ITK-103C Star
Stars are CenTrak’s dedicated RF network access points that receive
CenTrak tag ID and location transmissions and communicate it to the
network. Stars have 2-way communication with CenTrak components for
supervision and over-the-air configuration.
Stars are compatible with Ethernet and TCP/IP protocol and use browser
based protocol for communication. With a modular design, the Stars
provide an economical solution to a wide variety of asset and personnel
tracking problems. Tag transmissions can be processed in real-time to
quickly locate and identify tagged assets or personnel in defined areas.
The Star allows for very high tag densities. Large populations of tags can
be monitored using a single Star.
A smarter approach to RTLS. CenTrak’s ITK-103C interprets and
reports the radio frequency messages emitted by CenTrak’s tags.
•Enables Clinical-Grade Locating™
•Bi-directional communication to CenTrak components
•Small footprint and flexible mounting options
•Power Over Ethernet or dedicated power supply available
•High throughput performance supports large tag populations
•Supports up to 6 parallel systems in the same facility
•Ethernet interface
ITK-103C Star
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
© CenTrak 2014. All Rights Reserved. Proprietary and Confidential. Draft version subject to revision.
ITK-103C Star
Technical Specifications
Operation
FCC Operating Frequency Range 902‐928 MHz(Model #ITK‐103C)
CE Operating Frequency Range 868-870 MHz (Model #ITEU‐103C)
Ethernet 10/100 MBPS Ethernet
Protocol TCP/IP
Tag Density Up to 1,000 Tags per Star
Enclosure
Case width 4.5 in(114.3 mm)
Case height 1.25 in (31.7 mm)
Case length 4.0 in (101.6mm)
Case weight 8 oz (226.8 g)
Construction ABS Plastic
Environmental
Operating Temperature ‐10 C to +50 C
Storage temperature -40 C to +80 C
Operating Humidity 10% to 90% non-condensing
Power
POE Standard
External Power Supply 3.3 volts 350 mA
Power Consumption 1 W
Read Range
Monopole Antenna Diversity System Up to 300 feet (91.4m)
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Modifying or
tampering with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to
use these products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif
doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
ITK-103C Star
