Quick Start Spread CT 3S

: Casatunes Quick Start Spread Ct-3S Quick Start Spread CT-3S Quick Start & Install Guides

Open the PDF directly: View PDF .
Page Count: 2

For any source input that CasaTunes supplies a music stream, pick CasaTunes Media Player as

the Source type and set the Player Settings to match the audio jack you are using. In this exam-

ple, if we connect the first CasaTunes stream to the first Source, click on Player 1 and set the

settings as shown here. All of

the streams use the Speakers

(Realtek High Definition Audio).

You can assign any CasaTunes

Media Player to any of the

Sources.

For other source inputs, pick

the Source type. If we don’t list the device, pick “Unknown”. Hide sources that are not used.

Included Items

Audio Cables

Qty 3

Power Cable

Qty 1

Enable all of the music services

you are interested in.

Some music services require

setting up SqueezeBox. Follow

the directions in CasaSetup.

Some music services require

paid accounts, as noted in

CasaSetup.

Now, name all of your sources and rooms and set your Time Zone and Update settings. Check

Hide box for any Sources or Rooms not used. Click on Advanced Settings and use the Project

Information page to create a backup of the project.

Quick Start Guide for CasaTunes CT-3S Streamer

Need Help?

Control

Use our control apps.

OR

Go to http://CasaServer/CasaTunes on any

PC, or http://CasaServer.local/CasaTunes on

any Mac connected to the network

Check out the videos at

http://www.YouTube.com/CasaTunes

Check out our Tech Notes at

http://www.CasaTunes.com/guides

For live help, email us at

support@CasaTunes.com or phone us at

888-855-2272

Network Cable Qty 1

Serial Cable Qty 1

Use this guide only when using CasaTunes to

stream to and control RTI, Audio Authority,

Channel Vision, SpeakerCraft, NuVo and

Russound audio distribution systems.

CasaTunes Setup

(Cont)

Use Audio Cables to

connect stream outputs

to Audio Distribution

System RCA inputs

To Speakers

Connect to

Distribution System

Connect to LAN

and Power

Network Cable

Power Cable

RTI AD-8X used as an example

Connect serial cable.

CasaTunes Setup

Open any browser on the

LAN and go to CasaSetup:

Turn on the system at this time.

PC: http://CasaServer/CasaSetup

Mac: http://CasaServer.local/CasaSetup

Use CasaSetup to select the type of Audio Distribution system. Select the COM

port you will be using. Usually, the default COM port will be the correct choice.

After clicking on

Save, the Sources

and Rooms refer to

the source inputs and

zone or room outputs

of the Distribution

system you are con-

trolling. (continued

on back page).

From

external devices

(tuners, cable

boxes, etc.)
