained are various functions that can be set on the

scanner main unit.

Loading the film

Load the auto carrier with the film you want to view. For details

about the auto carrier installation, see the instructions you received

with the auto carrier.

Adjusting the image

Follow the procedure below to adjust the image on the screen.

Read and perform this procedure correctly to attain a crisp image

on the screen and a clear scanned image.

Rotating the image

To rotate the image to the desired angle, rotate the rotation fin ➀

to the left or right.

Enlarging and reducing image size

To make the image larger or smaller, rotate the zooming fin ➁ on

the lens to the left or right.

Focusing the image

To focus the image on the screen, rotate the focusing fin ➂ on the

lens to the left or right.

MS 300_english.p65 07.5.14, 10:1434

35

■ SETTING THE SCANNER ■

Selecting the polarity

This setting selects the film polarity (possitive or negative).

Press the Negative/Positive key on the operation panel to select

the film polarity.

Negative Prints positive from negative film.

Positive Prints positive from positive film.

AAuto Automatically detects the type of film in

use and prints a positive image. If you

select Auto, the Negative or Positive

lamp blinks to tell you which type of film

has been detected.

The EZ-04 zoom lens has no function to automatically

switch between Negative and Positive. When using the

EZ-04 zoom lens, always use the Negative/Positive

switching key to select ( ) Negative or ( ) Positive.

Do not use Auto for an image with a grey or light bor-

der (where black and white may be difficult to distin-

guish), or if you intend to remove the border from the

image, trim the image, or define the area on the image

with the other keys. If you intend to use these special

functions, set Negative or Positive manually.

Brightness adjustment

Adjust the brightness of the image during scanning. The bright-

ness can be adjusted automatically (AE) or manually.

Switching the operation modes can be also set in the

user mode.

Automatic adjustment

Press the AE key on the operation panel. The AE key lights and

the image brightness is adjusted automatically during scanning.

When automatic adjustment is selected, you can make

fine adjustment to the brightness through 17 level by

pressing the brightness adjustment key ( or ).

Moving the indicator to the right brightens the image

by fine increments, and moving it to the left darkens

the image by fine increments.

Manual adjustment

When the AE key is lit, you can use the brightness adjustment

key ( or ) to adjust the brightness of the scanned image. Mov-

ing the indicator to the right brightens the scanned image and

moving it to the left darkens the scanned image.

In manual adjustment, the brightness can be adjusted

through 33 levels, as shown in the figure at left.

MS 300_english.p65 07.5.14, 10:1435

36

■ SETTING THE SCANNER ■

Trimming/border removal settings

When an image on negative film is scanned and projected onto

the scanner screen, the area outside the image appears as a black

border around the image. The Automatic Border Removal func-

tion can be used to remove this black border around the scanned

image.

Trimming allows you to restrict scanning to a specified area of

the image.

Border removal allows you either to remove all the black border

around the image or to leave a narrow black margin around the

image.

• If Positive ( ) is selected as polarity, the Auto-

matic Border Removal function cannot be carried

out.

• In the ISIS/TWAIN Driver or CapturePerfect, “Trim-

ming” is called “Framing”, and “Automatic Border Re-

moval” is called “Auto-detection”.

Trimming

Press the border key on the operation panel until the ( ) indica-

tor lights and then scan the image. Follow the procedure below to

define the area to the image to be scanned.

Adjustment or modifications to the triming area should

be made from the application software before scan-

ning begins or while scanning is paused.

■Defining an area for trimming

1. Press and hold down the Trimming/Border key for approximately

2 seconds until the lamp for trimming ( ) starts blinking.

The current area setting is shown in the display.

2. To adjust the area setting, press the Print Number Setting keys.

The starting point or origin for defining the screen area is the lower

right corner of the screen.

Plus key Press to move in the vertical direction. The

number in the Print display shows the current

screen vertical coordinate.

Minus key Press to move in the horizontal direction. The

number in the Print display shows the current

horizontal coordinate.

MS 300_english.p65 07.5.14, 10:1436

37

■ SETTING THE SCANNER ■

For example, the illustration shows the vertical set for 4 and the

horizontal set for 7. The shaded area is the area trimmed and se-

lected for scanning.

