ITD-762 & ITD-762E Multi-Mode Patient Tag
ITA-774 - Attachment Bracket
A smarter approach to RTLS. CenTrak’s IT-762-G and IT-
762E-G adapts to your accuracy requirements (zone, room,
bed) and RF environment to maximize patient tracking
initiatives.
•Wi-Fi and Gen2IR™ enabled
•Leverages existing 802.11 networks for RF locating
•Provides certainty-based room-level accuracy using
CenTrak’s proven battery operated Gen2IR Monitors.
•Low Frequency (LF) sensor (only Model ITD-762E)
Used with CenTrak’s Low Frequency Monitors to
create choke points.
CenTrak’s Multi-Mode Patient Tags may be worn by patients
that need to be tracked, located and identified. The tags can
be located using existing Wi-Fi network infrastructure. Multi-
Mode tags can be rapidly deployed without additional
infrastructure. Battery operated Gen2IR components can be
added in the future to areas that require greater
performance and accuracy (such as for high acuity clinical
workflow).
Maintenance and management is easy. CenTrak’s ITD-762
and ITD-762E tags offer extreme battery life, are fully
configurable in the field and allow for wireless upgrades and
profile modifications onsite.
ITD762 & ITD-762E Tags
© CenTrak 2012. All Rights Reserved. Proprietary and Confidential. 5/12
CenTrak, Inc.
5 Caufield Place, Suite 102
Newtown, PA 18940
t: 215-860-2928
e: sales@centrak.com
www.centrak.com
ITD-762 & ITD-762E Multi-Mode Patient Tag
Technical Specifications
Tag Dimensions
Case Length
1.3 in (35mm)
Case Height
1.6 in (40 mm)
Case Width
0.7 - 0.8 in (18 - 20 mm)
Case Weight (with battery)
1.3 oz (36 g)
Construction
Heat reflective poly carbonate
Environmental
Operating Temperature (Tag)
-10 C to +75 C
Storage Temperature (Tag)
-25 C to +75 C (for best battery life store at
room temperature or below)
Sealing
Splash & water resistant
Power
Battery Type
1/10 D 3.6V (replaceable)
Smart Tag Feature
Remaining battery life notifications
Operation
Operating Frequency (Wi-Fi)
802.11 b/g
Operating Frequency (Secondary)
902-928 MHz
Configurable Button
YES
LED indicator
YES
Motion sensor
YES
Gen2IR sensor
YES
Low Frequency sensor
125 KHz (only Model ITD-762E)
Battery Replacement
YES
Tag Attachment
YES, designed to be used with standard
patient ID bands
ITD-762 & ITD-762E Tags
ITA-774 - Attachment Bracket
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cases undesired operation. Modifying or tampering
with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to use these
products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit
étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
