Carematix WS-2100-AA Weight Scale User Manual Carematix
Carematix Inc Weight Scale Carematix
Users Manual
Carematix 2100
Round Glass Digital
Weight Scale
Hints on Taking Your Weight
1 Place the scale on an even, flat surface
(carpet, tile, linoleum).
2. Tap the scale in the center with one foot
and wait until 0.00 appears on the display.
3. Step on scale (display will flicker). If “Err”
display appears, step off and wait till the display
shuts down and start all over again.
4. Remain still without moving your arm and body
and your weight measurement will appear
on the display. The scale will automatically
shut off after displaying your weight after
several seconds.
5. Important! Before using your scale for the
first time (or if you have moved it), step “on
and off” the scale once to activate the auto
zeroing feature. Your scale is now ready
to use.
5. Never submerge the scale under water.
To clean the scale surface, use a soft,
damp cloth or glass cleaner.
Helpful Hints
Your scale is a precision electronic instrument.
One of the hardest things to weigh is the
human body because it is always in motion.
Therefore the best accuracy attainable is 99%
of total body weight. To ensure reliable
readings, always try to place your feet on the
scale in the same place and stand still.
Power Supply
Battery Installation
1. Open the battery compartment cover on the
underside of the scale
2. When the compartment is opened, insert one 9V
battery in the compartment, making sure it snaps
in properly.
3. Replace the battery compartment cover on the
main unit.
Notes:
1. If the LCD display or the functioning of the unit is
not normal after changing the batteries, take out
the batteries and place them again correctly in the
battery compartment.
2. Since the first batteries are monitor batteries that
are installed at the time of shipment from the
factory, they may become exhausted before the
life of new battery.
Care and Maintenance
1. Because this unit uses precision parts, care
should be taken to avoid extremes in temperature
variations, humidity, shock, dust and direct
sunlight.
2. Do not open or take apart the scale or its
components. There are no user
serviceable parts.
3. Do not drop or strike this unit.
4. Do not kick the scale.
6. The scale is durable but misuse or abuse
may render the electronic sensors
inoperable.
7. If the unit is to be stored for a long period, be sure
to remove the batteries before storage.
Specifications
Operating Principle 4 load cells
Display 1.6" LCD
Logic (measurement 2 mode fuzzy logic
deflation)
Measuring Range 300 lbs or 150 kg
Accuracy +/- 1% + 1 LSD
Power Supply One 9V battery
Operating Temperature +50°F to +104°F
Relative humidity 15 to 90%
Storage Temperature -4°F to +122°F
Specifications are subject to change without
prior notice due to improvements in
performance and quality.
Warranty
This equipment is guaranteed for the period of 1 year
after the date of purchase against manufacturing
defects when returned along with the proof of date of
purchase. During this period, the unit will be repaired
or replaced free of charge if the failure is attributable to
faulty design or manufacture. This warranty does not
cover damage or malfunctions caused by improper
handling or use contrary to the instructions in this
manual. Opening or taking apart the unit or its
components will void the warranty. Should your
unit require service, please e-mail to us at
service@carematix.com
SAFETY PRECAUTION
Regarding Use of Information
From the Carematix 2100
The Carematix 2100 Monitor is designed to
provide supplemental information only.
Changes in treatment or therapy should not
be based on information provided by the
Monitor. The clinician is expected to
exercise clinical judgment and
independently corroborate the information
provided by the Carematix 2100 Monitor
prior to making any treatment or therapy
decisions
Therapy or intervention decisions should
not be based on information provided by the
Carematix 2100 Monitor. Any changes in
therapy should be based on an actual
examination by the clinician.
SAFETY PRECAUTIONS
Batteries should not be left in the Carematix
2100 Monitor for an extended period of time
that the Monitor is not is use.
Batteries should be disposed of properly
according to the manufacturer’s
recommendations.
If the monitor is accompanied by a base
station (hub) requiring plugging into a phone
line, the line should NEVER be plugged in
during a thunderstorm.
Carematix, Inc.
2 NORTH LASALLE STREET, SUITE 1904
CHICAGO, IL 60602
WEB SITE: HTTP//WWW.CAREMATIX.COM
NOTICE
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause undesired
operation.
CAUTION
Changes or modifications to this equipmen
t
not expressly approved by Carematix, Inc.
could void the user’s authority to operate
the equipment.
