ITD-763 & ITD-763E Multi-Mode Staff Tag
ITA-766 Suspender Clip
for Staff Tag
A smarter approach to RTLS. CenTrak’s ITD-763 and ITD-
763E adapt to your accuracy requirements (zone, room,
bed) and RF environment to maximize staff locating
initiatives.
•Wi-Fi and Gen2IR™ enabled
•Leverages existing 802.11 networks for RF locating
•Provides certainty-based room-level accuracy using
CenTrak’s proven battery operated Gen2IR Monitors.
•Hole mounts for portrait or landscape to wear behind a
standard badge
•Water resistant and easy to clean
•Three customizable buttons
•Low Frequency (LF) sensor (only Model ITD-763E)
Used with CenTrak’s Low Frequency Monitors to
create choke points.
CenTrak’s Multi-Mode Staff Tags are easily worn by staff
members that need to be located and identified. The tags
can be located using existing Wi-Fi network infrastructure.
Multi-Mode tags can be rapidly deployed without additional
infrastructure. Battery operated Gen2IR components can be
added in the future to areas that require greater
performance and accuracy (such as for high acuity clinical
workflow).
Maintenance and management is easy. CenTrak’s ITD-763
and ITD-763E tags offer extreme battery life, are fully
configurable in the field and allow for wireless upgrades and
profile modifications onsite.
ITD-763 & ITD-763E
CenTrak Staff Tags
© CenTrak 2012. All Rights Reserved. Proprietary and Confidential. 5/12
CenTrak, Inc.
5 Caufield Place, Suite 102
Newtown, PA 18940
t: 215-860-2928
e: sales@centrak.com
www.centrak.com
ITD-763 & ITD-763E Multi-Mode Staff Tag
Technical Specifications
Tag Dimensions
Case Length
3.6 in (92 mm)
Case Height
2.5 in (63 mm)
Case Width
0.2 to 0.4 in (3-7 mm)
Case Weight (with battery)
1.9 oz (53 g)
Construction
ABS & Poly Carbonate Mixture
Environmental
Operating Temperature (Tag)
-10 C to +75 C
Storage Temperature (Tag)
-25 C to +75 C (for best battery life store at
room temperature or below)
Sealing
Splash resistant
Power
Battery Type
1/10 D 3.6V (replaceable)
Smart tag Feature
Remaining battery life notifications
Operation
Operating Frequency (Wi-Fi)
802.11 b/g
Operating Frequency (Secondary)
902-928 MHz
Configurable buttons
YES, 3 configurable buttons
LED indicator
YES
Motion sensor
YES
Gen2IR sensor
YES
Low Frequency sensor
125 KHz (only Model ITD-763E)
Battery Replacement
YES, single screw
Audible alarms
YES
Tag Attachment
YES, designed to be worn behind standard
staff ID badges
ITD-763 & ITD-763E
CenTrak Staff Tags
ITA-766 Suspender Clip
for Staff Tag
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cases undesired operation. Modifying or
tampering with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to
use these products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif
doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
