DMX CHANNEL FUNCTIONS AND VALUES
ELATION SATURA PROFILE™
DMX Channel Values / Functions (54 DMX Channels)
Supports Software Versions: ≥ 1.0.2
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
1
1
PAN MOVEMENT [8 BIT]
0-255
PAN Movement
2
PAN FINE MOVEMENT [16 BIT]
0-255
Fine Control of PAN Movement
2
3
TILT MOVEMENT [8 BIT]
0-255
TILT Movement
4
TILT MOVEMENT [16 BIT]
0-255
Fine Control of TILT Movement
3
5
CYAN COLOR
0-255
0-WHITE ~ 255-100% CYAN
CYAN COLOR FINE
0-255
CYAN FINE Adjustment
4
6
MAGENTA COLOR
0-255
0-WHITE ~ 255-100% MAGENTA
MAGENTA COLOR FINE
0-255
MAGENTA FINE Adjustment
5
7
YELLOW COLOR
0-255
0-WHITE ~ 255-100% YELLOW
YELLOW COLOR FINE
0-255
YELLOW FINE Adjustment
6
8
CTO COLOR
0-255
0-WHITE ~ 255-100% CTO
CTO COLOR FINE
0-255
CTO FINE Adjustment
7
9
CMY / COLOR MACRO SPEED
0-255
MAX to MIN Speed
8
10
COLOR WHEEL
0-15
OPEN / WHITE
16-31
RED
32-47
BLUE
48-63
GREEN
64-79
YELLOW
80-95
MAGENTA
96-111
ORANGE
112-127
LIGHT BLUE
128-189
*Clockwise COLOR Rotation from FAST to SLOW
190-193
NO Rotation
194-255
*Counterclockwise COLOR Rotation from SLOW to FAST
COLOR WHEEL FINE ADJUSTMENT
0-255
FINE Adjustment of Color Wheel to Any Position
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
9
11
ROTATING GOBOS, CONTINUOUS ROTATION [GOBO WHEEL 1]
0-9
OPEN
10-19
Rotating Gobo 1
20-29
Rotating Gobo 2
30-39
Rotating Gobo 3
40-49
Rotating Gobo 4
50-59
Rotating Gobo 5
60-69
Rotating Gobo 6
70-89
Gobo 1 Shake SLOW to FAST
90-109
Gobo 2 Shake SLOW to FAST
110-129
Gobo 3 Shake SLOW to FAST
130-149
Gobo 4 Shake SLOW to FAST
150-169
Gobo 5 Shake SLOW to FAST
170-189
Gobo 6 Shake SLOW to FAST
190-255
*Clockwise Gobo Wheel Rotation from SLOW to FAST
10
12
ROTATING GOBOS, INDEX ROTATION [GOBO WHEEL 1]
0-127
Gobo Indexing
128-193
*Clockwise Gobo Rotation from FAST TO SLOW
194-255
*Counterclockwise Gobo Rotation from SLOW to FAST
DMX VALUE CHANGE WITH SOFTWARE UPDATE VERSION ≥1.0.6
See highlighted DMX values below which have been updated with this software update.
10
12
ROTATING GOBOS, INDEX ROTATION [GOBO WHEEL 1]
0-127
Gobo Indexing
128-189
*Clockwise Gobo Rotation from FAST TO SLOW
190-193
NO ROTATION
194-255
*Counterclockwise Gobo Rotation from SLOW to FAST
ROTATING GOBOS, FINE INDEX ROTATION [GOBO WHEEL 1]
0-255
Gobo Rotation FINE Indexing
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
11
13
STATIC / FIXED GOBOS [GOBO WHEEL 2]
0-13
OPEN
14-27
Static / Fixed Gobo 1
28-41
Static / Fixed Gobo 2
42-55
Static / Fixed Gobo 3
56-69
Static / Fixed Gobo 4
70-83
Static / Fixed Gobo 5
84-97
Static / Fixed Gobo 6
98-111
Static / Fixed Gobo 7
112-127
Shake SLOW to FAST Static / Fixed Gobo 1
128-143
Shake SLOW to FAST Static / Fixed Gobo 2
144-159
Shake SLOW to FAST Static / Fixed Gobo 3
160-175
Shake SLOW to FAST Static / Fixed Gobo 4
176-191
Shake SLOW to FAST Static / Fixed Gobo 5
192-207
Shake SLOW to FAST Static / Fixed Gobo 6
208-223
Shake SLOW to FAST Static / Fixed Gobo 7
224-255
*Clockwise Gobo Wheel Rotation from SLOW to FAST
DMX VALUES FOR OPTIONAL STATIC GOBO / ANIMATION WHEEL KIT
See highlighted DMX values below which support the control of the optional Static GOBO / Animation Wheel Kit.
Please contact ELATION CUSTOMER SUPPORT for more details.
