Centrak IT717E Micro Tag IT-717E IT-710E IT-720E User Manual PowerPoint Presentation

Centrak, Inc. Micro Tag IT-717E IT-710E IT-720E PowerPoint Presentation

User Manual

© CenTrak 2015. All Rights Reserved. Proprietary and Confidential.
Case length 1.5 in (36.9 mm)
Case width 1.1 in (27.9mm)
Case height (thickness) 0.4 in (8.9 mm)
Case weight (with battery) 0.38 oz (11 g)
IT-717E Tag Micro
Integrates with CenTrak’s RTLS and Guardian™ security solutions
Gen2IR™ Technology for Clinical-Grade Locating™ applications
Small size, lightweight
Skin sensing technology to trigger tamper events
Fully waterproof
Detachment sensor*
The tag is fully waterproof to allow for easy cleaning of all assets with the
operation of other hospital or personal medical equipment. It is also resistant
to soiling and UV light, and may be cleaned with a disinfectant solution. With
a remarkably small profile, the tag is ideal for all medical equipment
particularly smaller assets like scopes and today’s more compact equipment.
The tag communicates with CenTrak’s Guardian Security System as well as
CenTrak’s Clinical-Grade RTLS™, so facilities are able to continually monitor
assets locations to optimize workflow and utilization, as well as prevent
shrinkage.
IT-717E Tag Micro
CenTrak, Inc.
125 Pheasant Run
Newtown, PA 18940
t: 215-860-2928 e: sales@centrak.com
www.centrak.com
IT-717E in use
Specifications
FCC Operating Frequency Range 902-928 MHz
CE Operating Frequency Range 868-870 MHz
Average transmission power 2 uW (average)
Operating Temperature 0 C to +50 C
Sealing waterproof
This component complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) The device may not cause harmful
interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Modifying or tampering
with the transceiver’s or receiver’s internal components can cause a malfunction, invalidate the warranty, and will void FCC authorization to use these
products. This product or its systems are covered by one or more of the following U.S. patents: 5,917,425, 7,061,428, 7,378,964, 7,619,532.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit
étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
The CenTrak Tag Micro is an active RTLS tag contained in a small, ergonomic
casing. The tag incorporates a tamper detection mechanism enabled as soon
as the tag is applied to an asset. From this time forward, the tag is constantly
monitored by the system.
Gen2IR Sensor YES
Low Frequency Sensor (125 KHz) YES
*Not intended for use as a security system. Detachment sensing performance may vary based upon
type of asset, mounting, adhesive, etc.
