Casio Ctk 4400 Owners Manual WK240_CTK4400_EN

CTK-4400 to the manual 3c98a027-687b-4db6-b643-3bc7cc0971cf

Web_WK240_CTK4400-ES1A Web_WK240_CTK4400-ES1A_EN CTK-4400 | Electronic Musical Instruments | Manuals | CASIO

2015-03-09

: Casio Casio-Ctk-4400-Owners-Manual-590480 casio-ctk-4400-owners-manual-590480 casio pdf

Open the PDF directly: View PDF PDF.
Page Count: 76

GUÍA DEL USUARIO
USER’S GUIDE
EN/ES
WK240/CTK4400-ES1A
Guarde toda la información para futuras consultas.
Please keep all information for future reference.
Precauciones de seguridad
Antes de intentar usar el teclado digital, asegúrese de
leer las “Precauciones de seguridad” separadas.
Safety Precautions
Before trying to use the Digital Keyboard, be sure to
read the separate “Safety Precautions”.
CTK-4400
WK-240
WK-245
EnglishEspañol
This recycle mark indicates that the packaging conforms to
the environmental protection legislation in Germany.
Esta marca de reciclaje indica que el empaquetado se
ajusta a la legislación de protección ambiental en Alemania.
MA1402-A Printed in China
K
CTK4400_A5_x1a_EN_ES.indd 1 2014/02/19 10:25:10
Function Transmitted Recognized Remarks
Basic
Channel
1
1 - 16
1 - 16
1 - 16
Default
Changed
Note
Number
0 - 127
0 - 127 *1
12 - 120
True voice
Program
Change
O
0 - 127
O
0 - 127
:True #
After
Touch
Control
Change
X
X
X
X
O
Pitch Bender
O
System Exclusive
O
*2
O
Key’s
Ch’s
Velocity
O
9nH v = 1 - 127
X
9nH v = 0, 8nH v =**
O
9nH v = 1 - 127
X
9nH v = 0
Note ON
Note OFF
Mode
Mode 3
X
Mode 3
X
Default
Messages
Altered
System
Common
X
X
X
X
X
X
: Song Pos
: Song Sel
: Tune
Aux
Messages
Remarks
X
O
X
O
X
X
O
O
X
O
O
X
: All sound off
:
Reset all controller
: Local ON/OFF
: All notes OFF
: Active Sense
: Reset
System
Real Time
O
O
X
X
: Clock
: Commands
0, 32
1
6, 38
7
10
11
64
66
67
91
93
100, 101
Bank select
Modulation
Data entry
Volume
Pan
Expression
Hold 1
Sostenuto
Soft pedal
Reverb send
Chorus send
RPN LSB, MSB
Models: CTK-4400/WK-240/WK-245 Version : 1.0
Mode 1 : OMNI ON, POLY
Mode 3 : OMNI OFF, POLY
Mode 2 : OMNI ON, MONO
Mode 4 : OMNI OFF, MONO
O : Yes
X : No
O
X
X
O
O
X
O
O
O
X
O
X
*3
*3
*3
O
O
O
O
O
O
O
O
O
O
O
O
(MSB only)
*2
*2
*2
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
Declaration of Conformity
Model Number: CTK-4400/WK-240/WK-245
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
*1: Depends on tone.
*2: For details about NRPN, RPN, and system
exclusive messages, see MIDI Implementation at
http://world.casio.com/.
*3: In accordance with peal effect setting.
*1: Depende del tono.
*2: Para obtener información acerca de NRPN, RPN y
los mensajes exclusivos del sistema, consulte
Implementación MIDI en
http://world.casio.com/.
*3: De acuerdo con el ajuste de efecto de pedal.
CTK4400_A5_x1a_EN_ES.indd 2 2014/02/19 10:25:11
English
Important!
Please note the following important information before using this product.
Before using the optional AC Adaptor to power the unit, be sure to check the AC Adaptor for any damage first. Carefully check
the power cord for breakage, cuts, exposed wire and other serious damage. Never let children use an AC adaptor that is
seriously damaged.
Never attempt to recharge batteries.
Do not use rechargeable batteries.
Never mix old batteries with new ones.
Use recommended batteries or equivalent types.
Always make sure that positive (+) and negative (–) poles are facing correctly as indicated near the battery compartment.
Replace batteries as soon as possible after any sign they are getting weak.
Do not short-circuit the battery terminals.
The product is not intended for children under 3 years.
Use only a CASIO AD-E95100L adaptor.
The AC adaptor is not a toy.
Be sure to disconnect the AC adaptor before cleaning the product.
This mark applies in EU countries only.
Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal
use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION,
DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE
USE OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
The contents of this manual are subject to change without notice.
The actual appearance of the product may be different from that shown in the illustrations in this User’s Guide.
Company and product names used in this manual may be registered trademarks of others.
Manufacturer:
CASIO COMPUTER CO.,LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:
CASIO EUROPE GmbH
Casio-Platz 1, 22848 Norderstedt, Germany
Declaration of Conformity According to EU Directive
EN-1
CTK4400_A5_x1a_EN_ES.indd 3 2014/02/19 10:25:11
EN-2
Contents
General Guide ............................... EN-4
Using the 10-key Pad (br).............................. EN-7
FUNCTION Button (ct) Functions ................. EN-7
Returning the Digital Keyboard to Its
Factory Default Settings .................................. EN-8
Getting Ready to Play................... EN-9
Preparing the Music Stand .............................. EN-9
Power Supply .................................................. EN-9
Playing the Digital Keyboard ..... EN-10
Turning on Power and Playing ...................... EN-10
Using Headphones........................................ EN-11
Connecting a Microphone
(WK-240 and WK-245) .................................. EN-11
Changing Keyboard Response to
Touch Pressure (Touch Response)............... EN-12
Adjusting Display Contrast ............................ EN-12
Using the Metronome .................................... EN-13
Controlling the
Keyboard Sounds ....................... EN-14
Select from a variety of musical
instrument sounds ......................................... EN-14
Layering Two Tones......................................EN-15
Splitting the Keyboard between
Two Different Tones ...................................... EN-15
Using VIRTUAL HALL ................................... EN-16
Using Reverb................................................. EN-16
Using Chorus................................................. EN-17
Using a Pedal ................................................ EN-17
Changing the Pitch
(Transpose, Tuning, Octave Shift)................. EN-18
Sampling Sounds and Playing
Them on the Digital Keyboard ... EN-19
Connection and Preparation.......................... EN-19
Sampling and Playing a Melody Sound
(Melody Sampling) ........................................ EN-20
Incorporating a Sampled Sound into a
Drum Set (Drum Sampling) ........................... EN-22
Other Sampling Functions............................. EN-25
Playing Built-in Songs................ EN-27
Playing the Demo Songs............................... EN-27
Playing Back a Particular Song ..................... EN-28
Increasing the Selection of Songs................. EN-30
Using Built-in Songs to Master
Keyboard Play..............................EN-31
Phrases......................................................... EN-31
Step Up Lesson Flow.................................... EN-31
Selecting the Song, Phrase, and
Part You Want to Practice............................. EN-32
Lessons 1, 2, and 3....................................... EN-33
Lesson Settings ............................................ EN-34
Using Auto Step Up Lesson.......................... EN-36
Music Challenge
Keyboard Game ...........................EN-37
Using Auto Accompaniment.......EN-38
Playing the Rhythm Part Only....................... EN-38
Playing All Parts............................................ EN-39
Using Auto Accompaniment Effectively ........ EN-41
Using One-Touch Preset .............................. EN-42
Using Auto Harmonize .................................. EN-43
Looking Up the Notes of Chords
(Chord Book)................................................. EN-44
Editing Auto Accompaniment
Patterns ........................................EN-45
Saving Keyboard Setups to
Registration Memory...................EN-48
To save a setup to registration memory........ EN-49
To recall a setup from registration
memory ......................................................... EN-49
Recording Your
Keyboard Play..............................EN-50
Recording and Playing Back
Keyboard Play............................................... EN-50
Using Tracks to Record and Mix Parts ......... EN-51
Recording Two or More Songs, and
Selecting One for Playback........................... EN-53
Recording while Playing Along with a
Built-in Song.................................................. EN-53
Saving Recorded Data on an
External Device............................................. EN-54
CTK4400_A5_x1a_EN_ES.indd 4 2014/02/19 10:25:11
English
Contents
EN-3
Other Useful Digital Keyboard
Functions..................................... EN-55
Changing the Scale of the Keyboard............. EN-55
Using Music Preset ....................................... EN-56
Using the Arpeggiator.................................... EN-57
Deleting User Song Data............................... EN-58
Deleting All Data in Digital Keyboard
Memory ......................................................... EN-58
Connecting External Devices .... EN-59
Connecting to a Computer ............................ EN-59
MIDI Settings................................................. EN-60
Storing and Loading Digital Keyboard
Memory Data................................................. EN-62
Connecting to Audio Equipment....................EN-63
Reference..................................... EN-64
Troubleshooting............................................. EN-64
Specifications ................................................ EN-66
Operating Precautions................................... EN-67
Error Messages ............................................. EN-68
Song List ....................................................... EN-69
Fingering Guide............................................. EN-70
Chord Example List ....................................... EN-71
MIDI Implementation Chart
Included Accessories
Music Stand
Song Book
Leaflets
Safety Precautions
• Appendix
Other (Warranty, etc.)
Items included as accessories are subject to change without notice.
Separately Available Accessories
You can get information about accessories that
are separately for this product from the CASIO
catalog available from your retailer, and from the
CASIO website at the following URL.
http://world.casio.com/
CTK4400_A5_x1a_EN_ES.indd 5 2014/02/19 10:25:11
EN-4
General Guide
In this manual, the term “Digital Keyboard” refers to the CTK-4400/WK-240/WK-245.
Illustrations in this User’s Guide show the WK-240.
In this manual, buttons and other controllers are identified using the numbers shown below.
552211
brbr
bnbn
66 77 88 99 bkbk blbl
bsbs btbt ckck clcl cmcm
4433
bpbpbqbq bobo
ctctcscscncn coco cpcp cqcq crcr
bmbm
dk dmdl dn do dp dk
dq dr
CTK4400_A5_x1a_EN_ES.indd 6 2014/02/19 10:25:11
English
General Guide
EN-5
The following explains the meaning of the $ symbol that appears on the product console and with the key names below.
$: Indicates a function that is enabled by holding down the button for some time.
1P(POWER) button EN-10
2VOLUME knob EN-10
3VIRTUAL HALL, DEMO $ button EN-16, 27
4RHYTHM EDITOR button EN-45
5METRONOME, BEAT $ button EN-13
6INTRO, REPEAT button EN-29, 41
7NORMAL/FILL-IN, REW button EN-28, 41
8VAR./FILL-IN, FF button EN-28, 41
9SYNCHRO/ENDING, PAUSE button EN-28, 41
bk START/STOP, PLAY/STOP button EN-27, 38
bl CHORDS $, ACCOMP, PART SELECT button
EN-30, 39
bm TEMPO buttons EN-13
bn TONE button EN-14
bo RHYTHM, ONE TOUCH PRESET $ button
EN-38, 42
bp SONG BANK button EN-28
bq MUSIC PRESET button EN-56
br Number buttons, [–]/[+] keys EN-7
bs BANK, LISTEN button EN-33, 48
bt Area1, WATCH button EN-33, 48
ck Area2, REMEMBER button EN-34, 48
cl Area3, NEXT button EN-32, 48
cm Area4, AUTO button EN-36, 48
cn STORE, MUSIC CHALLENGE button EN-37, 49
co SPLIT button EN-15
cp LAYER button EN-15
cq AUTO HARMONIZE/ARPEGGIATOR,
TYPE $ button EN-43, 57
cr PIANO/ORGAN, CHORD BOOK $ button
EN-14, 44
cs RECORDER, SAMPLING $ button EN-50
ct FUNCTION button EN-7
dk Speakers
dl Song Bank list
dm Display
dn Music Preset list
do Rhythm list
dp Tone list
dq CHORD root names EN-39
dr Percussion instrument list EN-14
CTK4400_A5_x1a_EN_ES.indd 7 2014/02/19 10:25:12
General Guide
EN-6
ds USB port EN-59
dt SUSTAIN/ASSIGNABLE JACK EN-17
ek MIC VOLUME knob
(WK-240 and WK-245) EN-19
el MIC IN/SAMPLING jack
(WK-240 and WK-245) EN-19
em AUDIO IN jack EN-19
en DC 9.5V terminal EN-9
eo PHONES/OUTPUT jack EN-11
ds dt el em eoenek
Back
CTK4400_A5_x1a_EN_ES.indd 8 2014/02/19 10:25:12
English
General Guide
EN-7
Use the number buttons and the [–] and [+] keys to change
the settings of the parameters that appear in the upper left
area of the display.
Use the number buttons to enter numbers and values.
Enter the same number of digits as the currently displayed
value.
Negative values cannot be input using the number buttons.
Use [–] (decrease) and [+] (increase) instead.
You can use the [–] (decrease) and [+] (increase) keys to
change the displayed number or value.
Holding down either key scrolls the displayed setting.
Pressing both keys at the same time will revert to the initial
default setting or the recommended setting.
You can use the FUNCTION button (ct) to adjust the reverb
effect, to delete data, and to perform a wide range of other
Digital Keyboard operations.
1.
Press ct (FUNCTION) to display the function
menu.
2.
Use the br (10-key) [4] (o) and [6] (p) keys
to display the function you want.
You can exit the function menu by pressing ct
(FUNCTION).
After selecting functions 8 through 13, press the br
(10-key) [9] (ENTER) key to display the menu item’s
submenu. Then use [4] (o) and [6] (p) to select an
item. You can exit a submenu by pressing the br
(10-key) [7] (EXIT) key.
3.
Refer to the indicated pages for details about
each function.
Using the 10-key Pad (br)
Number Buttons
Example: To enter tone number 001, input 0 3 0 3 1.
[–] and [+] Keys
Setting
St .GrPno
FUNCTION Button (ct) Functions
To select a function
CTK4400_A5_x1a_EN_ES.indd 9 2014/02/19 10:25:12
General Guide
EN-8
The tone and other parameters revert to their initial
defaults whenever you turn on power (page EN-10).
Perform the following procedure when you want to return the
Digital Keyboard’s stored data and settings to their initial
factory defaults.
1.
Turn off the Digital Keyboard.
2.
While holding down bp (SONG BANK) and the
[1] 10-key (br) key at the same time, press 1.
Keep bp (SONG BANK) and the [1] 10-key (br) key
depressed until the next step is complete.
3.
When the message “Pls wait” appears on the
screen, release bp (SONG BANK) and the [1]
10-key (br) key.
You will be able to use the Digital Keyboard in a short
while after its system is initialized.
See “Turning on Power and Playing” (page EN-10) for
information about turning digital power on and off.
Function Display See
Page
1 Transpose Trans. EN-18
2 Accompaniment Volume AcompVol EN-42
3 Song Volume Song Vol EN-30
4 Touch Response Touch EN-12
5 Tuning Tune EN-18
6 Reverb Reverb EN-16
7 Chorus Chorus EN-17
8 Sampling SAMPLING
Automatic Sampling Start AutoStrt EN-25
Automatic Sampling Stop AutoStop EN-25
Sampled Tone Protect (Protect) EN-26
9 Step Up Lesson LESSON
Voice Fingering Guide Speak EN-34
Note Guide NoteGuid EN-35
Performance Evaluation Scoring EN-35
Phrase Length PhraseLn EN-35
10 Preset Scales SCALE EN-55
11 Other Settings OTHER
Arpeggiator Hold ArpegHld EN-57
Pedal Effect Jack EN-17
Accompaniment Scale AcompScl EN-56
LCD Contrast Contrast EN-12
12 MIDI Settings MIDI
Keyboard Channel Keybd Ch EN-60
Navigate Channels Navi. Ch EN-60
Local Control Local EN-61
Accomp Out AcompOut EN-61
13 Delete DELETE
Sampled Sound Delete (tone name) EN-26
User Rhythm Delete (rhythm name) EN-47
User Song Delete (song name) EN-58
All Data Delete All Data EN-58
Returning the Digital Keyboard to
Its Factory Default Settings
CTK4400_A5_x1a_EN_ES.indd 10 2014/02/19 10:25:12
English
EN-9
Getting Ready to Play
Either an AC adaptor or batteries can be used to power this
Digital Keyboard. Normally, use of AC adaptor power is
recommended.
The AC adaptor does not come with this Digital Keyboard.
Purchase it separately from your retailer. See page EN-3
for information about options.
Make sure that you use only the AC adaptor specified for this
Digital Keyboard. Use of a different type of AC adaptor can
cause malfunction.
