Cellphone Mate SureCall MINI-40UNDER Bi-Directional Amplifier User Manual SureCall Mini manualx
Cellphone-Mate Inc. dba SureCall Bi-Directional Amplifier SureCall Mini manualx
Users Manual Rev
SureCall®
CM-MINI
30dB Direct Connect Booster
User Manual
Model: CM-MINI
FCCID:RSNMINI‐40UNDER
CanadaIC:7784A‐M40UNDER
CONTENTS OF THE PACKAGE fdgbsddg
1. 30dB signal booster
2. Patch antenna with FME female connector
3. 12V car charger straight cord (12’ or 3.6m)
4. User manual (this document)
5. Velcro and screw mounting kits
SPECIFICATIONS fdgbsddg
1. Nominal pass band gain: 30dB
2. Nominal band width: 42 MHz（Cellular）, and 81.3 MHz (PCS) the
nominal bandwidths of bands are not consistent and it cannot
have sharp band edge
3. Rated Mean output power: 2watts
4. Input and output impedances: 50ohms
5. Max EIRP of the transmission system 2watts( 33dBm)
The Manufacturer's rated output power of this equipment is for
single carrier operation. For situations when multiple carrier signals
are present, the rating would have to be reduced by 3.5 dB,
especially where the output signal is re-radiated and can cause
interference to adjacent band users. This power reduction is to be by
means of input power or gain reduction and not by an attenuator at
the output of the device.
SAFETY NOTES fdgbsddg
The Federal Communications Commission (FCC) has tested this
product and found it to comply with their RF Exposure Requirements,
Pursuant to FCC Part 22 and 24, In order to comply with the FCC RF
exposure requirements, the human user’s body should always be
separated from the indoor antenna of the Amplifier by at least
8” (20cm).
Don't expose this product to extreme low or high temperature (-4° F
or -20° C and 150° F or 70° C).
There are no consumer serviceable or modifiable parts inside this
Amplifier product. Alteration or abuse of the Amplifier or other
components will void this product’s warranty, and could be
dangerous to the user.
CONNECTING THE AMPLIFIER sddg
The signal is received by the outside antenna from the cell tower,
then AMPLIFIED and transmitted to your phone through the inside
antenna. When the phone transmits, the signal is received by the
inside antenna, then AMPLIFIED and transmitted to the cell tower
through the outside antenna.
Connect the Inside Antenna: The patch antenna is intended for
indoor use only. Do not mount on a surface within 4” (10 cm) of metal.
Screw the patch antenna to the amplifier connector that’s marked
“INDOOR” and tighten it.
Connect the Outside Antenna: The magnetic antenna (purchased
separately) is for outdoor use only. Select an outside mounting
location. For best performance, keep the antenna on top of the
vehicle. The outside antenna should be located in an area with at
least a 12” (30cm) radius clear of obstructions, and other radiating
elements. Screw in the outside antenna to the “OUTDOOR”
connector of the amplifier and tighten it.
NOTE: Keep the separation distance between the inside and outside
antennas at least 6’ (2m) apart if possible.
WARNING: The outside antenna must not be co-located or
operating in conjunction with any other antenna or amplifier.
Connect the Power cord: Set the power switch on the amplifier to
the OFF position prior to plugging it into the vehicle’s DC power
source to prevent damaging the amplifier. Connect the DC power
cord to the amplifier then connect the cigarette lighter adapter. Make
sure that all of the connections to the amplifier are tight and secure,
then turn on the amplifier’s power switch. The LED light will glow,
indicating that the amplifier is ready to use.
Optional AC power supply can be purchased separately to use the
amplifier as a desktop system.
Warning light: If the red light turns on, the indoor
and outdoor antennas are too close together. Turn
off the amplifier immediately, move the two
antennas further apart, and then turn the power on
again.
Warning: NEVER operate the amplifier when the
red light is on.
Safety Warning: The input voltage for the amplifier is 5-12V. DO
NOT use this amplifier with a higher voltage power supply,
which could damage the amplifier and the user may also be
injured.
USING THE AMPLIFIER
Now you are ready to make and receive cellphone calls with
powerful signal amplification! Note that It is normal for the amplifier’s
case to be warm during operation.
Press any cell phone key to refresh its communication with the base
station. If your signal is weak, having this amplifier installed and
operating properly will give you a large increase in the signal
strength and quality. The change in the signal strength can be seen
on the visual display of your cellphone, and heard on your receiver or
headset. To see the difference, try operating your phone in an area
that is known to have weak cellphone signals. You will be amazed at
the dramatic difference the Cellphone-Mate Signal Amplifier
provides!
(Optional) Mounting the Amplifier: It is acceptable to place the
Amplifier on top of a flat surface or use the enclosed mounting
screws or Velcro straps to mount the Amplifier. There are two 2.4” or
6cm x 1” or 2.5cm Velcro strips (hook-and-loop pairs) in the box for
mounting the amplifier.