3. To save the setting, press the Border Button. The setting remains

in effect even after the power is turned off and turned again.

■Using the area setting cursors (optional)

With the optional Framing kit installed, you can set an area for

printing, using the guides on the right side and the bottom of the

screen. The area framed by 4 cursors will be scanned.

Border removal

Border removal allows you either to remove all the black border

around the image or to leave a narrow black margin around the

image.

■Removing the entire border

Press the border key on the operation panel until the ( ) indica-

tor lights and then scan the image.

■Leaving a margin around the image

Press the border key on the operation panel until the( ) indica-

tor lights and then scan the image. The margin is specified in the

application software.

• Border removal may not operate correctly for im-

ages with ill-defined borders.

• This function cannot be used when any part of the

image is outside the specified range.

• If multiple images are displayed on the screen at

the same time, the wrong image may be scanned.

• This function can only operate if there is a clear area

of at least 5 mm around the image.

3. Press the Print Number Setting key (+ or –) to set the [DATE,

TIME].

MS 300_english.p65 07.5.14, 10:1437

38

■ Printing (DMP mode) ■

Printing (DMP mode)

The following describes the printing procedure in the DMP mode.

1. Make necessary settings on the main unit.

2. Select the paper size that you want to print on.

■Using the Fileprint 270

If using the Fileprint 270, select paper size set on the multi-pur-

pose tray.

(1) Press the Cassette Select key or the Clear/Stop key for about 3

seconds to enter the paper size setting mode. The current pa-

per size then appears on the Print/Error display.

Display Setting

A4

Letter

B5

Legal

(2) When you press the plus (+) key of the Print Number Setting

key, the display changes as A4➞11➞b5➞14 in due order,

and if you press the minus (–) key, 14➞b5➞11➞A4 in due

order.

(3) Press the Clear/Stop key to define the paper size that you want

to use.

■Using the Fileprint 470

If using the Fileprint 470, select a paper cassette or the multi-

purpose tray to use.

The paper size to be set on the multi-purpose tray will

be selected by a service technician during the installa-

tion of Fileprint 470.

(1) Press the Clear/Stop key for about 5 seconds to enter the paper

cassette select mode. The current paper cassette then appears

on the Print/Error display.

Print/Error Display Tray selection

Multi-purpose tray selected

Upper cassette selected

Lower cassette selected

(2) When you press the plus (+) key on the Print Number Setting

key, the display changes as C0➞C1➞C2➞C0 in due order,

and if you press the minus (–) key, C0➞C2➞C1➞C0 in due

order.

(3) Press the Clear/Stop key to define the paper size that you want

to use. The Print/Error display then returns to “01.”

MS 300_english.p65 07.5.14, 10:1438

39

■ Printing (DMP mode) ■

3. Set the number of prints that you want to make (1 to 99).

Press the Print Number Setting key on the operation panel or

the operation keyboard to set the number of prints. If you press

the plus (+) key, the number increases, and if you press the

minus (–) it decreases.

If you want to change the number you have already

set, press the Clear/Stop key (C/ ) to reset the num-

ber to 1, and then set the number of prints you want to

make once again.

4. Make the Print mode settings if required.

5. Press the Start key on the operation panel or the operation

keyboard to start printing.

You can cancel printing at any time by pressing the

Stop/Clear key (C/ ).

MS 300_english.p65 07.5.14, 10:1439

40

■ USER MODE ■

USER MODE

In the user mode, you can arbitrarily change the settings of the

following features:

• Power saver mode

• Hi-speed scanning mode

• Scanning resolution

• Cleaning mode

• Switching the operation modes (DMP mode/Scanner mode)

User mode setting

1. Press the AE key about 2 seconds.

The LED of the AE key and the Print/Error display blink.

The power saving mode currently set will be displayed on the

Print/Error display.

2. Press the Brightness Adjustment key ( or ) to move the

blinking LED up to the point where a mode, of which settings

you want to change, is located.