Be sure to turn off Digital Keyboard power before
connecting or disconnecting the AC adaptor.
The AC adaptor will become warm to the touch after
very long use. This is normal and does not indicate
malfunction.
To prevent breaking of the wire, take care to avoid
putting any type of load on the power cord.
Never insert metal, pencils, or any other objects into
the product’s 9.5V DC terminal. Doing so creates the
risk of accident.
Be sure to turn off power before loading batteries.
It is up to you to prepare six commercially available
batteries. Do not use oxyride batteries or any other
nickel based batteries.
1.
Open the battery cover on the bottom of the
Digital Keyboard.
2.
Load six batteries into the battery compartment.
CTK-4400: AA-size batteries
WK-240/WK-245: D-size batteries
Make sure the positive + and negative - ends of the
batteries are facing as shown in the illustration.
3.
Insert the tabs of the battery cover into the
holes on the side of the battery compartment,
and close the cover.
Low Battery Indication
The indicator shown below starts to flash to let you know
when battery power is low. Replace the batteries with new
ones.
Preparing the Music Stand
Power Supply
Using the AC Adaptor
Specified AC Adaptor: AD-E95100L
(JEITA Standard plug)
No bending! No winding!
Music stand
Household power outlet
AC adaptor
DC 9.5V
Using Batteries
<CTK-4400> <WK-240/WK-245>
Tabs Tabs
Low battery indicator
(flashes)
CTK4400_A5_x1a_EN_ES.indd 11 2014/02/19 10:25:12
EN-10
Playing the Digital Keyboard
1.
Press 1 (P).
This turns on power.
To turn off the Digital Keyboard, press 1 again.
2.
Try playing something on the keyboard. Use 2
to adjust volume.
If you press 1 only lightly, the display will light up
momentarily but power will not turn on. This does not
indicate malfunction. Press 1 firmly and completely
to turn on power.
Turning off the Digital Keyboard causes most current
settings to be cleared. The Digital Keyboard will revert
to initial settings the next time you turn it on.
This is true for all settings except for sample sound
protection. Once you turn it on it remains on until you
turn it off again.
The message “Pls wait” will remain on the display
while a data save operation is in progress. Do not
perform any other operation while it is displayed.
Turning off the Digital Keyboard can cause Digital
Keyboard data to be deleted or become corrupted.
Pressing 1 to turn off power actually puts the Digital
Keyboard into a standby state. Minute amounts of current
continue to flow within the Digital Keyboard in the standby
state. If you do not plan to use the Digital Keyboard for a
long time or if there is a lightning storm in your area, be
sure to unplug the AC adaptor from the power outlet.
If you do not perform any operation on the Digital Keyboard
for one of the trigger times noted below, Auto Power Off will
turn off power.
Disabling Auto Power Off
You can disable Auto Power Off to ensure that power is not
turned off automatically during a concert, etc.
1.
While holding down bn (TONE), turn on power.
Auto Power Off will be disabled.
ctct
552211
bmbm
brbr
bnbn
Turning on Power and Playing Auto Power Off
During battery operation : 6 minutes
During AC adaptor operation: 30 minutes
CTK4400_A5_x1a_EN_ES.indd 12 2014/02/19 10:25:12
English
Playing the Digital Keyboard
EN-11
Using headphones cuts off output from the built-in speakers,
which means you can practice playing even late at night
without disturbing others.
Be sure to turn down the volume level before connecting
headphones.
Headphones do not come with the Digital Keyboard.
Use commercially available headphones. See page EN-3
for information about options.
Do not listen to very high volume output over
headphones for long period. Doing so creates the risk
of hearing damage.
If you are using headphones that require an adaptor
plug, make sure you do not leave the adaptor plugged
in when removing the headphones.
You can connect a dynamic microphone (only) to the Digital
Keyboard for output through the Digital Keyboard’s speakers.
You can adjust the volume level of microphone input with
the ek (MIC VOLUME) knob. Microphone volume control is
independent of overall keyboard volume.
Built-in effects (reverb, chorus) are also applied to input
from the microphone.
For details, see “Controlling the Keyboard Sounds” (page
EN-14).
Before connecting a microphone, make sure that the
Digital Keyboard and microphone are turned off.
Before connecting a microphone, set both the 2 and
ek (MIC VOLUME) knobs to low levels. Adjust volume
settings to appropriate levels after connecting the
microphone.
Using Headphones
PHONES/OUTPUT jack
Connecting a Microphone
(WK-240 and WK-245)
MIC IN/SAMPLING jack
CTK4400_A5_x1a_EN_ES.indd 13 2014/02/19 10:25:13
Playing the Digital Keyboard
EN-12
Touch Response alters tone volume in accordance with
keyboard pressure (speed). This provides you some of the
same expressivity you get on an acoustic piano.
Use the procedure below to control how much the volume of
played notes change in accordance with playing speed.
Select the setting that best matches your playing style.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“Touch” (page EN-7).
2.
Use br (10-key) [–] and [+] keys to select one of
the three Touch Response sensitivity settings.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“OTHER” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “Contrast”.
4.
Use the br (10-key) [–] and [+] keys to adjust
the contrast.
The contrast setting range is 01 to 17.
Changing Keyboard Response to
Touch Pressure
(Touch Response)
Pressing fast produces
louder notes.
Pressing slowly produces
softer notes.
Do not try to use too much
pressure.
Changing Touch Response Sensitivity
Off (oFF) Touch Response is turned off. Sound
volume is fixed, regardless of key press
speed.
Type 1 (1) Normal Touch Response
Type 2 (2) More sensitive Touch Response than Type 1
Touch
Adjusting Display Contrast
Flashes
OTHER
Con t r as t
CTK4400_A5_x1a_EN_ES.indd 14 2014/02/19 10:25:13
English
Playing the Digital Keyboard
EN-13
The metronome lets you play and practice along with a steady
beat to help keep you on tempo.
1.
Press 5.
This starts the metronome.
2.
Press 5 again to stop the metronome.
You can configure the metronome to use a bell sound for the
first beat of each measure of the song you are playing.
You can specify a value from 0 to 9 as the number of beat
per measure.
When playing a built-in song, the beats per measure setting
(which determines when the bell sounds) is configured
automatically for the currently selected song.
1.
Hold down 5 until the beats per measure
setting screen appears on the display.
If you do not perform any operation for a few seconds
after the beats per measure setting screen appears, the
display will return to the screen displayed before you
pressed 5.
2.
Use br (10-key) to enter the number of beats
per measure.
The bell will not sound if you specify 0 (Bell Off) for this
setting. In this case, all beats are indicated by a click
sound. This setting lets you practice with a steady beat,
without worrying how many beats there are in each
measure.
Use the following procedure to change the tempo of the
metronome.
1.
Press bm.
Use y (slower) and t (faster) to change the tempo
setting. Holding down either button changes the setting at
high speed.
Pressing t and y at the same time will initialize the
tempo setting in accordance with the currently selected
song or rhythm.
Pressing bm causes the tempo value to flash on the
display. While the tempo value is flashing, you can use
br (10-key) to change it.
Note that you must input leading zeros, so 89 is input
as 089.
The tempo value will stop flashing if you do not perform
any operation for a short while.
The metronome volume setting is changed automatically with
the volume level of the currently selected Auto
Accompaniment or song. The metronome volume cannot be
adjusted independently.
For information about changing the Auto Accompaniment
volume, see page EN-42.
For information about changing the song volume, see page
EN-30.
You cannot adjust the balance between the metronome
and note volume during Auto Accompaniment and built-in
tune play.
Using the Metronome
Start/Stop
Changing the Beats Per Measure
This pattern changes with each beat.
Bea t
Changing the Metronome Tempo
Changing the Metronome Sound Volume
Tempo value (flashes)
CTK4400_A5_x1a_EN_ES.indd 15 2014/02/19 10:25:13
EN-14
Controlling the Keyboard Sounds
Your Digital Keyboard lets you select tones for a wide variety
of musical instrument sounds, including violin, flute, orchestra,
and more. Even the same song sound takes on a different feel
by changing the instrument type.
1.
Press bn (TONE).
2.
Use br (10-key) to select the tone number you
want.
The corresponding tone number and tone name will
appear on the screen.
Use the number buttons to enter the tone number.
Specify three digits for the tone number.
See the separate “Appendix” for a complete list of available
tones.
When one of the drum sets is selected, each keyboard key
is assigned a different percussion sound.
3.
Try playing something on the keyboard.
The tone of the instrument you selected will sound.
Pressing cr toggles between the piano and organ modes.
Each press of cr toggles the tone setting between a piano
tone (Tone Number 001) and an organ tone (Tone Number
079).
In addition to the tone number, you also can configure the
settings listed below.
cococpcp crcr
bnbn
ctct
brbr
33
Select from a variety of musical
instrument sounds
To select an instrument for playing
Example: To select 001, enter 0 3 0 3 1.
St .GrPno
Tone nameTone number Playing with a Piano or Organ Tone
VIRTUAL HALL : Off
Reverb : “06”
Transpose : 00
Touch Response : Off:Returns to initial default
On: No change
Pedal Effect : SUS
Rhythm Number : “161” (When a piano tone is selected)
“094” (When an organ tone is selected)
Accompaniment : Rhythm part only
Local Control : On
Drum Assign : Off
Split : Off
Layer : Off
Chorus : Off
Octave Shift (Upper): 0
Auto Harmonize : Off
Arppegiator : Off
Scale : Equal
CTK4400_A5_x1a_EN_ES.indd 16 2014/02/19 10:25:13
English
Controlling the Keyboard Sounds
EN-15
You can use the following procedure to layer two different
tones (such as piano and strings) so they sound
simultaneously when you press a keyboard key.
1.
Select the first tone you want to use.
Press bn (TONE) and then use br (10-key) to select the
tone you want.
2.
Press cp.
3.
Use br (10-key) to select the second tone you
want.
4.
Play something on the keyboard.
Both tones sound at the same time.
5.
Pressing cp again to unlayer the keyboard (so
it plays only the tone you selected in step 1).
Each press of cp toggles between layered (two tones)
and unlayered (one tone).
You can use the procedure below to assign different tones to
the right range and left range of the keyboard, so it sounds
like you are playing an ensemble between two instruments.
1.
Select the tone for the right side range (page
EN-14).
Press bn (TONE) and then use br (10-key) to select the
tone you want.
2.
Press co.
3.
Use br (10-key) to select the left side range
tone you want.
4.
Play something on the keyboard.
This will sound the tones assigned to the left and right
side ranges of the keyboard.
Layering Two Tones
Example: 032 ELEC.PIANO 1
Example: 205 STRINGS
E.Pi ano1
Lights
St r in
g
s
Splitting the Keyboard between
Two Different Tones
To select the two tones for a split keyboard
Example: 303 FLUTE 1
Example: 064 VIBRAPHONE 1
Flute 1
Lights
Vi bes 1
F3
VIBRAPHONE 1 FLUTE 1
Split point
CTK4400_A5_x1a_EN_ES.indd 17 2014/02/19 10:25:13
Controlling the Keyboard Sounds
EN-16
5.
Pressing co again to unsplit the keyboard (so it
plays only the tone you selected in step 1).
Each press of co toggles between split (two tones) and
unsplit (one tone).
If you turn on both layer and split, layering will be applied to
the right side range of the keyboard only.
1.
While holding down co, press the keyboard key
where you want the split point to be.
The key you press will become the lowest note of the right
side range of the split keyboard.
The VIRTUAL HALL function lets you instantly configure the
Digital Keyboard to play with the acoustic effect of a classic
concert hall.
1.
Press 3 (VIRTUAL HALL) to turn on the
VIRTUAL HALL function.
2.
To turn off the VIRTUAL HALL function, press
3 again.
The reverb setting turns off automatically whenever the
VIRTUAL HALL function is turned on. When you turn
off the VIRTUAL HALL function, the reverb setting will
return to whatever it was before you turned on the
VIRTUAL HALL function.
Reverb adds reverberation to notes. You can change the
duration of the reverb.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“Reverb” (page EN-7).
2.
Use the br (10-key) [–] and [+] keys to select
the reverb setting you want.
Changing the reverb setting (including turning it off)
while the VIRTUAL HALL function is turned on will turn
off the VIRTUAL HALL function.
To change the split point
Example: Setting middle C (C4) as the split point.
Using VIRTUAL HALL
C4
Key name
Lights
The indicator will disappear when the VIRTUAL HALL function is
turned off.
Using Reverb
Off (oFF) Turns off reverb.
1 to 10 The larger the number selected, the longer
the reverb duration.
Reverb
Indicator disappears when reverb is turned off.
CTK4400_A5_x1a_EN_ES.indd 18 2014/02/19 10:25:14
English
Controlling the Keyboard Sounds
EN-17
Chorus is a function that adds depth and breadth to notes. It
makes you sound as if you are playing multiple instruments.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“Chorus” (page EN-7).
2.
Use the br (10-key) [–] and [+] keys to select
the chorus type you want.
There are five chorus types, plus an off setting.
The actual effect produced by chorus depends on the tone
you are using.
A pedal can be used to change notes in various ways while
playing.
A pedal unit does not come with the Digital Keyboard.
Purchase one separately from your retailer. See page EN-3
for information about options.
Connect an optional pedal unit.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“OTHER” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “Jack”.
4.
Use the br (10-key) [–] and [+] keys to select
the pedal effect you want.
The following shows the available pedal effects.
Using Chorus
Using a Pedal
Connecting a Pedal Unit
Chorus
Indicator disappears when chorus is turned off.
SUSTAIN/ASSIGNABLE JACK
Selecting the Pedal Effect
Sustain
(SUS)
Sustains notes played while the pedal is
depressed. Organ and other similar tone
notes are sustained even if the pedal is not
pressed.
Sostenuto
(SoS)
Sustains notes that are playing when the
pedal is depressed before the keyboard keys
are released.
Soft
(SFt)
Slightly softens notes played while the pedal
is depressed.
Rhythm
(rHy)
Pressing the pedal starts and stops Auto
Accompaniment or song playback.
OTHER
Flashes
Jack
CTK4400_A5_x1a_EN_ES.indd 19 2014/02/19 10:25:14
Controlling the Keyboard Sounds
EN-18
The transpose feature lets you change the pitch, in semitone
steps. A simple operation lets you instantly change the pitch
to match that of a singer.
The transpose setting range is –12 to +12 semitones.
1.
Press ct (FUNCTION).
2.
Use the br (10-key) [–] and [+] keys to select
the transpose setting you want.
Use the tuning feature when you need to adjust the pitch
slightly to play along with another musical instrument. Also,
some artists perform their music with slightly altered tuning.
You can use the tuning feature to adjust tuning so it exactly
matches a performance on a CD.
The tuning feature specifies the frequency of the A4 note.
You can set a frequency within the range of 415.5 to
465.9 Hz. The initial default setting is 440.0 Hz.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“Tune”.
2.
Use the br (10-key) [–] and [+] keys to adjust
the tuning.
Performing this step causes the display to change from
“Tune” to a value that indicates the current frequency
setting as shown below. You can change the frequency
in 0.1 Hz steps.
Even if you do not perform a br (10-key) operation to
adjust the tuning, the current frequency setting will
appear automatically after a few seconds.
Octave Shift lets you raise or lower the pitch of the keyboard
notes in octave units.
The octave shift setting range is –2 to +2 octaves.
When using Split (page EN-15), you can individually set the
left and right keyboard ranges to the pitches you want.
1.
Keep pressing cp until the screen shown below
appears on the display.
If you want to use Split, turn on Split before pressing cp.
If you do not perform any operation for a few seconds
after this screen appears, the display will return to the
previous screen automatically.
2.
Use the br (10-key) [–] and [+] keys to shift the
octave.
3.
Press cp.
4.
Press cp again.
Changing the Pitch
(Transpose, Tuning, Octave Shift)
Changing the Pitch in Semitone Steps
(Transpose)
Fine Tuning (Tuning)
Trans .
Tune
440.0Hz
Octave Shift
Split On : This step affects the right side keyboard
range only.
Split Off : This step affects the entire keyboard range.
Split On : The screen shown below will appear. Use the
br (10-key) [–] and [+] keys to shift the
octave for the left side keyboard range.
Split Off : The screen shown below will appear.
Advance to step 4.
Oc tU
pp
er
Oc t Lowe r
CTK4400_A5_x1a_EN_ES.indd 20 2014/02/19 10:25:14
English
EN-19
Sampling Sounds and Playing Them on the Digital
Keyboard
You can sample a sound from a microphone, a portable audio
player, or other device, and then play the sound on the
keyboard. For example, you could sample the bark of your
dog and then use the sound in a melody. You also can sample
and use passages from a CD. The sampling feature is a great
way to create new sounds that are highly creative.