Determine the location where your Amplifier will be placed. Clean the
intended surface and allow it to dry. Peel the protective paper from
the back of the hook sides of the Velcro. Press the adhesive side of
the Velcro strips into place on the bottom of the Amplifier, one strip
on each end. Wait 5 minutes for the adhesive to set before attaching
the loop side of the Velcro to the hook side. The adhesive bond will
reach its maximum strength after 24 hours.
With both of the Velcro loop and hook pieces attached to the back of
the Amplifier, peel the protective paper off of the back of the loop
strips. Press the entire Amplifier into its mounting place. Wait 5
minutes for the adhesive to set. Make sure the Amplifier is firmly
seated. To remove the Amplifier, rotate it across the Velcro – do not
pull the Amplifier or cables.
TROUBLESHOOTING GUIDE
During operation, if the Amplifier interferes with your radio or other
electronic receivers, move the Amplifier further away from those
devices.
For a list of Frequently Asked Questions and a complete and
up-to-date Troubleshooting Guide, please visit our website at:
www.Cellphone-Mate.com
You can also consult a Cellphone-Mate technical specialist directly
by sending an e-mail to us at: support@Cellphone-Mate.com
Or write to:
Cellphone-Mate, Inc.
48820 Kato Rd. Suite 300B
Fremont, CA, 94538 U.S.A.
WARRANTY
1. Cellphone-Mate, Inc. warrants to the Buyer that each of its
products, when shipped will be free from defects in material and
workmanship and will perform in full accordance with applicable
specifications. The limit of liability under this warranty is, at
Cellphone-Mate, Inc.’s option, to repair or replace any product or
part thereof which shall within TWO YEARS of purchase as
determined by examination by Cellphone-Mate, Inc., prove
defective in material and/or workmanship. Warranty returns must
first be authorized in writing by Cellphone-Mate, Inc. Disassembly
of any Cellphone-Mate, Inc. product by anyone other than an
authorized representative of Cellphone-Mate, Inc. voids this
warranty in its entirety. Cellphone-Mate, Inc. reserves the right to
make changes in any of its products without incurring any
obligation to make the same changes on previously delivered
products.
2. As a condition to the warranties provided for herein, the Buyer will
prepay the shipping charges for all products returned to
Cellphone-Mate, Inc. for repair and Cellphone-Mate, Inc. will pay
the return shipping with the exception of product returned from
outside the United States in which case the Buyer will pay the
shipping charges.
3. The Buyer will pay the cost of inspecting and testing any goods
returned under the warranty or otherwise which are found to meet
the applicable specifications or which are not defective or not
covered by this warranty.
4. Products sold by Cellphone-Mate, Inc. shall not be considered
defective or non-conforming to the Buyers’ order if they
satisfactorily fulfill the performance requirements that were
published in the product specification literature, or in accordance
with samples provided by Cellphone-Mate, Inc.. This warranty
shall not apply to any products or parts thereof which have been
subject to accident, negligence, alteration, abuse, or misuse.
Cellphone-Mate, Inc. makes no warranty whatsoever in respect to
accessories or parts not supplied by it.
5. Limitations of Warranty, Damages and Liability:
EXCEPT AS EXPRESSLY SET FORTH HEREIN, THERE ARE
NO WARRANTIES, CONDITIONS, GUARANTEES OR
REPRESENTATIONS AS TO MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE OR OTHER WARRANTIES,
CONDITIONS, GUARANTEES OR REPRESENTATIONS,
WHETHER EXPRESSED OR IMPLIED, IN LAW OR IN FACT,
ORAL OR IN WRITING.
CELLPHONE-MATE, INC.’S AGGREGATE LIABILITY IN
DAMAGES OR OTHERWISE SHALL NOT EXCEED THE
PAYMENT, IF ANY, RECEIVED BY CELLPHONE-MATE, INC.
FOR THE UNIT OF PRODUCT OR SERVICE FURNISHED OR
TO BE FURNISHED, AS THE CASE MAY BE, WHICH IS THE
SUBJECT OF CLAIM OR DISPUTE. IN NO EVENT SHALL
CELLPHONE-MATE, INC. BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL DAMAGES, HOWSOEVER
CAUSED.
6. All matters regarding this warranty shall be interpreted in
accordance with the laws of the State of California and any
controversy that cannot be settled directly shall be settled by
arbitration in California in accordance with the rules then
prevailing of the American Arbitration Association, and judgment
upon the award rendered may be entered in any court having
jurisdiction thereof.
7. If one or more provisions provided herein are held to be invalid or
unenforceable under applicable law, then such provision shall be
ineffective and excluded to the extent of such invalidity or
unenforceability without affecting in any way the remaining
provisions hereof
