- Accessories
- Read this first!
- Contents
- General Guide
- Monitor Screen Contents and How to Change Them
- Quick Start Basics
- What you can do with your CASIO camera
- First, charge the battery prior to use.
- Configuring Basic Settings the First Time You Turn On the Camera
- Preparing a Memory Card
- Turning the Camera On and Off
- Holding the Camera Correctly
- Shooting a Snapshot
- Viewing Snapshots
- Deleting Snapshots and Movies
- Snapshot Shooting Precautions
- Snapshot Tutorial
- Recording Movie Images
- Using BEST SHOT
- Advanced Settings
- Using On-screen Menus
- REC Mode Settings (REC)
- Selecting a Focus Mode (Focus)
- Changing the Focus Frame Shape (Focus Frame)
- Specifying the Auto Focus Area (AF Area)
- Using Face Detection (Face Detection)
- Using Continuous Shutter (CS)
- Reducing the Effects of Camera and Subject Movement (Anti Shake)
- Assigning Functions to the [<] and [>] Keys (L/R Key)
- Displaying the On-screen Grid (Grid)
- Turning on Image Review (Review)
- Using Icon Help (Icon Help)
- Configuring Power On Default Settings (Memory)
- Image Quality Settings (Quality)
- Viewing Snapshots and Movies
- Other Playback Functions (PLAY)
- Using the PLAY Panel
- Playing a Slideshow on the Camera (Slideshow)
- Rotating an Image (Rotation)
- To perform repeat movie playback (Repeat Movie Play)
- Applying Artistic Effects to Snapshots (Art Effect)
- Selecting Images for Printing (DPOF Printing)
- Protecting a File Against Deletion (Protect)
- Resizing a Snapshot (Resize)
- Cropping a Snapshot (Trimming)
- Adding Audio to a Snapshot (Dubbing)
- Copying Files (Copy)
- Dynamic Photo
- Printing
- Using the Camera with a Computer
- Other Settings (Set Up)
- Shooting and Playing back Images without Disturbing Others (Silent)
- Turning off Eye-Fi Card Communication (Eye-Fi)
- Configuring FlashAir Card Communication Settings (FlashAir)
- Configuring Camera Sound Settings (Sounds)
- Configuring a Startup Image (Startup)
- Specifying the File Name Serial Number Generation Rule (File No.)
- Configuring World Time Settings (World Time)
- Time Stamping Snapshots (Timestamp)
- Setting the Camera’s Clock (Adjust)
- Specifying the Date Style (Date Style)
- Specifying the Display Language (Language)
- Configuring Sleep State Settings (Sleep)
- Configuring Auto Power Settings (Auto Power Off)
- Configuring [_] Setting (REC)
- Configuring [>] Setting (PLAY)
- Disabling File Deletion (_ Disabled)
- Formatting Built-in Memory or a Memory Card (Format)
- Resetting the Camera to Factory Defaults (Reset)
- Appendix
1
EN
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User’s Guide.
• Keep the User’s Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM
Website at http://www.exilim.com/
Digital Camera
User’s Guide
2
As you unpack your camera, check to make sure that all accessories shown below
are included. If anything is missing, contact your original retailer.
*1 The type of USB-AC adaptor included varies according to the country or
geographic area where the camera is sold.
*2 A power cord is included with the AD-C53U USB-AC adapter. The shape of the
power cord plug varies according to the country or geographic area where the
camera is sold.
Accessories
Rechargeable lithium ion
battery (NP-80) Power cord*2Micro USB cable
USB-AC adaptor*1 (AD-C54UC/AD-C54UG/AD-C53U)
Strap Basic Reference
1
2
To attach the strap to the camera
Attach strap
here.
3
• The contents of this manual are subject to change without notice.
• The contents of this manual have been checked at each step of the production
process. Feel free to contact us if you notice anything that is questionable,
erroneous, etc.
• Any copying of the contents of this User’s Guide, either in part or its entirety, is
forbidden. Except for your own personal use, any other use of the contents of this
manual without the permission of CASIO COMPUTER CO., LTD. is forbidden
under copyright laws.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits suffered by you or any third party due to the use or malfunction of this
product.
• CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost
profits caused by loss of memory contents due to malfunction, repair, or any other
reason.
• Note that the example screens and product illustrations shown in this User’s Guide
may differ somewhat from the screens and configuration of the actual camera.
LCD Panel
The liquid crystal panel of the monitor screen uses high-precision technology that
provides a pixel yield in excess of 99.99%. This means that some very small number
of pixels may not light or may remain lit at all times. This is due to the characteristics
of the liquid crystal panel, and does not indicate malfunction.
Read this first!
Take a few test shots
Before shooting your final image, shoot a test shot to ensure that the camera is
recording correctly.
4Contents
Contents
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Monitor Screen Contents and How to Change Them . . . . . . . . . . . . . . . . . . . . 9
]\
Quick Start Basics 12
What you can do with your CASIO camera . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
First, charge the battery prior to use.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
]To load the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
]Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Configuring Basic Settings the First Time You Turn On the Camera. . . . . . . . 19
Preparing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
]To load a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
]To format (initialize) a new memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Holding the Camera Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Shooting a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
]To select an auto recording mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
]To shoot a snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Deleting Snapshots and Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Snapshot Shooting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
]\
Snapshot Tutorial 33
Using the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing the Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Size) . . 34
Using Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Flash) . . 37
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-timer) . . 39
Recording Beautiful Portraits . . . . . . . . . . . . . . . . . . . . . . . . . . (Make-up) . . 40
Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . . 40
Shooting with Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
]\
Recording Movie Images 44
To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
]\
Using BEST SHOT 46
To shoot an image with BEST SHOT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Shooting with Artistic Effects . . . . . . . . . . . . . . . . . . . . . . . . (ART SHOT) . . 48
Recording a Self-portrait . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Self-portrait) . . 49
Recording and Playing back Audio Only . . . . . . . . . . . (Voice Recording) . . 50
5Contents
]\
Advanced Settings 52
Using On-screen Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
REC Mode Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(REC) . . 54
]Selecting a Focus Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Focus). . . 54
]Changing the Focus Frame Shape . . . . . . . . . . . . . . . . . . . (Focus Frame). . . 56
]Specifying the Auto Focus Area . . . . . . . . . . . . . . . . . . . . . . . . . . (AF Area). . . 57
]Using Face Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Face Detection). . . 58
]Using Continuous Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (CS). . . 59
]Reducing the Effects of Camera and Subject Movement . . . . (Anti Shake). . . 60
]Assigning Functions to the [4] and [6] Keys . . . . . . . . . . . . . . . (L/R Key). . . 61
]Displaying the On-screen Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Grid) . . . 61
]Turning on Image Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Review). . . 62
]Using Icon Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Icon Help). . . 62
]Configuring Power On Default Settings . . . . . . . . . . . . . . . . . . . . (Memory). . . 63
Image Quality Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Quality) . . 64
]Specifying Snapshot Image Quality . . . . . . . . . . . .(T Quality (Snapshot)). . . 64
]Correcting Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (EV Shift). . . 64
]Controlling White Balance . . . . . . . . . . . . . . . . . . . . . . . . . (White Balance). . . 65
]Specifying ISO Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(ISO). . . 67
]Using Built-in Color Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Color Filter). . . 67
]\
Viewing Snapshots and Movies 68
Viewing Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Viewing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Zooming an On-screen Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Displaying the Image Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
]\
Other Playback Functions (PLAY) 70
Using the PLAY Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Playing a Slideshow on the Camera . . . . . . . . . . . . . . . . . . . . (Slideshow) . . 71
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Rotation) . . 72
To perform repeat movie playback . . . . . . . . . . . . . . (Repeat Movie Play) . . 72
Applying Artistic Effects to Snapshots . . . . . . . . . . . . . . . . . . . (Art Effect) . . 72
Selecting Images for Printing . . . . . . . . . . . . . . . . . . . . . . (DPOF Printing) . . 73
Protecting a File Against Deletion . . . . . . . . . . . . . . . . . . . . . . . . .(Protect) . . 73
Resizing a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Resize) . . 74
Cropping a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Trimming) . . 74
Adding Audio to a Snapshot . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Dubbing) . . 75
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Copy) . . 76
]\
Dynamic Photo 77
Inserting a Built-in Subject into a Snapshot or Movie . . . (Dynamic Photo) . . 77
]To view a Dynamic Photo . . . . . . . . . . . . . . . . . . . . . . (Dynamic Photo File). . . 78
6Contents
]\
Printing 79
Printing Snapshots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Using DPOF to Specify Images to be Printed and the Number of Copies. . . . 79
]\
Using the Camera with a Computer 82
Things you can do using a computer... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Using the Camera with a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . . 83
]Viewing and Storing Images on a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
]Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Using the Camera with a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
]Connecting the Camera to Your Computer and Saving Files . . . . . . . . . . . . . . . 87
]Playing a Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Using an SD Memory Card with Built-in LAN . . . . . . . . . . . . . . . . . . . . . . . . . 90
]Transferring Images with an Eye-Fi Card . . . . . . . . . . . . . . . . . . . (Eye-Fi). . . 90
]Using a Smartphone to Play Back Images Stored on
a FlashAir Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (FlashAir). . . 91
Files and Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Memory Card Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
]\
Other Settings (Set Up) 96
Shooting and Playing back Images without Disturbing Others . . . . (Silent) . . 96
Turning off Eye-Fi Card Communication . . . . . . . . . . . . . . . . . . . . (Eye-Fi) . . 97
Configuring FlashAir Card Communication Settings . . . . . . . . . (FlashAir) . . 97
Configuring Camera Sound Settings . . . . . . . . . . . . . . . . . . . . . (Sounds) . . 97
Configuring a Startup Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(Startup) . . 98
Specifying the File Name Serial Number Generation Rule . . . . . (File No.) . . 98
Configuring World Time Settings . . . . . . . . . . . . . . . . . . . . . (World Time) . . 99
Time Stamping Snapshots . . . . . . . . . . . . . . . . . . . . . . . . . . .(Timestamp) . 100
Setting the Camera’s Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Adjust) . 100
Specifying the Date Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Date Style) . 101
Specifying the Display Language . . . . . . . . . . . . . . . . . . . . . . (Language) . 101
Configuring Sleep State Settings . . . . . . . . . . . . . . . . . . . . . . . . . . (Sleep) . 101
Configuring Auto Power Settings . . . . . . . . . . . . . . . . . . (Auto Power Off) . 102
Configuring [r] Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(REC) . 102
Configuring [p] Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (PLAY) . 103
Disabling File Deletion . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Ü Disabled) . 103
Formatting Built-in Memory or a Memory Card . . . . . . . . . . . . . . .(Format) . 104
Resetting the Camera to Factory Defaults . . . . . . . . . . . . . . . . . . .(Reset) . 104
7Contents
]\
Appendix 105
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Precautions During Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
]Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
]Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
]Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Reset Initial Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
When things don’t go right... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
]Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
]Display Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Number of Snapshots/Movie Recording Time/Voice Recording Time . . . . . . 126
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
8
The numbers in parentheses indicate the pages where each item is explained.
General Guide
8 7
5312 4 6bk9
bs br bobpbq
bmbl bn
[ ]
[
SET
]
[ ]
[ ]
[ ]
1Zoom controller
(pages 26, 41, 69, 69)
2[0] (Movie) button
(page 44)
3Shutter button (page 26)
4[ON/OFF] (Power)
(page 23)
5Flash (page 37)
6Front lamp (page 39)
7Lens
8Microphone
(pages 45, 75)
9[r] (REC) button
(pages 23, 26)
bkBack lamp
(pages 15, 17, 37)
blStrap hole (page 2)
bm[USB] port
(pages 14, 16)
bnConnector cover
bo[SET] button (page 33)
bp[ ] (Delete) button
(page 30)
bq[p] (PLAY) button
(pages 23, 29)
brControl button
([8][2][4][6])
(pages 11, 30, 33, 37,
52)
bsMonitor screen
(pages 9, 11)
BackFront
Bottom
ck btclcm
btBattery/memory card slots (pages 13, 21)
ckBattery cover
clTripod hole
Use this hole when attaching to a tripod.
cmSpeaker
9
The monitor screen uses various indicators, icons, and values to keep you informed
of the camera’s status.
• The sample screens in this section are intended to show you the locations of all the
indicators and figures that can appear on the monitor screen in various modes.
They do not represent screens that actually appear on the camera.
.Snapshot Recording
Monitor Screen Contents and How to Change Them
1Remaining snapshot memory capacity
(page 126)
2Remaining movie memory capacity (page 44)
3Silent mode (page 96)
4Recording mode (page 25)
5White balance (page 65)
6Continuous shutter (page 59)
7Image deterioration indicator (page 42)
8Metering mode (page 128)
9Snapshot image size (page 34)
bkSnapshot image quality (page 64)
blMovie image quality (page 36)
bmFlash (page 37)
bnSelf-timer (page 39)
boMake-up (page 40)
bpLighting (page 40)
bqDate/time (page 100)
brISO sensitivity (page 67)
bsExposure compensation (page 64)
btFocus frame (pages 27, 57)
ckTimestamp indicator (page 100)
clBattery level indicator (page 18)
cmEye-Fi/FlashAir (pages 90, 91)
cnFace Detection (page 58)
coAnti Shake (page 60)
cpFocus mode (page 54)
bk
bl
bm
bo
bp
bn
bq
89341657
ck
2
bs br
co
cm
cn
cp
cl
bt
10
.Shutter Button Half-pressed
.Movie Recording
.Snapshot Viewing
1Recording mode (page 25)
2Flash (page 37)
3ISO sensitivity (page 67)
4Aperture value
5Shutter speed
6Focus frame (pages 27, 57)
NOTE
• Depending on recording settings, the aperture, shutter speed, and ISO sensitivity
values may not appear on the monitor screen. These values will be orange if the
Auto Exposure (AE) is not correct for some reason.
1Recording mode (page 44)
2White balance (page 65)
3Remaining movie memory capacity (page 44)
4Movie recording time (page 44)
5Exposure compensation (page 64)
6Battery level indicator (page 18)
7Anti Shake (page 60)
8Movie recording in progress (page 44)
1Silent mode (page 96)
2File type
3Protect indicator (page 73)
4Folder name/file name (page 93)
5Snapshot image quality (page 64)
6Snapshot image size (page 34)
7ISO sensitivity (page 67)
8Aperture value
9Shutter speed
bkDate/time (page 100)
blBattery level indicator (page 18)
bmEye-Fi (page 90)
63
4
2
5
1
12
6 5
8
3
4
7
42
5
8
6
9
bk
7
31
bl
bm
11
.Movie Playback
.Configuring Monitor Screen Settings
You can turn display information on and off by pressing [8] (DISP). You can
configure separate settings for the REC mode and PLAY mode.
REC mode
PLAY mode
1Repeat playback (page 68)
2Silent mode (page 96)
3File type
4Protect indicator (page 73)
5Folder name/file name (page 93)
6Movie recording time (page 44)
7Movie image quality (page 36)
8Date/time (page 100)
9Battery level indicator (page 18)
bkEye-Fi (page 90)
Information
display on Displays information about image settings, etc.
Information
display,
remaining movie
memory capacity,
date/time on
In addition to information about
snapshot settings, displays
remaining movie memory capacity
and the date/time screen.
• You can specify the date style you
want to use (page 101).
Information
display off No settings or other information displayed.
Information
display on
Displays settings when shooting, current date and time, and
other information.
Information
display off No information displayed when shooting.
6
7
5
8
9
bk
3 421
12 Quick Start Basics
Quick Start Basics
Your CASIO camera is packed with a powerful selection of features and functions to
make recording of digital images easier, including the following main functions.
What you can do with your CASIO camera
Premium Auto
Select Premium Auto recording and the camera automatically
determines whether you are shooting a subject or scenery,
and other conditions. Premium Auto delivers higher image
quality than standard Auto.
Make-up Function
The Make-up Function smoothes the skin texture of the
subject and softens facial shadows caused by harsh sunlight
for better looking portraits.
ART SHOT
A variety of artistic effects help to make even common,
ordinary subjects become more novel and exciting. “ART
SHOT” provides the following effects:
Toy Camera, Soft Focus, Light Tone, Pop, Sepia,
Monochrome, Miniature, Fisheye.
Silent
The Silent mode disables flash, mutes camera operation
tones, and changes other settings to help ensure that
shooting does not bother others around you.
BEST SHOT
Simply select the sample scene you want and the camera
sets up automatically. Then all you need to do is press the
shutter button for perfect images.
*See page 25 for more information.
*See page 40 for more information.
*See page 48 for more information.
*See page 96 for more information.
*See page 46 for more information.
13 Quick Start Basics
Note that the battery of a newly purchased camera is not charged. Perform the steps
below to load the battery into the camera and charge it.
• Your camera requires a special CASIO rechargeable lithium ion battery (NP-80) for
power. Never try to use any other type of battery.
1. Open the battery cover.
2. Load the battery.
With the CASIO logo on the
battery facing downwards (in the
direction of the lens), hold the
stopper next to the battery in the
direction indicated by the arrow
as you slide the battery into the
camera. Press the battery in until
the stopper secures it in place.
3. Close the battery cover.
First, charge the battery prior to use.
To load the battery
CASIO logo
Stopper
Battery
OK NG
14 Quick Start Basics
To replace the battery
1. Open the battery cover and
remove the current battery.
2. Load a new battery.
You can use either of the two following methods to charge the camera’s battery.
• USB-AC adaptor
• USB connection to a computer
.To charge with the USB-AC adaptor
The adaptor lets you charge the battery while it is loaded in the camera.
While the camera is turned off, connect in the sequence shown below.
Charging time: Approximately 120 minutes
• When disconnecting the USB-AC adaptor from the camera, be sure to disconnect
from the camera first.
Charge the Battery
Stopper
34
3
2
1
2
2
1
Micro USB cable
(included with camera)
u mark of the small
(micro USB) connector
facing the lens side.
[USB] port
USB-AC adaptor (AD-C53U)
Power cord
USB-AC adaptor
(AD-C54UG)
USB-AC adaptor
(AD-C54UC)
15 Quick Start Basics
IMPORTANT!
• Make sure that you insert the cable connector into the USB/
AV port until you feel it click securely into place. Failure to
insert the connector fully can result in poor communication or
malfunction.
• Note that even while the connector is fully inserted, you still
will be able to see the metal part of the connector as shown in
the illustration.
• Pressing [ON/OFF] (Power) while the USB-AC adaptor is connected to the camera
will turn on the camera. Because of this, charging will stop.
• The USB-AC adaptor will become warm during charging. This is normal and does
not indicate malfunction.
• The shape of the power plug depends on each country or geographic area.
Back Lamp Operation
Lamp Status Description
Lit Red Charging
Flashing Red
Abnormal ambient temperature, USB-
AC adaptor problem, or battery
problem (page 115)
Off Charging complete
Back lamp
16 Quick Start Basics
.To charge using a USB connection to a computer
USB connection lets you
charge the battery while it is
loaded in the camera.
While the camera is turned off,
connect in the sequence
shown below (1, 2). If the
camera is on, press [ON/OFF]
(Power) to turn it off before
connecting it to your computer.
Charging time: Approximately
140 minutes
IMPORTANT!
• The first time you connect the camera to your computer with the USB cable, an
error message may appear on your computer. If this happens, disconnect and then
reconnect the USB cable.
• Depending on the setup of your computer, you may not be able to charge the
camera’s battery over a USB connection. If this happens, use of the USB-AC
adaptor that comes with the camera is recommended.
• Charging is not performed while the connected computer is in the hibernate mode.
USB
2
1
Micro USB cable
(included with camera)
u mark of the small (micro USB) connector facing
the lens side.
[USB] port
USB port
Computer
(power turned on)
17 Quick Start Basics
Back Lamp Operation
• The information in parentheses in the above table shows the lamp status while the
camera is turned on during charging.
Other Charging Precautions
• With the two charging methods described above, you can charge the camera’s
battery (NP-80) without removing it from the camera. You also can charge the
battery using an optionally available charger unit (BC-80L). Never use any other
type of charger device. Attempting to use a different charger can result in
unexpected accident.
