©CenTrak2013.AllRightsReserved.ProprietaryandConfidential.

CenTrak,Inc.

125PheasantRun

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

IT‐723EPatientTag

•Gen2IR™TechnologyforClinical‐GradeLocating™applications

•Customizablebutton

•LEDremoteactivation

•Smallsize,lightweight,andlowcost

•Waterresistantandeasytoclean

•Lowpowerconsumptionforlonglastingbatterylife

•Attacheswithmoststandardpatientwristbands

•LowFrequency(LF)sensor

•CompatiblewithCenTrak’s LowFrequencyExcitersto

createchokepoints.

Healthcarefacilitieshaveacriticalneedforthewirelessmonitoringof

patientstoensuresafetyandimproveworkflow.CenTrak’s Clinical‐Grade

Locating™technologywasdevelopedtomeettheseneedswhenusedwith

automatedworkflowandbedmanagementapplications.TheCenTrak Tagis

securelyassociatedwithapatientwearingthetagtohelpwithidentification

beforemedicationisadministeredoramedicalprocedureisperformed,to

confirmidentityandreduceerrors.Thetagsenablepatientstohave

increasedmobilitywhileimprovingtheirsafetybyquicklyalertingstaffif

patientsenterorleaverestrictedareas.Patientsenjoyhavingthefreedom

andflexibilitytomoveassupportedbytheircareplan.

TheIT‐723EtagutilizesCenTrak’s Gen2IR™andLowFrequencyRFtosupport

Clinical‐GradeLocating™applications.Gen2IR™enablescertainty‐based

accuracyatthebed‐,bay‐andchair‐level,rapidlocationupdatespeedsand

extremebatterylife.LowFrequencyRFsupportspatientegressandwander

preventionwhilereducingtagloss.Thisenableshospitalsandhealthcare

administratorstomakedecisionsbasedonfactsaboutwhereandwhen

theirpeopleandresourcesarelocated.TheIT‐723Etagprovidestheability

tomonitorpatientsatanytimeanywhereinafacility.Thissingletagcanbe

usedtotrack,locate,protectandidentifyapatientinseconds.

TheIT‐723EisabatterypoweredRF/IRTagthatattachestopatientswho

needtobetracked,located,andidentified.Tagsmaybewornonstandard

issuedmedicalIDbracelets.Withamodulardesignandlowprice,tags

provideaneconomicalsolutiontoawidevarietyofpatientmanagement

challenges.

IT‐723EPatientTag

IT‐723EPatientTagshown

withattachmentaccessory

©CenTrak2013.AllRightsReserved.ProprietaryandConfidential.

CenTrak,Inc.

125PheasantRun

Newtown,PA18940

t:215‐860‐2928

e:sales@centrak.com

www.centrak.com

IT‐723EPatientTag

TechnicalSpecifications

Operation

FCCOperatingFrequencyRange 902‐928MHz (Model#IT‐723E)

CEOperatingFrequencyRange 868‐870MHz(Model#ITEU‐723E)

Groupcode&tagIDcodes 8Mcodes

Outdoortransmissionrange >300feet

Averagetransmissionpower 2uW (average)

Gen2IR sensor YES

LowFrequency sensor YES,125KHz

Smarttagfeatures 1button,LED,lowbatteryindicator

MotionSensor YES

AttachmentOptions

WristStrap Model#ITA‐754

TagDimensions

Case width 1.5in(38.1mm)

Caseheight 1.98in(50.3mm)

Casewidth 0.6in(15 mm)

Caseweight(withbattery)0.77 oz(21.8g)

Construction ABS&PolyCarbonatemixture

Environmental/Cleaning

OperatingTemperature 0Cto+70C

Storagetemperature ‐25Cto+80C

Sealing Splash&Waterresistant

Tagcleaningmethod Wipecleaning methodonly.SeeCenTrak Tag

DisinfectionGuideforInstructions.

Power

Batterytype LithiumCR2430

Smarttagfeature Lowbatteryindication

ITA‐754WristStrap

Thiscomponentcomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:1)Thedevicemaynotcauseharmful

interference,and2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.Modifyingortampering

withthetransceiver’sorreceiver’sinternalcomponentscancauseamalfunction,invalidatethewarranty,andwillvoidFCCauthorizationtousethese

products.ThisproductoritssystemsarecoveredbyoneormoreofthefollowingU.S.patents:5,917,425,7,061,428,7,378,964, 7,619,532.

L‘utilisationdecedispositifestautoriséeseulementauxconditionssuivantes:(1)ilnedoitpasproduiredebrouillage et (2)l’utilisateurdudispositifdoit

étre prêtàacceptertoutbrouillageradioélectriquereçu,mêmesicebrouillageestsusceptibledecompromettrelefonctionnement dudispositif.

IT‐723EPatientTag