Power saver mode

Hi-speed scanning mode

Scanning resolution

Cleaning mode

Switching the operation modes

(DMP mode/Scanner mode)

3. Press the Print Number Setting key (+ or –) to select the set

ting of each mode.

4. Press the Clear key to difine the setting.

User mode setting functions

Power saver mode

When the MS300II has not been operated for a specified length of

time, the scanner switches into standby mode and stops project-

ing the image on the screen to save power consumption.

: Does not switch into the power saver mode.

: Switches into the power saver mode if not operated more

than 15 minutes. (set at the factory before shipping)

: Switches into the power saver mode if not operated more

than 60 minutes.

MS 300_english.p65 07.5.14, 10:1440

41

■ USER MODE ■

• Default of the power saver mode at factory shipping

is set to so that the unit switches into the power

saver mode if not operated more than 15 minutes.

• The power saver mode can be canceled by any key

operation.

• When the FS Controller I is attached, the unit can-

not switch into the power saver mode.

Hi-speed scanning

This feature is available in the DMP mode and enables you to

speed up scanning by simplifying the startup operation.

: Normal mode (set at the factory before shipping)

: Hi-speed scanning mode

In the hi-speed scanning mode, the scanner delivers

printouts of the images upside down.

Scanning resolution

When using the DMP mode, you can select one of the following

scanning resolutions.

: 600DPI

: 300DPI (set at the factory before shipping)

Cleaning mode

This mode is enabled when the scanner is connected to the Fileprint

470 and used in the DMP mode so as to clean the fixing rollers of

the printer. (➞ P.45 “Cleaning mode”)

: Normal mode (set at the factory before shipping)

: Cleaning mode (Cleaning paper: A4 sized)

: Cleaning mode (Cleaning paper: Letter sized)

You need to prepare a sheet of paper of the size se-

lected for cleaning and print the cleaning pattern on

the paper before you start cleaning the fixing rollers.

Switching the operation modes

This feature is enabled when the optional DMP board is installed

in the scanner so as to switch to either of the following modes.

: Scanner mode

: DMP mode (set at the factory before shipping)

The MS300II can be used as a scanner even if the

operation mode is set to the [DMP mode]; however,

the Reader-Printer mode will be disabled in this case.

To enable the Reader-Printer mode, be sure to switch

to the [Scanner mode].

MS 300_english.p65 07.5.14, 10:1441

■ MAINTENANCE AND TROUBLESHOOTING ■

42

MAINTENANCE AND

TROUBLESHOOTING

This part of the manual describes how to replace the halogen lamp,

cleaning the scanner and dealing with errors. Regular scanner

maintenance is essential to eusure optimum performance and a

long service life from your scanner.

Replacing the lamp

The lamp projects the film image onto the screen, and the proce-

dure for replacing the lamp is described below, along with some

precautions to be observed when handling the lamp unit. If the

lamp burns out, use the procedure below to replace it.

When the lamp burns out, “LP” appears on the Print/Error dis-

play.

HEAT CAUTION

Immediately after the lamp burns out, the lamp and

the metal components of the lamp unit are very hot. To

avoid being burned, allow the lamp ample time to cool

down before touching it. The lamp will cool down more

quickly if you leave the scanner switched on for some

minutes with “LP” displayed. After checking that the

lamp and the metal components have cooled down,

proceed with lamp replacement.

1. When the lamp burns out, leave the scanner switched on for

several minutes until the lamp has cooled down.

After waiting at least 5 minutes, check that the lamp

has cooled down and then switch the scanner off.

2. Firmly grip the lamp unit on the right side of the main unit and

slowly pull the lamp unit out.

When you remove the lamp unit, “L5” appears in the

Print/Error display.

CAUTION

To avoid injury, do not touch the interior of the main

unit after you have removed the lamp unit.

3. Push the lever on the side of the lamp and remove the burned

out lamp.

HEAT CAUTION

Immediately after the lamp burns out, the lamp and

the metal components of the lamp unit are very hot.

Never handle the lamp or lamp unit while they are still

hot.

MS 300_english.p65 07.5.14, 10:1442

43

■ MAINTENANCE AND TROUBLESHOOTING ■

Check that there

is no gap between

the lamp and the

lamp socket.

