Users Manual
CENTRAK STAFF BADGE – IT-743 (FCC*)
Today’s hospitals have a critical need to locate personnel throughout their facilities. They require a
reliable RTLS to optimize patient care and provide alerting capabilities to ensure the safety of its
personnel. CenTrak’s IT-743 staff badge was developed to meet this need. It was designed using
feedback from hospital personnel and includes several unique features that improve upon legacy
staff locating technology.
The CenTrak Staff Badge, or IT-743 Tag, can be mounted onto the loop used to hold a standard
hospital issued employee badge. The Staff Badge is designed to stay with the caregiver, thus
eliminating the need for separate processes that require daily tagging of personnel. The Staff Badge
is water resistant and can be easily cleaned. Each Staff Badge has three customizable buttons that
can be assigned based upon the RTLS use case.
About CenTrak DualTrak™ Technology
CenTrak’s core RTLS differs from legacy technologies in its combined use of a patented combination
of second-generation infrared (Gen2IR™) and active RFID technology called DualTrak. Battery
powered Monitors transmit a unique room number using Gen2IR which is received by any tag in that
room. The tag communicates the room number and its own unique ID via RF to the CenTrak
Location Server using a hospital’s existing wired or Wi-Fi network, where it can be accessed in real-
time by hospital personnel and integrated with third party solution providers.
Like light, Gen2IR will not pass through walls and does not suffer from traditional infrared line-of-
sight limitations. Therefore, when a tag reads a room number, there are no errors. This is certainty-
based RTLS. Unlike estimation-based information, certainty-based location data can be used by
hospitals to make important improvements to process flow and automate decision making. Most
healthcare workflow improvements can only be realized when the location data is certainty-based.
DualTrak™ Technology for room and bed level accuracy
Three customizable buttons
System controlled LED
Ultra thin (only 3 mm thin) and light weight
Shape and size of a standard hospital issued badge
Hole mounts for portrait or landscape to wear behind a standard badge
Water resistant and easy to clean
Long battery life
*See Technical Specs on back for other frequency ranges
●
●
●
●
●
●
●
●
CenTrak, Inc.
207 Penns Trail
Newtown, PA 18940
t: 215-860-2928
e: sales@centrak.com
www.centrak.com
© CenTrak 2010. All Rights Reserved • DualTrak and CenTrak is a trademark of CenTrak, Inc. • Proprietary and Confidential Information
Caution: Any changes or modifications not expressly approved
by the party responsible for product compliance could void the
user's authority to operate the equipment.
902-928 MHz Model #IT-740*
4M codes
> 300 feet
2 uW (Average)
3 buttons, LED, low battery
YES
Operating temperature
Storage temperature
Sealing
-20 C to +70 C
-25 C to +80 C
Splash resistant
Battery type
Smart tag feature Low battery indication
Lithium CR2325x2 replaceable pack
Environmental
Power
FCC Operating Frequency Range
868-870 MHz Model #ITEU-740
CE Operating Frequency Range
Operation
Group code & tag ID codes
Typical transmission range
Field strength
Smart Tag features
Motion Sensor
Loop (portrait or landscape)
Lanyard (retractable)
Fits standard employment badge
mounting
(optional)
Mounting / Attachment Options
Case length
Case height
Case width
3.40 in (86 mm)
2.125in (55 mm)
0.125 in (3 mm)
Case weight
Construction
(with battery) 1.10 oz (34.02 g)
ABS & Poly Carbonate mixture
Tag Dimensions
Tag cleaning method
Warning: Must use CenTrak Disinfection procedure. Other methods may void product warranty.
Wipe Cleaning Method Only.
See CenTrak Tag Disinfection Guide
for Instructions
Cleaning
CenTrak, Inc.
207 Penns Trail
Newtown, PA 18940
t: 215-860-2928
e: sales@centrak.com
www.centrak.com
CENTRAK STAFF BADGE IT-743 (FCC*)
TECHNICAL SPECIFICATIONS
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful interference,
and 2) this device must accept any interference received, including interference that may cause undesired operation. Modifying or tampering with the
transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to use these products. This
product or its systems are covered by one or more of the following U.S. patents: 5,917,425 , 7,061,428 , 7,378,964
© CenTrak 2010. All Rights Reserved • DualTrak and CenTrak is a trademark of CenTrak, Inc. • Proprietary and Confidential Information • 7/10
WARNING: This guide is in draft form and can be changed without notice at any time by CenTrak. Please
contact CenTrak prior to commercial use to receive all the necessary latest information about the system.