• USB charging devices and power supply devices are subject to fixed standards.
Use of an inferior device or a device that is not up to standard can cause
malfunction and/or failure of your camera.
• Operation is not guaranteed in the case of a computer built or modified by you.
Even in the case of a commercially available computer, certain USB port
specifications may make it impossible to charge via the USB cable.
• A battery that is still warm due to normal use may not charge fully. Give the battery
time to cool before charging it.
• A battery discharges slightly even when it is not loaded in the camera. Because of
this, it is recommended that you charge the battery immediately before you need to
use it.
• Charging the camera’s battery may cause interference with TV and radio reception.
If this happens, plug the charger into an outlet that is further away from the TV or
radio.
• Actual charging time depends on current battery capacity and charging conditions.
• Do not use the USB-AC adaptor with any other device.
• Never use the power cord with another device.
• Use only the USB-AC adaptor and USB cable specified in this manual for charging.
Use of any other type of devices may result in improper charging.
Lamp Status Description
Lit Red,
(Lit/Flashing Amber) Charging
Flashing Red
Abnormal ambient temperature,
charging taking abnormally long, or
battery problem (page 115)
Off, (Lit Green) Charging complete
Back lamp
18 Quick Start Basics
Checking Remaining Battery Power
As battery power is consumed, a battery indicator on the monitor screen indicates
remaining power as shown below.
indicates battery power is low. Charge the battery as soon as possible.
Recording is not possible when is indicated. Charge the battery immediately.
• The level shown by the battery indicator may change when you switch between the
REC mode and PLAY mode.
• Leaving the camera for about 30 days with no power supplied while the battery is
dead will cause its date and time settings to be cleared. A message telling you to
configure time and date settings will appear the next time you turn on the camera
after restoring power. When this happens, configure date and time settings (page
100).
• See page 130 for information about battery life and number of shots.
• Battery power is used up more quickly when “On” is selected for the Anti Shake
setting (page 60). In this case, the camera may turn off even though the battery
level indicator is still amber. Recharge the battery more often than normal when
Anti Shake is enabled.
Battery Power Conservation Tips
• When you do not need to use the flash, select ?(Flash Off) for the flash setting
(page 37).
• Enable the Auto Power Off and the Sleep features to protect against wasting
battery power when you forget to turn off the camera (pages 101, 102).
Remaining Power High Low
Battery Indicator ***
Indicator Color Cyan *Amber *Red *Red
19 Quick Start Basics
The first time you load a battery into the camera, a screen appears for configuring the
display language, date, and time settings. Failure to set the date and time correctly
will cause the wrong date and time data to be recorded with images.
IMPORTANT!
• A screen for language selection will not appear in step 2 of the procedure below if
you purchased a camera intended for the Japanese market. To change the display
language from Japanese in this case, use the procedure under “Specifying the
Display Language (Language)” (page 101). Note that a version of this manual in
the language you select may not be included with a camera intended for the
Japanese market.
• Camera models sold in certain geographic areas may not support display language
selection.
1. Hold down [ON/OFF] (Power) until the
back lamp lights green momentarily.
2. Use [8], [2], [4], and [6] to select
the language you want and then press
[SET].
3. Use [8] and [2] to select a date style
and then press [SET].
Example: July, 10, 2015
YY/MM/DD * 15/7/10
DD/MM/YY * 10/7/15
MM/DD/YY * 7/10/15
4. Set the date and the time.
Use [4] and [6] to select the setting you want to
change and then use [8] and [2] to change it.
To switch between 12-hour and 24-hour format, press
[0] (Movie).
5. After setting the date and time, use [4] and [6]
to select “Apply” and then press [SET].
6. Use [8] and [2] to select “Auto” or “Premium Auto” as the auto
recording mode and then press [SET].
• See page 25 for information about the auto recording modes.
Configuring Basic Settings the First Time You Turn On the
Camera
[ON/OFF] (Power)
[0] (Movie)
Back lamp
20 Quick Start Basics
NOTE
• Each country controls its local time offset and the use of summer time, and so they
are subject to change.
• Removing the battery from the camera too soon after configuring time and date
settings for the first time can cause the settings to be reset to their factory defaults.
Do not remove the battery for at least 24 hours after configuring settings.
Though the camera has built-in memory that can be used to store images and
movies, you probably will want to purchase a commercially available memory card for
greater capacity. The camera does not come with a memory card. Images recorded
while a memory card is loaded are saved to the memory card. When no memory card
is loaded, images are saved to built-in memory.
• For information about memory card capacities, see page 126.
.Supported Memory Cards
– SD Memory Card
– SDHC Memory Card
– SDXC Memory Card
• The above are supported memory card types as of November 2013.
• This camera supports use of SD memory cards of the following types and
capacities: SD memory cards up to 2GB, SDHC memory cards from 2GB up to
32GB, SDXC memory cards from 32GB up to 2TB. Note that the ability to use any
particular card with this camera, even if it satisfies the above capacity and type
requirements, is not guaranteed.
• This camera supports use of Eye-Fi cards and FlashAir cards.
If you make a mistake configuring display language, date, or time settings with the
above procedure, refer to the following pages for information about how to correct
the settings.
– Display language: Page 101
– Date and time: Page 100
Preparing a Memory Card
21 Quick Start Basics
1. Press [ON/OFF] (Power) to turn off
the camera and then open the
battery cover.
2. Load a memory card.
Positioning the memory card so its
front is facing upwards (towards the
monitor screen side of the camera),
slide it into the card slot all the way in
until you hear it click securely into
place.
3. Close the battery cover.
IMPORTANT!
• Never insert anything besides a supported memory card (page 20) into the memory
card slot.
• Should water or any foreign object ever get into the card slot, immediately turn off
the camera, remove the battery, and contact your retailer or nearest CASIO
authorized service center.
To load a memory card
Front Back
Front
22 Quick Start Basics
To replace the memory card
Press the memory card and then release it.
This will cause it to pop out of the memory
card slot slightly. Pull the card out the rest of
the way and then insert another one.
• Never remove a card from the camera
while the back lamp is flashing green.
Doing so can cause the image save
operation to fail and even damage the
memory card.
Format a memory card on the camera before using it for the first time.
IMPORTANT!
• Formatting a memory card that already has snapshots or other files on it, will delete
its contents. Normally you do not need to format a memory card again. However, if
storing to a card has slowed down or if you notice any other abnormality, re-format
the card.
• Be sure to use the camera to format a memory card. Formatting a card on a
computer will result in a non-SD standard format, which can greatly slow down
processing time and cause compatibility, performance, and other problems.
• Before formatting a new Eye-Fi card to use it for the first time, copy the Eye-Fi
install files to your computer. Do this before formatting the card.
• Formatting a FlashAir card with the camera will delete files on the card that are
required for communication. For details about formatting, see the instructions that
come with the FlashAir card.
1. Press [ON/OFF] (Power) to turn on the camera and then press [SET].
2. Use [8] and [2] to select the “MENU” Control Panel option and then
press [SET] (page 33).
3. Use [4] and [6] to select the “Set Up” tab.
4. Use [8] and [2] to select “Format” and then press [6].
5. Use [8] and [2] to select “Format” and then press [SET].
To format (initialize) a new memory card
23 Quick Start Basics
.To turn power on
Pressing [ON/OFF] (Power) enters the REC mode so
you can record images. Pressing [p] (PLAY) while in
the REC mode enters the PLAY mode, which you can
use to view snapshots and movies (pages 29, 68).
•Pressing [p] (PLAY) turns on the camera and enters
the PLAY mode.
•Pressing [r] (REC) or the shutter button while in the
PLAY mode returns to the REC mode.
• Take care to ensure that nothing is restricting or
coming into contact with the lens as it extends.
Holding the lens with your hand so it cannot extend
creates the risk of malfunction.
• About 10 seconds after you press [p] (PLAY) to
enter the PLAY mode, the lens will retract into the
camera.
• The Sleep function or Auto Power Off (pages 101,
102) will turn off power automatically if you do not
perform any operation for a preset amount of time.
.To turn off the camera
Press [ON/OFF] (Power).
NOTE
• You also can configure the camera to turn on or off when you press [r] (REC) or
[p] (PLAY) (pages 102, 103).
Turning the Camera On and Off
[ON/OFF] (Power)
[p] (PLAY) [r] (REC)
Shutter button
24 Quick Start Basics
Your images will not come out
clearly if you move the camera
when you press the shutter
button. When pressing the
shutter button, be sure to hold the
camera as shown in the
illustration nearby, and keep it
still by pressing your arms firmly
against your sides as you shoot.
Holding the camera still, carefully
press the shutter button and take
care to avoid all movement as the shutter releases and for a few moments after it
releases. This is especially important when available lighting is low, which slows
down the shutter speed.
NOTE
• Take care that your fingers and the strap do not
cover any of the areas indicated in the illustration.
• To protect against accidentally dropping the
camera, attach the wrist strap and make sure it is
around your fingers or wrist while you are
operating the camera.
• Never swing the camera around by its strap.
• The supplied strap is intended for use with this
camera only. Never use it for any other purpose.
IMPORTANT!
• Take care to ensure that your fingers are not
blocking or are not too close to the flash. Fingers
can cause unwanted shadows when using the
flash.
Holding the Camera Correctly
Horizontal Vertical
Flash
Front lamp
Lens
Microphone
25 Quick Start Basics
You can select one of two auto recording modes (Auto or Premium Auto) according to
your digital imaging needs.
1. Press [ON/OFF] (Power) to turn on the camera.
The camera will enter the REC mode.
• If the camera is in the PLAY mode, press [r] (REC) or the shutter button.
• You also can configure the camera to turn on when you press [r] (REC)
(page 102).
2. Press [SET].
3. Use [8] and [2] to select the “Auto Recording Mode” Control Panel
option (page 33).
Shooting a Snapshot
To select an auto recording mode
Setting
REC Screen
Icon Display
Description
Auto This is the standard Auto recording mode.
Premium
Auto
With Premium Auto recording, the camera
automatically determines whether you are shooting a
subject or scenery, and other conditions. Premium
Auto recording delivers higher image quality than
standard Auto recording.
• Some of the settings configured automatically by
Premium Auto cannot be changed by you.
• Premium Auto recording takes longer to process
image data after it is shot than Auto recording.
• It also requires more power (and runs down the
battery quicker) than Auto.
R
Ÿ
26 Quick Start Basics
4. Use [4] and [6] to select “Auto” or “Premium Auto”, and then press
[SET].
This enters the selected auto recording mode.
1. Point the camera at the subject.
If you are using Premium Auto, text will appear in the
lower right corner of the monitor screen describing the
type of shot the camera has detected.
• You can zoom the image, if you want.
To shoot a snapshot
Shutter button
[r] (REC)
Monitor screen
[ON/OFF] (Power)
Auto recording mode icon
Remaining Snapshot Memory
Capacity (page 126)
[8][2][4][6]
[SET]
Appears when the
camera detects it is
stationary on a tripod.
w Wide Angle z Telephoto
Zoom controller
27 Quick Start Basics
3. Continuing to keep the camera still, press the shutter button the rest of
the way down.
This records the snapshot.
IMPORTANT!
• When “On” is selected for the Anti Shake setting (page 60), the camera will vibrate
and emit a mechanical operation noise when you half-press the shutter. Note that
this is normal and does not indicate malfunction.
2. Half-press the shutter button to
focus the image.
When focus is complete, the camera
will beep, the back lamp will light
green, and the focus frame will turn
green.
When you half-press the shutter button, the
camera automatically adjusts exposure and
focuses on the subject it is currently pointed at.
Mastering how much pressure is required for a
half-press and a full-press of the shutter button
is an important technique for good-looking
images.
Recording a Movie
Press [0] (Movie) to start
movie recording. Press
[0] (Movie) again to stop
movie recording. See
page 44 for details.
Focus frame
Back lamp
Half-press
Press lightly
until the
button stops.
Beep, beep (Image is in focus.)
Full-press
Snap (Image is recorded.)
[0] (Movie)
28 Quick Start Basics
.If the image does not focus...
If the focus frame stays red and the back lamp is flashing green, it means that the
image is not in focus (because the subject is too close, etc.). Re-point the camera at
the subject and try to focus again.
.Shooting with Auto
If the subject is not in the center of the frame...
“Focus lock” (page 55) is the name of a technique you can use when you want to
shoot an image in which the subject to be focused on is not within the focus frame in
the center of the screen.
To track the movement of a moving subject
Half-press the shutter button to follow and focus automatically on a moving subject.
See “OTracking” (page 57) for more information.
.Shooting with Premium Auto
• When shooting with Premium Auto, you can use the menu screen (page 52) to
change the settings of only the menu items below. No other menu items will appear
on the menu while you are shooting with Premium Auto.
– REC: Anti Shake, Grid, Review, Icon Help
– Quality: TQuality (Snapshot), EV Shift
– Set Up: All items
• In addition to shutter speed, aperture, and ISO sensitivity, the camera
automatically executes the following operation as required when shooting with
Premium Auto.
– Auto Focus is normally performed until you half-press the shutter button.
– The camera automatically determines the focus point on the screen and focuses
there.
– Make-up (page 40)
Under the initial default camera setup when you purchase it, selecting Premium
Auto as the auto recording mode (page 25) turns on the Make-up function.
– Anti Shake (page 60)
• Shooting with Premium Auto can cause vibration and noise to occur due to lens
operation. This does not indicate malfunction.
• In some cases, Premium Auto may not be able to interpret the shooting
environment correctly. If this happens, shoot with standard Auto.
29 Quick Start Basics
Use the following procedure to view snapshots on the camera’s monitor screen.
• For information about how to play back movies, see page 68.
1. Press [p] (PLAY) to enter the
PLAY mode.
• This will display one of the snapshots
currently stored in memory.
• Information about the displayed
snapshot also is included (page 10).
• You also can clear the information to
view only the snapshot (page 11).
• You can zoom in on the image by
rotating the zoom controller towards z (page 69). If you are recording a
snapshot that is very important to you, it is recommended that you zoom the
image and check its details after recording it.
2. Use [4] and [6] to scroll between images.
• Holding down either button scrolls at high speed.
NOTE
• Half-pressing the shutter button while in the PLAY mode or while a menu screen is
displayed will switch directly to the REC mode.
Viewing Snapshots
[p] (PLAY)
[6][6]
[4][4]
30 Quick Start Basics
If memory becomes full, you can delete snapshots and movies you no longer need in
order to free up storage and record more images.
• In either the REC mode or PLAY mode, you can delete files
simply by pressing [ ] (Delete).
IMPORTANT!
• Remember that a file (image) delete operation cannot be undone.
• Deleting an audio snapshot (page 75) deletes both the snapshot and the audio file.
• You cannot delete files while movie or audio recording is in progress.
• The delete menu will not appear if you press [ ] (Delete) while “On” is selected for
the camera’s “ÜDisabled” setting (page 103). You can delete files only while “Off”
is selected for “ÜDisabled”.
.To delete a single file
1. Press [ ] (Delete).
2. Use [4] and [6] to scroll through the files until the one
you want to delete is displayed.
3. Use [8] and [2] to select “Delete” and then press [SET].
• To delete other files, repeat steps 2 and 3.
• To exit the delete operation, press [ ] (Delete).
Deleting Snapshots and Movies
[ ] (Delete)
31 Quick Start Basics
.To delete specific files
1. Press [ ] (Delete).
2. Use [8] and [2] to select “Delete Files” and then press [SET].
• This displays a file selection screen.
3. Use [8], [2], [4], and [6] to move the selection boundary to the file
you want to delete, and then press [SET].
• This will select the check box of the currently selected file.
4. Repeat step 3 to select other files, if you want. After you are finished
selecting files, press [ ] (Delete).
5. Use [8] and [2] to select “Yes” and then press [SET].
• This deletes the files you selected.
• To exit the delete operation, press [ ] (Delete).
.To delete all files
1. Press [ ] (Delete).
2. Use [8] and [2] to select “Delete All Files” and then press [SET].
3. Use [8] and [2] to select “Yes” and then press [SET] to delete all files.
This will cause the message “There are no files.” to appear.
32 Quick Start Basics
Operation
• Never open the battery cover while the back lamp is flashing green. Doing so can
result in the image you just shot being saved incorrectly, damage to other images
stored in memory, malfunction of the camera, etc.
• If unwanted light is shining directly onto the lens, shade the lens with your hand
when shooting an image.
Monitor Screen when Shooting Snapshots
• Subject brightness conditions can cause monitor screen response to slow and can
cause digital noise in the monitor screen image.
• The image that appears on the monitor screen is for image composition. The actual
image will be recorded at the quality set for the image quality setting (page 64).
Shooting Indoors under Fluorescent Lighting
• Minute flickering of fluorescent lighting can affect the brightness or color of an
image.
.Auto Focus Restrictions
• Any of the following can make proper focus impossible.
– Solid color wall or other very low contrast subject
– Strongly back lit subject
– Very shiny subject
– Blinds or other subject with a repeating horizontal pattern
– Multiple subjects at varying distances from the camera
– Subject in a dark location
– Camera movement while shooting
– Fast-moving subject
– Subjects outside the focus range of the camera
• If you cannot focus properly, try using focus lock (page 55) or Manual Focus (page
54).
Snapshot Shooting Precautions
33 Snapshot Tutorial
Snapshot Tutorial
The Control Panel can be used to configure camera settings.
1. In the REC mode, press [SET].
• You can also display the Control Panel by pressing [2].
2. Use [8] and [2] to select the setting you want to change.
This will select one of the Control Panel icons and display its settings.*1
*1 Items displayed in the Control Panel depend on the recording mode.
*2 Snapshot image quality cannot be changed using the Control Panel.
3. Use [4] and [6] to change the setting.
4. If you want to configure another setting, repeat steps 2 and 3.
5. After all of the settings are the way you want, press [SET].
This will apply the settings and return to the REC mode.
• You can close the Control Panel by pressing [ ] (Delete).
Using the Control Panel
Control Panel
Available settings
1
9
5
3
4
7
8
2
6
[SET]
[8] [2] [4] [6]
1Auto recording mode (page 25)
2Snapshot image size/quality*2
(pages 34, 64)
3Movie image quality (page 36)
4Flash (page 37)
5Self-timer (page 39)
6Make-up (page 40)
7Lighting (page 40)
8REC menu display (page 52)
9BEST SHOT (page 46) scene
selection
34 Snapshot Tutorial
NOTE
• No icon is displayed for any Control Panel option (page 9) that is set to its initial
default (reset) setting. An icon will appear only if you change the setting of the
corresponding Control Panel option. The following are the initial defaults for Control
Panel options.
– Flash: Auto Flash
– Self-timer: Off
– Make-up: Off
– Lighting: Off
– Silent: Off
• You also can configure settings other than those listed above (page 52).
.Pixels and image size
A digital camera image is a collection of small
dots called “pixels”. The more pixels there are
in an image, the more detail there will be.
However, you generally can do with fewer
pixels when printing an image (L size) through
a print service, attaching an image to e-mail,
when viewing the image on a computer, etc.
The size of an image indicates how many
pixels it contains, and is expressed as
horizontal pixelsxvertical pixels.
Example:
• Note that larger images have more pixels, so they take up more memory space.
• For information about image size, image quality, and number of images that can be
stored, see page 126.
• For information about movie image size, see page 36.
• For information about resizing existing snapshots, see page 74.
Changing the Image Size (Size)
Image size Pixels
10M 3648x2736 (Approximately 10 million pixels)
3M 2048x1536 (Approximately 3 million pixels)
Pixel
35 Snapshot Tutorial
.To select the snapshot image size
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the “Snapshot Image Size” Control Panel
option (page 33).
3. Use [4] and [6] to select an image size and then press [SET].
• The initial factory default image size setting is “16M”.
• Selecting “3:2” records images with an aspect ratio of 3:2, which matches the
standard aspect ratio of print paper.