4. Fit the new lamp so that the manufacturer’s mark is facing

upwards and check that the lamp is fully inserted into the socket

so that there is no gap between the lamp and the lamp socket.

• Use only Canon-specified lamps as replacements.

• Take care not to touch the bulb in the new lamp.

Soiling or fingermarks on the bulb can adversely

affect image quality and shorten the service life of

the bulb.

• Always check that there is no gap between the lamp

and the lamp socket. Any gap between the lamp

and the lamp socket will result in damage to the lamp

holder.

5. Insert the lamp unit into the main unit with firm, even pres-

sure until it locks into place.

MS 300_english.p65 07.5.14, 10:1443

■ MAINTENANCE AND TROUBLESHOOTING ■

44

Field lens

Routine cleaning

Use the routine cleaning procedures described below to keep the

scanner components clean and ensure optimum performance.

Cleaning the screen and main unit

Use a cloth slightly dampened with water or mild detergent to

clean any soiling off the scanner screen and casing. Then wipe the

scanner with a clean dry cloth.

To avoid damaging the casing of the main unit, never

clean the unit with an organic solvent such as thinners.

Cleaning the lens

1. Switch off the scanner and remove the carrier and lens unit.

2. Gently wipe off the field lens with a clean soft cloth.

3. Carefully remove the lens from the lens unit and wipe the up-

per and lower surfaces of the lens with a clean dry cloth.

MS 300_english.p65 07.5.14, 10:1444

45

■ MAINTENANCE AND TROUBLESHOOTING ■

Cleaning mode

Cleaning mode is a mode for cleaning the Fileprint 470’s fixing

rollers. Clean the fixing rollers in the Fileprint 470 if black spots

appear on the front or back of the paper that is printed out.

The following describes the procedure for cleaning the fixing roll-

ers. Refer to the user’s guide for the Fileprint 470 for information

about taking care of the Fileprint 470.

Cleaning the Fixing Rollers

1. Select the Cleaning mode in the user mode settings.

The paper size currently selected will be displayed on the Print/

Error display.

2. Open the multi-purpose tray of the Fileprint 470 and set a sheet

of paper of the selected size on it.

3. Press the Start key. The cleaning paper will be printed out and

[CL] will be displayed on the printing count indicator.

Cleaning paper

To reset the Cleaning mode midway, press the Clear/

Stop key before pressing the Start key. Once the clean-

ing paper is printed out, you cannot reset the Cleaning

mode midway; therefore, you must go through the en-

tire cleaning procedure for the fixing rollers till the end.

4. Set the cleaning paper on the multi-purpose tray facing the

printed side down and pointing the arrow inward.

5. Press the Start key to start cleaning the fixing rollers.

Cleaning the fixing rollers requires about 75 seconds.

Other operations cannot be done while the fixing roll-

ers are being cleaned, so do not touch anything.

6. When the cleaning is completed, the Print/Error display will

return to normal.

If black spots still appear on the front or back of the

printouts after the fixing rollers are cleaned, instead of

using printed cleaning sheets, put blank A4 size paper

in the multi-purpose tray and clean them again.

MS 300_english.p65 07.5.14, 10:1445

■ MAINTENANCE AND TROUBLESHOOTING ■

46

Troubleshooting

If you detect a problem during operation of the main unit, check

the list of problems and possible solutions below.

Problem Solution

Screen does not come on, even after turning • Check that the lamp unit is properly fitted into the main unit.

on the power switch. • Check whether the lamp has burned out. When the lamp is

burned out, “LP” appears on the Error/User Mode display. If the

lamp has burned out, fit a new lamp. (➞P.42 “Replacing the

lamp”)

The screen brightness is uneven or the • Check the lens and make sure it is clean. (➞P.44 “Routine clean-

screen is too dark. ing”)

• Check the lens and make sure it is securely installed. (➞P.17

“Preparing the lens”)

• Check the lamp and lamp unit and make sure both are installed

securely. (➞P.42 “Replacing the lamp”)

• Check the setting of the Light Adjustment dial and make sure it

is set correctly for the type of lens installed. (➞P.17 “Preparing

the lens”)

Image is out of focus. • Rotate the focus fin on the lens to adjust the focus. (➞P.34 “Ad-

justing the image”)

• Check the lens and make sure that it is installed correctly.