Before connecting, make sure that this Digital
Keyboard, as well as the microphone (WK-240 or
WK-245) or external device (CTK-4400) being
connected, are all turned off.
1.
Connect a microphone or external device to the
Digital Keyboard.
<CTK-4400>
<WK-240/WK-245>
You cannot sample sounds input from through the
AUDIO IN jack.
Use a commercially available dynamic microphone.
Connection of an external device requires commercially
available connecting cords, supplied by you. Connecting
cords should have a stereo mini plug on one end and a plug
that matches the configuration of the external device on the
other end.
2.
Turn down the volume levels of the external
device and the Digital Keyboard.
3.
Turn on the external device or microphone, and
then turn on the Digital Keyboard.
When using a microphone, adjust the input volume
level with ek (MIC VOLUME).
It will take a few seconds after you turn on the Digital
Keyboard before you will be able to use the microphone.
Sampled sounds are recorded in monaural.
bobobnbn brbr
bsbsbtbtckckclclcmcmcncn cscscrcr ctct
Connection and Preparation
Digital Keyboard AUDIO IN jack
Stereo mini plug
CD player, Cassette player,
etc.
MIC IN/SAMPLING jack
CTK4400_A5_x1a_EN_ES.indd 21 2014/02/19 10:25:14
Sampling Sounds and Playing Them on the Digital Keyboard
EN-20
Use the procedures in this section to sample a sound and play
it as the melody part on the Digital Keyboard.
Up to five sampled sounds can be stored in Digital
Keyboard memory as tone numbers 601 through 605.
Simply select the tone number where the sound you want is
located to assign the sound to the keyboard.
1.
Press bn (TONE) and then use br (10-key) to
enter the tone number (601 to 605) where you
want to store the sampled sound.
2.
Hold down cs until the display changes to the
screen shown below.
This enters sampling standby.
The allowable sampling time (in seconds) will appear on
the display momentarily and then the display will change
to the following.
3.
What you should do next depends on your
Digital Keyboard model as described below.
• CTK-4400:
Output sound from the external device.
WK-240, WK-245:
Output the sound in the direction of the microphone.
Sampling will start automatically.
Sampling will not start if the volume of the sound is too
low.
4.
After the sound you want to sample is finished,
press cs.
Sampling will stop.
Even if you do not press cs, sampling will stop
automatically whenever there is no more sound being
input from the external device or microphone. Sampling
also will stop automatically 10 seconds after it is
started.
5.
Play something on the Digital Keyboard.
You may not be able to get 10 seconds of sampling if
Digital Keyboard memory is low due to storage of other
data. If this happens, deleting other memory data you no
longer need will free up memory space and you should be
able to sample for 10 seconds. See “Deleting a Sampled
Sound” on page EN-26 for more information.
Sampling sound and storing it will delete any sound
data currently stored under the same tone number. To
help ensure that you do not accidentally delete
important data, be sure to read “Protecting Against
Accidental Deletion of Sampled Sounds” on page
EN-26.
Sampling and Playing a Melody
Sound (Melody Sampling)
To sample a sound
No Da t a
No sampled sound stored
Lights
Flashes
W
aitin
g
Flashes
Sam
p
l in
g
S1 :Or
g
nl
Sampled sound 1
Used memory
(Unit: Kbytes) Remaining
memory capacity
CTK4400_A5_x1a_EN_ES.indd 22 2014/02/19 10:25:14
English
Sampling Sounds and Playing Them on the Digital Keyboard
EN-21
How sampled sounds are played
Pressing Middle C (C4) will play back the original sound. The
keys to the left and right of C4 play the sound at different
pitches.
You can use the following procedure to loop a sampled sound
so it continues to repeat, as you play on the Digital Keyboard.
1.
Press bo (RHYTHM).
2.
Press cs and ct at the same time.
This enters repeat standby.
3.
Press the button (bt to cn) that corresponds to
the melody sampling tone number you want to
select.
This will start looped playback of the selected sound.
4.
Press the same button again to stop playback.
5.
Press bs to return to the screen that was
displayed before step 2 of this procedure.
You can use the following procedure to change the volume
level of the looped playback of each sampled sound, if you
want.
1.
Press the button of the sampled sound whose
volume you want to change (bt to cn).
This will cause the sounds loop to sound.
2.
While the loop is sounding, hold down the same
sampled sound button (bt to cn) as you press
any keyboard key.
Pressing the keyboard key quickly will increase sample
sound volume, while pressing slowly will decrease
volume.
3.
After the sampled sound is at the volume level
you want, release its button (bt to cn).
Looping a Sampled Sound
To select this tone number: Press this button:
601 bt
602 ck
603 cl
604 cm
605 cn
C4
S
y
n t h P o
p
Lights
Changing the Volume of Sampled Sound
Looped Playback
CTK4400_A5_x1a_EN_ES.indd 23 2014/02/19 10:25:14
Sampling Sounds and Playing Them on the Digital Keyboard
EN-22
You can apply various effects to sampled sounds.
1.
Press bn (TONE) and then use br (10-key) to
enter the tone number (601 to 605) to which you
want to apply effects.
2.
Press bn (TONE) to cycle through the available
effects, described below.
Avoid assigning the same sampled sound to the keyboard
for play along and for looped play. Doing so will cause, the
Loop 1 effect to be applied to the keyboard tone while
looped play of the sampled sound is being performed.
You can use the procedure to change the drum sounds that
are assigned to each keyboard key.
You can store up to three drum sets and store them as tone
numbers 606, 607, and 608. Simply select the tone number
where the drum set you want is located to assign the drum
set sounds to the keyboard.
1.
Press bo (RHYTHM).
2.
Press bn (TONE) and then use br (10-key) to
enter the tone number (606, 607, or 608) for the
drum set whose sounds you want to change.
3.
Hold down cs until the display changes to the
screen shown below.
Applying Effects to a Sampled Sound
Effect Type
(Display) Description
Original (Orgnl) Normal sampled tone (no looping, no
effect).
Loop 1 (Loop1) Loops the sampled sound.
Loop 2 (Loop2)
Loops the sample sound and raises the
pitch of the resonating sound when the
keyboard key is released.
Loop 3 (Loop3)
Loops the sample sound and lowers the
pitch of the resonating sound when the
keyboard key is released.
Pitch 1 (Ptch1) Changes the pitch from low to high, at an
increasing rate.
Pitch 2 (Ptch2) Changes the pitch from high to low, at a
decreasing rate.
Pitch 3 (Ptch3)
Changes the pitch from high to low, at a
decreasing rate, and then raises the pitch
when the key is released.
Tremolo (Treml) Alternates volume between high and low.
Funny 1 (Funy1) Adds vibrato and changes the pitch by a
gradually increasing amount.
Funny 2 (Funy2) Alternates between high pitch and low
pitch.
Funny 3 (Funy3) Adds vibrato and changes the pitch from
low to high.
Incorporating a Sampled Sound
into a Drum Set (Drum Sampling)
No Da t a
Lights
No Da t a
Flashes
CTK4400_A5_x1a_EN_ES.indd 24 2014/02/19 10:25:15
English
Sampling Sounds and Playing Them on the Digital Keyboard
EN-23
4.
Press the keyboard key* to which you want to
assign the drum sound you are about to
sample.
This enters sampling standby.
The allowable sampling time (in seconds) will appear on
the display momentarily and then the display will change
to the following.
5.
What you should do next depends on your
Digital Keyboard model as described below.
• CTK-4400:
Output sound from the external device.
WK-240, WK-245:
Output the sound in the direction of the microphone.
Sampling will start automatically.
Sampling will not start if the volume of the sound is too
low.
6.
After the sound you want to sample is finished,
press cs.
Sampling will stop.
Even if you do not press cs, sampling will stop
automatically whenever there is no more sound being
input from the external device or microphone. Sampling
also will stop automatically 10 seconds after it is
started.
7.
Press the keyboard key.
You can repeat steps 3 through 6 to change other sounds
that make up the currently selected drum set. There are
eight sounds per drum set.
You may not be able to get 10 seconds of sampling if
Digital Keyboard memory is low due to storage of other
data. If this happens, deleting other memory data you no
longer need will free up memory space and you should be
able to sample for 10 seconds. See “Deleting a Sampled
Sound” on page EN-26 for more information.
Sampling a sound will delete any sound data currently
assigned to the same keyboard key. To help ensure
that you do not accidentally delete important data, be
sure to read “Protecting Against Accidental Deletion of
Sampled Sounds” on page EN-26.
Flashes
W
aitin
g
C2 C7
*Drum sounds cannot be assigned to these keys
(WK-240, WK-245).
Flashes
Sam
p
l in
g
Used memory
(Unit: Kbytes) Remaining
memory capacity
Sm
p
l D rm1
CTK4400_A5_x1a_EN_ES.indd 25 2014/02/19 10:25:15
Sampling Sounds and Playing Them on the Digital Keyboard
EN-24
You can use the procedures in this section to copy the drum
sound assigned to one keyboard key to another key, to
change the pitch of a sound, and to delete a sampled sound.
1.
Press bn (TONE) and then use br (10-key) to
enter the tone number (606, 607, or 608) for the
drum set you want.
2.
Hold down cs until the SAMPLING indicator
starts to flash.
3.
Press ct (FUNCTION).
This is the editing mode.
While in the editing mode, you can copy a sound,
change the pitch of a sound, or delete a sound (each of
which is described below). Pressing ct (FUNCTION)
again exits the editing mode and returns to step 2 of
this procedure.
To copy a sampled sound from one key to
another
While holding down the keyboard key to which the sampled
sound you want to copy is assigned, press the keyboard key
to which you want to copy it.
A keyboard key that already has a sampled sound assigned
cannot be selected as a copy destination.
To change the pitch of a sampled sound
While holding down the keyboard key of the sampled sound
whose pitch you want to change, use the br (10-key) [–] and
[+] keys to change the pitch.
You can change the pitch within a range of –64 to 63
semitones.
To delete a keyboard key’s sampled sound
While holding down the keyboard key whose sound you want
to delete, press bo (RHYTHM). In response to the “DelSure?”
message that appears, press the br (10-key) [+] (YES) key to
delete, or [–] (NO) to cancel the delete operation.
Deleting a sampled sound will return the key to its initial
default built-in sound.
Use the following procedure to change the rhythm part of an
Auto Accompaniment pattern to a drum set sound that you
sampled.
1.
Press bo (RHYTHM) and then use br (10-key)
to enter the rhythm number of the Auto
Accompaniment pattern you want.
You cannot use a Drum Sampling Tone in a user rhythm,
so do not select a user rhythm in the above step.
2.
Press bn (TONE) and then use br (10-key) to
enter the tone number of the sampling drum set
that contains the sound you want to use.
3.
Press bn (TONE).
This changes the rhythm part of the Auto Accompaniment
pattern you selected in step 1 to the sampled sound you
selected in step 2.
To change the Auto Accompaniment rhythm part back
to its original sound, press bn (TONE) again.
Some rhythm part drum sounds cannot be replaced by
sampled sounds.
Editing Sampled Drum Set Sounds
Example: To copy sampled sound of key C4 to key D4
Flashes
Sm
p
l D rm1
Flashes at high
speed
Indicates keyboard keys that have sounds assigned.
Indicates the keyboard key whose sound was copied.
Example: To delete the sound assigned to key D4
Using a Drum Sampling Tone in Auto
Accompaniment (Drum Assign)
Disappears
CTK4400_A5_x1a_EN_ES.indd 26 2014/02/19 10:25:15
English
Sampling Sounds and Playing Them on the Digital Keyboard
EN-25
Normally when the Digital Keyboard is in sampling standby, it
will start sampling automatically whenever it detects sound
input. You can use the following procedure to enable manual
sampling start, which will cause sampling to wait until you
press a button to start it. You can use this to insert silence
before the sampled sound.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“SAMPLING” (page EN-7).
2.
Press the br (10-key) [9] (ENTER) key.
3.
Press the br (10-key) [–] key to turn off
automatic sampling start.
This enables manual sampling start, which operates as
described below.
Melody sampling (page EN-20):
Sampling starts when you hold down cs in step 2 of
the sampling procedure to enter sampling standby, and
then press cs again.
Drum sampling (page EN-22):
Sampling starts when you press a keyboard key in step
4 of the sampling procedure to enter sampling standby,
and then press cs.
Normally the Digital Keyboard will stop sampling automatically
whenever it detects there is no sound input. You can use the
following procedure to enable manual sampling stop, which
will cause sampling to continue until you press a button to
stop it. You can use this to insert silence after the sampled
sound.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“SAMPLING” (page EN-7).
2.
Press the br (10-key) [9] (ENTER) key.
3.
Press the br (10-key) [6] (p) key.
4.
Press the br (10-key) [–] key to turn off
automatic sampling stop.
Sampling continues until you perform one of the
operations below, even if nothing is being input from an
external device or the microphone.
Melody sampling (page EN-20)
Press cs.
Drum sampling (page EN-22)
Press cs.
Other Sampling Functions
Changing to a Manual Sampling Start
SAMPL I NG
Flashes
Au t oSt r t
Changing to Manual Sampling Stop
AutoSto
p
CTK4400_A5_x1a_EN_ES.indd 27 2014/02/19 10:25:15
Sampling Sounds and Playing Them on the Digital Keyboard
EN-26
You can use the following procedure to specify a sampled
tone number and delete its data.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“DELETE” (page EN-7).
2.
Press the br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [–] and [+] keys to select
the tone number of the data you want to delete.
4.
Press the br (10-key) [9] (ENTER) key.
This displays a delete confirmation message.
5.
Press the br (10-key) [+] (YES) key to delete the
data, or [–] (NO) or [7] (EXIT) to cancel the
delete operation.
After the delete procedure is complete, “Complete” will
appear on the display followed by the screen in step 1
of the above procedure.
For information about deleting individual drum sounds
in a drum sampling set, see “Editing Sampled Drum Set
Sounds” on page EN-24.
You can use the following procedure to protect each sampled
sound against accidental deletion.
1.
Press bn (TONE) and then use br (10-key) to
enter the tone number of the sampled tone you
want to protect.
2.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“SAMPLING” (page EN-7).
3.
Press the br (10-key) [9] (ENTER) key.
4.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “Protect”.
5.
Press the br (10-key) [+] key to turn on
protection.
Once protected a tone cannot be deleted.
A protected tone is indicated as shown below.
Saving Sample Data on an External Device
See page EN-62 for details about how to transfer sampled
data to a computer for storage.
Deleting a Sampled Sound
DELETE
Flashes
S1 :Or
g
nl
Used memory
(Unit: Kbytes) Remaining
memory capacity
Sure?
Protecting Against Accidental Deletion of
Sampled Sounds
Protect
*
1:Or
g
nl
Protected
CTK4400_A5_x1a_EN_ES.indd 28 2014/02/19 10:25:15
English
EN-27
Playing Built-in Songs
With this Digital Keyboard, built-in tune data is referred to as
“songs”. You can listen to the built-in songs for your own
enjoyment, or you can play along with them for practice.
In addition to simple listening enjoyment, the built-in songs
can be used with the lesson system (page EN-31) for
practice.
You can increase the number of tunes using your computer
(page EN-59).
Use the following procedure to play back built-in songs.
1.
Hold down 3 until the display changes to the
screen shown below.
This will start playback of the demo songs.
See page EN-69 for information about song numbers
and the song sequence.
2.
To change to another song while demo
playback is in progress, use br (10-key) [–] and
[+] keys to enter the song number you want
(page EN-7).
This will cause demo playback to jump to the song whose
number you entered.
You cannot use br (10-key) number buttons to select a
song.
3.
To stop demo playback, press bk.
Demo playback continues until you stop it by pressing bk.
If Auto Power Off (page EN-10) is enabled, the Digital
Keyboard will turn off if 30 minutes (six minutes under
battery power) elapse without any keyboard operation
being performed. Use the procedure under “Disabling Auto
Power Off” (page EN-10) for information about how to
disable Auto Power Off.
66778899 bkbk blbl
brbr
bpbp
bmbm ctct
33
Playing the Demo Songs
Ei neKl ne
Tune nameSong number
CTK4400_A5_x1a_EN_ES.indd 29 2014/02/19 10:25:16
Playing Built-in Songs
EN-28
Use the procedure below to play back one of the built-in
songs. You can play along on the keyboard with song
playback.
1.
Press bp (SONG BANK).
2.
Use br (10-key) to enter the number of the song
you want.
See page EN-69 for a complete list of available songs.
Use the number buttons to enter the song number.
Specify three digits for the song number.