• The letters “HDTV” stand for “High Definition Television”. An HDTV screen has an
aspect ratio of 16:9, which makes them wider than the usual 4:3 aspect ratio of
television screens of the past. Your camera can record images that are compatible
with the aspect ratio an HDTV screen.
• You should regard the print paper sizes suggested here as guidelines only (200 dpi
print resolution).
Image Size
(Pixels)
REC Screen
Icon Display
Suggested
Print Size and
Application
Description
16M
(4608x3456) Poster Print
Good detail for better clarity even for
images cropped (page 74) from the
original
3:2
(4608x3072) Poster Print
16:9
(4608x2592) HDTV
10M
(3648x2736) A3 Print
Good detail
5M
(2560x1920) A4 Print
3M
(2048x1536) 3.5" ×5" Print
Best when preserving memory
capacity is relatively more important
than image quality.
VGA
(640x480) E-Mail
Image files are smaller, which is
better when attaching images to e-
mail. However, images are relatively
coarser.
36 Snapshot Tutorial
.Specifying Movie Image Quality
Movie image quality is a standard that determines the detail, smoothness, and clarity
of a movie during playback. Shooting with the high-quality (HD) setting will result in
better image quality, but it also shortens the amount of time you can shoot.
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the “Movie Image Quality” Control Panel
option and then press [SET] (page 33).
3. Use [4] and [6] to select the setting you want and then press [SET].
• The 16:9 aspect ratio is available when “HD” is selected as the image quality.
• Memory capacity (Movie recording time you can shoot) will be affected by the
quality settings you configure (page 127).
Image Quality
(Pixels)
REC Screen
Icon Display
Approximate Data
Rate Frame Rate
HD 1280x720 30.2 Megabits/second 30 frames/second
STD 640x480 10.6 Megabits/second 30 frames/second
37 Snapshot Tutorial
1. In the REC mode, press [2] ( ) once.
2. Use [4] and [6] to select the flash
setting you want and then press [SET].
• If there are no indicators on the monitor
screen, you can cycle through the flash
modes by pressing [2] ( ). You can turn
display information on or off by pressing
[8] (DISP) (page 11).
3. Press the shutter button to shoot.
• For information about Flash Range, see page 129.
Using Flash (Flash)
Setting
REC Screen
Icon Display
Description
Auto Flash None
Flash fires automatically in accordance with
exposure (amount of light and brightness)
conditions.
Flash Off Flash does not fire.
Flash On
Flash always fires. This setting can be used to
brighten a subject that normally comes out dark
due to daylight or backlight (daylight synchro
flash).
Red Eye
Reduction
Flash fires automatically. This type of flash can be
used to reduce the chance of redness in the
subject’s eyes.
[2] ( )
Flash
>
?
<
¥
Back lamp
Flashes amber while the flash is charging to
indicate that image recording is disabled.
• You will not be able to take another flash
snapshot until the lamp stops flashing amber,
which indicates that charging is complete.
< indicates the flash will fire.
B
38 Snapshot Tutorial
IMPORTANT!
• Foreign matter on the flash window can react with the light of the flash, producing
some smoke and abnormal odor. Though this does not indicate malfunction, oil
from your fingers and other foreign matter when left on the flash window can
become difficult to clean off later. Because of this, you should make it a regular
habit to wipe the window clean regularly with a soft, dry cloth.
NOTE
• Take care so your fingers and the strap do not block the flash.
• The desired effect may not be obtained when the subject is too far away or too
close.
• Flash charging time (page 129) depends on operating conditions (battery
condition, ambient temperature, etc.).
• Shooting with flash turned off when lighting is dim results in a slow shutter speed,
which can cause image blur due to camera movement. Under such conditions,
secure the camera with a tripod, etc.
• With red eye reduction, the flash is fired automatically in accordance with
exposure. It does not fire in areas where lighting is bright.
• The presence of outdoor sunlight, fluorescent lighting, or some other light source
can cause abnormal image colors.
• Select ?(Flash Off) for the flash setting when shooting in areas where flash
photograph is prohibited.
Red-eye Reduction
Using the flash to shoot at night or in a dimly lit room can cause red spots inside the
eyes of people who are in the image. This is caused when the light from the flash
reflects off of the retina of the eye. When red-eye reduction is selected as the flash
mode, the camera fires a pre-flash to cause the irises in the eyes of any people in the
image to close, which reduces the chance of red eye.
Note the following important points when using red-eye reduction.
• Red-eye reduction does not work unless the people in the image are looking
directly at the camera (flash).
• Red-eye reduction may not work very well if the subjects are located far away from
the camera.
39 Snapshot Tutorial
With the Self-timer, pressing the shutter button starts a timer. The shutter is released
and the image is shot after a fixed amount of time.
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the “Self-timer” Control Panel option (page
33).
3. Use [4] and [6] to select the setting you want and then press [SET].
• The front lamp flashes while the Self-timer countdown is
in progress.
• You can interrupt an ongoing Self-timer countdown by
pressing [SET].
NOTE
• The Self-timer cannot be used together with the following features.
CS, some BEST SHOT scenes
• The Triple Self-timer cannot be used together with the following features.
Movie, Make-up, some BEST SHOT scenes
Using the Self-timer (Self-timer)
Setting
REC Screen
Icon Display
Description
10sec
Self-timer 10-second Self-timer
2sec
Self-timer
2-second Self-timer
• When shooting under conditions that slow down
the shutter speed, you can use this setting to
prevent image blur due to camera movement.
×3 Self-
timer (Triple
Self-timer)
Shoots three images: one image 10 seconds after
the shutter button is pressed, and the next two
images as soon as the camera is ready after
shooting the previous image. How long it takes for
the camera to get ready to shoot depends on the
image size and quality settings, whether or not a
memory card is loaded in the camera, and the flash
charge condition.
Self-
timer Off None Turns off the Self-timer.
Ñ
Ì
Ï
Î
Front lamp
40 Snapshot Tutorial
Make-up smoothes the skin texture of the subject and softens facial shadows caused
by harsh sunlight for better looking portraits.
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the “Make-up” Control Panel option (page
33).
3. Use [4] and [6] to select “Make-up: On” and then press [SET].
4. Point the camera at the subject and shoot.
NOTE
• Turning on Make-up automatically turns on Face Detection (page 58).
• Make-up cannot be used with the following functions.
Movie recording, some BEST SHOT scenes, CS, Triple Self-timer
You can use this setting to optimize the balance between bright areas and dark areas
when shooting images.
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the “Lighting” Control Panel option (page
33).
Recording Beautiful Portraits (Make-up)
Setting
REC Screen
Icon Display
Description
On Make-up function enabled.
Off None Make-up function disabled.
Optimizing Image Brightness (Lighting)
±
½
41 Snapshot Tutorial
3. Use [4] and [6] to select the setting you want and then press [SET].
NOTE
• Lighting is disabled during movie recording.
Your camera provides you with 12X optical zoom (that changes the lens focal
distance), which can be used in combination with digital zoom (that digitally
processes the center portion of the image to enlarge it) for total zoom capabilities of
12X to 191.3X. The image deterioration point depends on the image size (page 43).
1. In the REC mode, rotate the zoom controller to zoom.
2. Press the shutter button to shoot the image.
IMPORTANT!
• Digital zoom is disabled while time stamping (page 100) is turned on.
Setting
REC Screen
Icon Display
Description
On
Performs brightness correction. When this option
is selected, it takes longer for the image to be
stored after the shutter button is pressed.
Off None Does not perform brightness correction.
Shooting with Zoom
w (Wide Angle): Reduces the size of the subject and broadens the range.
z (Telephoto) : Enlarges the subject and narrows the range.
Ï
Ì
w Wide Angle z Telephoto Zoom controller
42 Snapshot Tutorial
NOTE
• The higher the digital zoom factor, the coarser the recorded image. Note that the
camera also has a function that lets you record using digital zoom without image
deterioration (page 43).
• Use of a tripod is recommended to protect against image blur due to camera
movement when shooting with telephoto.
• Performing a zoom operation changes the lens aperture.
.Optical Zoom and Digital Zoom Switch Point
If you hold the zoom controller towards z (Telephoto), the zoom operation will stop
when the optical zoom factor reaches its maximum. Momentarily releasing the zoom
controller and then holding it again towards z (Telephoto) will switch to digital
zoom, which you can use to set an even higher zoom factor.
• During zoom, a zoom bar on the monitor screen shows the current zoom setting.
Image deterioration indicator
Zoom bar
Focusing range
(Displayed for Auto Focus, Macro Focus, and Manual
Focus.)
12X to 86.4X
Undeteriorated image
quality range
1X 48X to 191.3X
Zoom pointer (Indicates current zoom.)
Image deterioration
Optical/digital zoom switch point
• 12X optical zoom point
Deteriorated image
quality range
43 Snapshot Tutorial
• The image deterioration point
depends on the image size (page
34). The smaller the image size,
the higher the zoom factor you
can use before reaching the
image deterioration point.
• Though digital zoom generally
causes a deterioration of image
quality, some digital zoom
without image deterioration is
possible with image sizes of
“10M” and smaller. The range in
which you can use digital zoom
without image deterioration is
indicated on the display. The
deterioration point depends on
the image size.
Size
Maximum
Zoom Factor
Undeteriorated
zoom limit
16M
48.0X 12.0X
3:2
16:9
10M 60.6X 15.1X
5M 86.4X 21.6X
3M 107.8X 27.0X
VGA 191.3X 86.4X
44 Recording Movie Images
Recording Movie Images
1. Configure the quality setting for the movie (page 36).
The length of the movie you can record will depend on the quality setting you
select.
2. In the REC mode, point the
camera at the subject and then
press [0] (Movie).
This will start recording and display Y
on the monitor screen.
Movie recording includes monaural
audio.
3. Press [0] (Movie) again to stop
recording.
• Each movie can be up to 29 minutes
long. Movie recording stops automatically after 29 minutes of recording. Movie
recording also will stop automatically if memory becomes full before you stop
movie recording by pressing [0] (Movie).
Shooting with BEST SHOT
With BEST SHOT (page 46), you can select the sample scene that matches the type
of movie you are trying to shoot and the camera will change its setup accordingly, for
beautiful movies every time. Movie Recording is disabled while certain BEST SHOT
scenes are being used.
Minimizing the Effects of Camera Movement during Movie Recording
You can configure the camera to minimize the effects of camera movement during
movie recording (page 60). Note, however, that this does not prevent image blur due
to subject movement and it makes the field of view narrower.
To record a movie
Recording time
Remaining recording time
(page 127)
[0] (Movie)
45 Recording Movie Images
NOTE
• Spending a long time using movie recording will cause the camera to become
slightly warm to the touch. This is normal and does not indicate malfunction.
• The camera also records audio. Note the following points when
shooting a movie.
– Take care that the microphone is not blocked by your fingers,
etc.
– Good recording results are not possible when the camera is
too far away from what you are trying to record.
– Performing a zoom operation while shooting can cause zoom
and/or auto focus noise to be in the audio recording.
– Continuous AF becomes enabled when any focus mode other than manual
focus (MF) is selected. Continuous AF operation may cause the camera to emit
sound that can result in noise in audio recording.
• Shooting a very bright subject can cause a vertical band or a pink cast on the
monitor screen image. This does not indicate malfunction.
• Using the camera’s built-in memory or certain types of memory cards can slow
down processing speed. Whenever possible use an Ultra High-Speed Type
memory card. Note, however, that not all operations can be guaranteed even if an
Ultra High-Speed Type memory card is used. Certain movie quality settings can
result in too much time being required to record data, which can result in breaks in
the image and/or audio during playback. If this happens, the » and Y will flash
on the monitor screen.
• The effects of camera movement in an image become more pronounced when you
shoot close up or with a large zoom factor. Because of this, use of a tripod is
recommended under these conditions.
Microphone
46 Using BEST SHOT
Using BEST SHOT
BEST SHOT provides you with a collection of sample “scenes” that show a variety of
different types of shooting conditions. When you need to change the setup of the
camera, simply find the scene that matches what you are trying to achieve, and the
camera sets up for it automatically. This helps to minimize the chance of ruined
images due to poor exposure and shutter speed settings.
.Some Sample Scenes
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the
bottom Control Panel option (BS)
and then press [SET] (page 33).
This will display a menu of BEST
SHOT scenes.
3. Use [8], [2], [4], and [6] to
move the boundary to the scene
you want to select.
• The scene menu has multiple
pages. Use [8] and [2] to scroll
between menu pages.
• You can access information about the currently selected scene. See page 47
for details.
Portrait Scenery Self-portrait
(1 person) Night Scene Portrait
To shoot an image with BEST SHOT
[SET]
[8] [2] [4] [6]
Currently selected scene
(with boundary)
Scene number
Scene name
47 Using BEST SHOT
4. Press [SET] to configure the camera with the settings for the currently
selected scene.
This returns to the REC mode.
• The settings of the scene you selected remain in effect until you select a
different scene.
• To select a different BEST SHOT scene, repeat the above procedure from
step 1.
5. Press the shutter button (if you are shooting a snapshot) or [0] (Movie)
(if you are shooting a movie).
• To return to the auto recording mode, press [SET], use [8] and [2] to select
the top Control Panel option (Auto recording mode), and then select R(Auto)
or Ÿ(Premium Auto).
.Using Scene Information Screen
To find out more about a scene, select it with the boundary
on the scene selection screen, and then rotate the zoom
controller in either direction.
• To return to the scene menu, rotate the zoom controller
again.
• To scroll between scenes, use [4] and [6].
• To configure the camera with the settings for the currently
selected scene, press [SET].
.BEST SHOT Precautions
• Some BEST SHOT scenes cannot be used while recording a movie.
• “For YouTube” scene cannot be used while shooting a snapshot.
• The “Voice Recording” scene cannot be used while shooting a snapshot or
recording a movie.
• Some scenes like “Night Scene Portrait” results in a slow shutter speed setting.
Since a slow shutter speed increases the chance of digital noise in the image, the
camera automatically performs a digital noise reduction process when either of
these scenes is selected. This means that it will take a bit longer for the image to
be saved which is indicated by the back lamp flashing green. Do not perform any
key operation during that time. Also, it is a good idea to use a tripod to avoid image
blur due to camera movement when shooting at slow shutter speeds.
• The BEST SHOT YouTube scene sets up the camera for recording movies that are
optimized for uploading to YouTube. Movies recorded with the YouTube scene are
stored in a special folder to make them easy to locate for uploading (page 94).
• Your camera includes a sample scene that optimizes settings for auction site
images. Depending on your camera model, the sample scene is named either “For
eBay” or “Auction”. Images you record using the auction site sample scene are
stored in a special folder so you can easily find them on your computer (page 94).
48 Using BEST SHOT
• High Sensitivity
– The high sensitivity setting is disabled whenever the camera’s flash fires.
– High sensitivity may not produce the desired results in very dark conditions.
– When shooting with slow shutter speeds, use a tripod to protect against blurring
due to camera movement.
– Under certain lighting conditions, the camera will perform an automatic noise
filtering operation to reduce digital noise in the image. This operation causes the
camera to take longer than normal to save the image and be ready for the next
shot.
• BEST SHOT scene images were not shot using this camera.
• Images shot using a BEST SHOT scene may not produce the results you expected
due to shooting conditions and other factors.
• You can modify the camera settings that are made after you select a BEST SHOT
scene. Note, however, that the BEST SHOT settings revert to their defaults when
you select another BEST SHOT scene or turn off the camera.
A variety of artistic effects help to make even common, ordinary subjects become
more novel and exciting.
1. Select the BEST SHOT scene you want to use and then press [SET].
2. Press the shutter button to shoot.
Shooting with Artistic Effects (ART SHOT)
Scene Description
Toy Camera Dark edges and altered hues make images look like they
were shot by a toy camera.
Soft Focus Overall blurring for a soft and romantic effect.
Light Tone Weakened contrast for a feeling of airy refinement.
Pop Enhanced saturation make colors stand out in with rich clarity.
Sepia Sepia tones create a decidedly retro look.
Monochrome All of the strong contrast and graininess of a black and white
print.
Miniature Partial blurring makes scenes look like they are from of a
miniature world.
Fisheye A fisheye lens effect can be used to create a variety of
humorous images.
49 Using BEST SHOT
NOTE
• With this “ART SHOT” scene, the flash setting automatically becomes ?(Flash
Off).
• Movie recording is disabled while “ART SHOT” is selected.
• The ART SHOT cannot be used together with the following features.
Face Detection, CS, Make-up, Color Filter
• The following information applies to the Auto Focus (AF) area (page 57) of some
ART SHOT scenes.
–“OTracking” is automatically disabled.
–“USpot” always selected.
With this feature, you can shoot your own self-portrait simply by pointing the camera
at your face.
BEST SHOT has two self-portrait scenes from which to choose.
1. On the BEST SHOT scene menu, select “Self-portrait (1 person)” or
“Self-portrait (2 people)”.
2. Press the shutter button all the way down, and point
the camera at yourself.
About three seconds after you press the shutter button, the
camera will go into Auto Shutter standby and start face
detection. After the camera detects the specified number of
faces, focuses, and adjusts the exposure to the proper
level, it will beep twice and then release the shutter
automatically.
• The camera will emit a shutter sound and the front lamp will flash twice when
the shutter is released.
• To cancel Auto Shutter standby, press [SET].
IMPORTANT!
• If the camera remains in Auto Shutter standby without releasing the shutter, you
can record an image by pressing the shutter button all the way down again.
• Shooting with the self-portrait feature may produce a blurred image when shooting
in areas where lighting is dim, which results in a very slow shutter speed setting.
• The Auto Power Off (page 102) trigger time is fixed at five minutes while the
camera is in Auto Shutter standby. Sleep (page 101) is disabled while Auto Shutter
is being used.
Recording a Self-portrait (Self-portrait)
• Self-portrait (1 person): Shoots when the face of at least one person, including
you, is detected.
• Self-portrait (2 people) : Shoots when the faces of at least two people, including
you, are detected.
50 Using BEST SHOT
Voice Recording lets you record audio only, without a snapshot or movie.
• For information about Voice Recording capacities, see page 127.
.Recording audio only
1. On the BEST SHOT scene menu, select “Voice Recording”.
This causes ` to appear on the monitor screen.
2. Press the shutter button to start recording.
• The back lamp flashes green while recording is in
progress.
• Pressing [SET] during recording will insert a
marker into the recording. During playback, you
will be able to jump to the markers in the recording.
3. Press the shutter button again to stop audio
recording.
• To create another audio recording file, repeat
steps 2 and 3.
• To turn off Voice Recording, press [SET], use [8] and [2] to select the top
Control Panel option (Auto recording mode), and then select R(Auto) or
Ÿ(Premium Auto).
NOTE
• You can use [8] (DISP) during audio recording to toggle the monitor screen on
and off.
• When monitor screen contents are turned off, selecting the “Voice Recording” will
cause the monitor screen to turn off immediately (page 11).
Recording and Playing back Audio Only (Voice Recording)
Recording time
Remaining recording
time
51 Using BEST SHOT
About audio data
• Audio files can be played back on a computer with Windows Media Player or
QuickTime.
– Audio Data: WAVE/IMA-ADPCM (WAV extension)
.To play back an audio recording
1. In the PLAY mode, use [4] and [6] to display
the Voice Recording file you want to play.
` is displayed in place of an image for a Voice
Recording file.
2. Press [0] (Movie) to start playback.
Voice Recording Playback Controls
NOTE
• See page 30 for information about deleting a voice recording file.
Fast forward/fast reverse [4] [6]
Play/pause [SET]
Jump to marker
While playback is paused, press [4] or [6] to
jump to the next marker and then press [SET]
to resume playback.
Volume adjustment Press [2] and then press [8] [2]
Monitor screen on/off [8] (DISP)
Playback end [0] (Movie)
52 Advanced Settings
Advanced Settings
The following are menu operations you can use to configure various camera settings.
• REC mode menu contents and operations are different from those in the PLAY
mode. This section explains operations using the REC menu screen. See page 70
for information about PLAY menu screen operations.
