SEE YOUR HOME IN A
WHOLE NEW WAY.
CÔR™ INDOOR WI-FI® CAMERA
1080P FULL HD
QUICK-START GUIDE
ADDITIONAL SUPPORT
Questions/Comments?
We want to hear from you!
Call us: 844-692-6746 or
(844) MY-COR-HOME
Visit mycorhome.com.
1
3
2
RECORDING ON MEMORY CARD
Installing the Memory Card
Flip the memory card slot cover clockwise to open it.
(See image on left.)
Insert a microSD card into the slot until it clicks.
(See image on right.)
Replace the cover.
©2018 Côr™ Home Automation.
Wi-Fi® is a registered trademark of the Wi-Fi Alliance Corporation.
Apple and the Apple logo are trademarks of Apple Inc.,
registered in the U.S. and other countries. App Store is a service
mark of Apple Inc. Google Play is a trademark of Google Inc.
Android is a trademark of Google Inc. Other trademarks and logos
mentioned are the properties of their respective owners.
CTSTI-WH IM-CTSTI-WH-01
IR Light
Auto light source for dark environment.
The camera video has two modes: color
(for daylight recording) and black and white
with IR illuminator (for night conditions).
LED Indicator
Blinking Red and Blue: The camera is on;
you can configure the Wi-Fi® connection.
Steady Blue: The camera is being connected
and operated by user(s).
Slow Blue Flicker: The camera is running properly.
Steady Red: The camera is starting up.
Slow Red Flicker: The Wi-Fi connection has failed.
Fast Red Flicker: MicroSD card error.
Memory Card Slot
For microSD card (not included with this product).
Recommended compatibility: Class 10, maximum
space 128GB. After inserting the microSD card, you
can record the event inside the camera. You need to
initialize it on the Côr™ Smart Home app.
RESET
Hold down the RESET button for 10 seconds when
the camera is running. The camera will restart and
reset all camera settings to default.
Power Supply
5V 10%
+
-
Côr Smart Home app reads “The camera is offline” or
“The device is not registered” when camera is added.
Make sure your router is connected to the Internet
and you have a good Wi-Fi® signal.
The mobile device cannot receive notification
prompts when the camera is online.
Make sure the Côr Smart Home app is running on
your mobile device, Motion Detection is enabled and
Notifications are turned on.
Android users should make sure the app is running
in the background.
iOS users should enable the message push function
in “Settings > Notification.”
If alarm prompts still fail to appear, hold down the RESET
button for 10 seconds to restore the camera settings to
factory default. (Note: you will need to set up Wi-Fi again.)
Live view or playback failed.
Make sure your network is well-connected. Viewing live
video needs a good bandwidth. You can refresh the video
or change network and try again.
How to connect to a new Wi-Fi network.
Hold down the RESET button on the camera for
10 seconds to reset and restart the camera.
Reconnect the Wi-Fi by following the in-app steps.
Q
Q
Q
Q
A
A
A
A
TROUBLESHOOTING
Download the app
Connect your smart device to Wi-Fi.
®
Download and install the free Côr™ Smart Home app
from the iPhone App Store or Android Google Play™
.
Open the Côr Smart Home app.
Look for this Côr
Smart Home app icon
Turn on the camera
Plug the Côr camera into power outlet.
Wait for Red & Blue lights to flash on the camera.
This may take about a minute.
Create a user account (if you do not have one already)
Create a new user account.
Touch SIGN UP FOR AN ACCOUNT on the login
page of app and follow the steps to create a profile.
Then on the main menu, touch ADD NEW DEVICE.
If you already have a user account.
Sign in to your account.
Then on the main menu, touch ADD NEW DEVICE.
SET UP THE CAMERA
USING A WI-FI® SMART DEVICE
1
1
1
1
2
2
2
3
2
A
A
B
B
1
1
1
INSTALLING THE CAMERA
i
Installing the metal plate (Optional)
Pick a clean, flat surface and secure the metal plate to
the desired position with the foam stickers or screws.
There’s a magnet piece inside the camera. You can
skip this easy step if the surface is made of metal.
Installing the camera
Secure the camera magnetically
to the metal plate or metal surface.
Completing installation
Adjust the camera angle as required.
Set up the camera
Select the camera image and touch SETUP CAMERA.
Scan the QR code or manually input the nine-digit
serial number, both located on the back of the camera.
Confirm or enter the six-digit verification code found on
the back of the camera. Touch NEXT.
Verify serial number and touch CONFIRM DEVICE.
If you haven’t already, turn on the camera, select YES
and touch NEXT.
To turn on the camera, plug the power cable into the
USB adapter. Plug the USB power adapter into a
power outlet. When the indicator flickers red or blue,
the camera is ready for setup.
Confirm the device you are using is connected to the
Wi-Fi® network you want your camera to connect to and
touch NEXT.
Hold your mobile device within 2 inches of the camera
to transfer Wi-Fi credentials.
Once your camera is successfully added, touch
CONFIGURE SETTINGS.
Read and accept the Terms and Conditions agreement.
Select the Time Zone and touch NEXT.
Name your camera by selecting a name or creating a
custom name. Touch NEXT.
1
2
3
4
5
6
7
8
9
10
11
Congratulations, you have completed
the setup of your Côr
™
camera.
Motion-Detection setup
Turn on or enable Motion Detection to have the
camera record when motion occurs and to set up push
notifications and sound alerts. Touch NEXT.
If you opt to not enable motion detection,
touch NEXT.
Push-Notification setup
Turn on or enable Push Notifications if you wish to
receive notifications when motion has been detected.
Touch NEXT.
If you opt to not enable notifications, touch NEXT.
On the same screen, turn on or enable Use Schedule.
Touch NEXT.
If you already have a thermostat set up on this app,
you can use your thermostat schedule to specify periods
when you will receive motion alerts.
Click Thermostat Schedule to enable the Thermostat
Periods you would like to use and touch S AVE .
Touch SKIP if you choose to not enable any
of the Thermostat Periods.
Click Custom Schedule if you would like to
set up a custom schedule. Once the schedule is
complete, touch SAVE & CONTINUE SETUP.
If you opt to not enable Use Schedule,
touch NEXT to continue.
To receive push notifications, touch ALLOW when told
“Côr Smart Home Would Like to Send Push Notifications.”
Turn Sound Alerts on or off and touch FINISH.
1
1
3
A
C
B
D
2
4
5
Lens Speaker
IR Light
LED Indicator
Magnetic Base
Microphone
RESET
Memory Card Slot
Power Input
CÔR™ CAMERAS HAVE BEEN DESIGNED TO PROVIDE
COMFORT AND PEACE OF MIND. USING THEM IS
EASY AND INTUITIVE: JUST INSTALL THE CÔR
SMART HOME APP ON YOUR SMART DEVICE AND
FOLLOW THESE SIMPLE STEPS FOR SETUP. ONCE
THE APP IS INSTALLED, YOU CAN COMMUNICATE
AND STAY CONNECTED FROM ANYWHERE.
WHAT’S INSIDE
Côr™ Indoor Wi-Fi® Camera,
Quick-Start Guide/Installation Instructions,
AC Adapter, Optional Mounting Bracket
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Attention that changes or modification not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
Note: This product has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This product generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this product does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum
distance 20cm between the radiator and your body.