3.
Press bk.
This starts playback of the song.
4.
Press bk again to stop playback.
Song playback will continue (repeat) until you press bk to
stop it. You can cancel song repeat by pressing 6.
Use the operations in this section to perform pause, skip
forward, and skip back operations.
Pause
1.
Press 9.
This pauses song playback.
2.
Press 9 again to resume playback from the
point where you paused it.
Skip Forward
1.
Press 8.
This skips song playback forward to the next measure.
Each press of 8 skips ahead one measure. Holding
down 8 skips forward at high speed until you release it.
Pressing 8 while song playback is stopped performs
lesson function phrase skip forward (page EN-32).
Skip Back
1.
Press 7.
This skips song playback back to the previous measure.
Each press of 7 skips back one measure. Holding down
7 skips back at high speed until you release it.
Pressing 7 while song playback is stopped performs
lesson function phrase skip back (page EN-32).
Playing Back a Particular Song
Start/Stop
Example: To select 001, enter 0 3 0 3 1.
Twinkle
Tune nameSong number
Key
Tempo
Beat
Measure
Fingering
Sustain pedal
Note
Indicator disappears when song repeat is turned off.
Pause, Skip Forward, Skip Back
Measure number
CTK4400_A5_x1a_EN_ES.indd 30 2014/02/19 10:25:16
English
Playing Built-in Songs
EN-29
You can use the procedure in this section to repeat particular
measures for practice playing along until you master it. You
can specify the start measure and the end measure of the
section you want to play and practice.
1.
Press 6 to temporarily turn off song repeat.
2.
When song playback reaches the measure you
want to specify as the start measure, press 6.
This specifies the measure as the start measure.
3.
When playback reaches the measure you want
to select as the end measure, press 6 again.
This specifies the measure as the end measure and starts
repeat playback of the measures in the specified range.
During repeat play you can use 9 to pause playback,
8 to skip forward, or 7 to skip back.
4.
Pressing 6 again returns to normal playback.
Changing the song number clears the start measure and
end measure of the repeat operation.
You can use the following procedure to change the speed
(tempo) in order to slow down playback to practice difficult
passages, etc.
1.
Press bm.
Use y (slower) and t (faster) to change the tempo
setting. Holding down either button changes the setting at
high speed.
Pressing y and t at the same time will return the
current song to its original default tempo.
Pressing bm causes the tempo value to flash on the
display. While the tempo value is flashing, you can use
br (10-key) to change it. The tempo value will stop
flashing if you do not perform any operation for a short
while.
Changing the song number will return the song to its
original default tempo.
Repeating Playback of Specific Measures
Start End
These measures are repeated.
Disappears
Flashes
Lights
Changing Playback Speed (Tempo)
Disappears
CTK4400_A5_x1a_EN_ES.indd 31 2014/02/19 10:25:16
Playing Built-in Songs
EN-30
Use the following procedure to adjust the balance between
the volume of what you play on the keyboard and song
playback volume.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“Song Vol” (page EN-7).
2.
Use the br (10-key) [–] and [+] keys to adjust
the song volume.
The procedure below lets you select the same keyboard tone
as the one being used in the song and play along with your
favorite tunes.
1.
After selecting a song, hold down bp (SONG
BANK) for about two seconds until the
displayed tone name changes to the tone name
of the song.
If your currently selected tone is the same as the song
tone, the display contents will not change.
2.
Play along with song playback.
If you select a song that uses different tones for left and
right hand play, the right hand part tone is assigned to the
keyboard.
You can turn off the right hand part or the left hand part of a
song during playback and practice playing along with the
remaining part.
1.
Press bl to select the part you want to turn off.
Each press of bl cycles through the settings shown
below.
2.
Press bk.
This starts playback in accordance with the setting you
selected in step 1.
During playback with one part turned off, only the notes of
the part that is turned off are shown on the display.
You can load song data from an external device and increase
the selection of songs available on the keyboard. See the
following pages for more information.
See page EN-62 for details about how to transfer sampled
data to a computer for storage.
For information about how to delete song data loaded from
an external device, see page EN-58.
Adjusting the Song Volume
Playing with the Tone as Song Playback
Son
g
Vo l
Turning Off the Part of One Hand for Practice
(Part Select)
Increasing the Selection of Songs
Right hand part off
Left hand part off
Both hand parts off
Both hand parts on
CTK4400_A5_x1a_EN_ES.indd 32 2014/02/19 10:25:16
English
EN-31
Using Built-in Songs to Master Keyboard Play
To master a song, it is best to break it up into shorter parts
(phrases), master the phrases, and then put everything
together. Your Digital Keyboard comes with a Step Up Lesson
feature that helps you to do just that.
The built-in songs are pre-divided into phrases to help you
master keyboard play.
Step Up Lesson takes you through practice of the right hand
part, left hand part, and both hand parts for each phrase of a
song. Master all of the phrases and you master the song.
667788 bkbk blbl
bpbp
bsbsbtbtckckclclcmcm ctct
brbr
Phrases
Song start Song end
Phrase 1 Phrase 2 Phrase 3 . . . . Final
Phrase
Step Up Lesson Flow
Phrase 1
Right Hand Lesson 1, 2, 3
Left Hand Lesson 1, 2, 3
Both Hand Lesson 1, 2, 3
4
Repeat the above to practice phrase
2, 3, 4, and so on, until you reach the
final phrase of the song.
4
After mastering all of the phrases,
practice the entire song.
4
Now you have mastered the entire
song!
CTK4400_A5_x1a_EN_ES.indd 33 2014/02/19 10:25:16
Using Built-in Songs to Master Keyboard Play
EN-32
The following are the messages that appear on the display
during Step Lessons.
First, select the song, phrase, and part you want to practice.
1.
Select the song you want to practice (page
EN-28).
This will select the first phrase of the song.
2.
Press cl (or 8) to move forward one phrase,
or 7 to move back one phrase.
Holding down 8 or 7 scrolls through phrases at high
speed.
The Digital Keyboard remembers the last phrase you
practiced for up to 20 songs. To recall the last practice
phrase for the current song (if it is available), hold down
cl.
3.
Press bl to select the part you want to practice.
Each press of bl cycles through the settings shown
below.
4.
Hold down bp (SONG BANK) for about two
seconds.
The same tone used for song playback will be assigned to
the keyboard (page EN-30).
Messages that Appear during Lessons
Message Description
<Phrase> Appears when you select a phrase, when a
lesson starts, etc.
Note that certain phrases will cause
“<Wait>” to appear instead of “<Phrase>”.
<Wait> Appears when the lesson starts with an intro
or fill-in phrase that is not included in the
phrases to be practiced. Play toll advance
automatically to the next phrase after the un-
included phrase plays, so wait until then to
start playing on the keyboard.
NextPhrs Appears when advancing automatically to the
next phrase. This message appears following
a phrase for which “<Wait>” (see above) is
displayed, and during an Auto Step Up Lesson
(page EN-36).
Listen
Watch
Remember
Appears at the start of Auto Step Up lesson 1,
2, or 3 (page EN-36).
From top This message appears during Auto Step Up
Lesson (page EN-36) immediately before
practice from Phrase 1 up until the phrase
currently being practiced.
Complete Appears at the end of Auto Step Up Lesson
(page EN-36).
Selecting the Song, Phrase, and
Part You Want to Practice
<Phrase>
Phrase number
First measure of the selected phrase
*This indicator (setting) is skipped if you press bl while
a lesson is in progress.
Right hand practice
Left hand practice
Both hand practice
*
CTK4400_A5_x1a_EN_ES.indd 34 2014/02/19 10:25:17
English
Using Built-in Songs to Master Keyboard Play
EN-33
Now it is time to start the lessons. First, select the song and
part you want to practice.
First, listen to the example a few times to familiarize yourself
with what it sounds like.
1.
Press bs.
This starts example play.
2.
To stop Lesson 1, press bs or bk.
Play the song on the keyboard. During this lesson, the display
shows the key you need to press next. Voice fingering guide
also uses a simulate voice to announce which finger you
should use. Follow the instructions to press the correct
keyboard keys and play the notes. Don’t worry if you play the
wrong note. Song playback will wait until you play the correct
note. Take your time and play at your own pace.
1.
Press bt.
This starts Lesson 2.
2.
Play notes on the keyboard in accordance with
the instructions provided on the display and by
voice fingering guide.
During this lesson, the display shows the key you need to
press next. Voice fingering guide uses a simulate voice to
announce which finger you should use.
3.
To stop Lesson 2, press bt or bk.
If you complete Lesson 2 play to the end, a score that
rates your play appears on the screen.
Lessons 1, 2, and 3
Lesson 1: Listen to the song.
Lesson 2: Watch how the song is played.
<Lesson 2 Guidance>
Master playing the correct note with the correct finger
as instructed by the guidance. Practice playing with the
correct timing.
4
Song playback will wait for you to play the correct note.
Keyboard key goes from flashing to lit.
Note guide sounds the correct note to be played.
Voice Fingering Guide tells you what finger to use.
4
Pressing the correct keyboard key causes song
playback to resume and the key for the next note
flashes.
Bravo! You pass! Advance to the next lesson.
Again! Go back and try again.
Lights
Flashes
CTK4400_A5_x1a_EN_ES.indd 35 2014/02/19 10:25:17
Using Built-in Songs to Master Keyboard Play
EN-34
Though song playback stands by waiting for you to press the
correct keys as in Lesson 2, the Digital Keyboard does not
provide any guidance about what note you need to play next.
Remember everything you have learned up to Lesson 2 as
you play.
1.
Press ck.
This starts Lesson 3.
2.
Play the song along with the song playback.
3.
To stop Lesson 3, press ck or bk.
If you complete Lesson 3 play to the end, a score that
rates your play appears on the screen the same as with
Lesson 2.
After you successfully complete all of the phrases in Lessons
1, 2, and 3, it is time to try playing the entire song from
beginning to end.
1.
Use bl to turn off both hand parts and then
press bk.
Try playing with both hands and find out how the Digital
Keyboard evaluates your effort.
You can turn off phrase repeat for Lessons 1, 2, and 3.
1.
Press 6.
This disables phrase repeat play.
Use the following procedure to turn off voice fingering guide,
which tells you which finger to use to play each note in
Lesson 2 and Lesson 3.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“LESSON” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Press the br (10-key) [–] key to select the OFF
setting.
Lesson 3: Remember what you learned as
you play.
<Lesson 3 Guidance>
Press the keyboard keys you learned in Lesson 2.
4
Song playback will wait for you to play the correct note.
Note guide sounds the correct note to be played.
4
If you are still unable to press the correct keyboard
key, the Digital Keyboard will display keyboard
guidance and voice fingering guide will tell you what
finger to use, just as in Lesson 2.
4
Pressing the correct key will cause song playback to
resume.
Playing a Particular Song All the Way
Through
Lesson Settings
Playing without Phrase Repeat
Turning Off Voice Fingering Guide
Disappears
LESSON
Flashes
S
p
eak
CTK4400_A5_x1a_EN_ES.indd 36 2014/02/19 10:25:17
English
Using Built-in Songs to Master Keyboard Play
EN-35
Use the following procedure to turn off note guide, which
sounds the note to be played next in Lesson 2 and Lesson 3.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“LESSON” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “NoteGuid”.
4.
Press the br (10-key) [–] key to select the OFF
setting.
Use the following procedure to turn off performance
evaluation, which evaluates your performance and displays a
score in Lesson 2 and Lesson 3.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“LESSON” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “Scoring”.
4.
Press the br (10-key) [–] key to select the OFF
setting.
You can use the following procedure to change the length of
lesson phrases, or to configure the lesson feature so the song
is played all the way through, without being divided into
phrases.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“LESSON” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “PhraseLn”.
4.
Use the br (10-key) [–] and [+] keys to select
the phrase length you want.
The following options are available for songs loaded from
external sources only.
Turning Off Note Guide
Turning Off Performance Evaluation
No t eGu i d
Sco r i ng
Changing the Phrase Length
Off (oFF) The phrase length is from the beginning
to the end of the song.
Preset (PrE) Phrase lengths are as specified in the
song.
Short (Ln1) Length of one phrase is one measure.
Middle (Ln2) Length of one phrase is two measures.
Long (Ln3) Length of one phrase is four measures.
PhraseLn
CTK4400_A5_x1a_EN_ES.indd 37 2014/02/19 10:25:17
Using Built-in Songs to Master Keyboard Play
EN-36
With Auto Step Up Lesson, the Digital Keyboard advances
through each lesson automatically.
1.
Select the song and part you want to practice
(page EN-28).
2.
Press cm.
Listen to the first phrase in Lesson 1.
In Lesson 1, the sample phrase is played only once
before advancing to Lesson 2.
3.
Auto Step Up Lesson stops automatically after
you are able to get through all of the lessons
successfully.
In Lesson 2 and Lesson 3, the Digital Keyboard
advances to the next lesson if you are able to achieve
the “Bravo!” evaluation result.
To cancel a lesson, press cm or bk.
You can change the step and phrase during Auto Step Up
Lesson using 7, 8, and bs to cl.
Starting Auto Step Up Lesson automatically turns on
phrase repeat (page EN-34) and play evaluation (page
EN-35). These features cannot be turned off during
lessons.
Auto Step Up Lesson Procedure
*Auto Step Up Lesson advances to the next phrase,
regardless of whether the “Bravo!” result is attained.
Using Auto Step Up Lesson
Phrase 1
Lesson 1
4
Lesson 2
4
Lesson 3
4
Phrase 2
Lesson 1
4
Lesson 2
4
Lesson 3
4
Phrase 1, 2
Lesson 3*
4
Phrase 3
Lesson 1
4
Lesson 2
4
Lesson 3
4
Phrase 1, 2, 3
Lesson 3*
4
Next phrase practice using the same
procedure
4
Final phrase
Lesson 1
4
Lesson 2
4
Lesson 3
4
From Phrase 1 to the final phrase
Lesson 3*
4
Lesson complete
CTK4400_A5_x1a_EN_ES.indd 38 2014/02/19 10:25:17
English
EN-37
Music Challenge Keyboard Game
Music Challenge is a game that measures your reaction
speed as you press keys in response to on-screen keyboard
indicators and fingering guide indications.
1.
Press bp (SONG BANK).
2.
Press cn.
This causes a key on the on-screen keyboard to start to
flash, and starts the Music Challenge song.
3.
After the on-screen keyboard indicator changes
from flashing to lit, press the indicated key with
the indicated finger as quickly as possible.
This causes the on-screen keyboard key to go out to let
you know that you cleared the first note. The next on-
screen keyboard key starts to flash, so get ready to press
the next key.
The time it takes you to press the keyboard key after
the on-screen key lights appears on the display (Unit:
0.1 sec). The shorter the time, the higher your score.
Pressing a keyboard key before the on-screen key
goes from flashing to lit, will not advance to the next
note.
4.
The game ends when you advance successfully
through 20 notes.
Your playing time appears on the display. After a short
while, the playing time display changes to a score. To
clear the score from the display, press bn (TONE), bo
(RHYTHM), or bp (SONG BANK).
You can cancel a game at any time by pressing cn or
bk.
Notes and fingering guide fingers are indicated randomly.
The tempo of the game songs cannot be changed.
All buttons except 1, bk, and cn are disabled while a
game is in progress.
11 bobobnbn
cncnbkbk
bpbp
M . CHAL . !
Fingering
Displayed during a game.
Number of remaining notes
M . CHAL . !
Time 0.3sec
Score100
Time19.2
Playing time
Score
CTK4400_A5_x1a_EN_ES.indd 39 2014/02/19 10:25:17
EN-38
Using Auto Accompaniment
With Auto Accompaniment, simply select an accompaniment
pattern. Each time you play a chord with your left hand the
appropriate accompaniment will play automatically. It’s like
having a personal backup group along with you wherever you
go.
Auto Accompaniments are made up of the following three
parts.
(1) Rhythm
(2) Bass
(3) Harmony
You can have only the rhythm part play, or you can have all
three parts play at the same time.
The rhythm part is the foundation each Auto Accompaniment.
Your Digital Keyboard comes with a variety of built-in rhythms,
including 8-beat and waltz. Use the following procedure to
play the basic rhythm part.
1.
Press bo (RHYTHM).
2.
Use br (10-key) to select the rhythm number
you want.
See the separate “Appendix” for information about
individual rhythms.
Use the number buttons to enter the rhythm number.
Specify three digits for the rhythm number.
3.
Press bk or 7.
This starts the rhythm.
4.
Play along with the rhythm.
5.
To stop the rhythm, press bk again.
