IT-105
Clear Repeater
•Extends CenTrak Wireless Network
•Auto-enrolls into Mesh Network
•Designed to be installed throughout Senior Communities
•Creates a long-range 900 MHz Mesh Network for total
Community Coverage
•Easy installation with standard 120VAC plug in
•No cable or Ethernet required
•Can be placed in waterproof container for outdoor use
•Integrated backup battery inside
Senior Living Communities have a critical need for the wireless
monitoring of residents to ensure safety and improve
workflow. The IT-105 Clear Repeater is securely associated with
a community of residents via CenTrak Geo, IT-726E, to help
empower communities with a feeling of control while
maintaining safety and security of staff and residents.
The IT-105 utilizes our custom mesh network to extend
wireless coverage throughout the campus, including outdoor
walking paths, parking lots, and indoor areas such as stairwells.
Emergencies can happen anywhere, and the IT-105 easily
extends coverage without requiring constant management and
attention that Wi-Fi networks require. Furthermore, the IT-105
has built in battery backup that provides the Clear Network
with 24 hours of operation during power outages.
CenTrak, Inc.
826 Newtown-Yardley Road
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
© CenTrak 2018. All Rights Reserved. Proprietary and Confidential. Draft version subject to review
IT-105 Clear Repeater
© CenTrak 2015. All Rights Reserved. Proprietary and Confidential. Draft version subject to revision.
Technical Specifications
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cases undesired operation. Modifying or
tampering with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to
use these products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif
doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
CenTrak, Inc.
826 Newtown-Yardley Road
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-105
Clear Repeater
© CenTrak 2018. All Rights Reserved. Proprietary and Confidential. Draft version subject to review
IT-105 Clear Repeater
Operation
FCC Operating Frequency (Americas) 902-928 MHz
CE Operating Range (Europe, Middle
East)
868-870 MHz
FCC Operating Range (Australia/NZ) 920-926 MHz
Range 1500’ open range
Network Operation
Power over Ethernet (POE) No
Ethernet No
Dimensions
Case Length 1.9 in (48.2 mm)
Case Height (thickness) 0.5 in (12.3 mm)
Case Width 1.7 in (42.2 mm)
Case Weight (with battery) 0.3 oz (18 g)
Construction ABS Plastic
Environmental/Cleaning
Operating Temperature -10 °C to 50 °C
Storage Temperature -40 °C to 80 °C
Operating Humidity 10% to 90% non-condensing
Power
Power Consumption 5 volts 500 mA
External Power Supply 100 –240VAC
