ITK‐640 NetworkedDoor

ControllerPackage

ProductDescription

TheIT‐640ControllerisatthecenterofCenTrak’sGuardian™

SecuritySystem.TheControllergeneratesanexciterfield,which

definesthedoorcoverage.TheControllersupportsmultiple

alertsandalarms. Forexample,anexitalarmisgeneratedwhena

tagenterstheController'sexciterfield;ifanexitalarmis

detected,theControllercanactivateaMaglock toholdthedoor

securelyshut.TheControllerreceivesthetransmittedIDofthe

transponderenteringthefieldandstorestheIDaswellasits

locationintheHostPCactivitylog.EachControllerhasaunique

identityonthenetworkandisassignedanamefamiliartothe

facilitystaff(e.g.SWNurseryExit).Aconvenientloiteralertcan

beenabledatcloseddoorstoavoidnuisancealarmstothehost

PC.IfthehostPCgoesdown,theControllerwillstandaloneto

operatedoorlocksasusual.TheGuardiansystemwas

engineeredtoworkintandemwithCenTrak’s Clinical‐Grade

RTLS,soituniquelysupportsawidevarietyofhealthcare

applicationsallwithasingleRFIDtag.

ProductFeatures

IntegrationwithCenTrak’sClinical‐GradeRTLS™&CenTrak’s

Guardian™SecuritySystem

Themostconfigurableaccesscontrolsecuritysystem

availabletoday:

Abletoassociatetagstoallowforunlockingexceptions

(e.g.,motherornurseaccompanyinfanttounlockdoor)

Eachdoorcanhaveitsownprofileandrules,soaccesscan

beconfiguredandcustomizedatanindividuallevel

Individuallycontrolledexciterfields,soeachdoorcan

supportmultiplesizedfieldstosupportmultiple

environmentsandapplications

Systemiscompletelysoftwareconfigurable,soitcanbe

customizedforawidevarietyofapplications

IncludesIT‐660DoorKeypadwithbuilt‐insounder

IncludesIT650DoorExciterAntennawithCable

LocalPINcodedatabasethatduplicatesmasterdatabaseon

hostPC(Note:ControllerwillnotallowPINcodesupport

withoutcompatibleconfigurationsoftware)

Visualindicatorsforpower,communicationlinkandreceive

channelstatus

Exciterantennaandkeypaddisconnecttamperalarm

Doorajartamperalarmsupportoncompatiblecontact

ITK‐640NetworkedDoor

ControllerPackage:

IT‐640,IT‐650,andIT‐660

IT‐640NetworkedDoorController

IT‐650DoorExciter

AntennawithCable

IT‐660DoorKeypad

Withbuilt‐insounder

IT‐722PatientTagin‐use

Operation

RFFrequency902‐928MHz

Low Frequency(forEgressdetection) 125KHz

Ethernet CommunicationtoServer Yes

DoorAjar Detection Yes

AccessKeypad Keypad Input,supportsupto2

Maglock Supportsupto2

ExciterAntenna Coil Supportsupto2

Regulatory Approvals Power SupplyULlisted

FCCPart15compliant

Controller Dimensions

ControllerLength 10.7in(27.25cm)

ControllerHeight 2.5in (6.5 cm)

ControllerWidth 8.5in(21.5cm)

Weight4.2lb (1.90kg)

Environmental/Cleaning

OperatingTemperature+32° to+131°F(0° to+55°C)

StorageTemperature‐22° to+140°F(‐30° to+60°C)

Power

InputVoltage 24VDC@1A

OutputVoltage(aux) 12VDC@1A

ITK‐640NetworkedDoor

ControllerPackage

TechnicalSpecifications

ITK‐640NetworkedDoor

ControllerPackage:

IT‐640,IT‐650,andIT‐660

IT‐640NetworkedDoorController

IT‐650DoorExciter

AntennawithCable

IT‐660DoorKeypad

Withbuilt‐insounder

CenTrak,Inc.

125PheasantRun

Newtown,PA18940

t:215‐860‐2928e:marketing@centrak.com

w:www.centrak.com

Thiscomponentcomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:1)Thedevicemaynotcause

harmfulinterference,and2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired

operation.Modifyingortamperingwiththetransceiver’sorreceiver’sinternalcomponentscancauseamalfunction,invalidatethe

warranty,andwillvoidFCCauthorizationtousetheseproducts.Thisproductoritssystemsarecoveredbyoneormoreofthefollowing

U.S.patents:5,917,425,7,061,428,7,378,964,7,619,532.

L‘utilisationdecedispositifestautoriséeseulementauxconditionssuivantes:(1)ilnedoitpasproduiredebrouillage et (2)l’utilisateur

dudispositifdoitétre prêtàacceptertoutbrouillageradioélectriquereçu,mêmesicebrouillageestsusceptibledecompromettrele

fonctionnementdudispositif.

Howitworks.

TypicalDesignof

ITK‐640

IT‐722PatientTagin‐use
