Document # GUD20101010-03 CenTrak Inc.  Phone 215.860.2928  www.centrak.com

DropBoxMonitor

Part#IT‐317(2.0system)

rak.comwww.centr

TheCenTrakDropBoxMonitorisdesignedtosupportthemanagementof

patienttagsthatarereadytobeclearedfromtheCenTrakSystem.Itcanbe

utilizedatnurse’sstationsorindischargeareastoindicatethatapatient

hasleftthefacilityandthatatagcanbere‐assigned.Thisautomated

disassociationfeatureisanimportantcomponentofthesystem.



Whenapatientleavesthefacility,thetagisremovedanddroppedintothe

box.Thetagdropisautomaticallydetectedbythesystemandcanbe

translatedintoadischargeevent.Thenumberoftagsintheboxcanbe

queriedatanytime.Alertscanbegeneratedwhenthenumberoftags

approachesapredeterminedmaximumandsenttotheindividuals

responsibleforputtingtagsbackintoservice.



Includedinbox:

 Minimonitorassembly

 4screws



Howitworks

 Themonitorshouldbetreatedjustlikeothermonitorsexceptit

doesnotrequireprofilesetting.TheIT‐317canacceptallprofiles

thatdonotrequirenoisesetting(0‐9).

 Themonitorwillstartemittingsignalwhendropboxbinisinserted.



Themonitorcomesinanassemblywithdrycontactstoconnecttothedrop

boxswitch.



TechnicalSpecifications

 OperatingTemperature‐10Cto+50C

 FCCID:ST2‐IT317,IC:6012A‐IT317,

 FCCOperatingFrequencyRange902‐928MHz

 Batterylifeexpectancyis2.5years*

*Batteryexpectancyisonlyanestimateandcanvarybasedonoperatingconditions,typeof

batteriesusedandmethodofoperation(estimateassumesoperatingtemperatureof25C

andCenTraksuppliedbatteries).



PhysicalInstallation



Step1–Cutandremovefuse.Thewiresfromtheswitchmustbecutto

lengthsufficienttoreachthedrycontactjunction(about6inches).



Step2–Attachmonitorassemblywith4providedscrews.Attachswitch

wirestodrycontactjunction.



FCC and IC Statements:

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES AND INDUSTRY CANADA LICENSE-EXEMPT RSS STANDARD(S).

OPERATION IS SUBJECT TO THE

FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST

ACCEPT ANY INTERFERENCE

RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Modifying or tampering with the

transceiver’s or receiver’s internal

components can cause a malfunction, invalidate the warranty, and will void FCC authorization to use these products. This

product or its systems are covered

by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.

L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’

utilisateur du dispositif doit

étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le

fonctionnement du dispositif.
