藍牙喇叭 / Bluetooth Speaker
LS-105BMC 使用說明書 / Manual
繁體中文 English
產品介紹 Product Introduction
感謝您選擇了LS-105BMC 藍牙喇叭。LS-105BMC 藍牙喇叭可給您最佳的音質，帶給
您全新聽的享受，麥克風的功能更強化語音系統帶給生活的便利性。 Thank you for choosing the RockFire LS-105BMC Bluetooth speaker. RockFire LS-105BMC
provides you the best quality of sound to fulfill your hearing desire. The additional
microphone enhancement brings your conveniency to maxium.
產品規格 Specification
★藍牙版本：Bluetooth V3.0+EDR A2DP ★Bluetooth Version：Bluetooth V3.0+EDR A2DP
★傳輸距離：class II, 10 meters ★Transmission Distance：class II, 10 meters
★單体尺寸： 1.5 inch Coaxial Speaker ★Driver size： 1.5 inch Coaxial Speaker
★頻率範圍：15-15,000 Hz ★Frequency Range：15-15,000 Hz
★輸出功率： 3W(RMS) ★Output power： 3W(RMS)
★電池容量：3.7V 450mAh , Li-polymer ★Battery capacity：3.7V 450mAh , Li-polymer
★充電方式：Mini USB x1.5V ★Charging mode：Mini USB x1,5V
★連續撥放時間：5 hours ★Continuous playing time：5 hours
★音源輸入：3.5 x1 ★Audio In：3.5 x1
包裝內容 Package Content
★藍牙喇叭x1 ★ LS-105BMC Bluetooth speaker x1
★USB充電線x1 ★USB cable x1
★3.5mm音源傳輸線x1 ★3.5mm line-in cable
★操作說明書x1 ★User Manual x1
產品特色 Features
★NFC無線技術，無需透過配對即可連接。 ★NFC wireless support, connection without pairing
★符合Bluetooth V3.0+EDR A2DP ★Bluetooth V3.0+EDR A2DP
★無線體驗音響級音效，高品質的音效魅力，不失真。 ★Experience the high quality of audio performance without any distortion
★內建麥克風，實現您在免持通話的便利性，支援Skype電腦藍芽連接通話。 ★Support Microphone line-in for convience, support Bluetooth over Skype call.
★3W(RMS)輸出功率，體驗喇叭震撼的最佳選擇。 ★3W(RMS) output, shocking performance
★支援增強型音訊分配設定(A2DP)、免持聽筒設定(HFP)、耳機設定(HSP)。 ★Support Advanced Audio Distribution Profile (A2DP), handsfree profile(HFP), headset
★十公尺遠距連接，讓您更操控更靈活。(視實際範圍內的障礙物等因素而有所差 ★10 meter transmission distance (may vary depending on environment)
★可直接在按鍵上選曲,接聽電話,及轉換電話,調整音量大小。 ★Button control for selection, answering/transferring call, and adjusting volume
★續航力高，滿電可連續使用5~8hrs(視音量以及音訊內容而定)。 ★Continuous playing time from 5~8 hours (may vary depending on volume)
功能 Function
★Mini USB埠：充電 ★Mini USB port：charging
★撥動式電源開關：開機 / 關機 ★Toggle power switch: Power on / off
★Line In埠：有線連接音訊裝備 ★Line-in port: wire connection
★藍牙指示燈：顯示藍牙連線狀態 ★Bluetooth indicator: Displays the connection status
★電源指示燈：顯示電源狀態 ★Power buttons: Display current power status
★NFC：無線配對區域 ★NFC: wireless pairing
★內建麥克風 ★Built-in microphone
★3個按鍵操作 ★3 physical functional buttons
使用方法 Steps
對LS-105BMC進行充電 Charging LS-105BMC
取出配件中的USB線，將Mini USB端接上LS-105BMC，另一端USB可接上電腦或電源適
配器，以5V/0.5A對LS-105BMC進行充電，充電時電源指示燈會亮起紅燈，待滿電後
電源指示燈轉為綠燈，拔除USB線後，電源指示燈熄滅。
Take out the USB cable, connect the Mini USB end with LS-105BMC , while the other end
with your PC or power adapter. When the LED indicator turns red the device begins to
charge automatically. Unplug the cable when the LED turns green, thus finished
使用藍牙與LS-105BMC配對傳輸音訊 Bluetooth audio transmission using LS-105BMC
將LS-105BMC的撥動式開關鍵調至ON，此時電源指示燈亮起綠燈，藍色藍牙指示燈閃
爍，取出欲配對的藍牙裝置，將藍牙功能打開，搜尋BT SPEAKER裝置，搜尋到按下
配對，配對完成後的藍牙指示燈為藍色常亮，此時可使用藍牙裝置內的音訊資料撥
Switch the toggle to ON,the green lights up while the Bluetooth indicators begin
flashing. Turn on the bluetooth on your desired device and search for BT-SPEAKER to
pair up. When pairing is successful you can playback audio files within the bluetooth
使用NFC與LS-105BMC配對傳輸音訊 Using NFC pairing with LS-105BMC
將LS-105BMC的撥動式開關鍵調至ON，此時電源指示燈亮起綠燈，藍色藍牙指示燈閃
爍，取出欲配對的藍牙裝置，將NFC功能打開，把手機NFC感應位置靠近LS-105BMC的
NFC感應位置，有效距離為2至3公分，感應完成後藍牙裝置與LS-105BMC的藍牙連線
即完成，配對完成後的藍牙指示燈為藍色常亮，此時可使用藍牙裝置內的音訊資料
撥放。
Switch the toggle to ON,the green lights up while the Bluetooth indicators begin
flashing. Turn on the NFC sensor on your desired device and put it against LS-105BMC,
pairing will be done automatically as the bluetooth indicators become solid blue. You
can playback audio files with the bluetooth device.