• Check the carrier and make sure that it is installed correctly. For

details, read the instructions you received with the carrier.

• Check the lens and lamp and make sure they are clean. If re-

quired, clean the lens or lamp.

Image is skewed. • Rotate the rotation fin on the lens to adjust the image. (➞P.34

“Adjusting the image”)

• Check the carrier and make sure that it is installed correctly. For

details, read the instructions you received with the carrier.

Splices are seen on the image after a few scans. • This is one of the specifications to complement insufficient per-

formance of a currently connected computer. Upgrade the com-

puter performance to ease this phenomenon.

• System resource or work memory of the computer is insufficient.

Close all applications and reboot the computer. When using the

MS300II, it is recommended that all other applications be closed.

After pressing the start key, scan will not start. • Check that the computer is switched on and has started up

correctly.

• If the display shows a User Call Error, look it up in the table.

(➞P.47 “User call errors”)

• If the display shows a Service Call Error, look it up in the table.

(➞P.48 “Service Call Errors”)

MS 300_english.p65 07.5.14, 10:1446

47

■ MAINTENANCE AND TROUBLESHOOTING ■

User call errors

Here is a list of User Call Errors. If you see a User Call Error in

the Print display, look it up in the table below.

Scanner mode

Error Number Meaning

LP The lamp installed in the scanner

has burned out.

L5 The lamp unit is not correctly in-

stalled in the scanner.

DMP mode

Error Number

Meaning

P0 After removing a piece of jammed

paper, a sheet of paper is still

jammed in the printer.

P1, P2 A sheet of paper has jammed inside

the printer.

LP The lamp installed in the scanner

has burned out.

L1 Paper is not set in the printer.

L2 Toner in the toner cartridge is low,

or the toner cartridge is not installed

correctly.

L4 The printer cover is open.

L5 The lamp unit is not correctly in-

stalled in the scanner.

L8 Wrong paper size in printer multi-

purpose tray.

L9 The printer is not turned on, or a test

print is being done.

Solution

Remove the jammed sheet from the printer. For details,

refer to the printer manual.

Remove the jammed sheet from the printer. For details,

refer to the printer manual.

Replace the new lamp. (➞P.42 “Replacing the lamp”)

Supply paper to the paper cassette of the printer. For

details, refer to the printer manual.

Remove the toner cartridge and install it again. If the

message appears again, replace the toner cartridge. For

details, refer to the printer manual.

Close the printer cover and make sure it locks in place.

For details, refer to the printer manual.

Check the lamp installation and make sure it locks in place.

If the error occurs again, replace the halogen lamp.

(➞P.42 “Replacing the lamp”)

Re-load the tray with the correct paper size, or change

the paper size of the paper tray. (➞P.38“Printing DMP

mode”)

Turn on the power. Wait until the test print finishes and

then do the operation. For details, refer to the printer

manual.

Solution

Replace the new lamp. (➞P.42 “Replacing the lamp”)

Check the lamp installation and make sure it locks in place.

If the error occurs again, replace the halogen lamp.

(➞P.42 “Replacing the lamp”)

If “L1” is displayed while Fileprint 270 is printing, after

the paper stops feeding press the Clear/Stop key to

clear the error display and then press the Start key to

start printing again.

MS 300_english.p65 07.5.14, 10:1447

■ MAINTENANCE AND TROUBLESHOOTING ■

48

Service Call Errors

Every time you turn on the main unit, the unit automatically per-

forms a self-diagnostic test. If the unit detects a problem at power

on, or at any other time during operation, it will display a Service

Call Error message in the display. A Service Call Error is indi-

cated by an error code consisting of an “E” followed by three

digits (“Ennn” where “n” indicates a number). This code is dis-

played in 2 parts as “En” followed by “nn”. (Eg. “E123” is dis-

played as “E1” followed by “23”.)

Follow the procedure below when a Service Call Error occurs.