.Example REC Menu Screen Operation
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the “MENU” Control
Panel option and then press [SET] (page 33).
This will display the REC menu screen.
3. Use [4] and [6] to select the tab where the menu
item you want to configure is located.
4. Use [8] and [2] to select the menu item you
want, and then press [6].
5. Use [8] and [2] to change the setting of the
selected menu item.
6. After the setting is the way you want, press
[SET] to apply the setting and return to the
viewfinder screen.
• Pressing [4] instead of [SET] applies the
selected setting and returns to the menu item
selection.
• To configure settings on another tab after
pressing [4] to return to the menu item selection,
use [8] or [ ] (Delete) to move the highlighting
up to the tabs, and then use [4] and [6] to
select the tab you want.
Using On-screen Menus
[SET]
[8] [2] [4] [6]
Example:
When “TQuality” is
selected on the “Quality”
tab
Tabs
Selected menu item
Settings
53 Advanced Settings
NOTE
• [ ] (Delete) provides a helpful way to navigate around tabs and menus.
– Pressing [ ] (Delete) while a tab is selected will display the viewfinder screen.
– Pressing [ ] (Delete) while menu item or setting is selected will “back step” in
the following sequence: Settings * Menu items * Tab.
• Depending on the recording mode, some of the items on the menu that appears
may not be usable. Only the menu items whose settings can be configured (page
28) will be displayed on the menus while Premium Auto is in use.
.REC Menu Operations in This Manual
REC menu operations are represented in this manual as shown below. The following
operation is the same one described under “Example REC Menu Screen Operation”
on page 52.
Procedure
[r] (REC)
*
[SET]
*
MENU
*
“Quality” Tab
*
T Quality
Use [4] and [6] to select the
“Quality” tab.
Use [8] and [2] to select “T Quality”
and then press [6].
Press
[SET].
Press
[r] (REC).
Use [8] and [2] to select the “MENU” Control Panel
option and then press [SET].
54 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Focus
Auto Focus is the only focus mode available while Make-up (page 40) or Face
Detection (page 58) is enabled. To select another focus mode, first turn off Make-up
and Face Detection.
*1 The focus range is the distance from the lens surface.
*2 Range is affected by optical zoom.
REC Mode Settings (REC)
Selecting a Focus Mode (Focus)
Settings
REC
Screen
Icon
Display
Type of Shot
Focus Mode Approximate Focus Range
*
1
Snap-
shot Movies Snapshot Movies
AF (Auto
Focus)
None General
recording
Automatic
3 cm to
9 (infinity)
(1.2" to 9)
(Wide Angle)*2Fixed
distance
*2
´
Macro Close ups
3 cm to 50 cm
(1.2" to 19.7")
(Wide Angle)*2
MF
(Manual
Focus)
When you
want to focus
manually
Manual 3 cm to 9 (infinity)
(1.2" to 9) (Wide Angle)*2
55 Advanced Settings
To focus with manual focus
1. On the monitor screen, compose the image so
the subject you want to focus on is within the
yellow boundary.
2. Watching the image on the monitor screen use
[4] and [6] to adjust focus.
• At this time the image that is within the boundary
will enlarge and fill the monitor screen, which aids
in focusing. If you do not perform any operation for
two seconds while the enlarged image is displayed,
the screen in step 1 will re-appear.
NOTE
• An Auto Macro feature detects how far the subject is from the lens and
automatically selects either Macro Focus or Auto Focus accordingly.
• Auto Macro can be used when recording snapshots only.
• When using the “Miniature” or “Fisheye” ART SHOT scene, you can select either
Super Macro or Manual Focus only as the focus mode.
• Use of the flash together with Macro Focus can cause the light of the flash to
become blocked, which may result in unwanted lens shadows in your image.
• Whenever you perform an optical zoom operation while shooting with Auto Focus,
Macro Focus, or Manual Focus, a value will appear on the monitor screen to tell
you the focus range, as shown below.
Example: oo* cm – 9
*oo is the actual focusing range value.
• The operations assigned to the [4] and [6] keys with the “L/R Key” setting (page
61) are disabled while Manual Focus is selected as the focus mode.
Using Focus Lock
“Focus lock” is a technique you can use when you want
to compose an image in which the subject you want to
focus on is not within the focus frame in the center of the
screen.
• To use focus lock, select “USpot” for the Auto
Focus area (page 57).
1. Align the monitor screen’s focus frame with
the subject you want to focus on and then
half-press the shutter button.
Yellow boundary
Focus frame
Subject to
be focused on
56 Advanced Settings
2. Keeping the shutter button half-pressed
(which maintains the focus setting), move the
camera to compose the image.
3. When you are ready to shoot the image,
press the shutter button the rest of the way
down.
NOTE
• Focus lock also locks exposure (AE).
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Focus Frame
You can use this procedure to select from among five different shapes, including a
heart shape, for the focus frame.
• Note that the focus frame shape cannot be changed while the Make-up setting
(page 40) or Face Detection setting (page 58) is “On”.
NOTE
• Half-pressing the shutter button will cause the focus frame to change one of the
shapes shown below.
• When shooting with face detection, the frame shape is ß.
Changing the Focus Frame Shape (Focus Frame)
Settings ß¹ ™ ¬ μ
Focus successful
Focus not successful
57 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * AF Area
IMPORTANT!
• Auto Focus is disabled when “MF” (Manual Focus) is selected for the focus mode
(page 54), even if you select an AF area.
• Selecting “OTracking” can cause vibration and noise to occur due to lens
operation while tracking a subject. This does not indicate malfunction.
• While Face Detection (page 58) is turned on, regardless of the current AF Area
setting, “USpot” (center) focusing will be used automatically whenever a face
cannot be detected for some reason.
Specifying the Auto Focus Area (AF Area)
Spot This mode takes readings of a small area in the center of the
image. This setting works well with focus lock (page 55).
Multi
When you half-press the shutter button while this setting selected,
the camera will select the optimum Auto Focus area from among
nine possible areas. The focus frame of the area where the
camera focuses will be displayed in green.
Tracking Half-pressing the shutter button focuses on the subject and
causes the focus frame to track the movement of the subject.
U
I
O
“USpot” or “OTracking”
Focus frame Focus frame
“IMulti”
58 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Face Detection
When shooting people, the face detection feature detects the faces of up to ten
individuals and adjusts focus and brightness accordingly.
1. Use [8] and [2] to select “On” and then press [SET].
2. Point the camera at the subject(s).
The camera will detect human faces and display a
frame around each one.
3. Half-press the shutter button.
The camera will focus and the frames around the
faces it focuses on will turn green.
4. Press the shutter button the rest of the way
down.
IMPORTANT!
• The camera performs center focus if it cannot detect a face.
• The only focus mode available while face detection is enabled is Auto Focus (AF).
• Face detection may take a bit longer when you hold the camera sideways.
• Detection of the following types of faces is not supported.
– Face that is obstructed by hair, sunglasses, a hat, etc., or a face in dark shade
– A profile or a face that is at an angle
– A face that is very far away and small, or very close and large
– A face in an area that is very dark
– The face of a pet or some other non-human subject
• Face detection cannot be used in combination with any of the following features.
– Some BEST SHOT scenes
– Movie Recording
• The AF area setting (page 57) is ignored while face detection is enabled.
• Turning on Premium Auto (page 25) or Make-up (page 40) automatically turns on
Face Detection.
Using Face Detection (Face Detection)
Face Detection icon
59 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * CS
While Continuous Shutter is turned on, images are continually recorded until memory
becomes full, as long as you keep the shutter button depressed.
Releasing the shutter button stops shooting.
NOTE
• With continuous shutter, exposure and focus for the first image are applied for
successive images as well.
• Continuous shutter cannot be used in combination with any of the following.
– Premium Auto
– Make-up
– Some BEST SHOT scenes
– Movie Recording
–Self-timer
• When using a continuous shutter mode, keep the camera still until all recording is
finished.
• The continuous shutter rate depends on the current image size and image quality
settings.
• The speed of Continuous Shutter depends on the type of memory card loaded in
the camera and the amount of free space available for storage. When shooting to
built-in memory, continuous shutter shooting is relatively slow.
Using Continuous Shutter (CS)
60 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Anti Shake
You can turn on the camera’s Anti Shake feature to reduce image blur due to subject
movement or camera movement when shooting a moving subject using telephoto,
when shooting a fast-moving subject, or when shooting under dim lighting conditions.
NOTE
• The camera may vibrate and emit a sound during the Anti Shake operation. This
does not indicate malfunction.
• Only image blur due to camera movement is reduced when shooting a movie.
• ISO sensitivity, aperture, and shutter speed do not appear on the monitor screen
when you half-press the shutter button while “On” is selected. These values will
appear briefly, however, in the preview image that is displayed immediately after
you shoot a snapshot.
• Shooting while “On” is selected can cause an image to appear somewhat coarser
than normal and can cause slight deterioration of image resolution.
• Anti Shake may not be able to eliminate the effects of camera or subject movement
when movement is severe.
• Anti Shake may not work properly when the camera is mounted on a tripod. Turn
off Anti Shake.
Reducing the Effects of Camera and Subject Movement
(Anti Shake)
Setting REC Screen
Icon Display Description
On Minimizes the effects of hand and subject
movement.
Off None Turns off Anti Shake settings.
61 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * L/R Key
You can assign one of the four functions listed below to the [4] and [6] keys.
*While Make-up is turned on, you will be able to use the [4] and [6] keys to select
one of the following settings: 10sec Self-timer, 2sec Self-timer, Self-timer Off. Note
that you will not be able to configure the self-timer setting with the [4] and [6] keys
while Continuous Shutter (CS) is turned on.
NOTE
• The “L/R Key” setting cannot be used together with the following features.
– Some BEST SHOT scenes
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Grid
The on-screen grid can be displayed on the REC mode
monitor screen for easy vertical and horizontal alignment
when composing images.
Assigning Functions to the [4] and [6] Keys (L/R Key)
Setting [4]/[6] key operation
EV Shift Adjusts the EV shift value (page 64).
White Balance Changes the white balance setting (page 65).
ISO Changes the ISO Sensitivity setting (page 67).
Self-timer*Sets the self-timer time (page 39).
Off Cancels [4] and [6] key assignments.
Displaying the On-screen Grid (Grid)
62 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Review
While Review is turned on, the camera will display a image for about one second
immediately after you press the shutter button to record it.
• A review image is always displayed when shooting with Continuous Shutter (CS),
regardless of the Review setting.
• When shooting with some functions while “On” is selected for “Review” will cause
the message “Busy... Please wait...” to appear after you press the shutter button.
Shooting another image is disabled while this message is displayed. Wait a while
until the process being performed is complete.
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Icon Help
While Icon Help is turned on, a textual description will appear on the display for
certain icons when you switch between REC functions.
Functions Supported by Icon Help
• REC Mode, Flash, White Balance, Self-timer, EV Shift
Turning on Image Review (Review)
Using Icon Help (Icon Help)
63 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “REC” Tab * Memory
When you turn off the camera, it remembers the current settings of all enabled
memory items and restores them when you turn it back on. Any memory item that is
disabled will be returned to its initial default setting whenever you turn off the camera.
*Optical zoom setting only.
Configuring Power On Default Settings (Memory)
Setting Disabled (Initial Default Setting) Enabled
b BEST SHOT Off
Setting at power
off
Flash Auto
Focus AF (Auto Focus)
White Balance Auto
ISO Auto
AF Area Multi
CS Off
Self-timer Off
MF Position Position before manual focus was
selected.
Zoom Position*Full wide
64 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “Quality” Tab *
T Quality (Snapshot)
• The “Fine” setting helps to bring out details when shooting a finely detailed image
of nature that includes dense tree branches or leaves, or an image of a complex
pattern.
• Memory capacity (the number of images you can record) will be affected by the
quality settings you configure (page 126).
Procedure
[r] (REC) * [SET] * MENU * “Quality” Tab * EV Shift
You can manually adjust an image’s exposure value (EV value) before shooting it.
• Exposure Compensation Range: –2.0 EV to +2.0 EV
• Unit: 1/3 EV
1. Use [8] and [2] to adjust the exposure compensation value.
To cancel exposure compensation, change the EV value to 0.0.
Image Quality Settings (Quality)
Specifying Snapshot Image Quality (T Quality (Snapshot))
Setting REC Screen Icon
Display Description
Fine Gives image quality priority.
Normal Normal
Correcting Image Brightness (EV Shift)
[8] : Increases the EV value. A higher EV
value is best for light-colored subjects
and backlit subjects.
[2] : Decreases the EV value. A lower EV
value is best for dark-color subjects and
for shooting outdoors on a clear day.
65 Advanced Settings
2. Press [SET].
This applies the exposure compensation value. The exposure compensation
value you set remains in effect until you change it or turn off the camera (which
causes it to revert to “0.0”).
NOTE
• When shooting under very dark or very bright conditions, you may not be able to
obtain satisfactory results even after performing exposure compensation.
Procedure
[r] (REC) * [SET] * MENU * “Quality” Tab * White Balance
You can adjust white balance to match the source of light available where you are
shooting and avoid the blue cast that results when shooting outdoors when it is
cloudy, and the green cast that results when shooting under fluorescent lighting.
Controlling White Balance (White Balance)
Setting
REC Screen
Icon Display
Description
Auto None Configures the camera to adjust white balance
automatically.
(Daylight) For shooting outdoors on a clear day
(Overcast) For shooting outdoors on an overcast rainy day, in
the shade, etc.
(Shade) For shooting on a clear day in the shade of trees or
buildings
(DayWhite
Fluorescent)
For shooting under white or day white fluorescent
lighting
(Daylight
Fluorescent) For shooting under daylight fluorescent lighting
(Tungsten) For shooting under light bulb lighting
¤
'
“
†
–
«
66 Advanced Settings
• When “Auto” is selected for the white balance setting, the camera automatically
determines the white point of the subject. Certain subject colors and light source
conditions can cause problems when the camera tries to determine the white point,
which makes proper white balance adjustment impossible. If this happens, select
the white balance setting that matches your shooting conditions (Daylight,
Overcast, etc.).
Manual
For configuring the camera manually to suit a
particular light source
1Select “Manual”.
2Under the lighting conditions
you plan to use when
shooting, point the camera at
a blank white piece of paper
so it fills the entire monitor
screen and then press the
shutter button.
3Press [SET].
The white balance setting is retained even if you
turn off the camera.
Setting
REC Screen
Icon Display
Description
Blank white paper
67 Advanced Settings
Procedure
[r] (REC) * [SET] * MENU * “Quality” Tab * ISO
ISO sensitivity is a measure of sensitivity to light.
• “Auto” ISO sensitivity always is applied for movies, regardless of the current ISO
sensitivity setting.
• Higher ISO sensitivity values tend to result in digital noise in images.
Procedure
[r] (REC) * [SET] * MENU * “Quality” Tab * Color Filter
Settings: Off, B/W, Sepia, Red, Green, Blue, Yellow, Pink, Purple
• You cannot configure a color filter setting while using ART SHOT (page 48) as the
recording mode.
Specifying ISO Sensitivity (ISO)
Setting
REC Screen
Icon Display
Description
Auto None Adjusts sensitivity automatically according to conditions.
ISO 100 Lower
sensitivity
Higher
sensitivity
Slow shutter speed
Fast shutter speed
(Set for shooting in
dimly lit areas.)
Less noise
Some coarseness
(increased digital
noise)
ISO 200
ISO 400
ISO 800
ISO 1600
Using Built-in Color Filters (Color Filter)
68 Viewing Snapshots and Movies
Viewing Snapshots and Movies
See page 29 for the procedure for viewing snapshots.
1. Press [p] (PLAY) and then use [4] and [6] to display the movie you
want to view.
2. Press [0] (Movie) to start
playback.
Movie Playback Controls
NOTE
• Playback may not be possible for movies not recorded with this camera.
• Enables repeat playback of a recorded movie. See page 72 for details.
Viewing Snapshots
Viewing a Movie
Fast forward/
fast reverse
[4] [6]
• Each press of either button increases the speed of the fast
forward or fast reverse operation.
• To return to normal playback speed, press [SET].
Play/pause [SET]
1 frame forward/
back
[4] [6]
• Holding down either button scrolls continuously.
Volume
adjustment
Press [2] and then press [8] [2].
• Volume can be adjusted only while movie playback is in
progress.
Information
display on/off [8] (DISP)
Zoom
Rotate the zoom controller in the direction of z ([).
• You can use [8], [2], [4], and [6] to scroll the zoomed
image on the monitor screen. You can zoom a movie image
up to 4.5 times normal size.
Stop playback [0] (Movie)
Movie icon: »
Recording time
Image quality
Repeat playback
69 Viewing Snapshots and Movies
1. In the PLAY mode, use [4] and [6] to scroll through the images until
the one you want is displayed.
2. Rotate the zoom controller towards z ([) to
zoom.
You can use [8], [2], [4], and [6] to scroll the
zoomed image on the monitor screen. Rotate the
zoom controller towards w to unzoom the image.
– When monitor screen contents are turned on,
a graphic in the lower right corner of the screen
shows what part of the zoomed image is
currently displayed.
– To exit the zoom screen, press [ ] (Delete).
– Though the maximum image zoom factor is 8X,
certain image sizes may not allow zooming up
to the full 8X.
1. In the PLAY mode, rotate the zoom controller
towards w (]).
Use [8], [2], [4] and [6] to move the selection
boundary around the image menu.
To view a particular image, use [8], [2], [4], or [6] to
move the selection boundary to the image you want
and then press [SET].
• A question mark (?) will be displayed for images that
cannot be displayed for some reason.
Zooming an On-screen Image
Displaying the Image Menu
Image area
Current display area
Zoom factor
Boundary
70 Other Playback Functions (PLAY)
Other Playback Functions (PLAY)
This section explains menu items that you can use to configure settings and perform
other playback operations.
Pressing [SET] in the PLAY mode will display the PLAY Panel.
.Example PLAY Panel Operation
1. In the PLAY mode, press [SET].
The PLAY Panel will appear along the
right side of the monitor screen.
2. Use [8] and [2] to select the
PLAY Panel item you want, and
then press [SET].
3. The following describes the operations you can perform for each of the
PLAY Panel items.
Using the PLAY Panel
Exit Exits the PLAY Panel.
Playback
Start
The operation that is performed when this item is selected
depends on the type of file that is currently displayed on the
monitor screen.
• Movie: Starts movie playback (page 68).
• Voice recording: Starts voice recording playback (page 51).
• Audio snapshot: Starts audio playback (page 75).
Slideshow
Displays a slideshow menu. See “Playing a Slideshow on the
Camera (Slideshow)” (page 71) for slideshow menu operations.
Rotation Displays a rotation menu screen. See “Rotating an Image
(Rotation)” (page 72) for details about the rotation operation.
Menu Displays the PLAY menu.
For information about menu operations, see page 52.
[8] [2]
PLAY Panel[SET]
â
P
ä
ÿ
à
71 Other Playback Functions (PLAY)
1. In the PLAY mode, press [SET].
2. Use [8] and [2] to select the “Slideshow” PLAY Panel option and then
press [SET] (page 70).
• To stop the slideshow, press [ ] (Delete). Pressing [SET] instead of
[ ] (Delete) stops the slideshow and returns to the menu screen.
• Adjust audio volume by pressing [2] and then press [8] or [2] during
playback.
• All button operations are disabled while the slideshow is transitioning from one
image to another.
• The time required for transition from one image to another may be longer in the
case of an image that was not recorded with this camera.
Playing a Slideshow on the Camera (Slideshow)
Start Starts the slideshow.
Time Time from the start to the end of the slideshow
1 to 5 minutes, 10 minutes, 15 minutes, 30 minutes, 60 minutes
Interval
Amount of time each image remains displayed
Use [4] and [6] to select a value from 1 to 30 seconds, or “MAX”.
If you specify a value from 1 to 30 seconds, images change at the
specified interval, but the audio portion of movies and audio
snapshots will continue to play until the end.