99 bmbm667788 blblbkbk cqcq
brbr
ctct
bobobqbq
cscs
bnbnbpbp
Playing the Rhythm Part Only
Starting and Stopping the Rhythm Part Only
Example: To select 001, enter 0 3 0 3 1.
S
y
n t h P o
p
Rhythm number Rhythm pattern name
This pattern changes with each beat.
CTK4400_A5_x1a_EN_ES.indd 40 2014/02/19 10:25:18
English
Using Auto Accompaniment
EN-39
Playing a chord with your left hand automatically adds bass
and harmony accompaniment parts to the currently selected
rhythm. It is just like having your own personal back up group
on call.
1.
Start play of the Auto Accompaniment rhythm
part.
2.
Press bl.
This enables chord input on the accompaniment
keyboard.
3.
Use the accompaniment keyboard to play
chords.
This will cause bass and harmony Auto Accompaniment
parts to be added to the rhythm part.
The illustration below shows the chord keyboard range
under WK-240 and WK-245 initial default settings.
4.
Play other chords with left hand as you play the
melody with your right hand.
5.
Pressing bl again returns to rhythm only
accompaniment.
For information about starting Auto Accompaniment as
soon as a chord is played, see “Using Synchro Start” on
page EN-42.
You can use the split point to change the size of the
accompaniment keyboard range (page EN-16).
You can select from among the following five chord input
modes.
FINGERED 1
FINGERED 2
FINGERED 3
CASIO CHORD
FULL RANGE CHORD
1.
Hold down bl until the chord input mode
selection screen appears on the display.
2.
Use the br (10-key) [–] and [+] keys to select
the chord input mode you want.
If you do not perform any operation after the chord input
mode selection screen appears, the display will return
automatically to the screen that was displayed before
you held down bl.
Playing All Parts
Auto Accompaniment with Chords
Example: Pressing D-F#-A-C on the accompaniment keyboard
4
Accompaniment for the D-F#-A-C chord (D7) sounds.
Accompaniment keyboard
Lights
F3
Chords
(no melody played) Melody
Selecting a Chord Input Mode
Chord
Chord input mode
CTK4400_A5_x1a_EN_ES.indd 41 2014/02/19 10:25:18
Using Auto Accompaniment
EN-40
FINGERED 1, 2, and 3
With these three input modes, you play chords on the
accompaniment keyboard using their normal chord fingerings.
Some chord forms are abbreviated, and can be fingered with
one or two keys.
See page EN-70 for information about chords that are
supported and how they are fingered on the keyboard.
FINGERED 1
Play the component notes of the chord on
the keyboard.
FINGERED 2
Unlike FINGERED 1, 6th input is not
possible. m7 or m7b5 is input.
FINGERED 3
Unlike FINGERED 1, allows input of
fraction chords with the lowest keyboard
note as the bass note.
CASIO CHORD
With CASIO CHORD, you can use
simplified fingerings to play the four types
of chords described below.
CASIO CHORD Fingering
When playing a minor, seventh, or minor seventh chord, it
makes no different whether the additional keys you press
are black or white.
FULL RANGE CHORD
With this mode, you can use the full range
of the keyboard to play chords and the
melody.
See page EN-70 for information about
chords that are supported.
Accompaniment keyboard
Accompaniment keyboard
Chord Type Example
Major Chords
Letters above the accompaniment
keyboard indicate the chord assigned
to each key. Pressing a single
accompaniment area key in the
CASIO CHORD mode will play the
major chord whose name is marked
above the key. All of the
accompaniment area keys that are
marked with the same chord name
play exactly the same chord.
C (C Major)
Minor Chords
To play a minor chord, press the
accompaniment area key that
corresponds to the major chord, while
also pressing one other
accompaniment area key to the right.
Cm (C Minor)
Seventh Chords
To play a seventh chord, press the
accompaniment area key that
corresponds to the major chord, while
also pressing two other
accompaniment area keys to the right.
C7 (C Seventh)
Minor Seventh Chords
To play a minor seventh chord, press
the accompaniment area key that
corresponds to the major chord, while
also pressing three other
accompaniment area keys to the right.
Cm7
(C Minor Seventh)
A
CCDE F F
#
b
E
#
G
b
AB
B
b
CCDE F
E
#
b
A
CCDE F F
#
b
E
#
G
b
AB
B
b
CCDE F
E
#
b
A
CCDE F F
#
b
E
#
G
b
AB
B
b
CCDE F
E
#
b
A
CCDE F F
#
b
E
#
G
b
AB
B
b
CCDE F
E
#
b
Accompaniment keyboard / Melody keyboard
CTK4400_A5_x1a_EN_ES.indd 42 2014/02/19 10:25:18
English
Using Auto Accompaniment
EN-41
Use the following procedures to play intro and ending
patterns, to play fill-in patterns, and to play variations of basic
Auto Accompaniment patterns.
Auto Accompaniment Variation
Each Auto Accompaniment pattern has a basic “normal
pattern” as well as a “variation pattern”.
1.
Press 8.
This starts the variation pattern.
2.
Pressing 7 returns to normal pattern.
Auto Accompaniment Intro
Use the following procedure to play an intro of a few
measures.
1.
Press 6.
This starts the intro pattern. Normal pattern play will start
when the intro pattern is finished.
If you press 8 while an intro pattern is being played,
the variation pattern will start when the intro pattern is
finished.
Auto Accompaniment Fill-in
Use the procedure below to play a fill-in pattern during a
performance.
A “fill-in” is a short phrase played where you want to change
the mood of a piece. A fill-in pattern can be used to create a
link between two melodies or an accent.
Normal and variation patterns have their own unique fill-in
patterns.
Normal Pattern Fill-in
1.
While a normal pattern is playing, press 7.
This plays the fill-in for the normal pattern.
Normal pattern play will resume after the fill in pattern is
complete.
Variation Pattern Fill-in
1.
While a variation pattern is playing, press 8.
This plays the fill-in for the variation pattern.
Variation pattern play will resume after the fill in pattern
is complete.
Auto Accompaniment Ending
Use the following procedure to play an ending of a few
measures.
1.
While an Auto Accompaniment is playing, press
9.
This will play the ending pattern and then stop Auto
Accompaniment play automatically.
Using Auto Accompaniment
Effectively
Auto Accompaniment Pattern Variations
Lights
Lights
Lights
Lights
Lights
Lights
CTK4400_A5_x1a_EN_ES.indd 43 2014/02/19 10:25:19
Using Auto Accompaniment
EN-42
Using Synchro Start
Use the following procedure to configure the Digital Keyboard
to start Auto Accompaniment play as soon as you press a
keyboard key.
1.
Press 9.
This enters accompaniment start standby.
2.
Play a chord on the keyboard.
This will start full part accompaniment (normal).
Any of the following operations can be performed while in
synchro standby to start a non-normal pattern.
To start with intro pattern, press 6.
To start with variation pattern play, press 8.
Use the following procedure to change Auto Accompaniment
speed to a level that suits you.
1.
Press bm.
Use y (slower) and t (faster) to change the tempo
setting. Holding down either button changes the setting at
high speed.
Pressing y and t at the same time will initialize the
tempo setting in accordance with the currently selected
rhythm.
While the tempo value is flashing, you also can use br
(10-key) to change it.
If you do not perform any operation for a few seconds
after the tempo setting screen appears, the display will
return to the screen displayed before you pressed bm.
Use the following procedure to adjust the balance between
what you are playing on the keyboard and the volume of the
Auto Accompaniment.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“AcompVol” (page EN-7).
2.
Use the br (10-key) [–] and [+] keys to adjust
the accompaniment volume.
With One-Touch Preset, the Digital Keyboard automatically
configures optimal tone, tempo, and other settings in
accordance with the rhythm pattern you select.
1.
Hold down bo (RHYTHM) until the current tone
screen appears on the display.
This will automatically apply the One-Touch Preset
settings in accordance with the rhythm pattern that is
currently selected.
2.
Play a chord on the keyboard.
This will start accompaniment automatically.
Changing Auto Accompaniment Speed
(Tempo)
Flashes
Flashes
Adjusting the Accompaniment Volume
Using One-Touch Preset
Ac om
p
Vo l
CTK4400_A5_x1a_EN_ES.indd 44 2014/02/19 10:25:19
English
Using Auto Accompaniment
EN-43
Auto Harmonize automatically adds harmony to notes you
play with your right hand, which adds rich depth to the melody
of your performances. You can select from among 12 types of
Auto Harmonize to suit the type of music you are playing.
Auto Harmonize is controlled using the same button cq as
the Arpeggiator (page EN-57). Because of this, these two
functions cannot be used at the same time.
1.
Press bl to enable Auto Accompaniment with
chords (ACCOMP indicator lit) (page EN-39).
Auto Harmonize cannot be used while FULL RANGE
CHORD is selected as the chord input mode. Select
another mode if you want to use Auto Harmonize.
2.
Hold down cq until the Auto Harmonize or
Arpeggiator type number and type name appear
on the display.
If you do not perform any operation for a few seconds,
the display will return to previous screen automatically.
3.
Use the br (10-key) [–] and [+] keys to select
the Auto Harmonize type you want.
013 through 102 are Arpeggiator types (page EN-57).
Do not select them when using the Auto Harmonize.
4.
Press cq to turn on Auto Harmonize.
If you play chords with your left hand and the melody with
your right hand, harmony notes will be added to the
melody.
Press cq again to turn off Auto Harmonize.
Using Auto Harmonize
Due t 1
Type number Type name
Due t 2
Type
number Type Name Description
001 Duet 1 Adds close (separated by 2 to 4
degrees) 1-note harmony below
the melody note.
002 Duet 2 Adds open (separated by more
than 4 to 6 degrees) 1-note
harmony below the melody note.
003 Country Adds country style harmony.
004 Octave Adds the note from the next lower
octave.
005 5th Adds the fifth degree note.
006 3-Way Open Adds 2-note open harmony, for a
total of three notes.
007 3-Way Close Adds 2-note close harmony, for a
total of three notes.
008 Strings Adds harmony that is optimal for
strings.
009 4-Way Open Adds 3-note open harmony, for a
total of four notes.
010 4-Way Close Adds 3-note close harmony, for a
total of four notes.
011 Block Adds block chord notes.
012 Big Band Adds big band style harmony.
St .GrPno
Lit when on
CTK4400_A5_x1a_EN_ES.indd 45 2014/02/19 10:25:19
Using Auto Accompaniment
EN-44
You can use the Chord Book to look up chords that you do not
know how to play.
1.
Hold down cr until the message “ChordBk”
appears on the display.
2.
On the chord keyboard, press the keyboard key
that corresponds to the root note of the chord
you want to look up.
3.
Use the br (10-key) [–] and [+] keys to select
the type of chord you want.
Selecting a chord type causes the chord to sound, and
shows the chord name and its notes on the display.
You can select any one of the following chord types.
To display inverted forms of the chord, use br (10-key)
keys [0] through [4] as shown below.
4.
After you are finished looking up what you
want, press cr to exit the Chord Book.
You can also exit the chord book by pressing bn
(TONE), bo (RHYTHM), bp (SONG BANK), or bq.
Looking Up the Notes of Chords
(Chord Book)
Example: To look up C
ChordBk
Chord keyboard
ChordBk
Root note
Example: Selecting M (Major)
M(Major), m(minor), dim, aug, sus4, sus2, 7th, m7,
M7, m7b5, 7b5, 7sus4, add9, madd9, mM7, dim7, 69,
6th, m6
To display this inverted form: Press this key:
Normal form 0
First inversion 1
Second inversion 2
Third inversion 3
Fourth inversion 4
M
(
Ma
j
or
)
Chord type Chord notes
CTK4400_A5_x1a_EN_ES.indd 46 2014/02/19 10:25:19
English
EN-45
Editing Auto Accompaniment Patterns
You can use the procedure in this section to edit the Digital
Keyboard’s built-in Auto Accompaniment rhythm patterns and
create your own “user rhythms”.
You can store up to 10 user rhythms in Digital Keyboard
memory, using rhythm numbers 181 through 190.
Editable Accompaniment Patterns and
Instrument Parts
Any of the following parts that make up each rhythm that is
assigned a rhythm number can be edited.
Accompaniment patterns (intro, fill-in, etc.): 6 types
Instrument parts (drum, bass, etc.): 8 types
Editable Contents
Rhythm number
Part on/off
Tone number
Volume level
Left-right speaker balance (panning)
Reverb depth (reverb send)
Chorus depth (chorus send)
1.
Select the number of the rhythm you want to
edit.
2.
Press 4.
If the “Err Mem Full” message appears on the display, see
page EN-68 for information about what you should do.
99667788 blblbkbk
44 brbr
ctct
bobo
Accompaniment Pattern
Instrument
Parts
Button
I N NF V VF E
1Drum I-1 N-1 NF-1 V-1 VF-1 E-1
2Percussion I-2 N-2 NF-2 V-2 VF-2 E-2
3Bass I-3 N-3 NF-3 V-3 VF-3 E-3
4Chord 1 I-4 N-4 NF-4 V-4 VF-4 E-4
5Chord 2 I-5 N-5 NF-5 V-5 VF-5 E-5
6Chord 3 I-6 N-6 NF-6 V-6 VF-6 E-6
7Chord 4 I-7 N-7 NF-7 V-7 VF-7 E-7
8Chord 5 I-8 N-8 NF-8 V-8 VF-8 E-8
Button 677889
INTRO
NORMAL
NORMAL
FILL-IN
VARIATION
VARIATION
FILL-IN
ENDING
bl
To edit and save an Auto Accompaniment
Drm: Rh
y
.
Rhythm number
Editable content
Instrument part
Accompaniment Pattern
(Flashes)
Lights
CTK4400_A5_x1a_EN_ES.indd 47 2014/02/19 10:25:19
Editing Auto Accompaniment Patterns
EN-46
3.
Press a button from 6 to 9 to select the
Accompaniment Pattern you want to edit.
The name of the pattern will appear on the display.
Pattern selected by each button
4.
Press bl to select the instrument part you want
to edit.
The part number of the part you select will flash on the
display.
5.
Press bo (RHYTHM).
This will display the rhythm name.
6.
Use the br (10-key) [–] and [+] keys to select
the rhythm number you want to assign to the
instrument part you are editing.
A different rhythm number is assigned for each instrument
part.
You can play the data of the currently selected rhythm
number by pressing bk.
All of the eight instrument parts of an intro (I-1 to 8)
must have the same rhythm number. If you assign
rhythm 003 to I-1, for example, 003 also will be
assigned automatically to parts I-2 through I-8. If you
then assign rhythm 004 to part I-2, for example, I-1 and
all of the other parts also will change to 004. All of the
eight parts of an ending (E-1 to E-8) also must have the
same rhythm number.
7.
To edit the other contents, press ct
(FUNCTION) to display the screen for the
setting you want.
Each press of ct (FUNCTION) will cycle through the
settings shown below, from 1 through 6.
Use the br (10-key) [–] and [+] keys to change the
currently selected setting.
You can play the current settings of the editable part by
pressing bk.
*Instrument parts 1 and 2 can be assigned drum set tones
only.
8.
Repeat steps 4 through 7 as many times as
necessary to edit the parts you want for the
pattern you selected in step 3.
If you change the rhythm number in step 6, the editable
contents (1 through 6 in the above table) you last
configured in step 7 of this procedure will be overwritten
with the settings of the newly selected rhythm.
9.
Repeat steps 3 through 8 as many times as
necessary to edit the accompaniment patterns
you want (intro through ending).
10.
Press 4.
This will display a message asking if you want to save the
user rhythm.
6: Intro
7: Normal, Normal Fill-in
(Each press toggles the selection.)
8: Variation, Variation Fill-in
(Each press toggles the selection.)
9: Ending
Drm: Rh
y
8 Variation selected
Part 6 (Chord 3)
Flashing: Part selected for editing.
Parts that contain data.
Setting Type Display Settings
1 Part on/off Part On/Off
2 Tone number*Tone 001 - 583
3 Volume level Vol. 000 - 127
4Left-right speaker
balance (panning) Pan –64 - 0 - +63
5Reverb depth
(reverb send) Rvb 000 - 127
6Chorus depth
(chorus send) Cho. 000 - 127
CTK4400_A5_x1a_EN_ES.indd 48 2014/02/19 10:25:20
English
Editing Auto Accompaniment Patterns
EN-47
11-1.
Press the br (10-key) [–] key to exit without
saving.
This displays the delete confirmation message.
Press the br (10-key) [+] key to exit the editing
procedure.
11-2.
Press the br (10-key) [+] key to save the data.
Use br (10-key) [–] and [+] keys to select the rhythm
number you want to save.
You can edit the user rhythm name. Use the br
(10-key) [4] (o) and [6] (p) keys to move the cursor
to the character you want to change, and then use [+]
and [–] to change the character.
