Causes of 3 Alarm Technology
• TheHummingbirdCableLokwillalarmiftheLanyardiscut.
• TheHummingbirdCableLokwillalarmifinthedetectioneldoftheEAS
system.
Facts about the Hummingbird Hummingbird CableLok:
• UnithousesHummingbirdmoduleandlockingmechanism
• Longlifelithiumbattery.Batterylifedependsonthenumberandduration
ofalarms
• Thesoundemittedis95+decibels
• TostoptheHummingbirdCableLokfromalarming,followinstructionsfor
removingtheLanyard.
Protecting (Arming) Merchandise with the Hummingbird CableLok:
1.LooptheLanyardaroundanon-removableportionofthemerchandise.
(Figure 2)
2.Toengagethelock,inserttheLockingClipoftheLanyardcompletelyintothe
OpeningoftheHousinguntilyouhearafaintclick.(Figure 2)
(Clipisnon-directionalandcanbeinsertedeitherwayintoHousing.)
NOTE: Unit will play a conrmation tune and ash red. Unit is now armed and the
LED Light will continue to ash approximately once every ve seconds.
3.Merchandiseisnowsecureandreadyfordisplay.
Removing (Disarming) the Hummingbird CableLok from Merchandise:
1.AligntheEarsoftheManager’sKeywiththeIndentsontheHummingbird
CableLok.(Figure 3)
NOTE: The Manager’s Key Ears can be placed on either side of the Hummingbird
CableLok.
2.GentlypushinontheLanyarduntilyouhearafaintclick.Nowpullthe
LanyardoutfromtheHousing.(Figure 3)
3.RemovetheManager’sKey.
NOTE: Store Hummingbird CableLok in the open position for ease of application
and to prevent unnecessary battery drain.(Figure 4)
Productshouldbestored3feet(1meter)fromDeactivationUnits.
4.Productisnowreadyforsale.
For FCC information and compliance, please refer to page 2.
?
PleaseContactCustomerService:
NorthAmerica:800.633.2155
For supplemental information, check out our instructional videos at www.alphaworld.com/videos.asp
Instructions for the
Hummingbird CableLok
CAUTION: Do not place credit cards, ATM cards or magnetic
media of any kind near the Manger’s Key as this could erase
the magnetic strip.
Ears
Manager’s Key
FIG 2
FIG 3
FIG 4
Lanyard
Locking Clip
LED
Indents
Ears
Available in two (2)
Lanyard lengths
