IT-373ECO i-DIM
•Automatically tracks hand hygiene compliance at the
caregiver level
•Collects data on all events at hand washing stations
•Designed to integrate with Ecolab hand hygiene
dispensers
•Multiple mechanisms to activate the dispenser
•Works in conjunction with CenTrak’s full RTLS and with
CenTrak’s Clinical-Grade Locating Staff Badge.
The Integrated Dispenser Interface Module for Ecolab (IT-373ECO) is a
component of CenTrak’s Clinical-Grade Hand Hygiene Compliance Solution –
the healthcare industry’s only solution designed to automatically monitor
hygiene dispenser usage by caregivers as well as their entry and exit to patient
care areas. It eliminates costly manual monitoring, and proactively alerts
caregivers who enter patient care environments without proper hand hygiene,
to assist in compliance and behavior modification.
IT-373ECO units integrate with Ecolab dispensers, and automatically
communicate a specific caregiver’s badge ID from patient care areas along
with hand hygiene events, based upon hospital determined compliance
business rules. The IT-373ECO communicates each event to the network which
records each caregiver’s compliance performance. All of the recorded data is
stored on CenTrak’s local or hosted server and can be accessed by third party
compliance management and reporting solutions.
The LED indicator on the Dispenser flashes a gold confirmation light when the
dispenser is activated and detects a care giver with a CenTrak badge is within
range (approximately 4 feet).
The IT-373ECO captures all hand hygiene events whether or not a caregiver is
in direct line of sight of the module using a combination of technologies.
Unlike other hand hygiene compliance solutions, CenTrak is able to capture
100% of clinical hand washing events without errors.
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-373ECO shown integrated
with a Ecolab Dispenser
IT-373ECO i-DIM
© CenTrak 2014. All Rights Reserved. Proprietary and Confidential.
IT-373ECO i-DIM
Technical Specifications
Operation
FCC Operating Frequency Range 902-928 MHz
CE Operating Frequency Range 868-870 MHz
Maximum transmission power 1 mW peak
Low Frequency 125 KHz
Indicators
LED Indicators Not on unit; Enables integrated gold
confirmation LED light on Ecolab Dispenser
Enclosure
Case width 3.60 in (91.4 mm)
Case height 2.13 in (54.1 mm)
Case depth 2.05 in (52.1 mm)
Construction ABS Plastic
Environmental
Operating Temperature 0 C to +50 C
Storage temperature -30 C to +70 C
Operating Humidity 10% to 90% non-condensing
Power
Battery type N/A, Ecolab Dispenser powered
Note: Must use CenTrak disinfection procedure. Other methods may void product warranty.
Activation Sensors
Low Frequency Range Up to 4 feet
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Modifying or
tampering with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to
use these products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif
doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-373ECO shown integrated
with a Ecolab Dispenser
IT-373ECO i-DIM