12.
Press br (10-key) [9] (ENTER) key.
This will display a message asking if you want to save the
user rhythm.
Press the br (10-key) [+] key to save the data.
Press the br (10-key) [–] key to return to the screen
that was displayed before you pressed [9] (ENTER)
key.
If you select a user rhythm number that already
contains data, the existing data will be replaced by the
new data.
You cannot change the tone assigned to the keyboard
while an Auto Accompaniment editing (rhythm edit)
operation is in progress.
Saving User Rhythm Data on an External Device
See page EN-62 for details about how to transfer sampled
data to a computer for storage.
The following procedure cannot be performed while an Auto
Accompaniment editing (rhythm edit) operation is in progress.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“DELETE” (page EN-7).
2.
Press the br (10-key) [9] (ENTER) key.
3.
Press the br (10-key) [6] (p) key.
4.
Use the br (10-key) [–] and [+] keys to select
the user rhythm you want to delete.
5.
Press the br (10-key) [9] (ENTER) key.
This displays a delete confirmation message.
6.
Press the br (10-key) [+] (YES) key.
After the delete procedure is complete, “Complete” will
appear followed by the screen in step 2 of the above
procedure.
To cancel the delete operation, press [–] (NO) or [7]
(EXIT) in place of [+] (YES).
S
y
n t h P o
p
To delete saved data
Used memory (Unit: Kbytes)
Remaining memory capacity
DELETE
Flashes
Use 1
User rhythm name
Sure?
CTK4400_A5_x1a_EN_ES.indd 49 2014/02/19 10:25:20
EN-48
Saving Keyboard Setups to Registration Memory
Registration memory lets you store Digital Keyboard setups
(tone, rhythm, etc.) for instant recall whenever you need them.
Registration memory simplifies performance of complex
pieces that require successive tone and rhythm changes.
You can have up to 32 setups in Registration memory at one
time. bs and bt to cm are used for recording.
Each press of bank select button bs cycles through the
bank numbers, from 1 to 8.
Pressing a button from bt to cm selects the corresponding
area in the currently selected bank.
Registration Save Example
This example saves the data shown in the table below to the
following setups in Bank 1.
Initial melody setup saved to Setup 1-1.
Second melody setup saved to Setup 1-2.
Third melody setup saved to Setup 1-3.
Registration Memory Data
The following is the complete list of data that is saved to a
registration memory setup.
Tone numbers (main, layer, split)
Rhythm number
• Tempo
Auto Harmonize
• Transpose
Split point
Touch Response
Octave shift
Chord fingerings
Accompaniment volume
Arpeggiator setting (on, off, type)
Synchro start
VIRTUAL HALL (on, off)
Reverb (on, off, type)
Chorus (on, off, type)
Accomp (on, off)
Arpeggiator hold (on, off)
Layer (on, off)
Split (on, off)
Pedal effect
brbr
bobo
bsbsbtbtckckclclcmcmcncn
Area 1 Area 2 Area 3 Area 4
Bank 1 Setup 1-1 Setup 1-2 Setup 1-3 Setup 1-4
Bank 2 Setup 2-1 Setup 2-2 Setup 2-3 Setup 2-4
.
.
.
.
.
.
.
.
.
.
Bank 8 Setup 8-1 Setup 8-2 Setup 8-3 Setup 8-4
bs bt ck cl cm
Setup 1–1 Setup 1–2 Setup 1–3
Tone Number 001 062 001
Rhythm Number 118 005 089
Tempo 080 140 089
CTK4400_A5_x1a_EN_ES.indd 50 2014/02/19 10:25:20
English
Saving Keyboard Setups to Registration Memory
EN-49
1.
Press bo (RHYTHM).
2.
Configure the tone, rhythm, and other settings
you can to include in the setup.
3.
Press bs to select the bank you want.
Each press of bs cycles through the bank numbers.
You also can select a bank by holding down bs as you
use the br (10-key) number buttons to enter a bank
number.
4.
While holding down cn, press a button from bt
to cm to select an area.
This will save the settings you configured in step 2 into the
applicable setup.
If there is anything already stored in the setup, it will be
replaced (deleted) by the new setup.
1.
Press bs to select the bank that contains the
setup you want to recall.
2.
Use buttons bt to cm to select the area whose
setup you want to recall.
This will recall the registration memory setup and
automatically configure the Digital Keyboard settings
accordingly.
Notes currently being sounded by the keyboard may stop if
you recall a setup that causes a change in octave shift
(page EN-18). To keep this from happening, either select a
setup that does not cause a change in the octave shift
setting, or hold down the pedal (which will cause notes
currently being played to be sustained).
Saving registration Data on an External Device
See page EN-62 for details about how to transfer sampled
data to a computer for storage.
To save a setup to registration
memory
Bank number
Bank 4
Store
Stored in Setup 4-1
To recall a setup from registration
memory
Bank 6
Recal l
Setup 6-1 recalled
CTK4400_A5_x1a_EN_ES.indd 51 2014/02/19 10:25:20
EN-50
Recording Your Keyboard Play
The recorder feature lets you record your keyboard play.
Use the following procedure to record everything you play on
the keyboard.
1.
Press bo (RHYTHM).
2.
Press cs.
3.
Press cs again.
This will enter record standby.
4.
Configure the tone, rhythm, and other settings
you want to use.
5.
Start playing.
Recording starts as soon as you play something on the
keyboard.
You can use Auto Accompaniment while playing. If you do,
Auto Accompaniment also will be recorded.
6.
To stop recording, press bk.
7.
To play back what you have recorded, press bk
again.
Each press of bk starts and stops playback.
blblbkbk
brbr
bsbsbtbtckckclclcmcmcncn
bpbpbobobnbn
cscs
Recording and Playing Back
Keyboard Play
Lights
Flashes
Lights
CTK4400_A5_x1a_EN_ES.indd 52 2014/02/19 10:25:20
English
Recording Your Keyboard Play
EN-51
8.
Press cs twice to exit the recorder mode.
The flashing on the screen shown in step 3 becomes
faster when remaining recorder memory capacity
becomes less than 100 notes.
Total recorder memory capacity is approximately
12,000 notes. Recording will stop automatically when
there is no more unused recorder memory remaining.
Each press of cs cycles through the settings shown
below. You can listen to the recorded data as many
times as you like by pressing bk while in playback
standby.
To delete recorded data
After step 3 of the above procedure, do hold down cs
(without pressing any keyboard key) until the message
“Tr.Del?” appears on the display. Press [+] (YES) to delete the
data, or [–] (NO) to cancel the delete operation.
Turning off the Digital Keyboard while recording is in
progress will cause any data in recorder memory to be
deleted.
A new recording replaces (deletes) previously recorded
contents.
You can divide a song according to various types of parts
(instrument, left and right hand, etc.), and record each part to
a specific track. You can mix up to six tracks (the original track
plus five additional tracks) into a final song.
About tracks
Tracks are numbered from 1 to 6.
If you do not specify a track number when recording,
recording is performed to Track 1 automatically.
In addition to what you play on the keyboard, the following
information also is recorded.
Track 1
Settings:
Tone number, rhythm number, tempo, VIRTUAL HALL,
reverb, chorus, chords, layer/split settings, Auto
Harmonize/Arpeggiator setting
Operations:
Pedal, INTRO button, SYNCHRO/ENDING button,
NORMAL/FILL-IN button, VARIATION/FILL-IN button
Tracks 2 through 6
Tone number, pedal operation
Disappears
Recorder Off Playback
Standby Record Standby
Using Tracks to Record and Mix
Parts
CTK4400_A5_x1a_EN_ES.indd 53 2014/02/19 10:25:21
Recording Your Keyboard Play
EN-52
1.
Record the first part to Track 1.
To record to Track 1, perform steps 1 through 4 under
“Recording and Playing Back Keyboard Play” (page
EN-50).
2.
Press cs.
This will enter record standby.
3.
Press a button from bt to cn to select the track
number of the next track to which you want to
record.
This will enter record standby for the track you selected.
If you want to use a different tone than the one you
used in Track 1, press bn (TONE) and then use br
(10-key) to input the tone number.
4.
Press bk.
This will start playback of what you recorded up to this
point in other tracks and record what you play on the
keyboard to the currently selected track. Play the notes
you want on the keyboard.
5.
To stop recording, press bk.
To play back what you have recorded, press bk again.
Each press of bk starts and stops playback.
6.
Repeat steps 2 through 5 to record the other
tracks.
7.
After you finish recording all of the tracks,
press bk.
This will start playback of the recorded tracks. Press
bk to stop or restart playback.
At this time you can turn off playback of specific tracks
using buttons bs to cn. Pressing a key toggles
playback of each track on (track number displayed) or
off (track number not displayed).
If you want to re-record a track, press cs. This will
return to step 2 of the above procedure. Only the tracks
that are turned on (displayed) above will play as you
re-record.
8.
Press cs twice to exit the recorder mode.
To delete a recorded track
After step 3 of the above procedure, do hold down cs
(without pressing any keyboard key) until the message
“Tr.Del?” appears on the display. Press [+] (YES) to delete the
track, or [–] (NO) to cancel the delete operation.
To record to Tracks 1 through 6
Example: Track 2
Lights
Flashes
Flashes
Example: Tracks 2 and 3 selected
Disappears
Disappears
CTK4400_A5_x1a_EN_ES.indd 54 2014/02/19 10:25:21
English
Recording Your Keyboard Play
EN-53
You can record up to five songs (numbered 1 through 5) in
memory. After that, you can select a specific song for
playback.
1.
Press bo (RHYTHM).
2.
Press cs.
A song number will appear in the upper left corner of the
display for a few seconds. While it is, use br (10-key) to
specify the number of the song you want to record or play
back. The song number will disappear if you do not
perform any operation.
3.
Press cs to record, or bk to play back.
To stop recording or playback, press bk.
4.
Press cs twice to exit the recorder mode.
To delete recorded data
After step 2 of the above procedure, do hold down cs
(without pressing any keyboard key) until the message “Song
Del?” appears on the display. Press [+] (YES) to delete the
song, or [–] (NO) to cancel the delete operation.
This section explains how to play along and record along with
one of the Digital Keyboard’s built-in songs.
The following operations and settings also are
recorded along with your keyboard play.
Tone number, song number, pedal operation, tempo,
VIRTUAL HALL, reverb, chorus, layer/split settings
There can be only one recording of keyboard play with a
built-in song in recorder memory. Making a new recording
replaces (deletes) previously recorded data.
1.
Press bp (SONG BANK).
2.
Press cs.
This will enter playback standby.
3.
Press cs again.
This will enter record standby.
4.
Use br (10-key) to enter the song number you
want to assign to the recording.
Recording Two or More Songs,
and Selecting One for Playback
Example: Song 2
Pla
y
No .
Recording while Playing Along
with a Built-in Song
Lights
Flashes
CTK4400_A5_x1a_EN_ES.indd 55 2014/02/19 10:25:21
Recording Your Keyboard Play
EN-54
5.
Press bl to cycle through the parts in the
sequence shown below.
Configure tone and tempo settings at this time as well.
6.
Press bk to start built-in song playback and
recorder recording.
Play along with the playback.
To stop recording part way through, press bk.
7.
Recording will stop automatically when the end
of the built-in song is reached.
This will enter playback standby.
8.
Press bk.
This will start playback of what you recorded.
Each press of bk starts and stops playback.
9.
Press cs twice to exit the recorder mode.
To delete recorded data
After step 2 of the above procedure, do hold down cs until
the message “Song Del?” appears on the display. Press [+]
(YES) to delete the song.
You can save data you record with the Digital Keyboard on
your computer’s hard disk. See page EN-62 for details about
how to transfer sampled data to a computer for storage.
Example: Left-hand part recording
Right-hand Recording
Both-hand Recording
Left-hand Recording
Flashes
Lights
Saving Recorded Data on an
External Device
CTK4400_A5_x1a_EN_ES.indd 56 2014/02/19 10:25:21
English
EN-55
Other Useful Digital Keyboard Functions
You can use the following procedure to select from among 17
preset scales, including the standard Equal Temperament.
1.
Press bo (RHYTHM).
2.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“SCALE” (page EN-7).
3.
Press br (10-key) [9] (ENTER) key.
4.
Use the br (10-key) [–] and [+] keys to select
the preset scale you want. After selecting a
scale, press the key on the keyboard that you
want to use as the root key (C to B).
5.
After you are finished, press ct (FUNCTION) to
assign the scale to the keyboard.
cqcq ctct
brbr
bobobqbqbpbp bnbn
Changing the Scale of the
Keyboard
No. Scale name Display
00 Equal Temperament Equal
01 Pure Major PureMajr
02 Pure Minor PureMinr
03 Pythagorean Pythagor
04 Kirnberger 3 Kirnbrg3
05 Werckmeister Wercmeis
06 Mean-Tone MeanTone
07 Rast Rast
08 Bayati Bayati
09 Hijaz Hijaz
10 Saba Saba
11 Dashti Dashti
12 Chahargah Chaharga
13 Segah Segah
14 Gurjari Todi GujrTodi
15 Chandrakauns Cndrkuns
16 Charukeshi Carukesi
S C A L E
Flashes
E
q
u a l
Scale Name
CTK4400_A5_x1a_EN_ES.indd 57 2014/02/19 10:25:21
Other Useful Digital Keyboard Functions
EN-56
You can use the following procedure to reflect the preset
scale you selected in Auto Accompaniments.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“OTHER” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “AcompScl”.
4.
Use the br (10-key) [+] key to select on.
Selecting a Music Preset instantly changes the Digital
Keyboard to a preset setup (tone, rhythm, tempo, etc.) for play
of songs of various genres/categories. The press of a button
sets up the Digital Keyboard so those songs sound exactly the
way you thought they should.
See the separate “Appendix” for a complete list of the 305
Music Presets that are available.
1.
Press bq.
2.
Use br (10-key) to select the preset number
you want.
This will change the setup (tone, rhythm, etc.) of the
Digital Keyboard.
At this time the Digital Keyboard will go into Auto
Accompaniment synchro start standby (page EN-42).
Pressing bn (TONE), bo (RHYTHM), or bp (SONG
BANK) will return to the screen that was displayed
before you held down in step 1, above.
3.
Play along on the keyboard with the
accompaniment.
Using the Current Scale Notes for Auto
Accompaniments
Flashes
O T H E R
A c o m
p
S c l
Using Music Preset
I L o v e H e r
Preset number Preset name
Lights
CTK4400_A5_x1a_EN_ES.indd 58 2014/02/19 10:25:22
English
Other Useful Digital Keyboard Functions
EN-57
The Arpeggiator makes it possible to play an arpeggio pattern
automatically. There are 90 different arpeggio patterns from
which to choose in order to match the music you are playing.
The Arpeggiator is controlled using the same button cq as
Auto Harmonize (page EN-43). Because of this, these two
functions cannot be used at the same time.
1.
Hold down cq until the Auto Harmonize or
Arpeggiator type number and type name appear
on the display.
If you do not perform any operation for a few seconds,
the display will return to the previous screen
automatically.
2.
Use the br (10-key) [–] and [+] keys to select
the Arpeggiator type you want.
001 through 012 are Auto Harmonize types (page
EN-43). Do not select them when using the
Arpeggiator.
3.
Press cq to turn on Arpeggiator.
Playing a chord on the keyboard will start arpeggio play.
Press cq again to turn off Arpeggiator.
The tempo setting of the Arpeggiator is the same as that set
for the metronome (page EN-13).
Use the following procedure when you want an arpeggio
pattern to keep playing after you release the keyboard keys.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“OTHER” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Press the br (10-key) [+] key to select the ON
setting.
Using the Arpeggiator
Type
number Type Name Description
013-030 Up Rising
031-048 Down Falling
049-066 U/D A
Repeat pattern alternating
between rising and falling
(Type A)
067-084 U/D B
Repeat pattern alternating
between rising and falling
(Type B)
085-102 Random Random arrangement of
notes of the pressed keys
D u e t 1
Type number Type name
1 U
p
1
Speed (The number of arpeggio notes per beat)
Octave
1... Uses the actual notes played.
2... Uses the actual notes played plus the same notes one octave.
4... Uses the actual notes played plus the same notes three octaves.
Sustaining an Arpeggio (Arpeggiator Hold)
St .GrPno
Lit when on
A r
p
e
g
H l d
CTK4400_A5_x1a_EN_ES.indd 59 2014/02/19 10:25:22
Other Useful Digital Keyboard Functions
EN-58
You can use the following procedure to delete user song data
stored as song numbers 153 through 162.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“DELETE” (page EN-7).
2.