1. Immediately switch off the scanner and wait several minutes.

2. Switch the scanner on again and check the scanner status.

When a service call error occurs, it is sometimes pos-

sible to resolve the problem simply by switching the

scanner off for a while and then switching it on again.

■If the “E000” (fixer error) is displayed

The service call error “E000” is a printer fixer error. Switch off

the scanner and any peripheral units such as the carrier, unplug

the power cord and contact an authorized Canon service techni-

cian.

■When you cannot clear a service call error

Make a note of the error code and the nature of the problem. Then

switch off the scanner and any peripheral units such as the carrier,

unplug the power cord and contact an authorized Canon service

technician.

MS 300_english.p65 07.5.14, 10:1448

49

■ SPECIFICATIONS ■

SPECIFICATIONS

Microfilm Scanner 300II

Main Unit

Type Desktop digital microfilm scanner

Screen 300 mm x 300 mm

Scanning method 600 dpi digital scanning

Film Negative, Positive, Negative/Positive auto switching

Lens magnification x7,x9.5-x16, x16-x32, x30-x55, x10-x24, x20-x48

Light source Halogen lamp (20V 150W)

Film

Type Silver film, Diazo film, (blue/black)

Base density 0.6 to 1.4 for negative, 0.3 or less for positive

Image Adjustment

Focus/zoom Manual

Rotation 360˚ manual

Scanning

Scan size (USA or Canada) A4, Letter, Legal

Scan size (other areas) A4

Density control AE, Manual

Scan options Automatic border deletion, Trimming

Printing

Print Size (USA, Canada) A4, Letter, legal

Print Size (other areas) A4

Density control AE, manual

Continuous printing 1 to 99

Print options Automatic border deletion, Trimming

General

Power AC 120V 60 Hz

AC 220-240V 50/60 Hz

Power consumption 120V 2.0A

220-240V 1.2A

Acoustic noise level Less than 66 dB

Work environment Room temperature: 10˚C to 32.5˚C (50˚F to 90.5˚F)

Humidity: 10% to 80%RH (without condensation)

Dimensions 668 x 442 x 541 mm (H x W x D)

Weight Approx. 26 kg

Options

Fixed lens EX7 (x7)

Zoom lenses EZ01 (x9.5-x16), EZ02 (x16-x32), EZ03 (x30-x55), EZ04 (x10-x24)

Carriers FC 190 RII, AC 100C, FS Controller I, Roll Fiche Carrier 200

Installation Kit

Foot switch

Printer Fileprint 270, Fileprint 470

Specifications are subject to change without notice.