When the slideshow reaches a movie file while “MAX” is selected,
only the first frame of the movie will displayed. Voice Recording
files are not played back when “MAX” is selected.
Effect
Turns effect on or off.
On: Turns on the image change effect and background music.
Off: No image change effect or background music
72 Other Playback Functions (PLAY)
1. In the PLAY mode, display the snapshot you want to rotate.
2. Press [SET].
3. Use [8] and [2] to select the “Rotation” PLAY Panel option and then
press [SET] (page 70).
4. Use [8] and [2] to select “Rotation” and then press [SET].
Each press of [SET] will rotate the displayed image 90 degrees left.
5. When the displayed image is at the orientation you want, press
[ ] (Delete).
NOTE
• Note that this procedure does not actually change the image data. It simply alters
how the image is displayed on the camera’s monitor screen.
• An image that has been protected or zoomed cannot be rotated.
• The original (unrotated) version of the image will be displayed on the image menu
screen.
Procedure
[p] (PLAY) * Movie Screen * [SET] * MENU *
“PLAY” Tab * Repeat Movie Play
Selecting “On” causes “w” to appear on the monitor screen, which indicates that
repeat movie playback is enabled.
Procedure
[p] (PLAY) * Snapshot Screen * [SET] * MENU *
“PLAY” Tab * Art Effect
You can apply artistic effects to recorded snapshots and save the result as a new
snapshot. The original snapshot is also retained.
For information setting items, see page 48.
Rotating an Image (Rotation)
To perform repeat movie playback (Repeat Movie Play)
Applying Artistic Effects to Snapshots (Art Effect)
73 Other Playback Functions (PLAY)
Procedure
[p] (PLAY) * Snapshot Screen * [SET] * MENU *
“PLAY” Tab * DPOF Printing
See page 79 for details.
Procedure
[p] (PLAY) * [SET] * MENU * “PLAY” Tab * Protect
IMPORTANT!
• Note that even if a file is protected, it will be deleted if you perform the format
operation (page 104).
Selecting Images for Printing (DPOF Printing)
Protecting a File Against Deletion (Protect)
On
Protects specific files.
1Use [4] and [6] to scroll through the files
until the one you want to protect is
displayed.
2Use [8] and [2] to select “On” and then
press [SET].
An image that is protected is indicated by
the › icon.
3To protect other files, repeat steps 1 and 2.
To exit the protect operation, press [ ] (Delete). To unprotect a file,
select “Off” instead of “On” in step 2 above.
All Files:
On
Protects all files.
1Use [8] and [2] to select “All Files: On” and then press [SET].
2Press [ ] (Delete).
To unprotect all files, select “All Files: Off” instead of “All Files: On” in
step 1 above.
74 Other Playback Functions (PLAY)
Procedure
[p] (PLAY) * Snapshot Screen * [SET] * MENU *
“PLAY” Tab * Resize
You can reduce the size of a snapshot and save the result as a separate snapshot.
The original snapshot is also retained. You can select resize an image to one of three
image sizes: 10M, 5M, VGA.
• Resizing a 3:2 or 16:9 size snapshot will create an image with an aspect ratio of
4:3, with both sides cut off.
• The recording date of the resized version of the snapshot will be the same as the
recording date of the original snapshot.
Procedure
[p] (PLAY) * Snapshot Screen * [SET] * MENU *
“PLAY” Tab * Trimming
You can crop a snapshot to trim parts you do not need, and
save the result in a separate file. The original snapshot is
also retained.
Use the zoom controller to zoom the image to the size you
want, use [8], [2], [4], and [6] to display the portion of the
image you want to cut out, and then press [SET].
• The image produced by cropping a 3:2 or 16:9 image will
have an aspect ratio of 4:3.
• The recording date of the cropped image will be the
same as the recording date of the original snapshot.
Resizing a Snapshot (Resize)
Cropping a Snapshot (Trimming)
Represents
snapshot area
Part of snapshot that is
currently displayed
Zoom factor
75 Other Playback Functions (PLAY)
Procedure
[p] (PLAY) * Snapshot Screen * [SET] * MENU *
“PLAY” Tab * Dubbing
2. Press [SET] again to stop audio recording.
• Take care that you do not block the camera’s microphone
with your fingers while recording.
• Good recording results are not possible when the camera is
too far away from what you are trying to record.
• Your camera supports the following audio data formats.
– Audio Format: WAVE/IMA-ADPCM (WAV extension)
• You cannot add audio to an image that is protected.
• To delete audio, perform the following operation:
Dubbing * Delete * [SET] * [ ] (Delete).
IMPORTANT!
• Note that you cannot restore the original audio of an Audio Snapshot after you
delete or re-record it.
.To play snapshot audio
1. In the PLAY mode, use [4] and [6] to scroll through the images until
the Audio Snapshot you want is displayed.
An audio snapshot is one that has a ˆ icon.
2. Press [0] (Movie) to start playback.
Adding Audio to a Snapshot (Dubbing)
You can add audio to a snapshot after you shoot it.
You can re-record a snapshot’s audio whenever you
want. You can record up to about 30 seconds of audio
for a single snapshot.
1. Press [SET] to start audio recording.
Remaining recording time
Microphone
76 Other Playback Functions (PLAY)
Voice Recording Playback Controls
• Audio of an Audio Snapshot also can be played back on a computer with Windows
Media Player or QuickTime.
Procedure
[p] (PLAY) * [SET] * MENU * “PLAY” Tab * Copy
Files can be copied from the camera’s built-in memory to a memory card or from a
memory card to built-in memory.
NOTE
• You can copy snapshots, movies, audio snapshots, or Voice Recording files you
recorded with this camera.
Fast forward/fast reverse [4] [6]
Play/pause [SET]
Volume adjustment Press [2] and then
press [8] [2].
Display content switching [8] (DISP)
Stop playback [0] (Movie)
Copying Files (Copy)
Built-in * Card
Copies all files from built-in camera memory to a memory card.
This option copies all the files in built-in camera memory.
It cannot be used to copy a single file.
Card * Built-in
Copies a single file on the memory card to camera built-in
camera memory. Files are copied to the folder in built-in
memory whose name has the largest serial number.
1Use [4] and [6] to select the file you want to copy.
2Use [8] and [2] to select “Copy” and then press [SET].
77 Dynamic Photo
Dynamic Photo
This camera comes with a number of subjects in built-in
memory (“built-in subjects”), which you can insert into
snapshots to create Dynamic Photo images.
• The term “built-in subjects” refers to the moving figures
and characters that came pre-programmed in the
camera’s built-in memory.
Use the following procedure to insert a built-in subject image into a snapshot.
Procedure
[p] (PLAY) * [SET] * MENU * “PLAY” Tab * Dynamic Photo
1. Use [4] and [6] to select the background image you want and then
press [SET].
• Only an image that satisfies the following conditions can be used as a
background image.
– A snapshot recorded with this camera
– A snapshot with an aspect ratio of 4:3
2. Use [4] and [6] to select the built-in subject that you want to insert
into the image and then press [SET].
3. Use the zoom controller to adjust the size of the subject and use [8],
[2], [4], and [6] to adjust its position.
Inserting a Built-in Subject into a Snapshot or Movie
(Dynamic Photo)
™
Built-in Subject Another Image Dynamic Photo Image
78 Dynamic Photo
4. When everything is the way you want, press [SET].
This merges the subject with the background image and creates a Dynamic
Photo image.
• Inserting an animated subject into a snapshot will cause the resulting Dynamic
Photo image to be saved as a movie file. Inserting a stationary (non-moving)
character will cause the resulting image to be saved as a snapshot. In both
cases, the snapshot used as the background is also retained as-is.
• The final movie format is Motion JPEG standard.
• The final movie image size is 640x480 pixels.
NOTE
• Performing a delete or format operation will not delete the built-in subjects.
1. Press [p] (PLAY) and then use [4] and [6] to display the Dynamic
Photo you want to view.
• If the image has a moving character pasted in it, press [0] (Movie) to playback
the movement. See page 68 for information about operations that are
supported while playback is in progress.
To view a Dynamic Photo (Dynamic Photo File)
79 Printing
Printing
*You can specify which images you want to print, the number of copies, and date
stamp settings before printing (page 79).
.Digital Print Order Format (DPOF)
DPOF is a standard that allows you to include image type, number of copy,
and time stamp on/off information on the memory card with the images.
After configuring settings, you can use the memory card to print on a home
printer that supports DPOF or take the memory card to a professional print
service.
• Whether or not you will be able to use DPOF settings for printing depends on the
printer you are using.
• Some professional print services may not support DPOF.
Printing Snapshots
Professional Print Service*
You can take a memory card that contains the images you want
to print to a professional print service and have them printed.
Printing on a Home Printer*
You can use a printer equipped with a memory card slot to print
images directly from a memory card. For details, see the user
documentation that comes with your printer.
Printing with a Computer
After transferring the images to your computer, use
commercially available software to print.
Using DPOF to Specify Images to be Printed and the Number
of Copies
80 Printing
.Configuring DPOF Settings Individually for Each Image
Procedure
[p] (PLAY) * Snapshot Screen * [SET] * MENU *
“PLAY” Tab * DPOF Printing * Select images
1. Use [4] and [6] to scroll through the files until the image you want to
print is displayed.
2. Use [8] and [2] to specify the number of copies.
You can specify a value up to 99. Specify 00 if you do not want to print the image.
• If you want to include the date in the images, press [0] (Movie) so “On” is
shown for date stamping.
• Repeat steps 1 and 2 to configure settings for other images, if you want.
3. Press [SET].
.Configuring the Same DPOF Settings for All the Images
Procedure
[p] (PLAY) * Snapshot Screen * [SET] * MENU *
“PLAY” Tab * DPOF Printing * All images
1. Use [8] and [2] to specify the number of copies.
You can specify a value up to 99. Specify 00 if you do not want to print the image.
• If you want to include the date in the images, press [0] (Movie) so “On” is
shown for date stamping.
2. Press [SET].
DPOF settings are not cleared automatically after printing is complete.
The next DPOF print operation you execute will be performed using the last DPOF
settings you configured for the images. To clear DPOF settings, specify “00” for the
number of copies of all images.
Tell your print service about your DPOF settings!
If you take a memory card to a professional print service, be sure to tell them that it
includes DPOF settings for the images to be printed and the number of copies. If you
don’t, the print service may print all the images without regard to your DPOF settings,
or they may ignore your date stamp setting.
81 Printing
.Date Stamping
You can use one of the following three methods to include the recording date in the
printout of an image.
.Standards Supported by the Camera
•Exif Print
Printing on a printer that supports Exif Print uses information
about shooting conditions recorded with the image to enhance
printed image quality. Contact your printer manufacturer for
information about models that support Exif Print, printer upgrades, etc.
Configuring camera settings
Configure DPOF settings (page 79).
You can turn date stamping on and off each time you print. You can configure
settings so some images include the date stamp and some don’t.
Configure the Camera’s Time Stamp setting (page 100).
• The camera’s Time Stamp setting imprints the date into a snapshot when you
shoot it, so the date is always included when you print. It cannot be deleted.
• Do not turn on DPOF date stamping for an image that includes a date
stamped with the camera’s Time Stamp function. Doing so can cause the two
stamps to be overprinted.
Configuring computer settings
You can use commercially available image management software to date
stamp images.
Professional print service
Request date stamping when ordering prints from a professional print service.
82 Using the Camera with a Computer
Using the Camera with a Computer
You can perform the operations described below while the camera is connected to a
computer.
The procedures you need to perform are different for Windows and the Macintosh.
Things you can do using a computer...
Save images to a
computer and
view them there
• Save images and view them manually
(USB connection) (pages 83, 87).
• Transfer images to a computer
automatically over a wireless LAN for
viewing (Eye-Fi) (page 90).
Play back and
edit movies
• You can play back movies (pages 86, 89).
• To edit movies, use commercially
available software as required.
• Windows users should refer to “Using the Camera with a Windows Computer”
on page 83.
• Macintosh users should refer to “Using the Camera with a Macintosh” on page
87.
83 Using the Camera with a Computer
You can connect the camera to your computer in order to view and store images
(snapshot and movie files).
IMPORTANT!
• Never unplug the USB cable, or operate the camera while viewing or storing
images. Doing so can cause data to become corrupted.
NOTE
• You also can use your computer’s card slot (if it has one) or a commercially
available card reader to access image files directly from the camera’s memory
card. For details, see the user documentation that comes with your computer.
Using the Camera with a Windows Computer
When you want to do
this:
Operating
System Version Required Software See
page:
Save images to a
computer and view them
there manually
Windows 8,
Windows 7,
Windows Vista,
Windows XP (SP3)
Installation not required. 83
Play movies
Windows 8,
Windows 7,
Windows Vista,
Windows XP (SP3)
Windows Media Player 12
(installed on computer) 86
Viewing and Storing Images on a Computer
Never use your computer to modify, delete, move, or rename any image files
that are in the camera’s built-in memory or on its memory card.
Doing so can cause problems with the camera’s image management data, which
will make it impossible to play back images on the camera and can drastically alter
remaining memory capacity. Whenever you want to modify, delete, move, or
rename an image, do so only on images that are stored on your computer.
84 Using the Camera with a Computer
.To connect the camera to your computer and save files
1. Turn off the camera and
then use the micro USB
cable that comes with the
camera to connect it to
your computer.
• For details about connecting
to the camera and
precautions when
connecting, see page 16.
2. Press [ON/OFF] (Power) to turn on the camera.
When you turn on the camera, check to make sure that the color of its back lamp
changes from red to green or amber (page 17).
• The first time you connect the camera to your computer with the USB cable, an
error message may appear on your computer. If this happens, disconnect and
then reconnect the USB cable.
• Charging continues even if the camera is turned on.
3. Windows 8 users: Click “Desktop” and then “Explorer”.
Windows 7, Windows Vista users: Click “Start” and then “Computer”.
Windows XP users: Click “Start” and then “My Computer”.
4. Double-click “Removable Disk”.
• Your computer recognizes the memory card loaded in the camera (or built-in
memory if there is no card) as a removable disk.
5. Right-click the “DCIM” folder.
6. On the shortcut menu that appears, click “Copy”.
7. Windows 8 users: Click “Documents”.
Windows 7, Windows Vista users: Click “Start” and then “Documents”.
Windows XP users: Click “Start” and then “My Documents”.
• If you already have a “DCIM” folder in “Documents” (Windows 8, Windows 7,
Windows Vista) or “My Documents” (Windows XP), the next step will overwrite
it. If you want to keep the existing “DCIM” folder, you need to change its name
or move it to a different location before performing the next step.
Micro USB cable
(included with camera)
USB port
B
85 Using the Camera with a Computer
8. Windows 8 users: On the “Documents” menus, click “Home” and then
“Paste”.
Windows 7 users: On the “Documents” “Organize” menu, select
“Paste”.
Windows Vista users: On the “Documents” “Edit” menu, select
“Paste”.
Windows XP users: On the “My Documents” “Edit” menu, select
“Paste”.
This will paste the “DCIM” folder (and all the image files it contains) into your
“Documents” (Windows 8, Windows 7, Windows Vista) or “My Documents”
(Windows XP) folder. You now have a copy of the files that are in camera
memory on your computer.
9. After you finish copying images, disconnect the camera from the
computer.
On the camera, press [ON/OFF] (Power) to turn off the camera. After checking to
make sure that the back lamp is unlit or lit red, disconnect the USB cable.
.To view images you copied to your computer
1. Double-click the copied “DCIM” folder to open it.
2. Double-click the folder that contains the images you want to view.
3. Double-click the image file you want to view.
• For information about file names, see “Memory Folder Structure” on page 94.
• An image that was rotated on the camera will be displayed on your computer
screen in its original (unrotated) orientation.
86 Using the Camera with a Computer
Windows Media Player, which is already installed on most computers, can be used
for movie playback. To play back a movie, first copy the movie to your computer and
then double-click the movie file.
.Minimum Computer System Requirements for Movie Playback
The minimum system requirements described below are necessary to play back
movies recorded with this camera on a computer.
• The above are recommended system environments. Configuring one of these
environments does not guarantee proper operation.
• Certain settings and other installed software may interfere with proper playback of
movies.
.Movie Playback Precautions
• Be sure to move the movie data to the hard disk of your computer before trying to
play it. Proper movie playback may not be possible for data accessed over a
network, from a memory card, etc.
• Proper movie playback may not be possible on some computers. If you experience
problems, try the following.
– Try recording movies with a quality setting of “STD”.
– Try upgrading Windows Media Player to the latest version.
– Quit any other applications you have running, and stop resident applications.
Playing Movies
Operating System : Windows 8, Windows 7, Windows Vista, Windows XP (SP3)
CPU : Image Quality “HD”:
Pentium 4 3.2 GHz or higher
Image Quality “STD”:
Pentium M 1.0 GHz or higher
Pentium 4 2.0 GHz or higher
Required Software: Windows Media Player, DirectX 9.0c or higher
87 Using the Camera with a Computer
IMPORTANT!
• Never unplug the USB cable, or operate the camera while viewing or storing
images. Doing so can cause data to become corrupted.
• The camera does not support operation with Mac OS X 10.0. Operation is
supported with Mac OS 10.1, 10.2, 10.3, 10.4, 10.5, 10.6, 10.7, and 10.8 (using the
OS standard USB driver) only.
NOTE
• You also can use your computer’s card slot (if it has one) or a commercially
available card reader to access image files directly from the camera’s memory
card. For details, see the user documentation that comes with your computer.
Using the Camera with a Macintosh
When you want to do
this:
Operating
System
Version
Required Software
See
page:
Save images to your
Macintosh and view
them there manually
OS X Installation not required. 87
Save images to your
Macintosh
automatically/Manage
images
OS X iPhoto, which comes bundled with
some Macintosh products. –
Play movies OS X With QuickTime, which comes
bundled with your operating system. 89
Connecting the Camera to Your Computer and Saving Files
Never use your computer to modify, delete, move, or rename any image files
that are in the camera’s built-in memory or on its memory card.
Doing so can cause problems with the camera’s image management data, which
will make it impossible to play back images on the camera and can drastically alter
remaining memory capacity. Whenever you want to modify, delete, move, or
rename an image, do so only on images that are stored on your computer.
88 Using the Camera with a Computer
.To connect the camera to your computer and save files
1. Turn off the camera and
then use the micro USB
cable that comes with the
camera to connect it to
your Macintosh.
• For details about connecting
to the camera and
precautions when
connecting, see page 16.
2. Press [ON/OFF] (Power) to turn on the camera.
When you turn on the camera, check to make sure that the color of its back lamp
changes from red to green or amber (page 17). In this mode, your Macintosh
recognizes the memory card loaded in the camera (or the camera’s built-in
memory if it does not have a memory card loaded) as a drive. The appearance of
the drive icon depends on the Mac OS version you are using.
• The first time you connect the camera to your Macintosh with the USB cable,
an error message may appear on your computer. If this happens, disconnect
and then reconnect the USB cable.
• Charging continues even if the camera is turned on.
3. Double-click the camera’s drive icon.
4. Drag the “DCIM” folder to the folder to which you want to copy it.
5. After the copy operation is complete, drag the drive icon to Trash.
6. On the camera, press [ON/OFF] (Power) to turn off the camera. After
checking to make sure that the back lamp is unlit or lit red, disconnect
the USB cable.
Micro USB cable
(included with camera)
USB port
B
89 Using the Camera with a Computer
.To view copied images
1. Double-click the camera’s drive icon.
2. Double-click the “DCIM” folder to open it.
3. Double-click the folder that contains the images you want to view.
4. Double-click the image file you want to view.
• For information about file names, see “Memory Folder Structure” on page 94.
• An image that was rotated on the camera will be displayed on your Macintosh
screen in its original (unrotated) orientation.
You can use QuickTime, which comes bundled with your operating system, to play
back movies on a Macintosh. To play back a movie, first copy it to your Macintosh
and then double-click the movie file.
.Minimum Computer System Requirements for Movie Playback
The minimum system requirements described below are necessary to play back
movies recorded with this camera on a computer.