Press the br (10-key) [9] (ENTER) key.
3.
Press the br (10-key) [6] (p) key twice.
4.
Use the br (10-key) [–] and [+] keys to select
the user song you want to delete.
5.
Press the br (10-key) [9] (ENTER) key.
This displays a delete confirmation message.
6.
Press the br (10-key) [+] (YES) key.
After the delete procedure is complete, “Complete” will
appear followed by the screen in step 2 of the above
procedure.
To cancel the delete operation, press [–] (NO) or [7]
(EXIT) in place of [+] (YES).
Use the following procedure when you want to delete sampled
sounds, user songs and all other data, except for recorded
songs, currently in Digital Keyboard memory.
Performing this procedure also will delete protected
sampled sound data (page EN-26). It is recommended
that you save important data to your computer’s hard
disk (page EN-59).
This operation does not delete recorded song data.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“DELETE” (page EN-7).
2.
Press the br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “All Data”.
4.
Press the br (10-key) [9] (ENTER) key.
This displays a delete confirmation message.
5.
Press the br (10-key) [+] (YES) key.
After the delete procedure is complete, “Complete” will
appear followed by the screen in step 2 of the above
procedure.
To cancel the delete operation, press [–] (NO) or [7]
(EXIT) in place of [+] (YES).
Deleting User Song Data
Used memory
(Unit: Kbytes) Remaining
memory capacity
D E L E T E
Flashes
U S E R S O N G
User song name
S u r e ?
Deleting All Data in Digital
Keyboard Memory
Used memory
(Unit: Kbytes) Remaining
memory capacity
D E L E T E
Flashes
A l l D a t a
Flashes
S u r e ?
CTK4400_A5_x1a_EN_ES.indd 60 2014/02/19 10:25:22
English
EN-59
Connecting External Devices
You can connect the Digital Keyboard to a computer and
exchange MIDI data between them. You can send play data
from the Digital Keyboard to music software running on your
computer, or you can send MIDI data from your computer to
the Digital Keyboard for playback.
The following shows the minimum computer system
requirements for sending and receiving MIDI data. Check to
make sure that your computer complies with these
requirements before connecting the Digital Keyboard to it.
Operating System
USB port
Never connect to a computer that does not conform to
the above requirements. Doing so can cause problems
with your computer.
Make sure you follow the steps of the procedure below
exactly. Connecting incorrectly can make data send
and receive impossible.
1.
Turn off the Digital Keyboard and then start up
your computer.
Do not start up the music software on your computer
yet!
2.
After starting up your computer, use a
commercially available USB cable to connect it
to the Digital Keyboard.
3.
Turn on the Digital Keyboard.
If this is the first time you are connecting the Digital
Keyboard to your computer, the driver software
required to send and receive data will be installed on
your computer automatically.
4.
Start up commercially available music software
on your computer.
blbl ctct
brbr
Connecting to a Computer
Minimum Computer System Requirements
Windows® XP (SP2 or later) *1
Windows Vista® *2
Windows® 7 *3
Windows® 8 *4
Windows® 8.1*5
Mac OS® X
(10.3.9, 10.4.11, 10.5.X, 10.6.X, 10.7.X,
10.8.X
, 10.9.X)
*1: Windows XP Home Edition
Windows XP Professional (32-bit)
*2: Windows Vista (32-bit)
*3: Windows 7 (32-bit, 64-bit)
*4: Windows 8 (32-bit, 64-bit)
*5: Windows 8.1 (32-bit, 64-bit)
Connecting the Digital Keyboard to Your
Computer
B connector
Digital Keyboard USB port
Computer USB port
USB cable
(A-B type)
A connector
CTK4400_A5_x1a_EN_ES.indd 61 2014/02/19 10:25:22
Connecting External Devices
EN-60
5.
Configure the music software settings to select
one of the following as the MIDI device.
For information about how to select the MIDI device,
see the user documentation that comes with the music
software you are using.
Be sure to turn on the Digital Keyboard first before
starting up your computer’s music software.
Once you are able to connect successfully, there is no
problem with leaving the USB cable connected when you
turn off your computer and/or Digital Keyboard.
This Digital Keyboard conforms to General MIDI Level 1
(GM).
For detailed specifications and connections that apply to
MIDI data send and receive by this Digital Keyboard, see
the latest support information provided by the website at the
following URL.
http://world.casio.com/
A keyboard channel is the channel used for sending Digital
Keyboard data to a computer. You can select the channel you
want for sending Digital Keyboard data to a computer.
The keyboard channel setting range is 01 to 16.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“MIDI” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [–] and [+] keys to change
the keyboard channel.
The navigate channels can be used to display only the notes
of a particular channel (part) as on-screen guide information
from among the note information of a tune sent from the
computer.
Specifying the Navigate Channels
From among the 16 available channels (numbered 01 to 16),
you can specify any two neighboring channels (such as 05
and 06) as navigate channels. The smaller numbered channel
is the navigate (L) channel, while the larger numbered
channel is the navigate (R) channel. Specifying the navigate
(R) channel will automatically configure the navigate (L)
channel as well.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“MIDI” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “Navi. Ch”.
4.
Use the br (10-key) to specify the navigate (R)
channel.
This also will automatically configure the next lower
channel number as the navigate (L) channel.
CASIO USB-MIDI: For Windows Vista, Windows 7,
Windows 8, Windows 8.1, Mac OS X
USB Audio Device : For Windows XP
MIDI Settings
Keyboard Channel
M I D I
Flashes
K e
y
b d C h
Navigate Channels
N a v i . C h
CTK4400_A5_x1a_EN_ES.indd 62 2014/02/19 10:25:23
English
Connecting External Devices
EN-61
Turning Off the Navigate Channel Sound and
Playing the Part on the Keyboard
You can turn off the sound on one or both of the navigate
channels and play the cancelled part on the keyboard
yourself.
1.
Press bl to select the channel setting you want
to turn off.
Each press of bl cycles through settings (1) through (4)
described below.
If you turn off one channel, you can play the cancelled
part on the keyboard using the same tone as the
channel you turned off. If you turn off both channels
(option (3)), what you play on the keyboard sounds
using the tone of the navigate (R) channel.
There are times when exchanging data with a computer when
you may not want the Digital Keyboard to sound notes you
play on its keyboard. The local control setting lets you do just
that.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“MIDI” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “Local”.
4.
Use the br (10-key) [–] and [+] keys to specify
the local control setting.
Enabling the Accomp Out setting causes Auto
Accompaniment data to be sent to the computer.
1.
Press ct (FUNCTION) and then use the br
(10-key) [4] (o) and [6] (p) keys to display
“MIDI” (page EN-7).
2.
Press br (10-key) [9] (ENTER) key.
3.
Use the br (10-key) [4] (o) and [6] (p) keys
to display “AcompOut”.
4.
Use the br (10-key) [–] and [+] keys to turn
Accomp Out on or off.
Navigate (L)
Channel
Navigate (R)
Channel
Sound
On-
screen
Guide
Sound
On-
screen
Guide
(1) R only displayed
{××{
(2) L only displayed
×{{ ×
(3) LR displayed
×{×{
(4) LR not displayed
{{{{
Selected channel indicator appears.
Local Control
Accomp Out
L o c a l
A c o m
p
O u t
CTK4400_A5_x1a_EN_ES.indd 63 2014/02/19 10:25:23
Connecting External Devices
EN-62
You can transfer sampled sounds, recorded songs, and other
data in Digital Keyboard memory to a computer for storage.
You also can load standard MIDI file (SMF) data, and Auto
Accompaniment data you download from the CASIO website
to the Digital Keyboard, which greatly expands the Song Bank
songs and Auto Accompaniment patterns available to you.
A special Data Manager application is required in order to
transfer data to and from the Digital Keyboard.
You can transfer the types of data listed below between the
Digital Keyboard and a computer.
1.
Go to the CASIO WORLDWIDE site at the
following URL.
http://world.casio.com/
2.
At the site, select a geographic area or country.
3.
After accessing the area site, navigate to the
minimum computer system requirements for
Data Manager for this product.
You should be able to find a link to Data Manager
information on the product introduction page of this
product. If you cannot find such a link, use the search
form of the area site where you are located to enter the
model name of this product and search for it.
Note that site contents are subject to change without
notice.
4.
Check if your computer system complies with
the minimum requirements for Data Manager.
5.
Download Data Manager and its user’s guide to
your computer.
6.
Follow the procedure in the user’s guide that
you downloaded in step 5 to install and use
Data Manager.
You can download accompaniment data from the
Internet Data Expansion system of the CASIO MUSIC
SITE (http://music.casio.com/) and load it into the
memory of this Digital Keyboard. Note that there is not
any accompaniment data intended specifically for this
model, so you should use data for other models.
Since the accompaniment data is for other models, you
may experience some abnormalities when playing it on this
model.
For information about accompaniment data compatibility
between models, see the Data Manager user’s guide you
download in step 5 of the above procedure.
Storing and Loading Digital
Keyboard Memory Data
Data Types Supported for Data Transfer
Data Type Description File Name
Extension
Sampled sound
(page EN-20) Sampled sound data TW7
DW7*1
User rhythms
(page EN-45)
Edited Auto
Accompaniment data AC7
User songs
(page EN-30)
Song data loaded from a
computer (Cannot be sent
from the Digital Keyboard
to a computer.)
CM2
MID*2
Recorded songs
(page EN-50) Recorded song data SP7
SL7*3
Registration
setups
(page EN-48)
Tone and rhythm setup
settings RM7
All data Above data AL7
*1: Sampled drum set sounds
*2: Standard MIDI file (format 0, 1)
*3: Data recorded playing along with built-in song
Downloading Data Manager
CTK4400_A5_x1a_EN_ES.indd 64 2014/02/19 10:25:23
English
Connecting External Devices
EN-63
This Digital Keyboard can be connected to commercially
available stereo, amplifier, or recording equipment, to a
portable audio player or other equipment.
Connection requires commercially available connecting cords,
supplied by you. The connecting cords should have a stereo
standard plug on one end and a plug that matches the
configuration of the external device on the other end.
Turn off the external device when making connections.
After connecting, turn down the Digital Keyboard and
external device volume levels whenever turning power
on or off.
After connecting, turn on the Digital Keyboard and then
the external device.
If keyboard notes sound distorted when they are
sounded from external audio equipment, lower the
Digital Keyboard’s volume setting.
Connection requires commercially available connecting cords,
supplied by you. The connecting cords should have a stereo
mini plug on one end and a plug that matches the
configuration of the external device on the other end.
Turn off the Digital Keyboard when making
connections. After connecting, turn down the Digital
Keyboard and external device volume levels whenever
turning power on or off.
After connecting, turn on the external device and then
the Digital Keyboard.
If notes are distorted when they are sounded on the
external device, lower the volume setting of the
external device.
Connecting to Audio Equipment
Outputting Keyboard Notes to Audio
Equipment
Audio equipment, amplifier,
etc.
Stereo standard plug
Digital Keyboard PHONES/OUTPUT jack
Playing an External Device from the Digital
Keyboard
Portable audio player, etc.
Stereo mini plug
Digital Keyboard AUDIO IN jack
CTK4400_A5_x1a_EN_ES.indd 65 2014/02/19 10:25:23
EN-64
Reference
Troubleshooting
Symptom Action
Included Accessories
I can’t find something that should be here. Carefully check inside all of the packing materials.
Power Requirements
Power will not turned on. Check the AC adaptor or make sure that the batteries are facing
correctly (page EN-9).
Replace the batteries with new ones or switch over to AC adaptor
power (page EN-9).
The display lights up momentarily but power does
not turn on when I press the P (POWER) button
(1).
Press 1 firmly and completely to turn on power.
The Digital Keyboard outputs a loud sound and then
suddenly powers down.
Replace the batteries with new ones or switch over to AC adaptor
power (page EN-9).
The Digital Keyboard suddenly powers down after a
few minutes.
This happens when Auto Power Off (page EN-10) is triggered.
Display
The display keeps going out or are flashing. Replace the batteries with new ones or switch over to AC adaptor
power (page EN-9).
On-screen keyboard keys or notes remain on the
display.
A Step Up Lesson is in progress and the Digital Keyboard is waiting
for you to play the next note in the song. To stop this from happening,
cancel the lesson (page EN-33).
Screen contents are visible only from straight ahead. This is dues to production limitations. It does not indicate malfunction.
Sound
Nothing happens when I press any keyboard key. Adjust the volume setting (page EN-10).
Check if something is plugged into eo on the back of the Digital
Keyboard.
If there is no sampled sound in memory, nothing will play if you
press a keyboard key while a tone in the range of 601 to 608 is
selected (page EN-20).
Turn power off and then back on to initialize all keyboard settings
(page EN-10).
Nothing happens or notes do not play normally when
I play notes on the left side of the keyboard.
Press bl to disable chord input in the accompaniment keyboard area
(page EN-39).
Nothing happens when I start an Auto
Accompaniment.
With rhythms 171 to 180, nothing will sound until you play a chord
on the keyboard. Try playing a chord (page EN-39).
Check and adjust the accompaniment volume setting (page
EN-42).
If there is no user rhythm stored in memory, Auto Accompaniment
will not start when you press bk while a rhythm in the range of 181
to 190 is selected (page EN-45).
Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
Nothing happens when I start playback of a built-in
song.
It takes a little time after you press the button until the song starts to
play. Wait for a moment for the song to start.
Check and adjust the song volume (page EN-30).
If there is no user song stored in memory, song playback will not
start when you press bk while a song in the range of 153 to 162 is
selected (page EN-30).
Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
CTK4400_A5_x1a_EN_ES.indd 66 2014/02/19 10:25:23
English
Reference
EN-65
The metronome does not sound. Check and adjust the accompaniment volume setting (page
EN-42).
Check and adjust the song volume (page EN-30).
Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
Notes keep sounding, without stopping. Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
Replace the batteries with new ones or switch over to AC adaptor
power (page EN-9).
Some notes are cut off while they are playing. Notes are cut off whenever the number of notes being sounded
exceeds the maximum polyphony value of 48 (24 for some tones).
This does not indicate malfunction.
The volume or tone setting I made has changed. Adjust the volume setting (page EN-10).
Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
Replace the batteries with new ones or switch over to AC adaptor
power (page EN-9).
Output volume does not change even though is
change my keyboard touch.
Change the Touch Response setting (page EN-12).
Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
In certain keyboard ranges, the volume and tone
quality sound are slightly different from those in other
keyboard ranges.
This is due to system limitations. It does not indicate malfunction.
With some tones, octaves do not change at the far
ends of the keyboard.
This is due to system limitations. It does not indicate malfunction.
The pitch of the notes does not match other
accompanying instruments or sounds strange when
played long with other instruments.
Check and adjust the transpose (page EN-18) and tuning settings
(page EN-18).
Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
The reverb of notes seems to change suddenly. Check and adjust the VIRTUAL HALL setting (page EN-16) and
reverb setting (page EN-16).
Turn power off and then back on to initialize all Digital Keyboard
settings (page EN-10).
Operation
When I perform a skip forward or skip back
operation, the skip operation moves multiple song
measures instead of only a single measure.
While song playback is stopped or a Step Up Lesson is in progress,
skip forward and skip back operations are performed in phrase units
(page EN-28).
Tone, rhythm, and other settings revert to their initial
defaults whenever you turn on the Digital Keyboard.
Though Digital Keyboard settings reset when you turn off the Digital
Keyboard, you can save setups to registration memory for instant
recall whenever you need them (page EN-48).
Computer Connection
I can’t exchange data between the Digital Keyboard
and a computer.
Check to make sure that the USB cable is connected to the Digital
Keyboard and computer, and that the device is selected correctly
with your computer’s music software settings (page EN-59).
Turn off the Digital Keyboard and then exit the music software on
your computer. Next, turn the Digital Keyboard back on and then
restart the music software on your computer.