使用LINE IN與LS-105BMC傳輸音訊 Using LINE-IN with LS-105BMC
將LS-105BMC的撥動式開關鍵調至ON，此時電源指示燈亮起綠燈，藍色藍牙指示燈閃
爍，取出配件中的3.5音源傳輸線，將一端接上LS-105BMC，另一端接上欲連接的音
源裝置，藍牙指示燈將轉為紅色指示燈，切換至LINE IN模式，此時可使用音源裝置
內的音訊資料撥放。
Switch the toggle to ON, the green lights up while the Bluetooth indicators begin
flashing. Take out the 3.5 line-in cable from the accessory, connect one end with LS-
105BMC and another with your desired device, the bluetooth indicator will turn OFF
automatically and mode changes to Line-in. You can playback audio files within the
bluetooth device.
使用LS-105BMC的語音功能 LS-105BMC voice capabilities
當手機透過藍牙方式連上LS-105BMC，來電時LS-105BMC會從音樂轉到來電鈴聲，此
時按下LS-105BMC的撥放鍵，可透過內置麥克風及揚聲器進行語音功能。 When connected to the phone via Bluetooth, LS-105BMC will switch from playing music to
ringtones when incoming call is detected. Press the PLAY button to use the built-in
microphone for answering.
操作方式 Operation Mode
按下"撥放鍵"，可執行輸出裝置的撥放、暫停及接聽功能；短按"+鍵"，可執行上一
曲功能;短按"-鍵"，可執行下一曲功能；長按"+鍵"，可執行聲音增大功能；長按"-
鍵"，可執行聲音減小功能。
When the PLAY button is pressed, the system output either playback or pause; holding
the "+ key" will increase the sound wile holding the "-" key will reduce sound. ; press
the "+ key" to perform the next function; and press the "- key" to perform the previous
song function;
提示
★MIC免提通話功能，在有電話打進來的同時，音響會自動接聽電話，如果在撥放音
樂時，則會使播放器處於暫停狀態，此時可以按下"撥放鍵"以進行免提通話功能。 ★MIC speaker phone function, when a call comes in but the speaker is in usage, the
audio will automatically answer the call, making the music player in a suspended state,
you can press the PLAY button for speakerphone functionality. The LS-105BMC will go
into sleep mode if no pairing is done within five minute after turn ON, please reboot
if pairing is needed after.
★當LS-105BMC開啟後，藍牙如5分鐘內未進行配對，LS-105BMC將進入休眠，此
時如要再重新配對，需重新開機即可。
產品安全訊息
MODEL：LS-105BMC
本產品及其包裝與相關手冊上印載之品牌名稱、註冊商標及圖案等，其所有權皆屬
各商標之所有者。
MODEL：LS-105BMC
The product, its packaging, and related manuals printed on brand names are all
registered trademarks and designs. All ownership belongs to the property of their
respective trademark owners. For updates or service, please link to the official
website of the Company. Website：
http://www.rockfire.com.tw
E-mail：service@rockfire.com.tw
FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and 2. This device must
accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
RF Exposure: A distance of 20 cm shall be maintained between the antenna
and users, and the transmitter may not be co-located with any other transmitter
or antenna.
Manual
version:LS
-
105BMC
Ver.1.0
