©CenTrak2013.AllRightsReserved.ProprietaryandConfidential.1/03

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

CenTrak VirtualWallIT‐323*

•Nophysicalwallorcurtainneededtolimitareabeingdivided

•Semi‐privateroomseparationtoaccuratelylocateanassetor

persononeithersideoftheroom

•DivisionofbaysorbedareastypicallyimportantinERandOR

Pre‐Op/Post‐Opsettings

•Batteryoperatedforsimpleinstallation,upto7yearsbattery

life(basedonconfiguration)

•Canbeconfiguredandmonitoredbycentralserverfor

superiorcontrol

•Simpletoinstallclip‐onceilingmountingbracket

TheVirtualWallisaGen2IR(infrared)signalingunitusedwithIR‐enabledtags

toprovideamethodoflocatingtaggedassetsorpeopleforfacilitiesthat

requiresub‐roomlevelaccuracy.VirtualWallsaregearedtosemi‐private

roomsandbaystypicallyfoundinERandORsettings.Unlikeroom‐level

monitors,VirtualWallsdonotneedphysicalwallstolimittheareaof

coverage.

AboutCenTrak HybridRTLSTechnology™

TheCenTrakcoreRTLSdiffersfromlegacyinitscombineduseofapatented

second‐generationinfrared(Gen2IR™)andactiveRFIDtechnology.Battery

poweredmonitorstransmitauniqueroomnumberusingGen2IR,whichis

receivedbyanytaginthatroom.Thetagcommunicatestheroomnumberand

itsownuniqueIDviaRFtotheCenTrak LocationServerusingahospital’s

existingwiredorWiFi network,whereitcanbeaccessedinreal‐timeby

hospitalpersonnelandintegratedwiththirdpartysolutionproviders.

*IT‐323isforusewiththeCenTrak 2.0system.OrderIT‐321forusewiththe1.0system.

IT‐323CenTrak VirtualWallMonitor

IT‐323CenTrak VirtualWall

shownmountedtoaceiling

©CenTrak2013.AllRightsReserved.ProprietaryandConfidential.1/03

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

CenTrak VirtualWallIT‐323*

TechnicalSpecifications

Operation

FCCOperatingFrequencyRange 902‐928MHz (Model#IT‐323)*

CEOperatingFrequencyRange 868‐870MHz(Model#ITEU‐323)*

PowerControl Localon/off,Remoteon/off

DefaultSetting Factorysetlocationcode–markedon

Monitor

Indicators None

BayAreaCoverage

MaximumRoomSize 14’longx12’wide(12’high)**

MinimumRoomSize 8’longx6’wide(7’high)**

WallThickness Upto1’

ProductDimensions

BaseWidth 5.5in(139.7 mm)

BaseLength 8.5in (215.9mm)

BaseDepth 1.5in(38.1 mm)

BaseWeight 18.5oz(0.53kg)

Mounting Ceilingtileclip,aboveceilingtile

Environmental

OperatingTemperature 0Cto+50 C

Storagetemperature ‐20Cto+70C

OperatingHumidity 10%to90%non‐condensing

Power

Batterytype Pre‐installed2xDLithium(Extrabattery

packavailable).Upto3‐7yearsbatterylife

basedonconfiguration

*IT‐323isforusewiththeCenTrak 2.0system.OrderIT‐321forusewiththe1.0system.

THISDEVICECOMPLIESWITHPART15OFTHEFCCRULESANDINDUSTRYCANADALICENSE‐EXEMPTRSSSTANDARD(S).

OPERATIONISSUBJECTTOTHEFOLLOWINGTWOCONDITIONS:(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFERENCE,

AND(2)THISDEVICEMUSTACCEPTANYINTERFERENCERECEIVED,INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIRED

OPERATION.Modifyingortamperingwiththetransceiver’sorreceiver’sinternalcomponentscancauseamalfunction,

invalidatethewarranty,andwillvoidFCCauthorizationtousetheseproducts.Thisproductoritssystemsarecoveredbyone

ormoreofthefollowingU.S.patents:5,917,425,7,061,428,7,378,964,7,619,532

L‘utilisationdecedispositifestautoriséeseulementauxconditionssuivantes:(1)ilnedoitpasproduiredebrouillage et (2)l’

utilisateurdudispositifdoitétre prêtàacceptertoutbrouillageradioélectriquereçu,mêmesicebrouillageestsusceptiblede

compromettrelefonctionnementdudispositif.

IT‐323CenTrak VirtualWallMonitor

IT‐323CenTrak VirtualWall

shownmountedtoceiling

©CenTrak2013.AllRightsReserved.ProprietaryandConfidential.1/03

CenTrak,Inc.

5CaufieldPlace,Suite102

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

CenTrak VirtualWallIT‐323*

Accessories

*IT‐323isforusewiththeCenTrak 2.0system.OrderIT‐321forusewiththe1.0system.

ITA‐371VWMonitor

CeilingAttachment

(9/16inch)

ITA‐372VW

MonitorCeiling

Attachment(15/16

inch)Standard

IT‐323CenTrak VirtualWallMonitor

ITA‐365VWMonitor&BatteryPackConnectorCable(1pack)

ITA‐367VWMonitor&BatteryPackConnectorCable(2pack)

CeilingAttachments

Power

IRBlocker

ITA‐366VWMonitor IR

Blocker–4inch

ITA‐359

IRRegenerator

VWMonitor

ITA‐357

2DCellLithium

Batteriesin

PackforVW

Monitor(2

pack)

IT‐323CenTrak VirtualWall

shownmountedtoceiling

ITA‐373VW

MonitorCeiling

Attachment

(15/16inch)Long

ITA‐356

DCellLithium

Battery(2)

(forillustration

purposesonly)