Symptom Action
CTK4400_A5_x1a_EN_ES.indd 67 2014/02/19 10:25:24
Reference
EN-66
Specifications
Models CTK-4400/WK-240/WK-245
Keyboard CTK-4400: 61 standard size keys
WK-240/WK-245: 76 standard size keys
Touch Response 2 types, Off
Maximum Polyphony 48 notes (24 for certain tones)
Tones
Built-in Tones 600
Sampling Tones Up to 8 (Melody Sampling: 5, Drum Sampling: 3)*
Up to 10 seconds
Functions Layer, Split, Piano/Organ button
VIRTUAL HALL On, Off
Reverb 1 to 10, Off
Chorus 1 to 5, Off
Metronome
Beats per Measure 0 to 9
Tempo Range 30 to 255
Song Bank
Built-in Songs 152
User Songs Up to 10*
Step Up Lesson
Lessons 4 (Listen, Watch, Remember, Auto)
Lesson Part L, R, LR
Functions Repeat, Voice Fingering Guide, Note Guide, Performance Evaluation
Music Challenge 20 notes
Auto Accompaniment
Built-in Rhythms 180
User Rhythms Up to 10 (Accompaniment Edit)*
Chord Book Function Chord guide
Registration 32 (4 setups × 8 banks)
Recorder Real-time recording, playback
Keyboard Play 5 songs, 6 tracks
Playing Along with a
Built-in Songs 1 song (L, R, LR)
Memory Capacity Approximately 12,000 notes (total for 6 songs)
Other Functions
Transpose ±1 octaves (–12 to +12 semitones)
Octave Shift Upper/Lower ±2 octaves
Tuning A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
Preset Scales 17
Music Preset 305
One Touch Preset 180
Auto Harmonize 12 types
Arpeggiator 90 types
MIDI 16 multi-timbre received, GM Level 1 standard
Musical Information Function Tone, Rhythm, Song Bank numbers and names, staff notation, fingering, pedal operation,
tempo, measure and beat number, chord name, etc.
CTK4400_A5_x1a_EN_ES.indd 68 2014/02/19 10:25:24
English
Reference
EN-67
Design and specifications are subject to change without notice.
*This data is stored in a shared memory area with a total capacity of approximately 320Kbytes (1Kbyte = 1,024bytes).
Be sure to read and observe the following operating precautions.
Location
Avoid the following locations for this product.
Areas exposed to direct sunlight and high humidity
Areas subjected to temperature extremes
Near a radio, TV, video deck, or tuner
The above devices will not cause malfunction of the product, but interference from the product can cause audio or video
interference of a nearby device.
User Maintenance
Never use benzine, alcohol, thinner, or other chemical agents to clean the product.
To clean the product or its keyboard, wipe with a soft cloth moistened in a weak solution of water and a mild neutral detergent.
Wring all excess moisture from the cloth before wiping.
Included and Optional Accessories
Use only accessories that are specified for use with this product. Use of unauthorized accessories creates the risk of fire, electric
shock, and personal injury.
Weld Lines
Lines may be visible on the exterior of the product. These are “weld lines” that result from the plastic molding process. They are not
cracks or scratches.
Musical Instrument Etiquette
Always be aware of others around you whenever using this product. Be especially careful when playing late at night to keep the
volume at levels that do not disturb others. Other steps you can take when playing late at night are closing the window and using
headphones.
Inputs/Outputs
USB port TYPE B
Sustain/Assignable jack Standard jack (sustain, sostenuto, soft, rhythm)
Phones/Output jack
Stereo standard jack
Output Impedance: 140Ω, Output Voltage: 4.5V (RMS) MAX
Audio In jack Stereo mini jack
Input Impedance: 9kΩ, Input Sensitivity: 200mV
Mic In/Sampling jack
(WK-240/WK-245)
Standard jack (connect a dynamic microphone only)
Input Impedance: 3kΩ, Input Sensitivity: 10mV
Power Jack DC9.5V
Power Supply 2-way
Batteries CTK-4400: 6 AA-size zinc-carbon batteries or alkaline batteries
WK-240/WK-245: 6 D-size zinc-carbon batteries or alkaline batteries
Battery Life CTK-4400: Approximately 3 hours continuous operation on alkaline batteries
WK-240/WK-245: Approximately 5 hours continuous operation on zinc-carbon batteries
AC Adaptor AD-E95100L
The AC adaptor can be used safely in areas up to 4,000 meters above sea level.
Auto Power Off Approximately 6 minutes (during battery operation) or 30 minutes (during AC adaptor
operation) without any operation, Auto Power Off can be disabled.
Speakers 12cm × 2 (Output: 2.5W + 2.5W)
Power Consumption 9.5V = 7.7W
Dimensions CTK-4400: 94.8 × 35.0 × 10.3 cm (37 5/16 × 13 3/4 × 4 1/16 inch)
WK-240/WK-245: 116.1 × 38.5 × 13.4 cm (45 3/4 × 15 3/16 × 5 1/4 inch)
Weight CTK-4400: Approximately 4.3kg (9.5 lbs) (without batteries)
WK-240/WK-245: Approximately 6.9kg (15.2 lbs) (without batteries)
Operating Precautions
CTK4400_A5_x1a_EN_ES.indd 69 2014/02/19 10:25:24
Reference
EN-68
Error Messages
Display
Message Cause Action
Err Exist A sampled drum set sound cannot be copied (page
EN-24) to a keyboard key because the key already
has a sampled sound assigned to it.
Delete the sampled sound that is currently assigned
to the key you are copying to (page EN-26).
Copy the sampled sound to another key that does not
yet have a sampled sound assigned to it.
Err Limit The tone number you selected before starting
sampling already has the allowable maximum of eight
sampled sounds assigned to it.
Delete the one or more of the sampled sounds
currently assigned to the tone number (page EN-26).
Select another tone number that has less than eight
sampled sounds currently assigned to it (page
EN-22).
Err Mem Full There is not enough memory available for sampling or
Auto Accompaniment editing.
Delete some or all of the following user data from
memory to make room for new data.
Sampled sounds (page EN-19), user rhythms (page
EN-47), user songs (page EN-58)
Err No Data There is no data in the selected user area (tone,
rhythm, song number, etc.)
Select a Digital Keyboard user area that contains data.
Err Protect Sampled sounds are protected. Unprotect one or more of the sampled sounds, which will
allow it to be overwritten or deleted.
Err SizeOver Auto Accompaniment editing cannot be performed
because the accompaniment pattern or instrument
part data is too large.
Select a different accompaniment pattern or instrument
parts.
CTK4400_A5_x1a_EN_ES.indd 70 2014/02/19 10:25:24
English
Reference
EN-69
*Asterisks indicate songs played as demo songs.
Song List
SONG BANK
WORLD
001 TWINKLE TWINKLE LITTLE STAR
002 LIGHTLY ROW
003 LONG LONG AGO
004 ON TOP OF OLD SMOKEY
005 SAKURA SAKURA
006 WHEN THE SAINTS GO MARCHING IN
007 AMAZING GRACE *
008 AULD LANG SYNE
009 COME BIRDS
010 DID YOU EVER SEE A LASSIE?
011 MICHAEL ROW THE BOAT ASHORE
012 DANNY BOY
013 MY BONNIE
014 HOME SWEET HOME
015 AURA LEE
016 HOME ON THE RANGE
017 ALOHA OE
018 SANTA LUCIA
019 FURUSATO
020 GREENSLEEVES *
021 JOSHUA FOUGHT THE BATTLE OF JERICHO
022 THE MUFFIN MAN
023 LONDON BRIDGE
024 UNDER THE SPREADING CHESTNUT TREE
025 SIPPIN’ CIDER THROUGH A STRAW
026 GRANDFATHER’S CLOCK
027 ANNIE LAURIE
028 BEAUTIFUL DREAMER
029 IF YOU’RE HAPPY AND YOU KNOW IT, CLAP YOUR
HANDS
030 MY DARLING CLEMENTINE
031 LITTLE BROWN JUG
032 HOUSE OF THE RISING SUN
033 SHE WORE A YELLOW RIBBON
034 YANKEE DOODLE
035 MY OLD KENTUCKY HOME
036 SZLA DZIEWECZKA
037 TROIKA
038 WALTZING MATILDA
039 ON THE BRIDGE OF AVIGNON
040 I’VE BEEN WORKING ON THE RAILROAD
041 OH! SUSANNA
042 CAMPTOWN RACES
043 JEANNIE WITH THE LIGHT BROWN HAIR
044 TURKEY IN THE STRAW
045 JAMAICA FAREWELL
EVENT
046 SILENT NIGHT
047 WE WISH YOU A MERRY CHRISTMAS
048 JINGLE BELLS
049 JOY TO THE WORLD
050 O CHRISTMAS TREE
PIANO/CLASSICS
051 MARY HAD A LITTLE LAMB
052 LE CYGNE FROM “LE CARNAVAL DES ANIMAUX” *
053 JE TE VEUX *
054 SONATA op.13 “PATHÉTIQUE” 2nd Mov. *
055 HEIDENRÖSLEIN
056 AIR FROM “SUITE no.3”
057 SPRING FROM “THE FOUR SEASONS”
058 HABANERA FROM “CARMEN”
059 BRINDISI FROM “LA TRAVIATA”
060 HUNGARIAN DANCES no.5
061 MINUET IN G MAJOR
062 MUSETTE IN D MAJOR
063 GAVOTTE (GOSSEC)
064 ARABESQUE (BURGMÜLLER)
065 CHOPSTICKS
066 DECK THE HALL
067 ODE TO JOY
068 AVE MARIA (GOUNOD)
069 SONATINA op.36 no.1 1st Mov.
070 PRELUDE op.28 no.7 (CHOPIN)
071 RÊVERIE
072 GYMNOPÉDIES no.1
073 GOING HOME FROM “FROM THE NEW WORLD”
074 FÜR ELISE
075 TURKISH MARCH (MOZART)
076 SONATA op.27 no.2 “MOONLIGHT” 1st Mov.
077 ETUDE op.10 no.3 “CHANSON DE L’ADIEU”
078 THE ENTERTAINER
079 WEDDING MARCH FROM “MIDSUMMER NIGHT’S
DREAM”
080 AMERICAN PATROL
081 FRÖHLICHER LANDMANN
082 LA CHEVALERESQUE
083 SONATA K.545 1st Mov.
084 LA PRIÈRE D’UNE VIERGE
085 VALSE op.64 no.1 “PETIT CHIEN” *
086 LIEBESTRÄUME no.3
087 JESUS BLEIBET MEINE FREUDE *
088 CANON (PACHELBEL)
089 SERENADE FROM “EINE KLEINE NACHTMUSIK” *
090 MARCH FROM “THE NUTCRACKER” *
091 INVENTIONEN no.1
092 PRAELUDIUM no.1 (J.S.BACH)
093 SONATINE op.20 no.1 1st Mov.
094 HUMORESKE (DVO ÁK)
095 DOLLY’S DREAMING AND AWAKENING
096 LA FILLE AUX CHEVEUX DE LIN
097 ARABESQUE no.1 (DEBUSSY)
098 TRÄUMEREI
099 MAPLE LEAF RAG
100 NOCTURNE op.9 no.2 (CHOPIN) *
EXERCISE
101 - 150 EXERCISE I / II / III
DEMO TUNES
151 - 152 DEMO TUNES *
USER SONGS
153 - 162 USER SONGS
CTK4400_A5_x1a_EN_ES.indd 71 2014/02/19 10:25:24
Reference
EN-70
In addition to the chords that can be fingered with Fingered 1
and Fingered 2, the following chords also are recognized.
With Fingered 3, the lowest note fingered is interpreted as
the base note. Inverted forms are not supported.
With Full Range Chord, when the lowest note fingered is a
certain distance from the neighboring note, the chord is
interpreted as a fraction chord.
Unlike Fingered 1, 2, and 3, Full Range Chord requires
pressing of at least three keys to form a chord.
Fingering Guide
Fingered 1, Fingered 2 Chords
*1 With Fingered 2, interpreted as Am7.
*2 With Fingered 2, interpreted as Am7b5.
*3 Inverted form not supported in some cases.
C
Cm
Cdim
Caug
*3
Csus4
*3
Csus2
*3
C7
Cmadd9
CmM7
Cdim7
*3
C69
*3
C6
*1
*3
Cm6
*2
*3
Cm7
*3
CM7
Cm7
b5
*3
C7sus4
Cadd9
C7
b5
*3
Fingered 3, Full Range Chords
C
#
C
D
C
E
C
F
C
G
C
A
b
C
B
b
C
B
C
C
#
m
C
Dm
C
Gm
C
Am
C
B
b
m
C
Ddim
C
A
b
7
C
F7
C
Fm7
C
Gm7
C
A
b
add9
C
Fm
C
    
   
CTK4400_A5_x1a_EN_ES.indd 72 2014/02/19 10:25:25
English
Reference
EN-71
Chord Example List
M
m
dim
aug
sus4
sus2
7
m7
M7
m7b5
7b5
7sus4
add9
madd9
mM7
dim7
69
6
m6
(A#)/BbBF#/(Gb)G(G#)/AbAFCC
#/(Db)D(D#)/EbE
*2
*1
Since the chord input range is limited, this model may not support some of the chords shown above. *1 Root *2 Chord Type
CTK4400_A5_x1a_EN_ES.indd 73 2014/02/19 10:25:27
Function Transmitted Recognized Remarks
Basic
Channel
1
1 - 16
1 - 16
1 - 16
Default
Changed
Note
Number
0 - 127
0 - 127 *1
12 - 120
True voice
After
Touch
Control
Change
X
X
X
X
O
Pitch Bender
O
Key’s
Ch’s
Velocity
O
9nH v = 1 - 127
X
9nH v = 0, 8nH v =**
O
9nH v = 1 - 127
X
9nH v = 0
Note ON
Note OFF
Mode
Mode 3
X
Mode 3
X
Default
Messages
Altered
0, 32
1
6, 38
7
10
11
64
Bank select
Modulation
Data entry
Volume
Pan
Expression
Hold 1
Models: CTK-4400/WK-240/WK-245 Version : 1.0
O
X
X
O
O
X
O
*3
O
O
O
O
O
O
O
(MSB only)
*2
MIDI Implementation Chart
**:no relation
**:sin relación
CTK4400_A5_x1a_EN_ES.indd 146 2014/02/19 10:25:50
Function Transmitted Recognized Remarks
Basic
Channel
1
1 - 16
1 - 16
1 - 16
Default
Changed
Note
Number
0 - 127
0 - 127 *1
12 - 120
True voice
Program
Change
O
0 - 127
O
0 - 127
:True #
After
Touch
Control
Change
X
X
X
X
O
Pitch Bender
O
System Exclusive
O
*2
O
Key’s
Ch’s
Velocity
O
9nH v = 1 - 127
X
9nH v = 0, 8nH v =**
O
9nH v = 1 - 127
X
9nH v = 0
Note ON
Note OFF
Mode
Mode 3
X
Mode 3
X
Default
Messages
Altered
System
Common
X
X
X
X
X
X
: Song Pos
: Song Sel
: Tune
Aux
Messages
Remarks
X
O
X
O
X
X
O
O
X
O
O
X
: All sound off
:
Reset all controller
: Local ON/OFF
: All notes OFF
: Active Sense
: Reset
System
Real Time
O
O
X
X
: Clock
: Commands
0, 32
1
6, 38
7
10
11
64
66
67
91
93
100, 101
Bank select
Modulation
Data entry
Volume
Pan
Expression
Hold 1
Sostenuto
Soft pedal
Reverb send
Chorus send
RPN LSB, MSB
Models: CTK-4400/WK-240/WK-245 Version : 1.0
Mode 1 : OMNI ON, POLY
Mode 3 : OMNI OFF, POLY
Mode 2 : OMNI ON, MONO
Mode 4 : OMNI OFF, MONO
O : Yes
X : No
O
X
X
O
O
X
O
O
O
X
O
X
*3
*3
*3
O
O
O
O
O
O
O
O
O
O
O
O
(MSB only)
*2
*2
*2
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
Declaration of Conformity
Model Number: CTK-4400/WK-240/WK-245
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
*1: Depends on tone.
*2: For details about NRPN, RPN, and system
exclusive messages, see MIDI Implementation at
http://world.casio.com/.
*3: In accordance with peal effect setting.
*1: Depende del tono.
*2: Para obtener información acerca de NRPN, RPN y
los mensajes exclusivos del sistema, consulte
Implementación MIDI en
http://world.casio.com/.
*3: De acuerdo con el ajuste de efecto de pedal.
CTK4400_A5_x1a_EN_ES.indd 2 2014/02/19 10:25:11
GUÍA DEL USUARIO
USER’S GUIDE
EN/ES
WK240/CTK4400-ES1A
Guarde toda la información para futuras consultas.
Please keep all information for future reference.
Precauciones de seguridad
Antes de intentar usar el teclado digital, asegúrese de
leer las “Precauciones de seguridad” separadas.
Safety Precautions
Before trying to use the Digital Keyboard, be sure to
read the separate “Safety Precautions”.
CTK-4400
WK-240
WK-245
EnglishEspañol
This recycle mark indicates that the packaging conforms to
the environmental protection legislation in Germany.
Esta marca de reciclaje indica que el empaquetado se
ajusta a la legislación de protección ambiental en Alemania.
MA1402-A Printed in China
K
CTK4400_A5_x1a_EN_ES.indd 1 2014/02/19 10:25:10

Navigation menu