• The above are recommended system environments. Configuring one of these
environments does not guarantee proper operation.
• Certain settings and other installed software may interfere with proper playback of
movies.
.Movie Playback Precautions
Proper movie playback may not be possible on some Macintosh models. If you
experience problems, try the following.
– Change the movie image quality setting to “STD”.
– Upgrade to the latest version of QuickTime.
– Shut down other applications that are running.
IMPORTANT!
• Be sure to move the movie data to the hard disk of your Macintosh before trying to
play it. Proper movie playback may not be possible for data accessed over a
network, from a memory card, etc.
Playing a Movie
Operating System : Mac OS X 10.3.9 or higher
Required Software: QuickTime 7 or higher
90 Using the Camera with a Computer
Shooting with an Eye-Fi wireless SD memory card loaded in the camera makes it
possible to transfer image data automatically to a computer via wireless LAN.
1. Configure LAN access point, transfer destination and other settings for
the Eye-Fi card in accordance with the instructions that come with the
Eye-Fi card.
2. After configuring settings, load the Eye-Fi card into the camera and
record.
Images you record are sent by wireless LAN to your computer, etc.
• For full details, see the user documentation that comes with the Eye-Fi card.
• Before formatting a new Eye-Fi card to use it for the first time, copy the Eye-Fi
install files to your computer. Do this before formatting the card.
IMPORTANT!
• Recorded images are transferred over wireless LAN. Do not use the Eye-Fi card or
turn off Eye-Fi card communication (page 97) when on an aircraft or in any other
location where use of wireless communication is limited or prohibited.
• Loading an Eye-Fi card will cause the Eye-Fi indicator to
appear on the monitor screen. Its transparent or not transparent
appearance indicates the communication status as shown below.
• A communication icon will appear on the monitor screen while image data
transfer is in progress.
• The camera’s Auto Power Off (page 102) function is disabled while image data
transfer is in progress.
• A confirmation message will appear on the monitor screen if you try to turn off the
camera while image data transfer is in progress. Follow the instructions in the
messages (page 124).
• Transfer of a large number of images can take some time to complete.
• Depending on the type of Eye-Fi card you are using and its settings, images on the
Eye-Fi card may be deleted following image data transfer.
• When recording a movie to an Eye-Fi card, it can take too much time to record
data, which can result in breaks in the image and/or audio.
Using an SD Memory Card with Built-in LAN
Transferring Images with an Eye-Fi Card (Eye-Fi)
Transparent Access point cannot be found or no
transferable image data exists.
Not transparent Image transfer in progress
Flashing Searching for access points
91 Using the Camera with a Computer
• Proper Eye-Fi card data communication may not be possible due to camera
settings, battery level, or operating conditions.
Loading a commercially available FlashAir card in the camera makes it possible to
view images on and copy them to a smartphone or computer over a wireless LAN
connection.
• For more information, see the instructions that come with the card.
1. Use a computer or other device to configure the settings of the
FlashAir card.
• To protect your personal information, it is recommended that you change the
password of a FlashAir card after you purchase it. For more information, see
the instructions that come with the card.
• If the FlashAir card’s “Start automatically at boot” setting is selected, a wireless
LAN connection will be established automatically whenever the camera is
turned on.
• If you want to turn “FlashAir” (page 97) on and off manually on the camera,
change the FlashAir card’s setting to “Start with the control image”.
2. Load the configured FlashAir card into the camera and shoot the
images you want.
• Formatting a FlashAir card with the camera will delete files on the card that are
required for communication. For details about formatting, see the instructions
that come with the card.
3. Access the FlashAir card from a smartphone or other device.
Using a Smartphone to Play Back Images Stored on a FlashAir
Card (FlashAir)
92 Using the Camera with a Computer
IMPORTANT!
• When on an aircraft or in any other location where use of wireless communication
is limited or prohibited, do not use a FlashAir card, or change the camera’s
“FlashAir” setting (page 97) and the FlashAir card’s setting to those shown below.
FlashAir: Off
Memory Card: Start with the control image
• Loading a FlashAir card into the camera will cause the FlashAir icon to appear
on the monitor screen.
• The following applies to camera operations while image data on a FlashAir card is
being manipulated from a smartphone or other device.
– icon displayed on the monitor screen.
– The Sleep function (page 101) and Auto Power Off function (page 102) are
disabled.
– A confirmation message appears on the monitor screen if you try to turn it off. If
this happens, follow the instructions in the message (page 124).
• The FlashAir wireless LAN connection is automatically terminated if no operation is
performed for a certain amount of time.
• Recording or playing back a movie to a FlashAir card can result in breaks in the
image and/or audio.
• Proper FlashAir card communication may not be possible due to camera settings,
battery level, or operating conditions.
• Changing the configuration of camera settings and performing other operations
may take longer than normal when a FlashAir card is running.
Transparent No wireless LAN connection
Not transparent Communication enabled
Flashing Running (Communication disabled)
93 Using the Camera with a Computer
The camera creates a file and saves it each time you shoot a snapshot, record a
movie, or perform any other operation that stores data. Files are grouped by storing
them in folders. Each file and folder has its own unique name.
• For details about how folders are organized in memory, see “Memory Folder
Structure” (page 94).
• You can view folder and file names on your computer. For details about how file
names are displayed on the camera’s monitor screen, see page 10.
• The total number of folders and files allowed depends on the image size and
quality, and capacity of the memory card being used for storage.
Files and Folders
Name and Maximum Number Allowed Example
File
Each folder can contain up to 9999 files named
CIMG0001 through CIMG9999. The extension
on the file name depends on the file type.
26th file name:
Folders
Folders are named from 100CASIO to
999CASIO.
There can be up to 900 folders in memory.
• The BEST SHOT (page 46) includes a sample
scene that optimizes settings for auction site
images. Depending on your camera model,
the sample scene is named either “For eBay”
or “Auction”.
– Images recorded with the eBay scene are
stored in a folder named “100_EBAY”.
– Images recorded with the Auction scene are
stored in a folder named “100_AUCT”.
• BEST SHOT also has a scene named “For
YouTube” that optimizes movie settings for
recording movies for upload to YouTube.
Images recorded with the YouTube scene are
stored in a folder named “100YOUTB”.
100th folder name:
Extension
Serial number (4 digits)
100CASIO
Serial number (3 digits)
94 Using the Camera with a Computer
The camera stores images you shoot in accordance with the Design Rule for Camera
File System (DCF).
.About DCF
The following operations are supported for DCF-compliant images. Note, however,
that CASIO makes no performance guarantees concerning these operations.
• Transferring this camera’s DCF-compliant images to another manufacturer’s
camera and view them.
• Printing this camera’s DCF-compliant images on another manufacturer’s printer.
• Transferring another camera’s DCF-compliant images to this camera and view
them.
.Memory Folder Structure
DCIM Folder
Recording Folder
Image File
Movie File
Audio File
Audio Snapshot Image File
Audio Snapshot Audio File
Recording Folder
Recording Folder
DPOF File Folder
DPOF File
*Other folders are created when the following BEST SHOT scenes are used for
recording: “For eBay” or “Auction” (scene name depends on camera model), or
“For YouTube”. The following shows the name of the folder created for each scene.
• eBay scene: 100_EBAY
• Auction scene: 100_AUCT
• YouTube scene: 100YOUTB
Memory Card Data
DCIM
100CASIO *
CIMG0002.AVI
CIMG0003.WAV
CIMG0004.WAV
101CASIO *
102CASIO *
MISC
AUTPRINT.MRK
95 Using the Camera with a Computer
.Supported Image Files
• Image files shot with this camera
• DCF-compliant image files
This camera may not be able to display an image, even if it is DCF-compliant. When
displaying an image recorded on another camera, it may take a long time for the
image to appear on this camera’s monitor screen.
.Built-in Memory and Memory Card Data Handling Precautions
• Whenever copying memory contents to your computer, you should copy the DCIM
folder and all of its contents. A good way to keep track of multiple DCIM copies of
the DCIM folders is to change its name to a date or something similar after you
copy it to your computer. If you later decided to return the folder to the camera,
however, be sure to change its name back to DCIM. The camera is designed to
recognize only a root file with the name DCIM. Note the camera also will not be
able to recognize the folders inside the DCIM folder unless they have the names
they originally had when you copied them from the camera to your computer.
• Folders and files must be stored in accordance with the “Memory Folder Structure”
shown on page 94 in order for the camera to be able to recognize them correctly.
96 Other Settings (Set Up)
Other Settings (Set Up)
This section explains menu items that you can use to configure settings and perform
other operations in both the REC mode and PLAY mode.
Procedure
[SET] * MENU * “Set Up” Tab * Silent
The Silent mode automatically configures camera settings to avoid disturbing others
around you. It disables flash operation and mutes camera operation tones, audio
during movie and audio snapshot playback, and voice recorder playback. This comes
in handy when shooting or playing back in a museum or other areas where care is
required when operating the camera.
Selecting “On” causes “m” to appear on the monitor screen, which indicates that the
Silent mode is enabled.
• The settings shown below are fixed and cannot be changed while in the Silent
mode.
• See the following for details.
– Flash (page 37)
– Self-timer (page 39)
– Sounds (page 97)
See the following for more information.
– REC Menu (page 52)
– PLAY Menu (page 70)
Shooting and Playing back Images without Disturbing Others
(Silent)
Setting Description
Flash Off
Self-timer Off
Sounds Off
97 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * Eye-Fi
Select “Off” to disable Eye-Fi card communication (page 90).
Procedure
[SET] * MENU * “Set Up” Tab * FlashAir
Selecting “Start with the control image” for the FlashAir card setting and selecting
“On” for the camera’s “FlashAir” setting will establish a FlashAir wireless LAN
connection (page 91).
• If the FlashAir card’s “Start automatically at boot” setting is selected, a wireless
LAN connection will be established automatically whenever the camera is turned
on.
Procedure
[SET] * MENU * “Set Up” Tab * Sounds
• Setting a volume level of 0 mutes output.
Turning off Eye-Fi Card Communication (Eye-Fi)
Configuring FlashAir Card Communication Settings (FlashAir)
Configuring Camera Sound Settings (Sounds)
Startup
Specifies the startup sound.
Sound 1 - 5: Built-in sounds (1 through 5)
Off: Sound off
Half Shutter
Shutter
Operation
Operation Specifies the sound volume.
Play Specifies the volume of movie and Audio Snapshot audio
output.
=
=
98 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * Startup
Display the image you want to use as your startup image and then select “On”.
• The startup image does not appear when you turn on the camera by pressing
[p] (PLAY).
• You can specify a snapshot you recorded as the startup image, or you can use the
special startup image provided in the camera’s built-in memory.
• If you select an audio snapshot as the startup image, the audio will not play at
startup.
• Formatting built-in memory (page 104) will delete the current startup image setting.
Procedure
[SET] * MENU * “Set Up” Tab * File No.
Use the following procedure to specify the rule that governs generation of the serial
number used in file names (page 93).
Configuring a Startup Image (Startup)
Specifying the File Name Serial Number Generation Rule
(File No.)
Continue
Tells the camera to remember the last used file number. A new file will
be named using the next sequential number, even if files are deleted or
if a blank memory card is loaded. If a memory card is loaded and that
card already has files stored on it and the largest sequential number in
the existing file names is greater than the largest sequential number
remembered by the camera, numbering of new files will start from the
largest sequential number in the existing file names plus 1.
Reset
Restarts the serial number from 0001 whenever all files are deleted or
when the memory card is replaced with a blank one. If a memory card
is loaded and that card already has files stored on it, numbering of new
files will start from the largest sequential number in the existing file
names number plus 1.
99 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * World Time
You can use the World Time screen to view the current time in a zone that is different
from your Home City when you go on a trip, etc. World Time displays the current time
in 162 cities in 32 time zones around the globe.
1. Use [8] and [2] to select “Destination” and then press [6].
• To change the geographic area and city for the time where you normally use
the camera, select “Home”.
2. Use [8] and [2] to select “City” and then press [6].
• To change the “Destination” setting to summer time, use [8] and [2] to select
“DST” and then select “On”. Summer time is used in some geographical areas
to advance the current time setting by one hour during the summer months.
3. Use [8], [2], [4], and [6] to select the geographic area you want and
then press [SET].
4. Use [8] and [2] to select the city you want and then press [SET].
5. Press [SET].
IMPORTANT!
• Before configuring World Time settings, make sure that the Home City setting is
the place where you live or normally use the camera. If it isn’t, select “Home” on the
screen in step 1 and configure the Home City, date, and time settings as required
(page 100).
Configuring World Time Settings (World Time)
100 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * Timestamp
You can configure the camera to stamp the recording date only, or date and time in
the lower right corner of each snapshot.
• Once date and time information is stamped into a snapshot, it cannot be edited or
deleted.
Example: July, 10, 2015, 1:25 p.m.
• Even if you do not stamp the date and/or time with Timestamp, you can do so later
using the DPOF function or some printing application (page 81).
• Digital zoom is disabled while time stamping is turned on.
• Time stamping is disabled when certain BEST SHOT scenes are being used.
Procedure
[SET] * MENU * “Set Up” Tab * Adjust
When the date and time settings are what you want, press [SET] to apply them.
• You can specify a date from 2001 to 2049.
• Be sure to select your Home City (page 99) before setting the time and date. If you
set the time and date while the wrong city is selected for your Home City, the times
and dates of all of the World Time cities (page 99) will be wrong.
Time Stamping Snapshots (Timestamp)
Date 2015/7/10
Date & Time 2015/7/10 1:25pm
Off No stamping of date and/or time
Setting the Camera’s Clock (Adjust)
[8] [2]Change the setting at the cursor location
[4] [6]Move the cursor between settings
[0] (Movie) Toggles between 12-hour and 24-hour format
101 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * Date Style
You can select from among three different styles for the date.
Example: July, 10, 2015
Procedure
[SET] * MENU * “Set Up” Tab * Language
.Specify the display language you want.
1Select the tab on the right.
2Select “Language”.
3Select the language you want.
• Camera models sold in certain geographic areas
may not support display language selection.
Procedure
[SET] * MENU * “Set Up” Tab * Sleep
This feature turns off the monitor screen and lights the back lamp (green) whenever
no camera operation is performed for a preset period of time. Press any button to turn
the monitor screen back on.
Trigger Time Settings: 30 sec, 1 min, 2 min, Off (Sleep is disabled while “Off” is
selected.)
• Sleep is disabled under any of the following conditions.
– In the PLAY mode
– While the camera is connected to a computer or other device
– During “OTracking”
– During Voice Recording playback or recording
– During movie recording and playback
• When both sleep and Auto Power Off are turned on, Auto Power Off takes priority.
Specifying the Date Style (Date Style)
YY/MM/DD 15/7/10
DD/MM/YY 10/7/15
MM/DD/YY 7/10/15
Specifying the Display Language (Language)
Configuring Sleep State Settings (Sleep)
1
23
102 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * Auto Power Off
Auto Power Off turns off the camera whenever no camera operation is performed for
a preset amount of time.
Trigger Time Settings: 1 min, 2 min, 5 min (The trigger time is always 5 minutes in the
PLAY mode.)
• Auto Power Off is disabled under any of the following conditions.
– While the camera is connected to a computer or other device
– During a slideshow
– During “OTracking”
– During Voice Recording playback or recording
– During movie recording and playback
Procedure
[SET] * MENU * “Set Up” Tab * REC
• With “Power On/Off”, the camera turns off when you press [r] (REC) in the REC
mode.
• When “Power On” or “Power On/Off” is enabled, you can turn on the camera by
holding down [r] (REC) until the back lamp lights green momentarily.
Configuring Auto Power Settings (Auto Power Off)
Configuring [r] Setting (REC)
Power On Camera turns on whenever [r] (REC) is pressed.
Power On/Off Camera turns on or off whenever [r] (REC) is pressed.
Disable Camera does not turn on or off whenever [r] (REC) is
pressed.
103 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * PLAY
• With “Power On/Off”, the camera turns off when you press [p] (PLAY) in the
PLAY mode.
• When “Power On” or “Power On/Off” is enabled, you can turn on the camera by
holding down [p] (PLAY) until the back lamp lights green momentarily.
Procedure
[SET] * MENU * “Set Up” Tab * Ü Disabled
The camera will not start the image delete operation when you press [ ] (Delete)
while “ÜDisabled” is turned on.
You can protect against accidental deletion of images by selecting “On” for
“ÜDisabled”.
• Performing a format operation (page 104) will cause all images to be deleted, even
if file deletion is disabled (“On” selected for “ÜDisabled”) for some images.
Configuring [p] Setting (PLAY)
Power On Camera turns on whenever [p] (PLAY) is pressed.
Power On/Off Camera turns on or off whenever [p] (PLAY) is pressed.
Disable Camera does not turn on or off whenever [p] (PLAY) is
pressed.
Disabling File Deletion (Ü Disabled)
104 Other Settings (Set Up)
Procedure
[SET] * MENU * “Set Up” Tab * Format
If a memory card is loaded in the camera, this operation will format the memory card.
It will format built-in memory if no memory card is loaded.
• The format operation will delete all contents on the memory card or in built-in
memory. It cannot be undone. Make sure you do not need any data currently on
the card or in built-in memory before you format it.
• Formatting built-in memory will delete the following data.
– Protected images
– Startup screen
• Formatting a memory card will delete the following data.
– Protected images
• Formatting will cause all images to be deleted, even if file deletion is disabled (“On”
selected for “ÜDisabled” (page 103)) for some images.
• Make sure the camera’s battery is sufficiently charged before starting a formatting
operation. Formatting may not be performed correctly and the camera may stop
operating normally if the camera powers down while formatting is in progress.
• Never open the battery cover while formatting is in progress. Doing so can cause
the camera to stop operating normally.
Procedure
[SET] * MENU * “Set Up” Tab * Reset
See page 117 for details about the camera’s factory default settings.
The settings below are not reset.
World Time settings, clock settings, date style, screen language
Formatting Built-in Memory or a Memory Card (Format)
Resetting the Camera to Factory Defaults (Reset)
105 Appendix
Appendix
*DANGER
This symbol indicates information that, if ignored or applied incorrectly, creates the
danger of death or serious personal injury.
*WARNING
This indication stipulates matters that have the risk of causing death or serious injury
if the product is operated incorrectly while ignoring this indication.
*CAUTION
This indication stipulates matters that have the risk of causing injury as well as
matters for which there is the likelihood of occurrence of physical damage only if the
product is operated incorrectly while ignoring this indication.
Symbol Examples
Safety Precautions
!This circle with a line through it (-) means that the indicated action must not
be performed. Indications within or nearby this symbol are specifically
prohibited. (The example at left indicates that disassembly is prohibited.)
$
The black dot (0) means that the indicated action must be performed.
Indications within this symbol are actions that are specifically instructed to be
performed. (The example at left indicates that the power plug must be
unplugged from the electrical socket.)
*DANGER
.Rechargeable Battery
• To charge the battery, use only the method specifically described in this
manual. Attempting to charge the battery by an unauthorized means
creates the risk of battery overheating, fire, and explosion.
• Do not expose or immerse the battery in fresh water or salt water. Doing
so can damage the battery, and cause deterioration of its performance
and loss of service life.
• The battery is intended for use with a CASIO Digital Camera only. Use
with any other device creates the risk of the battery damage, or
deterioration of battery performance and service life.
+
%
+
106 Appendix
• Failure to observe any of the following precautions creates the risk of battery
overheating, fire, and explosion.
– Never use or leave the battery near open flame.
– Do not expose the battery to heat or fire.
– Make sure the battery is oriented correctly when charging it.
– Never carry or store the battery together with items that can conduct electricity
(necklaces, pencil lead, etc.).
– Never disassemble the battery, pierce it with a needle, or expose it to strong
impact (hit it with a hammer, step on it, etc.), and never apply solder to it.
Never place the battery into a microwave oven, dehumidifier, high-pressure
generating device, etc.
– Never remove the outer sticker from the battery.