MS 300_english.p65 07.5.14, 10:1449

50

■ INDEX ■

A

Adjusting ............................................................... 34

AE .......................................................................... 35

Auto ....................................................................... 35

B

Border removal ............................................... 36, 37

Brightness .............................................................. 35

C

CapturePerfect ....................................................... 10

Carrier

Autocarrier 100C ............................................... 16

Fiche Carrier 190RII.......................................... 16

FS Controller I ................................................... 16

Roll/Fiche Carrier 200 ....................................... 16

Carrier stage........................................................... 14

Carriers .................................................................. 13

Cleaning................................................................. 44

Cleaning mode ....................................................... 45

D

DIN connector ....................................................... 14

DMP board ............................................................ 13

DMP mode............................................................. 11

F

field lens ................................................................ 44

Fileprint ................................................................. 13

Fileprint 270 ................................................... 19, 38

Fileprint 470 ............................................ 19, 38, 45

Film........................................................................ 34

Focusing ................................................................ 34

Framing Kit ........................................................... 13

FS Controller I ....................................................... 18

I

Installation Kit ................................................ 13, 16

ISIS/TWAIN Driver ........................................ 28, 30

L

lamp ....................................................................... 42

lamp socket ............................................................ 43

Lamp unit................................................. 14, 42, 46

Lens ....................................................................... 13

lens

Fixed lens........................................................... 17

Zoom lens .......................................................... 17

Lens holder ............................................................ 14

Lens label........................................................ 17, 18

Light adjustment dial ............................... 14, 18, 46

N

Negative ................................................................. 35

O

Operation mode ..................................................... 11

Operation panel .............................................. 14, 15

P

Polarity .................................................................. 35

Positive ........................................................... 35, 36

POWER ON/OFF .................................................. 23

Power supply ........................................................... 7

Power switch.......................................................... 14

Printing .................................................................. 38

R

Reader-Printer mode ....................................... 10, 31

Rotating ................................................................. 34

Routine cleaning .................................................... 44

S

Scanner mode ........................................................ 11

Scanner recognition ............................................... 24

Screen ............................................................. 14, 44

SCSI cable ............................................................. 21

SCSI ID ................................................................. 21

Setup CD ............................................................... 12

Start key ................................................................. 15

T

Trimming ............................................................... 36

Troubleshooting ..................................................... 46

U

User mode.............................................................. 40

User mode setting .................................................. 40

W

Work Safely ............................................................. 5

Z

zoom lens ............................................................... 35

INDEX

MS 300_english.p65 07.5.14, 10:1450

Copyright

Copyright © 2007 by Canon Electronics Inc. All rights reserved. No part of this publication may be

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or

computer language in any form or by any means, electronic, mechanical, magnetic, optical, chemical,

manual, or otherwise, without the prior written permission of Canon Electronics Inc.

Trademarks

• Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and

other countries.

• ISIS is a trademark of EMC Corporation in the United States.

• Kodak is a trademark of Eastman Kodak Company.

• 3M is a trademark of Minnesota Mining Manufacturing Company.

• TUSCAN is a trademark of the TUSCAN Corporation.

Other brand and product names may be trademarks or registered trademarks of their respective compa-

nies.

FCC REGULATIONS (For 120V models)

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy, and if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation of this equip-

ment in a residential area is likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If

such changes or modifications should be made, you could be required to stop operation of the equip-

ment.

RADIO INTERFERENCE REGULATIONS (For 120V models)

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus

set out in the Interference-causing equipment standard entitled "Digital Apparatus", ICES-003 of the

Industry Canada.

RÈGLEMENT SUR LE BROUILLAGE RADIOÉLECTRIQUE (For 120V models)

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils

numériques de Classe A prescrites dans la norme sur le matériel brouilleur: "Appareils Numériques",

NMB-003 édictée par l'lndustrie Canada.

MODEL NAMES

The following names may be provided for the safety regulations in each sales region of this Microfilm

Scanner.

Model Microfilm Scanner 300II : M31026.

MS 300_english_Cover.p65 08.6.5, 2:57 PM2

ENGLISH

Be sure to read this instructions before you use the equipment.

Keep this instructions on hand for reference to ensure optimum preformance.

CANON ELECTRONICS INC.

1248, SHIMOKAGEMORI, CHICHIBU-SHI, SAITAMA 369-1892, JAPAN

CANON U.S.A. INC.

ONE CANON PLAZA, LAKE SUCCESS, N.Y. 11042, U.S.A.

CANON CANADA INC.

6390 DIXIE ROAD, MISSISSAUGA, ONTARIO L5T 1P7, CANADA

CANON EUROPA N.V.

BOVENKERKERWEG 59-61, P.O.BOX 2262, 1180EG AMSTELVEEN, THE NETHERLANDS

CANON LATIN AMERICA, INC.

703, WATERFORD WAY, SUITE 400 MIAMI, FLORIDA 33126 U.S.A.

CANON AUSTRALIA PTY. LTD.

1 THOMAS HOLT DRIVE, NORTH RYDE, SYDNEY. N.S.W, 2113. AUSTRALIA

CANON SINGAPORE PTE. LTD.

1 HARBOUR FRONT AVENUE #04-01 KEPPEL BAY TOWER, SINGAPORE 098632

CANON HONGKONG CAMPANY LTD.

19TH FLOOR, THE METROPOLIS TOWER, 10 METROPOLIS DRIVE, HUNGHOM, KOWLOON, HONG KONG.

PUB.CE-IE-338-02 0608C0.1 © CANON ELECTRONICS INC. 2007 PRINTED IN JAPAN

*CE-IE-338-02*

MS 300_english_Cover.p65 08.6.5, 2:57 PM1