11
13
STATIC / FIXED GOBOS [GOBO WHEEL 2]
0-13
OPEN
14-27
Static / Fixed Gobo 1
28-41
Static / Fixed Gobo 2
42-55
Static / Fixed Gobo 3
56-69
Static / Fixed Gobo 4
70-111
ANIMATION EFFECT
112-127
Shake SLOW to FAST Static / Fixed Gobo 1
128-143
Shake SLOW to FAST Static / Fixed Gobo 2
144-159
Shake SLOW to FAST Static / Fixed Gobo 3
160-175
Shake SLOW to FAST Static / Fixed Gobo 4
176-223
ANIMATION EFFECT SHAKE SLOW to FAST
224-255
*Clockwise Gobo Wheel Rotation from SLOW to FAST
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
12
14
ROTATING PRISM, PRISM / GOBO MACROS
0-63
OPEN
64-127
3-FACET Rotating Prism
128-135
Prism / Gobo Macro 1
136-143
Prism / Gobo Macro 2
144-151
Prism / Gobo Macro 3
152-159
Prism / Gobo Macro 4
160-167
Prism / Gobo Macro 5
168-175
Prism / Gobo Macro 6
176-183
Prism / Gobo Macro 7
184-191
Prism / Gobo Macro 8
192-199
Prism / Gobo Macro 9
200-207
Prism / Gobo Macro 10
208-215
Prism / Gobo Macro 11
216-223
Prism / Gobo Macro 12
224-231
Prism / Gobo Macro 13
232-239
Prism / Gobo Macro 14
240-247
Prism / Gobo Macro 15
248-255
Prism / Gobo Macro 16
13
15
ROTATING PRISM, PRISM INDEX ROTATION
0-127
Prism Indexing
128-189
*Clockwise Linear Prism Rotation from FAST to SLOW
190-193
NO Rotation
194-255
*Counterclockwise Linear Prism Rotation from SLOW to FAST
14
16
SHUTTER, STROBE
0-31
Shutter CLOSED
32-63
NO Function (Shutter OPEN)
64-95
Strobe Effect SLOW to FAST
96-127
NO function (Shutter OPEN)
128-159
Pulse Effect In Sequences
160-191
NO Function (Shutter OPEN)
192-223
Random Strobe Effect SLOW to FAST
224-255
NO Function (Shutter OPEN)
15
17
DIMMER INTENSITY
0-255
Intensity 0 to 100%
DIMMER INTENSITY FINE [16 BIT]
0-255
Intensity 0 to 100%
16
18
DIMMER CURVE MODES
0-20
STANDARD
21-40
STAGE
41-60
TV
61-80
ARCHITECTURAL
81-100
THEATER
101-255
DEFAULT to UNIT CURVE SETTING
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
17
19
FROST
0-127
OPEN
128-255
100% Frost
18
20
IRIS
0-191
MAX to MIN Diameter
192-223
Pulse Closing FAST to SLOW
224-255
Pulse Closing SLOW to FAST
IRIS FINE
0-255
Iris FINE Adjustment
19
21
FOCUS
0-255
Continuous Adjustment from FAR to NEAR
FOCUS FINE
0-255
Continuous FINE Focus Adjustment
20
22
MOTORIZED ZOOM
0-255
ZOOM Adjustment from SMALL to BIG
MOTORIZED ZOOM FINE
0-255
ZOOM FINE Adjustment
21
23
BLADE #1
0-255
OPEN to CLOSE
BLADE #1 FINE [16 BIT]
0-255
OPEN to CLOSE FINE Adjustment
22
24
BLADE #1 ROTATION
0-255
ROTATION
BLADE #1 ROTATION FINE [16 BIT]
0-255
ROTATION FINE Adjustment
23
25
BLADE #2
0-255
OPEN to CLOSE
BLADE #2 FINE [16 BIT]
0-255
OPEN to CLOSE FINE Adjustment
24
26
BLADE #2 ROTATION
0-255
ROTATION
BLADE #2 ROTATION FINE [16 BIT]
0-255
ROTATION FINE Adjustment
25
27
BLADE #3
0-255
OPEN to CLOSE
BLADE #3 FINE [16 BIT]
0-255
OPEN to CLOSE FINE Adjustment
26
28
BLADE #3 ROTATION
0-255
ROTATION
BLADE #3 ROTATION FINE [16 BIT]
0-255
ROTATION FINE Adjustment
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
27
29
BLADE #4
0-255
OPEN to CLOSE
BLADE #4 FINE [16 BIT]
0-255
OPEN to CLOSE FINE Adjustment
28
30
BLADE #4 ROTATION
0-255
ROTATION
BLADE #4 ROTATION FINE [16 BIT]
0-255
ROTATION FINE Adjustment
29
31
ALL (4) BLADES ROTATION
0-255
All (4) Blade Rotation
ALL (4) BLADES ROTATION FINE [16 BIT]
0-255
All (4) Blade FINE Rotation
30
32
BLADE SPEED
0-255
BLADE Speed FAST to SLOW
31
33
BLADE MACROS
0-14
OFF
15-29
Blade Macro 1
30-44
Blade Macro 2
45-59
Blade Macro 3
60-74
Blade Macro 4
75-89
Blade Macro 5
90-104
Blade Macro 6
105-119
Blade Macro 7
120-134
Blade Macro 8
135-149
Blade Macro 9
150-164
Blade Macro 10
165-179
Blade Macro 11
180-194
Blade Macro 12
195-209
Blade Macro 13
210-224
Blade Macro 14
225-239
Blade Macro 15
240-255
Blade Macro 16
32
34
PAN / TILT MOVEMENT SPEED
0-225
MAX to MIN Speed
226-235
Blackout by Movement
236-255
Blackout by COLOR / GOBO Wheel Movement
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
33
35
LAMP ON/OFF, RESET, INTERNAL PROGRAMS
0-19
GOBO Change Normal
20-29
COLOR Change to Any Position
30-39
GOBO Change to Any Position
40-59
NO FUNCTION
60-79
NO FUNCTION
80-84
ALL Motors Reset
85-87
SCAN Motor Reset
88-90
COLOR Motors Reset
91-93
GOBO Motors Reset
94-96
NO FUNCTION
97-99
OTHER Motors Reset
100-119
Internal Program 1 (Scene1-8)
120-139
Internal Program 2 (Scene 9-16)
140-159
Internal Program 3 (Scene 17-24)
160-179
Internal Program 4 (Scene 25-32)
180-199
Internal Program 5 (Scene 33-40)
200-219
Internal Program 6 (Scene 41-48)
220-239
Internal Program 7 (Scene 49-56)
240-255
NO FUNCTION