• Should you ever notice leakage, strange odor, heat generation,
discoloration, deformation, or any other abnormal condition while using,
charging, or storing a battery, immediately remove it from the camera
and keep it away from open flame. Also, do not use the affected battery after the
abnormal symptoms disappear.
• Do not use or leave the battery under direct sunlight, in an automobile
parked in the sun, or in any other area subject to high temperatures.
Doing so can damage the battery, and cause deterioration of its
performance and loss of service life. Also, these conditions can cause the
battery to swell to the point that you may not be able to remove it.
• Battery fluid can damage your eyes. Should battery fluid get into your
eyes accidentally, immediately rinse them with clean tap water and then
consult a physician.
*DANGER
-
+
-
+
107 Appendix
*WARNING
.Smoke, abnormal odor, overheating, and other abnormalities
• Continued use of the camera while it is emitting smoke or strange odor,
or while it is overheating creates the risk of fire and electric shock.
Immediately perform the following steps whenever any of the above
symptoms are present.
1. Turn off the camera.
2. If you are using the USB-AC adapter to power the camera, unplug the power
plug from the power outlet. Also, remove the battery from the camera, taking
care to protect yourself against burn injury.
3. Contact your retailer or nearest CASIO authorized service center.
.Keep Away From Fire
• Never expose the camera to fire, which can cause it to explode and
creates the risk of fire and personal injury.
.Avoid Use While In Motion
• Never use the camera to record or play back images while operating an
automobile or other vehicle, or while walking. Looking at the monitor
while in motion creates the risk of serious accident.
.Flash and Other Light Emitting Functions
• Never use light emitting functions in areas where there is the chance of
flammable or explosive gas being present. Such conditions create the
risk of fire and explosion.
• Never fire the flash or use light emitting functions pointed in the direction
of a person operating a motor vehicle. Doing so can interfere with the
driver’s vision and create the risk of accident.
.USB-AC Adapter
• Misuse of USB-AC adapter creates the risk of fire and electric shock. Be sure to
observe the following precautions.
– Use only the specified USB-AC adapter.
– Never use the USB-AC adapter with another device.
– Use a power outlet that matches the power supply specified for the
USB-AC adapter.
– Never plug the USB-AC adapter or power cord into a wall outlet that is shared
by other devices, or into a shared extension cord.
– Never locate the USB-AC adapter near a stove or other heating device.
• Misuse of the USB-AC adapter can cause them to become damaged, creating
the risk of fire and electric shock. Be sure to observe the following precautions.
– Never place heavy objects on the USB-AC adapter or subject it to
direct heat.
– Do not modify the USB-AC adapter, allow it to become damaged, or
forcibly bend it.
– Do not twist or pull on the power cord.
– When in use, locate the cord where it will not be tripped over.
$
-
-
-
-
-
-
108 Appendix
• Never touch the power plug while your hands are wet. Doing so creates
the risk of electric shock.
• Should the power cord or power plug become damaged, contact your
retailer or nearest CASIO authorized service center.
• Do not use the USB-AC adapter in areas where liquids* might spill on
them. Liquids create the risk of fire and electric shock.
*Liquids: Water, sports drinks, seawater, animal or pet urine, etc.
• Do not place a flower vase or any other liquid container on top of the
USB-AC adapter. Water creates the risk of fire and electric shock.
• Do not touch the camera or USB-AC adapter during lightning storms.
If a power cord was included with your camera
• The power cord that comes with the camera is designed for use in the
country where the camera was purchased. If you use the camera in
another country, be sure to use a power cord that conforms to that
country’s ratings and power supply voltage. Use of an improper power cord
creates the risk of fire and electric shock.
• Before going out, be sure to unplug the USB-AC adapter from the power
outlet and put in a place away from objects used by animals and pets.
An animal or pet chewing on the power cord can cause it short, leading
to the risk of fire.
.Water and Foreign Matter
• Water, other liquids, or foreign matter (especially metal) getting inside
the camera creates the risk of fire and electric shock. Immediately
perform the following steps whenever any of the above symptoms are
present. Particular care is required when using the camera where it is raining or
snowing, near the ocean or other body of water, or in a bathroom.
1. Turn off the camera.
2. If you are using the USB-AC adapter to power the camera, unplug the power
plug from the wall outlet. Also, remove the battery from the camera, taking
care to protect yourself against burn injury.
3. Contact your retailer or nearest CASIO authorized service center.
.Disassembly and Modification
• Never try to take the camera apart or modify it in any way. Doing so
creates the risk of electric shock, burn injury, and other personal injury.
Be sure to leave all internal inspection, maintenance, and repair up to
your retailer or nearest CASIO authorized service center.
*WARNING
"
+
-
%
1
+
+
%
!
109 Appendix
.Dropping and Rough Treatment
• Continued use of the camera after it is damaged by dropping or other
rough treatment creates the risk of fire and electric shock. Immediately
perform the following steps whenever any of the above symptoms are
present.
1. Turn off the camera.
2. If you are using the USB-AC adapter to power the camera, unplug the power
plug from the wall outlet. Also, remove the battery from the camera, taking
care to protect yourself against burn injury.
3. Contact your retailer or nearest CASIO authorized service center.
.Memory Cards
• Memory cards are small and present a risk of accidentally being
swallowed by infants and young children. Keep memory cards out of the
reach of infants and young children. If a memory card is ever swallowed
accidentally, contact a physician immediately.
.Precaution when Camera is On
• Do not touch the camera for long periods while it is on. The camera
becomes warm when on, and long term contact creates the risk of low-
temperature burns.
*CAUTION
.USB-AC Adapter
• Misuse of the USB-AC adapter creates the risk of fire and electric shock. Make
sure you observe the following precautions.
– Never cover the USB-AC adapter or power cord with a quilt, blanket,
or other cover while it is in use, and do not use it near a heater. Doing
so can interfere with heat radiation and cause the area around them
to become hot.
– Do not use detergent when cleaning the power cord, the USB-AC adapter, or
the USB cable (especially the plugs and jacks).
– Insert the power plug into the wall outlet as far as it will go.
– Unplug the power plug from the wall outlet before leaving the camera
unattended for long periods, such as when leaving on a trip, etc.
– At least once a year, use a cloth or vacuum cleaner to clean any dust build up
on the prongs of the power plug and in the area around them.
– (Power cord included with your camera) When unplugging from the wall outlet,
never pull on the power cord. Grasp the power plug and pull.
*WARNING
-
+
+
-
+
110 Appendix
.Rechargeable Battery
• If battery charging does not end normally within the specified charging
time, stop charging anyway and contact your local CASIO authorized
service center. Continued charging creates the risk of battery
overheating, fire, and explosion.
• Be sure to read the user documentation that comes with the camera and
special charger unit before using or charging the battery.
• Store batteries in a location that cannot be reached by infants and young
children. When using a battery where infants and young children are
present, be on guard to ensure that they do not have the chance to
remove the battery from the charger unit or camera.
• Do not leave batteries near areas used by pets. A pet chewing on a
battery can lead to accidents caused by the battery leaking, overheating,
or exploding.
• Should fluid from a battery accidentally get onto clothing or your skin,
immediately rinse it off with clean tap water. Prolonged contact with
battery fluid can cause skin irritation.
.Connections
• Never plug any devices that are not specified for use with this camera
into connectors. Connecting a non-specified device creates the risk of
fire and electric shock.
.Unstable Locations
• Never place the camera on an unstable surface, on a high shelf, etc.
Doing so can cause the camera to fall, creating the risk of personal
injury.
.Locations To Be Avoided
• Never leave the camera in any of the following types of locations. Doing so
creates the risk of fire and electric shock.
– Areas subject to large amounts of humidity or dust
– Food preparation areas or other locations where oil smoke is present
– Near heaters, on a heated carpet, in areas exposed to direct sunlight,
in a closed vehicle parked in the sun, or other areas subject to very high
temperatures
*CAUTION
+
+
+
-
+
-
-
-
111 Appendix
.Monitor Screen
• Do not apply strong pressure to the LCD panel surface or subject it to
strong impact. Doing so can cause the display panel glass to crack and
lead to personal injury.
• Should the monitor screen ever become cracked, never touch any of the
liquid inside the monitor screen. Doing so creates the risk of skin
inflammation.
• Should monitor screen liquid ever get into your mouth, immediately rinse
your mouth out and contact your physician.
• Should monitor screen liquid ever get into your eyes or onto your skin,
immediately rinse with clean water for at least 15 minutes and contact
your physician.
.Backing Up Important Data
• Always keep backup copies of important data in camera memory by
transferring it to a computer or other storage device. Note that data can
be deleted in the case of camera malfunction, repair, etc.
.Memory Protection
• Whenever replacing the battery, be sure to follow the correct procedure
as described in the documentation that comes with the camera.
Incorrectly replacing the battery can result in corruption or loss of data in
camera memory.
.Flash and Other Light Emitting Functions
• Never fire the flash or use light emitting functions pointed in the direction
of and too close to a person’s face. Doing so creates the risk of loss of
eyesight. In the case of infants and young children in particular, keep the
light source at least one meter away the eyes.
• Take care that your fingers, glove, or other items are not touching the
flash window when you shoot. Touching the flash window can lead to
burn injury, smoke, discoloration, or other problems.
• Do not fire the flash while the flash window is dirty, dusty, or soiled with
foreign matter. Doing so can lead to smoke emission and discoloration.
.Transport
• When in an aircraft or medical facility, comply with instructions of
personnel in charge. Electromagnetic waves and other signals emitted
by the camera can adversely affect other equipment.
*CAUTION
-
1
+
+
+
+
-
-
-
+
112 Appendix
.Data Error Precautions
Your digital camera is manufactured using precision digital components. Any of the
following creates the risk of corruption of data in camera memory.
– Removing the battery or memory card while the camera is performing some
operation
– Removing the battery or memory card while the back lamp is flashing green after
turning off the camera
– Disconnecting the USB cable while communication is in progress
– Shooting with a battery that quickly goes low right after it is charged
• Shooting with a battery that quickly goes low right after it is charged can also
cause camera malfunction. Replace the battery with a new one immediately.
– Other abnormal operations
Any of the above conditions can cause an error message to appear on the monitor
screen (page 124). Perform the action indicated by the message that appears.
.Operating Environment
• Operating Temperature Requirements: 0 to 40°C (32 to 104°F)
• Operating Humidity: 10 to 85% (non condensation)
• Do not place the camera in any of the following locations.
– In an area exposed to direct sunlight, or large amounts of moisture, dust, or sand
– Near heating or cooling devices, or in other areas subjected to extreme changes
in temperature or humidity
– Inside of a motor vehicle on a hot day, or in an area subjected to strong vibration
.Condensation
Sudden and extreme temperature changes, such as when the camera is moved from
the outdoors on a cold winter day into a warm room, can cause water droplets called
“condensation” to form on the interior and the exterior of the camera, which creates
the risk of malfunction. To prevent condensation from forming seal the camera in a
plastic bag before changing locations. Then leave the bag sealed to allow the air
inside to naturally change to the same temperature as the air in the new location.
After that, remove the camera from the bag and open the battery cover for a few
hours.
Precautions During Use
113 Appendix
.Lens
• Never apply too much force when cleaning the surface of the lens. Doing so can
scratch the lens surface and cause malfunction.
• You may sometimes notice some distortion in certain types of images, such as a
slight bend in lines that should be straight. This is due to the characteristics of
lenses, and does not indicate malfunction of the camera.
.Caring for your camera
• Never touch the lens or flash window with your fingers. Finger smudges, dirt, and
other foreign matter on the lens or flash window can interfere with proper operation
of the camera. Use a blower or other means to keep the lens and flash window free
of dirt and dust, and wipe gently with a soft, dry cloth.
• To clean the camera, wipe it with a soft, dry cloth.
.Old Rechargeable Battery Handling Precautions
• Insulate the positive and negative terminals with tape, etc.
• Do not peel the covering off of the battery.
• Do not try to take the battery apart.
.Discarding or Transferring Ownership of a Memory Card or the
Camera
The format and delete functions of the camera do not actually delete files from the
memory card. The original data remains on the card. Note that responsibility for the
data on a memory card lies with you. The following procedures are recommended
whenever you discard a memory card or the camera, or if you transfer ownership to
another party.
• When discarding a memory card, either physically destroy the memory card or use
commercially available data delete software to completely delete the data on the
memory card.
• When transferring ownership of a memory card to another party, use commercially
available data deletion software to completely delete the data on it.
• Use the format function (page 104) to completely delete the data in built-in memory
before discarding or transferring ownership of the camera.
.Other Precautions
The camera becomes slightly warm during use. This is normal and does not indicate
malfunction.
114 Appendix
.Copyrights
Except for your own personal enjoyment, unauthorized use of snapshots or movies of
images whose rights belong to others, without the permission of the right holder, is
forbidden by copyright laws. In some cases, shooting of public performances, shows,
exhibitions, etc. may be restricted entirely, even if it is for your own personal
enjoyment. Regardless of whether such files are purchased by you or obtained for
free, posting them on a website, a file sharing site, or any other Internet site, or
otherwise distributing them to third parties without the permission of the copyright
holder is strictly prohibited by copyright laws and international treaties. For example,
uploading or distributing on the Internet images of TV programs, live concerts, music
videos, etc. that were photographed or recorded by you may infringe upon the rights
of others. Note that CASIO COMPUTER CO., LTD. shall not be held liable for use of
this product in any way that infringes on the copyrights of others or that violates
copyright laws.
Note that trademark ™ and registered trademark ® are not used within the text of this
manual.
• SDXC Logo is a trademark of SD-3C, LLC.
• Microsoft, Windows, Windows Media, Windows Vista, Windows 7, Windows 8, and
DirectX are registered trademarks or trademarks of Microsoft Corporation in the
United States and other countries.
• Macintosh, Mac OS, QuickTime, and iPhoto are trademarks of Apple Inc.
• YouTube and the YouTube logo are trademarks or registered trademarks of
Google Inc.
• Eye-Fi and the Eye-Fi logo are trademarks of Eye-Fi, Inc.
• FlashAir and the FlashAir logo are trademarks of TOSHIBA CORPORATION.
• EXILIM and Dynamic Photo are registered trademarks or trademarks of CASIO
COMPUTER CO., LTD.
• All other company or product names mentioned herein are registered trademarks
or trademarks of their respective companies.
Any and all unauthorized copying, distribution, and transfer for commercial purposes
of the software provided by CASIO for this product are prohibited.
The camera’s YouTube recording function are provided under license granted by
YouTube, LLC.
The following terms, which are used in this manual, are registered trademarks or
trademarks of their respective owners.
115 Appendix
.If the camera’s back lamp starts flashing red...
• Ambient temperature or the temperature of the battery may be either too high or
too low. Disconnect the USB cable and wait until temperature is within the
allowable charging range before trying again.
• Battery contacts may be dirty. Wipe them with a dry cloth.
• Try connecting to a different computer USB port. Depending on the setup of your
computer, you may not be able to charge the camera’s battery over a USB
connection.
.Precautions during Use
• Operation provided by a battery under cold conditions is always less than operation
under normal temperatures. This is due to the characteristics of the battery, not the
camera.
• Charge the battery in an area where the temperature is within the range of 15°C to
35°C (59°F to 95°F). Outside this temperature range charging can take longer than
normal or even fail.
• Do not tear or remove the battery outer label.
• If a battery provides only very limited operation following a full charge, it probably
means the battery has reached the end of its service life. Replace the battery with a
new one.
.Storage Precautions
• Storing the battery for a long time while it is charged can cause deterioration of
battery characteristics. If you do not plan to use a battery for some time, fully use
up its charge before storing it.
• Always remove the battery from the camera when you are not using it. A battery left
in the camera can discharge and go dead, which will require some time to charge
when you need to use the camera.
• Store batteries in a cool, dry place (20°C (68°F) or lower).
• To prevent over discharging of an unused battery, fully charge it, and then load it in
the camera and fully use up the charge about once every six months.
Power Supply
Charging
If problems continue to occur after you perform the above steps, it could mean that
the battery is faulty. Contact your nearest CASIO authorized service center.
Battery Precautions
116 Appendix
.Precautions during Use
• The bundled USB-AC adaptor is designed for operation with any power supply in
the range of 100V to 240V AC, 50/60Hz. Note, however, that the shape of the
power plug depends on each country or geographic area. Before taking the camera
and USB-AC adaptor along on a trip, check with travel agent about the power
supply requirements in your destination(s).
• Do not connect the USB-AC adaptor to a power supply through a voltage converter
or similar device. Doing so can lead to malfunction.
.Extra Batteries
• Taking along extra fully charged batteries (NP-80) is recommended while on a trip
in order to avoid not being able to shoot images due to the battery going dead.
See page 20 for information about supported memory cards and how to load a
memory card.
.Using a Memory Card
• SD memory cards, SDHC memory cards, and SDXC
memory cards have a write protect switch. Use the
switch when you need to guard against accidentally
deleting data. Note, however, if you write protect an SD
memory card you must then turn write protection off
whenever you want to record to it, format it, or delete
any of its images.
• If a memory card starts to behave abnormally during image playback, you can
restore normal operation by reformatting it (page 104). However, it is
recommended that you always take along multiple memory cards whenever using
the camera far away from the home or office.
• As you record data to and delete data from a memory card a number of times, it
loses its ability to retain data. Because of this, periodic re-formatting of a memory
card is recommended.
• Electrostatic charge, electrical noise, and other phenomena can cause data to
become corrupted or even lost. Make sure that you always back up important data
on other media (CD-R, CD-RW, hard disk, etc.).
Using the Camera in another Country
Using a Memory Card
Write enabled
Write disabled
117 Appendix
.Memory Card Handling Precautions
• Certain types of memory cards can slow down processing speed. Whenever
possible use an Ultra High-Speed Type memory card. Note, however, that not all
operations can be guaranteed even if an Ultra High-Speed Type memory card is
used. Certain movie quality settings can result in too much time being required to
record data, which can result in breaks in the image and/or audio during playback.
If this happens, the » and Y will flash on the monitor screen.
The tables in this section show the initial default settings on menus that appear in the
REC mode and PLAY mode when you reset the camera (page 104).
• A dash (–) indicates an item whose setting is not reset or an item for which there is
no reset setting.
IMPORTANT!
• Depending on the recording mode, some of the items on the menu that appears
may not be usable.
.REC Mode
“REC” Tab
“Quality” Tab
Reset Initial Default Settings
Focus AF
Focus Frame ß
AF Area I Multi
Face Detection On
CS Off
Anti Shake On
L/R Key Off
Grid Off
Review Off
Icon Help On
Memory
b BEST SHOT:
Off /
Flash: On /
Focus: Off /
White Balance: Off /
ISO: Off /
AF Area: On /
CS: Off /
Self-timer: Off /
MF Position: Off /
Zoom Position: Off
Quality
(Snapshots) Normal
EV Shift 0.0
White Balance Auto
T
ISO Auto
Color Filter Off
118 Appendix
“Set Up” Tab
.PLAY Mode
“PLAY” Tab
“Set Up” Tab
• The contents of the “Set Up” tab are the same in the REC mode and PLAY mode.
Silent Off
Eye-Fi On
FlashAir On
Sounds
Startup: Sound 1 /
Half Shutter:
Sound 1 /
Shutter: Sound 1 /
Operation: Sound 1 /
=Operation:
...////
/
=Play:
...////
Startup Off
File No. Continue
World Time –
Timestamp Off
Adjust –
Date Style –
Language –
Sleep 1 min
Auto Power
Off 2 min
REC Disable
PLAY Power On
Ü Disabled Off
Format –
Reset –
Repeat Movie
Play Off
Dynamic Photo –
Art Effect Cancel
DPOF Printing –
Protect –
Resize –
Trimming –
Dubbing –
Copy –
119 Appendix
When things don’t go right...
Troubleshooting
Problem Possible Cause and Recommended Action
Power Supply
Power does not
turn on.
1)The battery may not be loaded correctly (page 13).
