Quick Start Guide
Thank you for purchasing this 802.11b network standard devices.Your 802.11g Wireless
LAN Mni PCI Card certainly will bring you into such a high-speed networking sphere.
With the easiness installation and configuration, you could operate your network with
much enjoyments in either an independent mode or an infrastructure mode.
The former, which is also known as peer-to-peer or ad-hoc network, lets you directly
directly make connection with other wireless-equipped computers, and the later, the so-
called infrastructure network, allows you to communicate with wired LAN via an access
point.
Wired Network
Ad-Hoc Network Configuration
Access Point
Infrastructure N etw o rk C onfiguration
Printer
Internet
Please go along with the procedures below to install the 802.11b Wireless LAN Mini PCI
Card.
Installation Procedures
1. Insert the 802.11b Wireless LAN Mini PCI Card into an available mini PCI slot of your
computer. The Found New Hardware Wizard dialog box will appear because the
system has detected the insertion of the Card.
2. In the Found New Hardware Wizard dialog box, choose Install from a list or specific
location [Advanced] and then click Next.
3. In the next dialog box, choose Includes this location in the search under Search for
the best driver in these locations.
4. Choose Browse to open the Browse For Folder dialog box.
5. Find the folder named Install from directories on the supplied CD, and then click OK to
close the dialog box.
6. In the Found New Hardware Wizard dialog box, click Next to proceed.
7. If you are operating Windows XP, the system will notify you that the driver has not
passed Windows Logo testing. Because the Card has been tested to work with
Windows XP, please choose Continue Anyway. Otherwise, if you are operating other
systems, please skip to next step.
8. Your system will start to copy the drivers found. It might take a couple of seconds.
When done, click Next.
9. Click Finish when the Completing the Found New Hardware Wizard screen
appears.