2)The battery may be dead. Charge the battery (page 14). If the
battery goes dead soon after being charged, it means the
battery has reached the end of its life and needs to be
replaced. Purchase a separately available CASIO NP-80
rechargeable lithium ion battery.
The camera
suddenly powers
down.
1)Auto Power Off may have activated (page 102). Turn power
back on.
2)The battery may be dead. Charge the battery (page 14).
3)The camera’s protection function may have activated
because camera temperature is too high. Turn off the camera
and wait until it cools down before trying to use it again.
Power will not turn
off. Nothing
happens when a
button is pressed.
Remove the battery from the camera and then reload it.
Charging
The back lamp
does not light red
and the battery
won’t charge.
1)Unplug the USB cable from the camera and then plug it back
in again.
2)Remove the battery from the camera and then reload it (page
14).
Image Recording
Image is not
recorded when the
shutter button is
pressed.
1)If the camera is in the PLAY mode, press [r] (REC) to enter
the REC mode.
2)If the flash is charging, wait until the charge operation
finishes.
3)If the message “Memory Full” appears, transfer images to
your computer, delete images you no longer need, or use a
different memory card.
Auto Focus does
not focus properly.
1)If the lens is dirty, clean it off.
2)The subject may not be in the center of the focus frame when
you compose the image.
3)The subject you are shooting may not be a type that is
compatible with Auto Focus (page 32). Use manual focus
(page 54).
4)You may be moving the camera when shooting. Try shooting
with Anti Shake or use a tripod.
5)You may be pressing the shutter button all the way without
waiting for Auto Focus. Half-press the shutter button and
allow enough time for Auto Focus to focus.
120 Appendix
The subject is out
of focus in the
recorded image.
The image may not be focused properly. When composing the
image, make sure the subject is located inside the focus frame.
The flash does not
fire.
1)If ?(Flash Off) is selected as the flash mode, change to
another mode (page 37).
2)If the battery is dead, charge it (page 14).
3)If a BEST SHOT scene that uses ?(Flash Off) is selected,
change to a different flash mode (page 37) or select a
different BEST SHOT scene (page 46).
The red ?(Flash
Off) icon is
displayed on the
monitor screen and
the flash does not
fire.
The flash unit may be malfunctioning. Contact a CASIO
authorized service center or your original retailer. Note that
though the flash will not fire, you still can use the camera for
non-flash shots.
Camera powers
down during Self-
timer countdown.
The battery may be dead. Charge the battery (page 14).
The monitor screen
image is out of
focus.
1)You may be using Manual Focus and have not focused the
image. Focus the image (page 55).
2)You may be using ´(Macro) for scenery or portraits. Use
Auto Focus for scenery and portrait shots (page 54).
3)You may be trying to use Auto Focus when shooting a close-
up shot. Use the ´(Macro) for close ups (page 54).
There is a vertical
line in the monitor
screen image.
Shooting a very brightly lit subject can cause a vertical band to
appear in the monitor screen image. This is a CCD
phenomenon known as “vertical smear”, and does not indicate
malfunction of the camera. Note that vertical smear is not
recorded with the image in the case of a snapshot, but it is
recorded in the case of a movie.
There is digital
noise in images.
1)Sensitivity may have been increased automatically for a dark
subject, which increases the chance of digital noise. Use a
light or some other means to illuminate the subject.
2)You may be attempting to shoot in a dark location with
?(Flash Off) selected, which can increase digital noise and
make images appear coarse. In this case, turn on flash (page
37) or use lights for illumination.
3)Shooting with a high ISO sensitivity setting or with the
Lighting feature can cause an increase in digital noise. Use a
light or some other means to illuminate the subject.
Problem Possible Cause and Recommended Action
121 Appendix
A recorded image
was not saved.
1)Camera power may have been turned off before the save
operation was complete, which will result in the image not
being saved. If the battery indicator shows , charge the
battery as soon as possible (page 18).
2)You may have removed the memory card from the camera
before the save operation was complete, which will result in
the image not being saved. Do not remove the memory card
before the save operation is complete.
Though available
lighting is bright,
the faces of people
in the image are
dark.
Not enough light is reaching the subjects. Change the flash
mode setting to <(Flash On) for daylight synchro flash (page
37), or adjust EV shift to the + side (page 64).
Night shots come
out bad.
Select Premium Auto as the recording mode (page 25).
Subjects are too
dark when shooting
images in a
seashore or ski
area.
Sunlight reflected by water, sand, or snow, can cause
underexposure of images. Change the flash mode setting to
<(Flash On) for daylight synchro flash (page 37), or adjust EV
shift to the + side (page 64).
Digital zoom
(including HD
zoom) does not
work. The zoom
bar indicates zoom
only up to a zoom
factor of 12.0.
Time stamping may be turned on, which will cause digital zoom
to be disabled. Turn off time stamping (page 100).
The image is out of
focus during movie
recording.
1)Focusing may not be possible because the subject is outside
the focus range. Shoot within the allowable range.
2)The lens may be dirty. Clean the lens (page 113).
I can’t change the
settings of menu
items. Menu items
for some settings
are not displayed
on the menu.
Depending on the recording mode, some of the items on the
menu that appears may not be usable. Only the menu items
whose settings can be configured (page 28) will be displayed on
the menus while Premium Auto is in use.
Problem Possible Cause and Recommended Action
122 Appendix
Playback
The color of the
playback image is
different from what
appears on the
monitor screen
when shooting.
Sunlight or light from another source may be shining directly
into the lens when you are shooting. Position the camera so
sunlight does not shine directly into the lens.
Images are not
displayed.
This camera cannot display non-DCF images recorded onto a
memory card using another digital camera.
Images cannot be
edited (with
resizing, trimming,
rotation).
Note that you cannot edit the following types of snapshots.
•Movies
• Snapshots recorded with another camera
File Deletion
A file cannot be
deleted.
1)The file may be protected. Unprotect the file (page 73).
2)“ÜDisabled” setting may be “On”. Change the setting to
“Off” (page 103).
Other
The wrong date
and time are
displayed, or the
wrong date and
time are being
stored along with
image data.
The date and time setting is off. Set the correct date and time
(page 100).
The messages on
the display are in
the wrong
language.
The wrong display language is selected. Change the display
language setting (page 101).
Images cannot be
transferred over a
USB connection.
1)The USB cable may not be connected securely. Check all
connections.
2)If the camera is not turned on, turn it on.
3)Your computer may not be able to recognize the camera if
you connect via a USB hub. Always connect directly to the
computer’s USB port.
4)USB communication may not be possible when the battery
level indicator is . Charge the battery before connecting.
Problem Possible Cause and Recommended Action
123 Appendix
Language selection
screen appears
when the camera is
turned on.
1)You did not configure initial settings after purchasing the
camera or the camera may have been left with a dead
battery. Check the camera setup (pages 19, 101).
2)There may be a problem with the camera’s memory data.
If this is the case, perform the reset operation to initialize the
camera’s setup (page 104). After that, configure each setting.
If the language selection screen does not re-appear when you
turn the camera on, it means that the camera’s memory
management data has been restored.
If the same message appears after you turn power back on,
contact your retailer or a CASIO authorized service center.
There are various
indicators and
values on the
monitor screen.
The monitor screen shows indicators and other information
about shooting conditions and the image you are recording. You
can use [8] (DISP) to select what information you want to
include on the display (page 11).
The time and date
settings configured
the first time after
purchasing the
camera are reset to
their factory
defaults when
remove the
camera’s battery.
Load the camera’s battery and reconfigure the time and date
settings (page 19). Do not remove the battery from the camera
for at least 24 hours after configuring time and date settings.
After that, the settings will not be reset if you remove the
battery.
• If the time and date are reset to their factory default settings
when you remove the battery after it has been loaded for
more than 24 hours, it could mean that the camera’s setting
memory is defective. Contact your retailer or a CASIO
authorized service center.
Buttons are not
responsive right
after the power has
been turned on.
With large capacity memory cards there is a delay after the
power has been turned on before the buttons become
responsive.
Problem Possible Cause and Recommended Action
124 Appendix
Display Messages
ALERT
The camera’s protection function may have activated
because camera temperature is too high. Turn off the
camera and wait until it cools down before trying to use it
again.
Battery is low. Battery power is low.
Card ERROR
There is something wrong with the memory card. Turn off the
camera, remove the memory card and then reload it into the
camera. If this message re-appears when you turn the
camera back on, format the memory card (page 104).
IMPORTANT!
• Formatting a memory card deletes all its files. Before
formatting, try transferring recoverable files to a computer
or some other storage device.
Connecting to the
network
Camera power was turned off while image data was being
copied to a computer or other device using a FlashAir card
(page 91).
File could not be
saved because
battery is low.
Battery power is low, so an image file could not be saved.
Folder cannot be
created.
You are trying to record a file while there are already
9999 files stored in the 999th folder. If you want to record
more, delete files you no longer need (page 30).
Images are being
transferred. Stop
transfer and turn
off power?
You are attempting to turn off power while image data is
being transferred using the Eye-Fi card (page 90).
LENS ERROR
This message appears and the camera turns off whenever
lens performs some unexpected operation. If the same
message appears after you turn power back on, contact a
CASIO authorized service center or your original retailer.
LENS ERROR 2
The Anti Shake unit of the camera may be malfunctioning. If
the same message appears after you turn power back on,
contact your retailer or a CASIO authorized service center.
Memory Full
Memory is full with images you recorded and/or files saved
by editing operations. Delete files you no longer need (page
30).
Record Error Image compression could not be performed for some reason
during image data storage. Shoot the image again.
125 Appendix
RETRY POWER ON
The lens came into contact with an obstruction while moving.
The camera will turn off automatically when this message
appears. Remove the obstruction and turn power back on
again.
SYSTEM ERROR Your camera system is corrupted. Contact your retailer or a
CASIO authorized service center.
The card is locked.
The LOCK switch of the SD, SDHC, or SDXC
memory card loaded in the camera is in the
locked position. You cannot store images to
or delete images from a memory card that is
locked.
There are no files. There are no files in built-in memory or on the memory card.
This card is not
formatted.
The memory card loaded in the camera is not formatted.
Format the memory card (page 104).
This file cannot be
played.
The file you are trying to access is corrupted or is a type that
cannot be displayed by this camera.
This function
cannot be used.
This message will appear part way through an operation
when you attempt to use a function that is not allowed in
combination with another function.
LOCK
126 Appendix
Snapshot
Number of Snapshots/Movie Recording Time/
Voice Recording Time
Image Size
(Pixels) Quality Approximate
File Size
Built-in Memory
*
1
Recording Capacity
SD Memory Card
*
2
Recording
Capacity
16M
(4608x3456)
Fine 5.57MB 3 2790
Normal 3.71MB 5 4189
3:2
(4608x3072)
Fine 4.92MB 4 3159
Normal 3.28MB 6 4738
16:9
(4608x2592)
Fine 4.10MB 5 3790
Normal 2.75MB 7 5651
10M
(3648x2736)
Fine 3.38MB 6 4598
Normal 2.27MB 9 6847
5M
(2560x1920)
Fine 1.72MB 12 9036
Normal 1.22MB 17 12739
3M
(2048x1536)
Fine 1.25MB 17 12434
Normal 820KB 26 18954
VGA
(640x480)
Fine 290KB 74 53595
Normal 240KB 89 64761
127 Appendix
Movies
Voice Recording
*1 Built-in memory capacity after formatting (Approx. 28.0MB)
*2 When using a 16GB SDHC memory card (SanDisk Corporation). Number of image and
recording time values depend on the memory card you are using.
*3 The allowable recording time will be shorter if the capacity of the SD memory card you
are using is smaller than the maximum size of one file.
*4 The data transfer rate of built-in memory is not sufficient for HD movies. Whenever
possible use an Ultra High-Speed Type memory card.
• Snapshot, movie recording capacity, and voice recording capacity values are
approximate and intended for reference only. Actual capacity depends on image
contents.
• File size and data rate values are approximate and intended for reference only. Actual
values depend on the type of image being shot.
• When using a memory card with a different capacity, calculate the number of images as a
percentage of 16GB.
• Each movie can be up to 29 minutes long. Movie recording stops automatically after
29 minutes of recording.
• The maximum size of each file when shooting with the “For YouTube” scene is
2048MB. The maximum recording time is 15 minutes.
Size/Pixels
(Audio)
Approximate Data
Rate (Frame Rate)
Maximum
File Size
Built-in
Memory
*
1
Recording
Capacity
Maximum
Recording
Time with
SD Memory
Card
*
2
File Size of
1-minute
Movie
Continuous
Recording
Time per
Movie
*
3
HD
1280
x
720
(Monaural)
30.2 Megabits/
second
(30 frames/second) 4GB or
29 minutes
6 seconds
*
4
1 hour
5 minutes 226.3MB 17 minutes
9 seconds
STD
640x480
(Monaural)
10.6 Megabits/
second
(30 frames/second)
18 seconds
3 hours
6 minutes 79.0MB 29 minutes
File Format File Size
Maximum
File Size
Built-in Memory
*
1
Recording
Capacity
SD Memory
Card
*
2
Recording
Capacity
Continuous
Recording Time
per Recording
*
3
WAV
IMA-ADPCM
5.5 KB/second
4GB 1 hour
25 minutes
796 hours
53 minutes
3 hours
5 minutes
128 Appendix
Specifications
File Format Snapshots:
JPEG (Exif Version 2.3); DCF 2.0 standard; DPOF compliant
Movies:
Motion JPEG AVI, IMA-ADPCM audio (monaural)
Audio (Voice Recording): WAV (monaural)
Recording Media Built-in Memory (Image Storage Area: 28.0MB)
SD/SDHC/SDXC
Recorded Image Sizes Snapshot:
16M (4608x3456), 3:2 (4608x3072), 16:9 (4608x2592),
10M (3648x2736), 5M (2560x1920), 3M (2048x1536),
VGA (640x480)
Movies:
HD (1280x720), STD (640x480)
Effective Pixels 16.10 Megapixels
Imaging Element Size: 1/2.3-inch square pixel CCD
Total Pixels: 16.57 Megapixels
Lens/Focal Distance F3.1 (W) to 6.3 (T) f = 4.3 to 51.6 mm
(equivalent to 24 to 288 mm in 35 mm format)
Zoom 12X optical zoom, 4X digital zoom (48X in combination with
optical zoom)
Up to 191.3X when HD Zoom and Digital zoom are used in
combination (VGA size)
Focusing Contrast Detection Auto Focus
• Focus Modes:
Auto Focus, Macro Focus, Manual Focus
•AF Area:
Spot, Multi, Tracking
Approximate Focus
(Snapshot)
(From Lens Surface)
Auto Focus: 3 cm to 9 (1.2" to 9) (Wide Angle)
Macro Focus: 3 cm to 50 cm (1.2" to 19.7") (Wide Angle)
Manual: 3 cm to 9 (1.2" to 9) (Wide Angle)
• Range is affected by optical zoom.
Metering Multi-pattern (center weighted for some BS scenes) by imaging
element
Exposure Control Program AE
Exposure
Compensation
–2.0 EV to +2.0 EV (in 1/3EV steps)
Shutter CCD shutter, mechanical shutter
Shutter Speed Snapshot (Auto): 1/2 to 1/2000 second
Snapshot (Premium Auto): 4 to 1/2000 second
• May differ due to the camera setup.
Aperture Value F3.1 (W) to F7.8 (W) (ND filter)
• Using optical zoom changes the aperture value.
White Balance Auto, Daylight, Overcast, Shade, Day White Fluorescent,
Daylight Fluorescent, Tungsten, Manual WB
129 Appendix
Sensitivity (Standard
Output Sensitivity)
Snapshots:
Auto, ISO 100, ISO 200, ISO 400, ISO 800, ISO 1600
equivalent
Movies: Auto
Flash Modes Auto, Off, On, Red-eye reduction
Flash Range
(ISO Sensitivity: Auto)
Wide Angle: 0.4 m to 3.6 m (1.3' to 11.8')
Telephoto: 1.5 m to 1.8 m (4.9' to 5.9')
• Range is affected by optical zoom.
Flash Charging Time Approximately 5 seconds maximum
Monitor Screen 3.0-inch TFT color LCD
460,800 dots
External connection
terminal
Micro USB port (Hi-Speed USB compliance, USB charging)
Microphone Monaural
Speaker Monaural
Power Requirements Rechargeable lithium ion battery (NP-80) x 1
130 Appendix
Approximate Battery Life
All of the values provided below represent the approximate amount of time under
normal temperature (23°C (73°F)) before the camera turns off. These values are not
guaranteed. Low temperatures shorten battery life.
• Battery: NP-80 (Rated Capacity: 700 mAh)
• Recording Medium: 16GB SDHC memory card (SanDisk Corporation)
*1 In accordance with CIPA (Camera and Imaging Products Association) standards
*2 In accordance with CASIO standards
*3 Approximate continuous recording time
*4 Standard temperature (23°C (73°F)), one-image scroll approximately every
10 seconds
• The above values are based a new battery, starting from a full charge. Repeated
charging shortens battery life.
• Frequency of flash, zoom, and Auto Focus usage, and the time the camera is on
greatly affects recording time and number of shots values.
Number of snapshots (Operating Time)*1175 shots
Actual movie recording time (HD movie)*140 minutes
Approximate continuous movie recording time
(HD movies)*21 hour 20 minutes
Continuous Voice Recording*33 hours 5 minutes
Continuous Playback*42 hours 50 minutes
Power Consumption 3.7 V DC, Approximately 3.3 W
Dimensions 104.5 (W) x 61.9 (H) x 26.4 (D) mm
(4.1" (W) x 2.4" (H) x 1.04" (D))
(21.1 mm (0.83") thick excluding projections)
Weight Approximately 179 g (6.3 oz) (including battery and memory card*)
Approximately 162 g (5.7 oz) (excluding battery and memory card)
*16GB SDHC memory card (SanDisk Corporation)
131 Appendix
.Rechargeable lithium ion battery (NP-80)
.USB-AC adaptor (AD-C54UG)
.USB-AC adaptor (AD-C54UC)
.USB-AC adaptor (AD-C53U)
• Power cord precautions for use in Singapore
The power cord set is not supplied. The power cord used must comply with
relevant national and/or international standards.
Rated Voltage 3.7 V
Rated Capacitance 700 mAh
Operating Temperature
Requirements
0 to 40°C (32 to 104°F)
Dimensions 31.4 (W) x 39.5 (H) x 5.9 (D) mm
(1.24" (W) x 1.56" (H) x 0.23" (D))
Weight Approximately 15 g (0.53 oz)
Input 100 to 240 V AC, 50/60 Hz, 90 mA
Output 5.0 V DC, 650 mA
Operating Temperature
Requirements
5 to 35°C (41 to 95°F)
Dimensions 64.6 (W) x 56.9 (H) x 24 (D) mm
(2.5" (W) x 2.2" (H) x 0.9" (D)) (excluding projections)
Weight Approximately 45 g (1.6 oz)
Input Power 100 to 240 V AC, 50/60 Hz, 90 mA
Output Power 5.0 V DC, 650 mA
Operating Temperature
Requirements
5 to 35°C (41 to 95°F)
Dimensions 64.6 (W) x 38.4 (H) x 24 (D) mm
(2.5" (W) x 1.5" (H) x 0.9" (D)) (excluding projections)
Weight Approximately 40 g (1.4 oz)
Input 100 to 240 V AC, 50/60 Hz, 100 mA
Output 5.0 V DC, 650 mA
Operating Temperature
Requirements
5 to 35°C (41 to 95°F)
Dimensions 53 (W) x 21 (H) x 45 (D) mm
(2.1" (W) x 0.83" (H) x 1.8" (D)) (excluding projections)
Weight Approximately 37 g (1.3 oz)
B
132 Appendix
Manufacturer:
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:
CASIO EUROPE GmbH
Casio-Platz 1, 22848 Norderstedt, Germany
Declaration of Conformity According to EU Directive
B
2014
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome
Shibuya-ku, Tokyo 151-8543, Japan
MA1403-BM29
